Worktrainer UPdesk Cross User manual

+
b
x4
x1
x1 x1
A B C
D
ab
c
25KG
120-505mm(±5)
22mm/s
0-40°C
100-240V
E F
700MM
120-505MM
308MM
375MM
880MM
415MM
880MM
Item No.：EMT107M
Installation guide
Technical Data Table cover size:
Max:25KG
MAX
Max:3KG
MAX
>950mm
>610mm
Please do not exceed the
maximum WARNING bearing weight
WARNING
Max Loading
Capacity
Height Range
Frequency 10%(Continuous operation for 2mins at most after pause for 18mins)
Input Voltage
Max Speed
Temperature
Power Adapter Power Cable
No. Desktop Frame No.
No. Cable Management No.
Keyboard Tray No. Cable Ties
No.
TOOLS
STEP 1
Only use the sit stand desk on top of flat and stable surface,
strong enough to support the product and any equipment placed on top of it.
STEP 2
Hang the junction plate on the knob
assembled and then tighten the Knob
When removing the keyboard,
please open the wrench and
remove the keypad
UPdesk
Cross

2
1
1
STEP 3
CAUTION
DO NOT place hands on or near support bars.
Pinch points are created during lifting and
lowering the desktop. Failure to follow these
instructions may result in serious personal
injury.
Connect power
adapter and cable
STEP 4
Please put the devices onto the
top of the workstation.
Please make sure all installed equipments
are on the table, and not sticking out of the
edge, or it may harm or cause damage.
Careful
Cable
Adhesive buckle helps to make the
cables tidy and clean. Please leave
enough length of cable for height
adjustment function, otherwise it
may cause unexpected lost.
Nylon ties
This surface is with glue,
helping to fix the cable
management on the table
STEP 5
Careful
Use the cable management
to guide and bundle the cables
1
How to use handswitch
●“▲”
●“▼”
Adjust the desk upwards
Adjust the desk downwards
Button
Upwards
Downwards
Fault Phenomenon Method
Attention
1. Power supply: AC100V-240V,50/60HZ
2. Service Environment: 0-40℃
3. Unplug the power plug before cleaning, wipe the dust on surface with slight wet dishcloth
when cleaning, be careful not to let the drops into the internal parts, not loose the connector.
4. The electric box contains electronic components, metals, plastics, wires etc., so dispose of
it in accordance with each country's environmental legislation, not the general household
waste.
5. Check carefully to ensure correct and complete assembly before using.
6. Be familiar with all functions and program settings of the product before first use.
7. Children are forbidden to play on the product because of unforeseen action when playing,
so any dangerous consequences caused by this improper action will not be on
8. Slight noise caused by the V-ribbed belt or brake system due to structure will not have any
effect on the use of the equipment.
9. Corrosive or abrasive materials are forbidden to clean the equipment. Must ensure that the
cleaner used will not pollute the environment.
10. This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance.
11. Cleaning and user maintenance shall not be made by children without supervision.
12. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
a similarly qualified person in order to avoid a hazard.
13. Please make sure there is no hazard sources in your operating environment. e.g., do not
litter the tools around. Always be careful to treat the packaging materials in order to avoid any
possible danger, e.g. plastic bag may lead to choking hazard to children.
14. Keep the original package of the equipment if necessary in case of the future use in
transportation.
Common fault treatment
The following tips will help you detected and eliminate the common fault and error.
If the fault you met is not listed below, please contact with your supplier. Only the
manufacturer and professionals are capable for investigating and correcting
those fault and error.
No response while long pressing
down/up button after connected
with power supply
Downward sliding
Overwork
(Duty c ycle: Max 2m in on / 18min off)
1.Check if all the cables be connected well
2. Contact your supplier or dealer
1.Check if overloaded, Max loading :25kg
2.Contact your supplier or dealer
1.Restart after susp end for 30mins
2.Contact your supplier or dealer
Waste disposal This marking indicates that this product should not be disposed with other
household wastes. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, recycle it responsibly to promote
the sustainable reuse of material resources. To return your used device,
please use the return and collecon systems or contact the retailer where the
product was purchased. They can take this product for environmental safe
recycling.
Please first adjust it to the highest,
then remove equipment to avoid
harm or damage.
Attention
Please move it by two
persons, or parts may
collide and cause damage.
Attention
