Worktrainer Linak SmartDesk User manual

Handleiding
Assembly Manual
Linak SmartDesk

-2x
-4x
-8x
-8x
-4x
Clamp screws
Screws for feet
Screws for frame
Content

1 2
8x 8x
- For both columns
- Screws for frame
(M6x12 button head screw)
- For both columns
- Screws for feet
(M6x16 button head screw)

3 4
4x
4x
- For both columns - For both columns
- Screws for frame
(M6x15 flat head screw)

5 6
2x
100 %
100 %
- First expand the frame by sliding it to the correct size
- Clamp screws
(M8x10)
- For both columns
- Screws for frame
(M6x12 button head screw)

-
-
Error code Name Description Possible solution (initialization = reset)
E01 Unknown height error in reading current altitude
E02 Overload up Overload in outward motion
E03 Overload down overbelasting in neerwaartse beweging
E08 Unexpected reset
E09 LIN-bus error
E10 Power-error
E11 Number of channels changed
E12 Position difference
E13 Short circuit
E14 Control
E15 Power cut
E16 Invalid key
E17 No safety
E18 Missing initialization plug
E23
E24
E25
E26
E27
E28
E29
E30
E31
E32
E33
E34
E35
E36
E37
E38
E39
E40
*Not applicable if the lower position is limited.
Step 1: Put the desk at the lowest position.
Step 2: After the desk is in its lowest position,
release the control and then hold it down again
until the desk makes a small movement down
and up.
Initialization (Reset):
Error codes
Initialization
Better weight distribution between columns/remove excess weight/initialization
Better weight distribution between columns/remove excess weight/initialization
Initialization
An error occur on LIN bus Initialization
Power failure occurred or regulator power set below 10% Check mains power
Number of channels connected to the system has changed since the last initialization Initialization
Difference between minimum and maximum position of reference has been exceeded Initialization
Short circuit is detected during use Remove power cord/ check cables/ initialization
Position check failed, all channels have lost position Initialization
System has reached the power limitation Obstacle removal / in misalignment initialization
Invalid key combination Press a maximum of 1 key at a time
Safety function does not allow movement but a key has been pressed Obstacle removal / in misalignment initialization
A special service tool /plug is required to change the number of channels in the control box contact supplier
Channel 1 is missing
An actuator on channel is missing :
check motor cable/start at port 1 /initialization/
Channel 2 is missing check motor cable/start at port 1 /initialization/
Channel 3 is missing check motor cable/start at port 1 /initialization/
Channel 4 is missing check motor cable/start at port 1 /initialization/
Channel 5 is missing check motor cable/start at port 1 /initialization/
Channel 6 is missing check motor cable/start at port 1 /initialization/
Channel 1 type The type of actuator connected is different than during initialization
OR traffic detected Initialization by the system
Channel 2 type
The type of actuator connected is different than during initialization OR
traffic detected by the system OR not equal to actuator channel 1
initialization/check item numbers
Channel 3 type initialization/check item numbers
Channel 4 type initialization/check item numbers
Channel 5 type initialization/check item numbers
Channel 6 type initialization/check item numbers
Channel 1 pulse
Too much pulse errors
Initialization
Channel 2 pulse Initialization
Channel 3 pulse Initialization
Channel 4 pulse Initialization
Channel 5 pulse Initialization
Channel 6 pulse Initialization
overload in downward motion
Initialization

E41
E42
E43
E44
E45
E46
E47
E48
E49
E50
E51
E52
E53
E54
E55
E56
E57
E58
E59
E60
E61
E62
E63
E64
E65
E66
E67
E68
E69
E70
E71
E72
E73
E74
E75
E76
E77
E78
E79
E80
E81
E82
-
-
*Not applicable if the lower position is limited.
Step 1: Put the desk at the lowest position.
Step 2: After the desk is in its lowest position,
release the control and then hold it down again
until the desk makes a small movement down
and up.
Initialization (Reset):
Error codes
Initialization
Initialization
Initialization
Initialization
Initialization
Initialization
Channel 1 overload UIT
Overload in outward motion
Better weight distribution between columns/remove excess weight
Channel 2 overload UIT Better weight distribution between columns/remove excess weight
Channel 3 overload UIT Better weight distribution between columns/remove excess weight
Channel 4 overload UIT Better weight distribution between columns/remove excess weight
Channel 5 overload UIT Better weight distribution between columns/remove excess weight
Channel 6 overload UIT Better weight distribution between columns/remove excess weight
Channel 1 overload IN
Overload in downward motion
Obstacle removal / in misalignment initialization
Channel 2 overload IN Obstacle removal / in misalignment initialization
Channel 3 overload IN Obstacle removal / in misalignment initialization
Channel 4 overload IN Obstacle removal / in misalignment initialization
Channel 5 overload IN Obstacle removal / in misalignment initialization
Channel 6 overload IN Obstacle removal / in misalignment initialization
Channel 1 Anti-Collision Protection
the limit of anti-collision protection has been exceeded
Obstacle removal / in misalignment initialization
Channel 2 Anti-Collision Protection Obstacle removal / in misalignment initialization
Channel 3 Anti-Collision Protection Obstacle removal / in misalignment initialization
Channel 4 Anti-Collision Protection Obstacle removal / in misalignment initialization
Channel 5 Anti-Collision Protection Obstacle removal / in misalignment initialization
Channel 6 Anti-Collision Protection Obstacle removal / in misalignment initialization
Channel 1 SLS activated
SLS is activated
Obstacle removal / in misalignment initialization
Channel 2 SLS activated Obstacle removal / in misalignment initialization
Channel 3 SLS activated Obstacle removal / in misalignment initialization
Channel 4 SLS activated Obstacle removal / in misalignment initialization
Channel 5 SLS activated Obstacle removal / in misalignment initialization
Channel 6 SLS activated Obstacle removal / in misalignment initialization
Channel 1B type
Port B OR channel type has been changed
Channel 2B type
Channel 3B type
Channel 4B type
Channel 5B type
Channel 6B type
Channel 1A shorted
Short circuit detected on output :
Remove power cord/ check cables/ initialization
Channel 1B shorted Remove power cord/ check cables/ initialization
Channel 2A shorted Remove power cord/ check cables/ initialization
Channel 2B shorted Remove power cord/ check cables/ initialization
Channel 3A shorted Remove power cord/ check cables/ initialization
Channel 3B shorted Remove power cord/ check cables/ initialization
Channel 4A shorted Remove power cord/ check cables/ initialization
Channel 4B shorted Remove power cord/ check cables/ initialization
Channel 5A shorted Remove power cord/ check cables/ initialization
Channel 5B shorted Remove power cord/ check cables/ initialization
Channel 6A shorted Remove power cord/ check cables/ initialization
Channel 6B shorted Remove power cord/ check cables/ initialization

E83
E84
E85
E86 Master
E87 Slave 1
E88 Slave 2
E89 Slave 3
E100
E101
E102
E103
E104
E105
E106
E107
-
-
*Not applicable if the lower position is limited.
Step 1: Put the desk at the lowest position.
Step 2: After the desk is in its lowest position,
release the control and then hold it down again
until the desk makes a small movement down
and up.
Initialization (Reset):
Error codes
Initialization
Initialization
Initialization
Initialization
Initialization
Initialization
Initialization
Initialization
Massage Massager has been disconnected OR has failed Mounting/Initializing Device
DC output DC device has been disconnected OR has failed Mounting/Initializing Device
Radio turned off Radio circuit is turned off and needs to be restarted Mounting/Initializing Device
Lost connection to the master OR next message is from the master control motor cable/initialization/
Lost connection with slave 1 OR next message is from slave 1 control motor cable/initialization/
Lost connection with slave 2 OR next message is from slave 2 control motor cable/initialization/
Lost connection with slave 3 OR next message is from slave 3 control motor cable/initialization/
Forced initialization
reference 1 Forced initialization initiated
Forced initialization
reference 2
Forced initialization
reference 3
Forced initialization
reference 4
Forced initialization
reference 5
Forced initialization
reference 6
Forced initialization
reference 7
Forced initialization
reference 8
