World Market Chase Platform Storage Bed User manual

Assembly Instructions
Chase Platform Storage Bed
SKU - 420929
Page 1 of 9
THANK YOU FOR PURCHASING OUR QUALITY PRODUCT. IF YOU
HAVE ANY QUESTION PERTAINING TO THE ASSEMBLY OF THIS
FURNITURE PIECE, PLEASE CONTACT YOUR NEAREST
COST PLUS WORLD MARKET STORE FOR ASSISTANCE.

Parts List
Page 2 of 9
A.
C.
E.
G.
Headboard
Center Frame A
2 pcs
Side Rail
1 pc
Drawer Front
2 pcs
4 pcs
I.
Drawer Bottom 4 pcs
B.
D.
F.
H.
J.
Center Rail
Center Frame B
1 pc
Slat
1 pc
Drawer Side
4 pcs
8 pcs
Drawer Back 4 pcs

Page 3 of 9
Hardware List
H-1
Label Picture Description
Connector Bolt M6 x 80mm
Flat Washer
2
H-2 Connector Bolt M6 x 60mm 4
H-3
H-4
H-6
Connector Bolt M8 x 50mm
Spring Washer M6
4
H-8 U-Shaped Spacer 4
6
H-5 Spring Washer M8 4
6
L-Bracket
H-7 2
Qty
Tool List
1
Label Picture Description Qty
T-1 Allen Wrench M5
1
Allen Wrench M4
T-2
H-9 Wood Dowel M8 2
H-10 Wood Dowel M10 8
H-11 Castor 16
H-12 Castor Screw M3.5 x 12mm 64
H-13 Drawer Screw M4 x 25mm 48
H-14 L-Bracket Screw M4 x 20mm 4
H-15 Slat Screw M4 x 20mm 16

Assembly Preparation
Page 4 of 9
Before Beginning:
Unpack all hardware bags and components to ensure you have all parts -
Read instructions, cover to cover -
Have 2 adults on hand for assembly -
Do not assemble on flooring or carpet -
Assemble on a clean non-marking surface (packing foam) -
Save all packaging until finished -
In case of missing parts, please contact your nearest Cost Plus World Market Store.
2X
BD
C
E
I
G
H
H
J
F
F
F
FE
A
A

Drawer Assembly
Page 5 of 9
Step 1:
Step 3:
Step 2:
Step 4:
a. Attach Drawer Back (J) to the end of
Drawer Sides (H) and secure with Drawer
Screws (H-13).
a. Place Drawer Front (G) on a
scratch-free surface.
b. Attach Drawer Sides (H) to Drawer
Front (G) and secure with Drawer
Screws (H-13) using Phillips Screwdriver,
not provided.
a. Secure Drawer Bottom (I) with Drawer
Screws (H-13).
b. Attach Castor (H-11) to Drawer
Bottom (G) with Castor Screws (H-12).
c. Repeat procedure for the remaining 3
drawers.
a. Slot Drawer Bottom (I) into the groove of
Drawer Front (G) and Drawer Sides (H).
H-12
H/W Required
16
12
H-13
4 sets
H-11 4
G
H
HG
G
H
H
H
H
I
I
I
J
H-13
H-13
H-13
H-12
H-11
H-13
H-12

Assembly Steps
Page 6 of 9
Step 1:
Step 2:
a. Place Center Rail (B) on a soft, non-marring surface.
b. Attach Center Frame (C) and (D) to Center Rail (B). Secure Center Frame (C) and (D) using
Connector Bolt (H-1), Spring Washer (H-4) and Flat Washer (H-6), provided.
a. Attach Headboard (A) to the assembly, secure using Connector Bolt (H-2), Spring Washer (H-4) and
Flat Washer (H-6). Tighten using Allen Key (T-2), provided.
H-1
H-4
H-6
H/W Required
2
2
2
D
C
C
B
B
H-1
H-4
H-6
T-2
H-2
H-4
H-6
H/W Required
2
2
2
D
C
A
H-2
H-4
H-6
T-2
B

Assembly Steps
Page 7 of 9
Step 3:
Step 4:
a. Repeat Step 3 to attach the remaining HeadBoard (A).
b.Using provided L-Brackets (H-7) and Screws (H-14), secure Center Frame (B) to the assembly
firmly. Tighten with a Phillips Screwdriver, not provided.
c. Secure Center Frame (C) to Headboard (A) using two Connector Bolts M6X80mm (H-2),
Flat Washer (H-6) and Spring Washer (H-4). Tighten with Allen Key M4 (T-2), provided.
a. Insert Wood Dowel M8 (H-10) onto Center Frame Long ( B). Attach Side Rails (E) to the
assembly using Wood Dowels M10 (H-10) and secure using Connector Bolts M8X50mm (H-3),
Spring Washer (H-5) and U-Shaped Spacer (H-8). Tighten with Allen Key M5 (T-1), provided.
H-5
H-3
H-8
H/W Required
2
2
2
H-9
2
H-10
2
A
E
E
E
E
B
B
H-10
H-3
H-8
H-5
H-9
A
A
E
A
H-10
B
E
B
E
E
H-3
H-8
H-5
T-1
T-2
H-2
H-4
H-6
H-4
H-6
H/W Required
2
2
H-3
H-2
2
2
H-7
2
H-8
2
H-10
2
H-14
4
H-5
2

Assembly Steps
Page 8 of 9
Step 5:
Step 6:
a. Place Slat (F) rolls on top of the assembly as illustrated. Secure Slats to the assembly using
Slat Screws ( H-15). Tighten using a Phillips Screw Driver.
b. Adjustable levelers are provided underneath Center Frame Long (B), Center Frame (C) & (D),
that can be adjusted to make the assembly leveled on the floor.
Insert Drawers assembled earlier into the Bed Assembly. Assembly is complete.
H-15
H/W Required
16
F
H-15

Care & Maintenance
Page 9 of 9
Do not put hot items directly on furniture surface.
Do not clean furniture with harsh cleansers or polish.
Do not place furniture in direct sunlight.
Do not place furniture near heating or cooling vents.
Do not write on furniture without a padded barrier to protect the surface.
Do not place furniture outside. For indoor use only.
Dust and pick-up spills using a clean, non-colored, lint-free cloth.
Stains may be removed with mild soap solution and damp cloth.
Not for commercial use. For residential use only.
