WorldWEIGH T100-WF User manual

WorldWEIGH
Pallet Scale
V1.2
Instruction Manual

WorldWEIGH Pallet Scale Manual
- 2 -
Contents
1. INTRODUCTION……………….……………...…………………………………………3
2. SPECIFICATIONS…………………….……...………………………………………..…4
3. INSTALLATION…………………...…………...………………………………………….5
3.1 General installation…………………………………………….………………………..5
3.2 Installation of TPS series………………….……...…..………………………………..5
3.2.1 Install handle……………………………………...…………….……………………..5-6
3.2.2 Adjust release device………………………………..………………………………..7
3.2.3 Install Display Head…………………………………………………………………..8
4. PALLET TRUCK OPERATE……………….…………………………………………….9
4.1 Control lever……………………...….………………………….………………………9
4.2 Safety Notes……………………………………………..……………………………..9-10
5. KEY DESCRIPTIONS…………………………………………………………………11-12
Display …………...…………………...………………..………………………………..12
6. OPERATION………………………………….………………….………………………13
6.1 Basic Operation………………………………………..……………………......13
6.2 Check weighing………………………………………………………………..13-14
6.3. Accumulation……..……….………………………………..…………………..15
6.4. Animal Weighing.…………………………………………………………….…16
6.5. Keyboard Lock…………………………………………………………………….16
6.6. Set auto power off………………………………………………………………..16
6.7. Set Back Light……………………………………………………………………17
7. PARAMETERS……………………………………………………………….……….18-20
8. CALIBRATION………………………………………………………………..…………21-22
9. DRAWING………………………………………………………………………………..23
APPENDIX 1 DRAWING OF PUMP ASSEMBLY AND HANDLE……………...……..24-26
APPENDIX 2 DRAWING OF FRAME………………………………………..……….…27-28
B-TEK Contact information……………………………………………………………29

WorldWEIGH Pallet Scale Manual
- 3 -
1. INTRODUCTION
The T100 series of pallet scale provides an accurate, fast weighing solution for pallets.
All the keypads are mechanical switches, and the displays are large backlit easy to read
liquid crystal type displays (LCD).
All units include automatic zero tracking, unit selection, gross/net selection and an
accumulation that allows the individual weights to be stored and recalled as an
accumulated total.
There are 2 different fork size options narrow fork and wide.

WorldWEIGH Pallet Scale Manual
- 4 -
2. SPECIFICATIONS
Model
T100-NF T100-WF
Max Lifting weight
4400lb 2000kg
Min. Fork Height
3.25”
Max. fork height
7.75”
Fork length
44.75”
Fork overall width
21.75”/27”
Individual fork width
7”
Capacity
4400lb/2000kg
division
2lb/1kg
External resolution
1/2,000d
Stabilisation Time
1 Seconds typical
Operating
Temperature
0°C ~ +40°C / 14°F - 104°F
Power supply
External AC adapter, 12V 500mA, built-in rechargeable
battery (lead acid, 6V/10Ah)
Calibration
Automatic External
Display
51/2digits LCD digital display with 52mm high digits
(White LED backlight display)
Interface
RS-232 Output Optional
Load cells
4 load cells

WorldWEIGH Pallet Scale Manual
- 5 -
3. INSTALLATION
3. 1 General Installation
Avoid extreme temperatures.
Do not place in direct sunlight or near air conditioning vents.
Avoid high humidity that might cause condensation.
Do not spray or immerse the scales in water.
Keep the scale clean of debris.
Do not stack material on the scale when not in use.
Ensure that the load is centered to the scale.
Only take weight readings when the scale is stationary.
Ensure that the battery is fully charged before use, see detail in SECTION 9.
3. 2 Installation of TPS series
3.2.1 Install handle
The handle is packed separate from pallet truck.
1. Loosen the set screw (140H) on the crank link (139H).
2. Remove three screws (H109) and three spring washers (H110) from the base (103).

WorldWEIGH Pallet Scale Manual
- 6 -
3. Place the handle (H101) on the base (103), please note: Feed the rod and chain
(H107) through the center of the base (103) and axle (109).
4. Insert three screws (H109) with spring washers (H110) into the base (103). Then
tighten them securely.
5. Raise the crank link (139H) and put the pin on rod and chain (H107) into the groove
of crank link (139H).

WorldWEIGH Pallet Scale Manual
- 7 -
3.2.2 Adjusting the release lever.
On the handle of the pallet truck, you will find the control lever (H106) which can be set
in three positions.
1. First tighten the setting screw (140H) on the crank link (139H) until the LOWER
position function works.
2. If the forks elevate while pumping in the NEUTRAL position, turn the setting screw
(140H) clockwise until pumping the handle does not raise the forks and the NEUTRAL
position functions correctly.
3. If the forks descend while pumping in the NEUTRAL position, turn the setting screw
(140H) counterclockwise until the forks do not lower.
4. If the forks do not descend when the control lever (H106) is in the LOWER position,
turn the setting screw (140H) clockwise until raising the control lever (H106) lowers the
forks. Then check the NEUTRAL position as per item 2 and 3.
5. If the forks do not lift while pumping in the ASCENT position, turn the setting screw
(140H) counterclockwise until the forks elevate while pumping in the ASCENT position.
Then check the NEUTRAL and LOWER position as per item 2, 3 and 4.
Set Screw and Locking Nut

WorldWEIGH Pallet Scale Manual
- 8 -
Install Display Head (Weighing Indicator)
Remove the display head (indicator) from the carton, and place to fix on the top of
the pallet head.
Remove the screws from the display head and pull the front housing of the
display head, bottom side of the display head has 3 holes for to use screws to fix
display head to the pallet.
Use Allen screws to fix the display head on the pallet truck head by using allen
wrench. (Note: Allen key and screw are enclosed in the package). Close the
housing cover and tighten the screws.

WorldWEIGH Pallet Scale Manual
- 9 -
4. PALLET TRUCK OPERATION
4. 1 CONTROL LEVER
the control lever (H106) has three positions for use.
LOWER: to lower the forks
NEUTRAL: to move the load
ASCENT: to raise the forks. After assembling the handle, you
can adjust the three positions.
4.2 SAFETY NOTES For safe operation of the truck, please read
all warning signs and instructions here and
on the truck before using this truck.

WorldWEIGH Pallet Scale Manual
- 10 -
SAFETY NOTES CONTINUED
1. Do not operate the pallet truck unless you are familiar with it and have been trained
or authorized to do so.
2. Do not operate the truck unless you have checked its condition. Give special
attention to the wheels, the handle assembly, the forks, lift and the lower control.
3. Do not use the truck on sloping ground.
4. Never place any part of your body in the lifting mechanism or under the forks or load.
5. Do not carry passengers.
6. The operator should wear gloves and safety shoes for protection.
7. Do not handle unstable or loosely stacked loads.
8. Do not overload the truck.
9. Do not move unbalanced loads.
10. The capacity of the truck assumes an evenly distributed load with the center of the
load being at the halfway point of the length of the forks.
10. Make sure that length of the forks matches the length of the pallet.
11. Lower the forks to lowest height when the truck is not being used.
12. The operator of the pallet jack should always operate equipment with safety in mind.

WorldWEIGH Pallet Scale Manual
- 11 -
5. KEYS DESCRIPTION
Keyboard
Keys
Description
Power ON/OFF
Zero the scale
To perform a tare function, Subtracts weights.
Memory recall key, show the stored values from the
memory. Press and hold 3 seconds for store the pre-tare
values
Accumulator key, current values will be stored into the
memory.
Shift to Gross / Net Weight.
To select the weighing unit

WorldWEIGH Pallet Scale Manual
- 12 -
Secondary functions of the keys
Function
Keys
To confirm the selected menu
To change the menu and active digit
To move the active digit to right
To move the active digit to left
To clear the setting values
Exit the menu to normal operation.
Display
Weighing Units
Low Battery
Symbol
Net weight
mode

WorldWEIGH Pallet Scale Manual
- 13 -
6. OPERATION
Initial Start-up
Warm-up time of 15 minutes stabilizes the measured values after powering the scale on.
6.1. Basic Operation
1. Power On/Off:
Switch on the scale by pressing the on/ off key.
When the scale is powered on a power up test is performed before the scale can
be used. Press the power button again to turn the scale off.
2. Zero
Environmental conditions can cause the scale to drift slightly off zero. However,
you can set the display of your balance to zero any time by pressing key
to ensure the scale reads zero before use.
3. Tare
The weight of any container can be removed by pressing the button.
•Load weight on the platform.
•Press key. Zero is displayed, and tare is subtracted.
•Remove weight on the platform. Tared weight is displayed. Only one tare value
can be stored at a time. Tare weight will be shown with a minus value.
•Press G/N to change between gross weight and net weight.
•To clear the tare value, remove the load and press key. Zero is displayed,
tare weight is cleared.
4. Select Unit
Press and hold three seconds key, to change the unit.
6.2. Check Weighing
Set an upper or lower limit when weighing with the limits range.
When using the limits an alarm will sound off when the scales weight is outside the set
limits.

WorldWEIGH Pallet Scale Manual
- 14 -
6.2.1. Set Limits
•Press and key together, display will show set h.
•Press key to select set h or set l.
•Press key to confirm, display will show 00000, the last
digit will blink.
•Enter the high limit value by using and keys to
change the active digits and press key to increment the
value.
•Press key to confirm, display will show set l.
•Enter the low limit value by using and keys to
change the active digits and press key to increment the
value.
•Press key to confirm.
•Exit the settings menu by pressing the key.
6.2.2. Set Check Weighing
•Press the and key together, display will show set h.
•Press the key to select beep.
•Press the key to confirm, display will show no or ok or
ng.
•Check mode no: No beep sound while using limits. Function turned off.
•Check mode ok: When the weight is between the limits. OK will be shown,
and beeper will be sounded.

WorldWEIGH Pallet Scale Manual
- 15 -
•Check mode ng: When the weight is out of the limits, the beeper
will be sounded and OK will be shown.
Note: Check weighing available only when the weight is more than 20d
6.3. Accumulation
The scale can be set to accumulate manually by pressing key. For settings, see
the parameter p 2 Com »mode » pr 2.
Before operating the scale ensure the scale is stable and returns to zero, accumulation
is available only when the weight is more than 20d.
Accumulation Operation
•Place the load on the platform.
•Press key when the STABLE indicator is displayed.
•The display will show acc 1 then will show the total saved value.
These values will be displayed for three seconds.
•Remove the weight from the pan.
•When the scale shows zero and is stable then place the second
weight on the scale.
•This can be done until the memory is full, or 99 items have been
entered.
6.3.1 Memory Recall
To recall memory, press key.
The display will show acc X(X: Total number of accumulation) then will show the total
saved value. This will be displayed for three seconds.
6.3.2. Memory Clear
To clear the memory, press and keys together.
The display will show Acc 0, all accumulation memory will be cleared from the memory.
6.3.3. Automatically accumulation.
The scale can be set to accumulate automatically. For settings, see the parameter p 2
Com »mode » auto

WorldWEIGH Pallet Scale Manual
- 16 -
Automatic Accumulation Operation
•Place the load on the platform.
•When the display shows the STABLE indicator, the display will show
acc 1 then will show the total saved value. This will display for
three seconds.
•Remove the weight from the pan.
•When the display displays zero and is stable then place the second
weight.
•This can be done until the memory is full, or 99 items have been
entered.
6.4. Animal Weighing
The T100 can be used for loads with vibration while weighing. This function can be used
for animal weighing. For settings, see the parameter p 4 oth »anm
Apply the load to the platform, when the load is stable, the reading on the display will
lock for a few seconds.
Loads can be added or removed, and the locked values updated.
To enter or exit animal weighing mode, press and key together.
When in animal weighing mode HOLD indicator will be displayed.
6.5. Keyboard Lock
The scale can be set to lock keyboard, for settings, see the parameter p 4 oth »
lock.
When the keys are not in use for 10 minutes, the keys will lock automatically.
Enter the lock function, press the keys, display will show k-lok. The scale will go
back to normal display.
To unlock the keys, press and hold , and keys for three seconds.
The display will show u lck Then will go back to the normal display.
6.6. Set auto power off.
The scale can be set to power off when scale not in use, the scale will turn off after the
set time.

WorldWEIGH Pallet Scale Manual
- 17 -
•Hold the key for three seconds the display will show setbl
•Press the key to change Set of, then press the key to
confirm.
•Press the key to change the options.
Set of
Of 0
To set auto off function turn off, for scale always
on
Of 3
Set to turn off three minutes later
Of 5
Set to turn off five minutes later
Of 10
Set to turn off 10 minutes later
Of 3 0
Set to turn off 30 minutes later
•After selecting the auto off option, press the key to confirm, then press
the key to exit the settings menu.
6.7. Set Back Light
To set the back light when the scale is in use.
•Hold the key for three seconds the display will show setbl
•Press the key to confirm.
setbl
Bl au
To set auto option. When start to use back light
will be on and when stop the operation back light
also will off.
Bl on
To set always on. After turn on the power, back
light also will be on.
Bl off
To set the back light off. Back light will be off
during operations
•After selecting the back light option press the key to confirm and press
key to exit the menu settings.

WorldWEIGH Pallet Scale Manual
- 18 -
7.PARAMETERS
To set parameters, turn the scale on and follow the steps below.
•Press the key during the self-check countdown.
•The display will show pn
•Press the , and the to enter, display will show po chk
Menu
Sub Menu
Description
P 0 chk
Set H
Set high limits for check weighing
Set lo
Set low limits for check weighing
beep
No
No beep for check weighing
Ok
Beep, when check weighing between the
limits
ng
Beep, when check weighing out of the limits
P1 ref
A 2n 0
Automatic zero tracking
Options: 0 .5d, 1d, 2d, 4d
0auto
Setting the ZERO range, percentage of the
scale that can be zeroed when the ZERO
button is pressed.
Options: 0, 2, 5,10, 20, 50, 100
0range
Manual zero setting range.
Options: 0, 2, 5,10, 20, 50, 100
0tare
Auto zero tracking for NET mode.
(After pressing tare, NET weight will be zero)
Option: on / off
Speed
Set the ADC speed.
Option: 7 .5 / 15 / 3 0 / 60
Zero
Set new zero point,
P 2 com
Mode
This option is used to set accumulation
and RS-232 communication.
Options:
Cont: data send continues.
St 1: Send data one time, when stable.
St c: Send data continuously, when stable.
P r1: Send data one time, when press print
Key (in printer mode).
Pr 2: Send data to print and accumulation,
When press .key
Auto: Auto accumulate and auto print mode.

WorldWEIGH Pallet Scale Manual
- 19 -
When weight stable and return to
zero.
Ask : Ask mode,
Command R: read data
Command T: Tare
Command Z: Zero
Wireles: Wireless mode (communication
through wireless)
Kit 1 :
Baud
To set the baud rate.
Options:
600 / 1200 / 2400 / 4800 / 9600
Pr
To set the parity
Options:
7 e1 / 7 o1 / 8 n1
Ptype
To set printer model
Options:
Tpu p : set the printer tpup
Lp50 : Set the printer LP-50
L ab
To set the print format for gross weight /
accumulation options
Options:
lab 0 / lab 1 / lab 2 / lab 3
Prt
To set the print format for date / time options.
Options:
Prt 0 / prt 1 / prt 2 / prt 3 / prt 4 / prt 5 / prt 6
/ prt 7
L ang
To set language.
Options:
Eng for English
Chn for Chinese
P3 cal
Deci
To set to use decimal
Options;
0 / 0.0 / 0.00 / 0.000
Div
To select the scale division.
Options:
1 / 2 / 5 / 10 / 20 / 50
Cap
To set the capacity
Cal
To set nonlinear calibration
Count
Showing scale internal counts
gra
To set local gravity
P4 oth
Lock
To set keypad lock
Options: on / off
anm
To set animal mode.
Options: on / off

WorldWEIGH Pallet Scale Manual
- 20 -
P5 unit
Kg / lb /oz /g
To set unit.
Options; on / Off when the unit option is on,
that unit can be active.
P 6 xcl
External calibration
P7 rst
To reset the parameter back to the factory
settings
P8 uw b
U w b
On
Set the Bluetooth function on or off, When the
Bluetooth function set as on, RS-232 could not
be use.
off
P9 DAT
To set the date format
