Worx WG545 User manual

Cordless Li-Ion Blower/Sweeper
Souffleuse/Balayeuse sans fil Li-Ion
Sopladora/barredora inalámbrica con batería de iones de litio
EN
F
ES
P05
P12
P20
WG545 WG545.1 WG545.2 WG545.5
WG545.9 WG575 WG575.1
32

4
3
2
1
5

7
6
A1 A2
B C D
E1 E2

Cordless Li-Ion Blower/Sweeper EN
5
1. HANDLE
2. ON/OFF SWITCH
3. TUBE RELEASE BUTTON
4. BLOWER TUBE
5. BATTERY PACK
6. BATTERY PACK RELEASE BUTTONS (See Fig. B)
7. WALL MOUNT BRACKET* (See Fig. E1)
* Not all the accessories illustrated or described are included in standard delivery.
TECHNICAL DATA
WG545 WG545.1 WG545.2 WG545.5 WG545.9 WG575 WG575.1
Voltage 20V Max* 32V Max**
No load speed 12500/min 13800/min
Blow speed 120mph
Charger WA3732/ WA3742 WA3847 / WA3740
Machine weight 3.5lbs 2.7 lbs 4.0 lbs
* Voltage measured without workload. Initial battery voltage reaches maximum of 20 volts.
Nominal voltage is 18 volts.
** Voltage measured without workload. Initial battery voltage reaches maximum of 32 volts.
Nominal voltage is 28.8 volts.

Cordless Li-Ion Blower/Sweeper EN
6
ACCESSORIES
WG545 WG545.1 WG545.2 WG545.5 WG545.9 WG575 WG575.1
Battery 1(WA3520) 1(WA3525) 1(WA3520) / 1(WA3537)
Charger 1(WA3732/ WA3742) 1(WA3847) / 1(WA3740)
Wall mount bracket 1 / 1 1 / / /
Wide nozzle / 1 1 / 1 / 1
Dust brush / 1 1 / 1 / 1
Inflator nozzle / 1 1 / 1 / 1
Dust tube / 1 1 / 1 / 1
Accessory clip holder / 1 1 / 1 / 1
Extension hose / 1 1 / 1 / 1
Short tube / 1 1 / 1 / 1
Detail brush / 1 1 / 1 / 1
Deflation cover / 1 1 / 1 / 1
Accessory bag / 1 1 / 1 / 1
1: Attachment included;
/: Attachment not included
Only use the appropriate accessories intended for this tool. Accessory information can be found
on the product packaging, at a WORX dealer or on our website at www.worx.com or by calling
1-866-354-WORX(9679).

Cordless Li-Ion Blower/Sweeper EN
7
WARNING: Some dust created by
power sanding, sawing, grinding,
drilling and other construction activities
contains chemicals known to the state of
California to cause cancer, birth defects or
other reproductive harm. Some examples of
these chemicals are:
• Lead from lead-based paints;
• Crystalline silica from bricks and cement
and other masonry products and
• Arsenic and chromium from chemically-
treated lumber.
Your risk from these exposures varies,
depending on how often you do this type
of work.To reduce your exposure to these
chemical: work in a well ventilated area,
and work with approved safety equipment,
such as those dust masks that are specially
designed to filter out microscopic particles.
IMPORTANT SAFETY
INSTRUCTIONS
WARNING! When using electric
gardening appliances, basic safety
precautions should always be followed to
reduce the risk of fire, electric shock, and
personal injury, including the following:
WARNING: Read all instructions
WARNING: This product maybe
contains lead, phthalate or other chemicals
known to the State of California to cause
cancer, birth defects and other reproductive
harm. Please wash your hands after use.
FOR ALL APPLIANCES
1) Avoid Dangerous Environment - Don’t
use appliances in damp or wet locations.
2) Don’t Use In Rain.
3) Keep Children Away - All visitors should
be kept at a distance from work area.
4) Dress Properly - Do not wear loose
clothing or jewelry. They can be
caught in moving parts. Use of rubber
gloves and substantial footwear is
recommended when working outdoors.
Wear protective hair covering to contain
long hair.
5) Use Safety Glasses - Always use face or
dust mask if operation is dusty.
6) Use Right Appliance - Do not use
appliance for any job except that for
which it is intended.
7) Don’t Force Appliance - It will do the
job better and with less likelihood of a
risk of injury at the rate for which it was
designed.
8) Don’t Overreach - Keep proper footing
and balance at all times.
9) Stay Alert - Watch what you are doing.
Use common sense. Do not operate
appliance when you are tired.
10) Store Idle Appliances Indoors - When
not in use, appliances should be stored
indoors in dry, and high or locked-up
place - out of reach of children.
11) Maintain Appliance With Care - Keep
cutting edge sharp and clean for best
performance and to reduce the risk of
injury. Follow instructions for lubricating
and changing accessories. Keep handles
dry, clean, and free from oil and grease.
12) Check Damaged Parts - Before further
use of the appliance, a guard or other
part that is damaged should be carefully
checked to determine that it will operate
properly and perform its intended
function. Check for alignment of moving
parts, binding of moving parts, breakage
of parts, mounting, and any other
condition that may affect its operation.
A guard or other part that is damaged
should be properly repaired or replaced
by an authorized service center unless
indicated elsewhere in this manual.
FOR ALL BATTERY – OPERATED
GARDENING APPLIANCES
1. For all battery-operated gardening
appliances:
1) Do not charge appliance in rain, or in wet
locations.
2) Do not use battery-operated appliance in
rain.
3) Remove or disconnect battery before
servicing, cleaning or removing material
from the gardening appliance.

Cordless Li-Ion Blower/Sweeper EN
8
2. For all battery-operated products
employing a detachable or separable battery:
1) Use only the following type and size
battery(ies): WA3520/WA3525/WA3537.
2) Do not dispose of the battery(ies) in a
fire.The cell may explode. Check with
local codes for possible special disposal
instructions.
3) Do not open or mutilate the battery(ies).
Released electrolyte is corrosive and
may cause damage to the eyes or skin. It
may be toxic if swallowed.
4) Exercise care in handling batteries
in order not to short the battery with
conducting materials such as rings,
bracelets, and keys.The battery or
conductor may overheat and cause
burns.
3. Avoid Unintentional Starting – Do not
insert the battery with finger on the switch.
Be sure the switch is off when inserting the
battery.
ADDITIONAL SAFETY
WARNINGS
IMPORTANT
SAFETY
INSTRUCTIONS
When using an electrical appliance, basic
precautions should always be followed,
including the following:
READ ALL
INSTRUCTIONS
BEFORE
USING THIS
APPLIANCE
WARNING – To reduce the risk
of fire, electric shock, or
injury:
1. To reduce the risk of electric shock –
Do not use on wet surfaces. Do not
expose to rain. Store indoors.
2. Do not allow to be used as a toy.
Close attention is necessary when
used by or near children.
3. Use only as described in this
manual. Use only manufacture’s
recommended attachments.
4. If appliance is not working as
it should, has been dropped,
damaged, left outdoors, or dropped
into water, return it to a service
center.
5. Keep hair, loose clothing, fingers,
and all parts of body away form
openings and moving parts .
6. Do not charge the unit outdoors.
7. Use only the charger supplied by
the manufacturer to recharge.
8. Do not incinerate the appliance
even if it is severely damaged.The
batteries can explode in a fire.
9. Do not put any object into openings.
Do not use with any opening
blocked; keep free of dust, lint, hair,
and anything that may reduce air
flow .
10. Do not handle plug or appliance
with wet hands .
11. Do not leave appliance when
plugged in. Unplug from outlet
when not in use and before
servicing .
12. Turn off all controls before
unplugging .
13. Use extra care when cleaning on
stairs .
GENERAL SAFETY
WARNINGS
1) WARNING: Risk of fire and
burns. Do not disassemble,
heat above 100°C (212°F), or
incinerate. Do not expose cells or

Cordless Li-Ion Blower/Sweeper EN
9
batteries to heat or fire. Avoid
storage in direct sunlight.
2) Dispose of used battery promptly..
When disposing of secondary cells
or batteries, keep cells or batteries
of different electrochemical systems
separate from each other.
3) Keep battery out of reach of
children and in original package until
ready to use.
4) Never put batteries in mouth. If
swallowed, contact your physician
or local poison control center.
5) CAUTION – The battery used in this
device may present a risk of fire or
chemical burn if mistreated. Replace
battery with (WORX) only. Use of
another battery may present a risk
of fire or explosion
6) WARNING: Do not use a visibly
damaged battery pack or
appliance as applicable.
7) WARNING: Do not modify or
attempt to repair the appliance
or the battery pack as applicable.
8) BATTERY MUST BE RECYCLED
9) Do not short-circuit a cell or battery.
Do not store cells or batteries
haphazardly in a box or drawer
where they may short-circuit each
other or be short-circuited by
conductive materials.
10) Do not subject cells or batteries to
mechanical shock.
11) Keep cells and batteries clean and
dry. Wipe the cell or battery terminals
with a clean dry cloth if they become
dirty.
12) Do not maintain secondary cells and
batteries on charge when not in use.
13) Retain the original cell and battery
literature for future reference.
14) Do not use any charger other than
that specifically provided for use
with the equipment. Secondary cells
and batteries need to be charged before
use. Always use the correct charger and
refer to the manufacturer’s instructions
or equipment manual for proper
charging instructions.
15) When possible, remove the battery from
the equipment when not in use.
16) Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to battery pack, picking up
or carrying the appliance. Carrying the
appliance with your finger on the switch
or energizing appliance that have the
switch on invites accidents.
17) Disconnect the battery pack from
the appliance before making any
adjustments, changing accessories, or
storing appliance. Such preventive safety
measures reduce the risk of starting the
appliance accidentally.
18) Under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from
the battery may cause irritation or burns.
19) Have servicing performed by a qualified
repair person using only identical
replacement parts.This will ensure that
the safety of the product is maintained.
SAVE THESE
INSTRUCTIONS

Cordless Li-Ion Blower/Sweeper EN
10
ASSEMBLY
ASSEMBLING THE BLOWER TUBE
(See Fig. A1 & A2)
Before assembling the BlowerTube(4), be sure
the on/off switch (2) is in ‘’O’’ Off position.
Fit the BlowerTube to the motor housing as
shown in Fig A1. Check if the BlowerTube is
firmly secured.
WARNING! Do not attempt to operate
or disable the On/Off Switch by any
means other than the normal assembly or
removal of the tube.
NOTE: Before disassembling the Blower
Tube, be sure the on/off switch (2) is in ‘’O’’
Off position. Press the Release Button(3) , so
that you can separate the tube. (See Fig. A2)
Do not try to separate the tubes by force or by
using tools.
OPERATION
WARNING! The charger and battery
pack are specially designed to work
together, so do not attempt to use any other
devices. Never insert or allow metallic objects
into your charger or battery pack connections
because of an electrical failure and hazard will
occur.
1. BEFORE USING YOUR CORDLESS
BLOWER
Your battery pack is UNCHARGED, you must
charge before use.
The battery charger supplied is matched to the
Li-Ion battery installed in the machine. Do not
use another battery charger.
2. CHARGING YOUR BATTERY PACK
The Li-Ion battery is protected against deep
discharging. When the battery is empty,
the machine is switched off by means of
a protective circuit:The machine will stop
running.
In a warm environment or after heavy use, the
battery pack may become too hot to permit
charging. Allow time for the battery to cool
down before recharging.
SYMBOLS
To reduce the risk of injury, user
must read instruction manual
Li-Ion battery, battery must be
recycled
POSITEC Inc. has established
a partnership with the RBRC
Corporation to recycle any
Positec batteries with the
RBRC-call2recycle seal. For
environmental protection, please
do not discard batteries in the
trash. After the batteries’ life
cycle is ended, then please call
1-800-822-8837 for a free service
that will properly dispose of the
battery.
Wear ear protection
