Worx Nitro WG186E.1 Operation instructions

WG186E.1 WG186E.92
Cordless Grass Line Trimmer & Brushcutter, Attachment-Capable
Kabellose/r Grastrimmer/Motorsense, geeignet für Zubehör
Coupe-bordure et débroussailleuse sans fil, compatible avec différents accessoires
Tabgliaerba a batteria a filo e decespugliatore, Supporto per accessori
Cortacésped y desbrozadora sin cable, compatible con implementos
Aparador de relva com cordão sem fio e cortador de arbustos, com capacidade de fixação de acessórios
Snoerloze graskantentrimmer & borstelmaaier, opzetbaar
Ledningsfri græstrimmer og kratrydder. Vedhæftning - Effektivt
Trådløs gresslinjetrimmer og buskrydder, tilbehør kan kobles til
Sladdlös grästrimmer och buskklippare med fäste
Akumulatorowa podkaszarka do trawy i krzewów, z mozliwoscia mocowania
Χλοοκοπτικό μενήμαμπαταρίας και θαμνοκοπτικό μεδυνατότητα τοποθέτησης προσαρτημάτων
Vezeték nélküli funyíró és bozótvágó, alkalmas csatolásra
Motocoasăși mașinăde tăiat arboret cu acumulator, cu dispozitiv de prindere accesorii
Bezšnurová strunová kosa & krovinorez, umožnující použití nástavcu
Akumulátorový vyžínac trávy a krovinorez s možnostou pripojenia
Brezžicni rezalnik za travo in nitna kosa, z možnostjo nastavkov
EN
D
F
I
ES
PT
NL
DK
NOR
SV
PL
GR
HU
RO
CZ
SK
SL
P08
P23
P41
P59
P77
P95
P113
P131
P147
P162
P177
P195
P214
P231
P248
P265
P282

Original Instruction
Originalbetriebsanleitung
Notice originale
Istruzioni originali
Manual original
Manual original
Oorspronkelijke gebruiksaanwijzing
Original brugsanvisning
Original driftsinstruks
Bruksanvisning i original
Instrukcja oryginalna
ΜΕΤΑΦΡΑΣΗ ΤΩΝ ΠΡΩΤΟΤΥΠΩΝ ΟΔΗΓΙΩΝ
Eredeti használati utasítás
Instrucţiuni originale
Původní návod k používání
Pôvodný návod na použitie
Izvirna navodila
EN
D
F
I
ES
PT
NL
DK
NOR
SV
PL
GR
HU
RO
CZ
SK
SL

4
5
3
10
12
13
14
9
6
2
7
16
18
19
17
23
21
20
22 25
24
1
8
11
15

C
A
B2
1
2
B1

E1
1
E2
2
E4 E5
D
100%
0%
E3

G
F
1
2
K
I
J
H

L1 L2
L3 M
2
N
1

Cordless Grass Line Trimmer &
Brushcutter, Attachment-Capable
8
EN
PRODUCT SAFETY
GENERAL POWER TOOL
SAFETY WARNINGS
WARNING Read all
safety warnings,
instructions, illustrations
and specifications
provided with this power
tool. Failure to follow all
instructions listed below may
result in electric shock, fire
and/or serious injury.
Save all warnings and
instructions for future
reference.
The term "power tool" in
the warnings refers to your
mains-operated (corded)
power tool or battery-
operated (cordless) power
tool.
1)Work area safety
a) Keep work area clean
and well lit. Cluttered or
dark areas invite accidents.
b)Do not operate power
tools in explosive
atmospheres, such
as in the presence
of flammable liquids,
gases or dust. Power
tools create sparks which
may ignite the dust or
fumes.
c)Keep children and
bystanders away while
operating a power tool.
Distractions can cause you
to lose control.
2)Electrical safety
a) Power tool plugs must
match the outlet. Never
modify the plug in any
way. Do not use any
adapter plugs with
earthed (grounded)
power tools. Unmodified
plugs and matching outlets
will reduce risk of electric
shock.
b)Avoid body contact
with earthed or
grounded surfaces,
such as pipes,
radiators, ranges and
refrigerators. There is an
increased risk of electric
shock if your body is
earthed or grounded.
c)Do not expose power
tools to rain or wet
conditions. Water
entering a power tool will
increase the risk of electric
shock.
d)Do not abuse the cord.
Never use the cord
for carrying, pulling or
unplugging the power

9
Cordless Grass Line Trimmer &
Brushcutter, Attachment-Capable EN
tool. Keep cord away
from heat, oil, sharp
edges or moving parts.
Damaged or entangled
cords increase the risk of
electric shock.
e)When operating a
power tool outdoors,
use an extension cord
suitable for outdoor
use. Use of a cord suitable
for outdoor use reduces
the risk of electric shock.
f) If operating a power
tool in a damp location
is unavoidable, use a
residual current device
(RCD) protected supply.
Use of an RCD reduces the
risk of electric shock.
3)Personal safety
a) Stay alert, watch what
you are doing and use
common sense when
operating a power tool.
Do not use a power
tool while you are tired
or under the influence
of drugs, alcohol or
medication. A moment of
inattention while operating
power tools may result in
serious personal injury.
b)Use personal protective
equipment. Always
wear eye protection.
Protective equipment such
as dust mask, non-skid
safety shoes, hard hat, or
hearing protection used for
appropriate conditions will
reduce personal injuries.
c)Prevent unintentional
starting. Ensure
the switch is in the
off-position before
connecting to power
source and/or battery
pack, picking up or
carrying the tool.
Carrying power tools with
your finger on the switch
or energising power tools
that have the switch on
invites accidents.
d)Remove any adjusting
key or wrench before
turning the power tool
on. A wrench or a key left
attached to a rotating part
of the power tool may
result in personal injury.
e)Do not overreach. Keep
proper footing and
balance at all times.
This enables better control
of the power tool in
unexpected situations.
f) Dress properly. Do not
wear loose clothing or
jewellery. Keep your

Cordless Grass Line Trimmer &
Brushcutter, Attachment-Capable
10
EN
hair and clothing away
from moving parts.
Loose clothes, jewellery or
long hair can be caught in
moving parts.
g)If devices are provided
for the connection of
dust extraction and
collection facilities,
ensure these are
connected and properly
used. Use of dust
collection can reduce dust-
related hazards.
h)Do not let familiarity
gained from frequent
use of tools allow you
to become complacent
and ignore tool safety
principles. A careless
action can cause severe
injury within a fraction of a
second.
4)Power tool use and
care
a) Do not force the power
tool. Use the correct
power tool for your
application. The correct
power tool will do the job
better and safer at the rate
for which it was designed.
b)Do not use the power
tool if the switch does
not turn it on and off.
Any power tool that
cannot be controlled with
the switch is dangerous
and must be repaired.
c)Disconnect the plug
from the power
source and/or
remove the battery
pack, if detachable,
from the power tool
before making any
adjustments, changing
accessories, or
storing power tools.
Such preventive safety
measures reduce the risk
of starting the power tool
accidentally.
d)Store idle power
tools out of the reach
of children and do
not allow persons
unfamiliar with the
power tool or these
instructions to operate
the power tool. Power
tools are dangerous in the
hands of untrained users.
e)Maintain power tools
and accessories. Check
for misalignment or
binding of moving
parts, breakage of parts
and any other condition
that may affect the
power tool’s operation.

11
Cordless Grass Line Trimmer &
Brushcutter, Attachment-Capable EN
If damaged, have the
power tool repaired
before use. Many
accidents are caused by
poorly maintained power
tools.
f) Keep cutting tools
sharp and clean.
Properly maintained
cutting tools with sharp
cutting edges are less likely
to bind and are easier to
control.
g)Use the power tool,
accessories and tool
bits etc. in accordance
with these instructions,
taking into account
the working conditions
and the work to be
performed. Use of the
power tool for operations
different from those
intended could result in a
hazardous situation.
h)Keep handles and
grasping surfaces dry,
clean and free from oil
and grease. Slippery
handles and grasping
surfaces do not allow for
safe handling and control
of the tool in unexpected
situations.
5)Battery tool use and
care
a) Recharge only with
the charger specified
by the manufacturer. A
charger that is suitable for
one type of battery pack
may create a risk of fire
when used with another
battery pack.
b)Use power tools
only with specifically
designated battery
packs. Use of any other
battery packs may create a
risk of injury and fire.
c)When battery pack
is not in use, keep it
away from other metal
objects, like paper
clips, coins, keys, nails,
screws or other small
metal objects, that can
make a connection
from one terminal to
another. Shorting the
battery terminals together
may cause burns or a fire.
d)Under abusive
conditions, liquid may
be ejected from the
battery; avoid contact.
If contact accidentally
occurs, flush with
water. If liquid contacts
eyes, additionally seek
medical help. Liquid

Cordless Grass Line Trimmer &
Brushcutter, Attachment-Capable
12
EN
ejected from the battery
may cause irritation or
burns.
e)Do not use a battery
pack or tool that is
damaged or modified.
Damaged or modified
batteries may exhibit
unpredictable behaviour
resulting in fire, explosion
or risk of injury.
f) Do not expose a
battery pack or tool
to fire or excessive
temperature. Exposure
to fire or temperature
above 130 °C may cause
explosion.
g)Follow all charging
instructions and do
not charge the battery
pack or tool outside
the temperature
range specified in
the instructions.
Charging improperly or
at temperatures outside
the specified range may
damage the battery and
increase the risk of fire.
6)Service
a) Have your power
tool serviced by a
qualified repair person
using only identical
replacement parts.
This will ensure that the
safety of the power tool is
maintained.
b)Never service damaged
battery packs. Service
of battery packs should
only be performed
by the manufacturer
or authorized service
providers.
BRUSH CUTTER SAFETY
WARNINGS
1. Do not use the machine
when the operator is tired,
ill or under the influence of
alcohol or other drugs.
2. Keep a firm footing and
balance during operating.
Use the harness provided.
3. Replace cutting blade
if cracked, chipped, or
damaged in any way. Be
sure the blade is properly
installed and securely
fastened. Failure to do so
can cause serious injury.
4. Keep away from cutting
blade. Even after the motor
has stopped, the cutting
blade will continue to
rotate for several seconds.
Please wait until cutting
blade has fully stopped

13
Cordless Grass Line Trimmer &
Brushcutter, Attachment-Capable EN
before putting the machine
down or accessing the
cutting area.
5. Switch off the machine
when not cutting. Never
leave the machine running
when unattended.
GENERAL SAFETY
WARNINGS
WARNING Read all
safety warnings and
all instructions. Failure
to follow the warnings and
instructions may result in
electric shock, fire and/or
serious injury.
Save all warnings and
instructions for future
reference.
The appliance is only to be
used with the power supply
unit provided with the
appliance.
IMPORTANT
READ CAREFULLY
BEFORE USE
KEEP FOR FUTURE
REFERENCE
Safe operating practices
1.Training
a) Read the instructions
carefully. Be familiar with
the controls and the correct
use of the machine.
b) Never allow children,
persons with reduced
physical, sensory or mental
capabilities or lack of
experience and knowledge
or people unfamiliar
with these instructions
to use the machine, local
regulations may restrict
the age of the operator.
c) Keep in mind that the
operator or user is
responsible for accidents
or hazards occurring to
other people or their
property.
2.Preparation
a) Before use, always visually
inspect the machine for
damaged, missing or
misplaced guards or
shields.
b) Never operate the machine
while people, especially
children, or pets are
nearby.
3.Operation
a) Wear eye protection, long
trousers and stout shoes
at all times while operating
the machine.
b) Avoid using the machine
in bad weather conditions
especially when there is a

Cordless Grass Line Trimmer &
Brushcutter, Attachment-Capable
14
EN
risk of lightning.
c) Use the machine only in
daylight or good artificial
light.
d) Never operate the machine
with damaged guards or
shields or without guards
or shields in place.
e) Switch on the motor only
when the hands and feet
are away from the cutting
means.
f) Always disconnect the
machine from the power
supply (e.g. remove the
battery pack from the
machine)
1) whenever the machine
is left unattended;
2) before clearing a
blockage;
3) before checking,
cleaning or working on the
machine;
4) after striking a foreign
object;
5) whenever the machine
starts vibrating abnormally.
g)Take care against injury to
feet and hands from the
cutting means.
h) Always ensure that the
ventilation openings are
kept clear of debris.
i) Never fit metal cutting
elements.
j) Always be sure of your
footing on slopes.
k) Walk, never run.
l) Not overreach and keep
the balance at all times.
m)Not to touch moving
hazardous parts before
removing the battery pack
from the machine and the
moving hazardous parts
have come to a complete
stop.
4.Maintenance and
storage
a) Disconnect the machine
from the power supply
(e.g. remove the battery
pack from the machine)
before carrying out
maintenance or cleaning
work.
b) Use only the
manufacturer’s
recommended
replacement parts and
accessories.
c) Inspect and maintain the
machine regularly. Have
the machine repaired only
by an authorized repairer.
d) When not in use, store the
machine out of the reach of
children.

15
Cordless Grass Line Trimmer &
Brushcutter, Attachment-Capable EN
SAFETY WARNINGS FOR
BATTERY PACK
a) Do not dismantle, open
or shred cells or battery
pack.
b)Do not short-circuit a
battery pack. Do not
store battery packs
haphazardly in a box or
drawer where they may
short-circuit each other
or be short-circuited by
conductive materials.
When battery pack is not
in use, keep it away from
other metal objects, like
paper clips, coins, keys,
nails, screws or other small
metal objects, that can
make a connection from
one terminal to another.
Shorting the battery
terminals together may
cause burns or a fire.
c)Do not expose battery
pack to heat or fire.
Avoid storage in direct
sunlight.
d)Do not subject battery
pack to mechanical
shock.
e)In the event of battery
leaking, do not allow
the liquid to come into
contact with the skin
or eyes. If contact
has been made, wash
the affected area with
copious amounts of
water and seek medical
advice.
f) Seek medical advice
immediately if a cell or
battery pack has been
swallowed.
g)Keep battery pack
clean and dry.
h)Wipe the battery
pack terminals with a
clean dry cloth if they
become dirty.
i) Battery pack needs to
be charged before use.
Always refer to this
instruction and use
the correct charging
procedure.
j) Do not maintain battery
pack on charge when
not in use.
k)After extended periods
of storage, it may be
necessary to charge
and discharge the
battery pack several
times to obtain
maximum performance.
l) Battery pack gives its
best performance when
it is operated at normal
room temperature (20 °C
± 5 °C).

Cordless Grass Line Trimmer &
Brushcutter, Attachment-Capable
16
EN
m)When disposing
of battery packs,
keep battery
packs of different
electrochemical
systems separate from
each other.
n)Recharge only with
the charger specified
by WorxNITRO. Do not
use any charger other
than that specifically
provided for use with
the equipment. A charger
that is suitable for one type
of battery pack may create
a risk of fire when used
with another battery pack.
o)Do not use any battery
pack which is not
designed for use with
the equipment.
p)Keep battery pack out
of the reach of children.
q)Retain the original
product literature for
future reference.
r) Remove the battery
from the equipment
when not in use.
s) Dispose of properly.
t) Do not mix cells of
different manufacture,
capacity, size or type
within a device.
u)Do not remove battery
pack from its original
packaging until required
for use.
v)Observe the plus (+)
and minus (–) marks on
the battery and ensure
correct use.
SYMBOLS
To reduce the risk of injury, user
must read instruction manual
Wear dust mask
Wear protective gloves
Wear protective footwear
Wear head protection
Wear protective clothing
Keep bystanders away
Wear eye and ear protection
Do not expose to rain

17
Cordless Grass Line Trimmer &
Brushcutter, Attachment-Capable EN
The distance between the
machine and bystanders shall
be at least 15 m
Beware of thrown objects
Beware of blade thrust
Waste electrical products
must not be disposed of with
household waste. Please recycle
where facilities exist. Check with
your local authorities or retailer
for recycling advice.
Li-Ion batteryThis product has
been marked with a symbol
relating to ‘separate collection’
for all battery packs and battery
pack. It will then be recycled or
dismantled in order to reduce
the impact on the environment.
Battery packs can be hazardous
for the environment and for
human health since they contain
hazardous substances.
Do not burn
Batteries may enter water cycle if
disposed improperly, which can
be hazardous for ecosystem. Do
not dispose of waste batteries as
unsorted municipal waste.
Make sure the battery is removed
prior to changing accessories.
Trimming
COMPONENT LIST
1. BATTERY INDICATOR LIGHT
2. BATTERY PACK *
3. LOCK-OFF BUTTON
4. SWITCH TRIGGER
5. ECO BUTTON
6. UPPER SHAFT
7. AUXILIARY HANDLE
8. SAFETY-STOP HANDLE
9. LOCKING KNOB
10. LOWER SHAFT
11. SAFETY GUARD
12. LINE CUTTER
13. SKIRT
14. TRIMMER HEAD (BUMP HEAD)
15. RELEASE TAB
16. BRUSH-CUTTER BLADE
17. WASHER
18. BLADE HOUSING
19. LOCK-NUT
20. SHOULDER STRAP
21. WRENCH
22. HEX KEY
23. POLE HEDGE TRIMMER ATTACHMENT*
24. POLE SAW ATTACHMENT *
25. EDGER ATTACHMENT *
* Not all the accessories illustrated or
described are included in standard delivery.
TECHNICAL DATA
Type Designation: WG186E.1 WG186E.92
(1-designation of machinery, representative of
Cordless Grass Trimmer/ Brush Cutter)
WG186E.1 WG186E.92
Voltage 40V
MAX (2x20V MAX) **
No load speed 6000/min
Cutting Diameter
for grass
trimmer 38cm
Cutting diameter
for brush cutter
blade 25cm
Line Diameter 2 x2.4mm

Cordless Grass Line Trimmer &
Brushcutter, Attachment-Capable
18
EN
Line length 2 x3m
Battery type Lithium-ion /
Battery Model WA3014 (4.0Ah) /
Charger Model WA3883 /
Charging time
(approx.)
Battery pack:
4.0Ah (1pc)
4.0Ah (2pcs) 1 hr 2 hrs
/
Machine Weight 5.5kg 4.1kg
**Voltage measured without workload. Initial battery
voltage reaches maximum of 20 volts. Nominal
voltage is 18 volts.
FOR GRASS TRIMMER:
NOISE INFORMATION
A weighted sound pressure LpA = 81.5dB(A)
KpA 1.93dB(A)
A weighted sound power LwA = 94.4dB(A)
KwA 1.93dB(A)
Wear ear protection
VIBRATION INFORMATION
Typical weighted vibration ah=2.822m/s2
Uncertainty K = 1.5m/s²
The declared vibration total value may be used for
comparing one tool with another, and may also be used in a
preliminary assessment of exposure.
WARNING: The vibration emission value during
actual use of the power tool can differ from the
declared value depending on the ways in which the tool
is used dependant on the following examples and other
variations on how the tool is used:
How the tool is used and the materials being cut or drilled.
The tool being in good condition and well maintained
The use the correct accessory for the tool and ensuring it is
sharp and in good condition.
The tightness of the grip on the handles and if any anti
vibration accessories are used.
And the tool is being used as intended by its design and
these instructions.
This tool may cause hand-arm vibration syndrome if
its use is not adequately managed
WARNING: To be accurate, an estimation of
exposure level in the actual conditions of use
should also take account of all parts of the operating
cycle such as the times when the tool is switched off
and when it is running idle but not actually doing the
job.This may significantly reduce the exposure level
over the total working period.
Helping to minimise your vibration exposure risk.
ALWAYS use sharp chisels, drills and blades
Maintain this tool in accordance with these instructions
and keep well lubricated (where appropriate)
If the tool is to be used regularly then invest in anti
vibration accessories.
Plan your work schedule to spread any high vibration
tool use across a number of days.
FOR BRUSH CUTTER:
NOISE INFORMATION
A weighted sound pressure LpA = 72.53dB(A)
KpA 3dB(A)
A weighted sound power LwA = 92.53dB(A)
KwA 3dB(A)
Wear ear protection
VIBRATION INFORMATION
Vibration total values (triax vector sum) determined
according to EN 62841:
Vibration emission value: ah= 2.673m/s2
Uncertainty K = 1.5m/s²
The declared vibration total value and the declared noise
emission value have been measured in accordance with a
standard test method and may be used for comparing one
tool with another.
The declared vibration total value and the declared
noise emission value may also be used in a preliminary
assessment of exposure.
WARNING: The vibration and noise emissions
during actual use of the power tool can differ from
the declared value depending on the ways in which the
tool is used especially what kind of workpiece is processed
dependant on the following examples and other variations
on how the tool is used:
How the tool is used and the materials being cut or drilled.
The tool being in good condition and well maintained.
The use of the correct accessory for the tool and ensuring it
is sharp and in good condition.
The tightness of the grip on the handles and if any anti
vibration and noise accessories are used.
And the tool is being used as intended by its design and
these instructions.

19
Cordless Grass Line Trimmer &
Brushcutter, Attachment-Capable EN
This tool may cause hand-arm vibration syndrome if
its use is not adequately managed.
WARNING: To be accurate, an estimation of
exposure level in the actual conditions of use should
also take account of all parts of the operating cycle such
as the times when the tool is switched off and when it
is running idle but not actually doing the job.This may
significantly reduce the exposure level over the total
working period.
Helping to minimise your vibration and noise exposure risk.
Always use sharp chisels, drills and blades.
Maintain this tool in accordance with these instructions and
keep well lubricated (where appropriate).
If the tool is to be used regularly then invest in anti vibration
and noise accessories.
Plan your work schedule to spread any high vibration tool
use across a number of days.
ACCESSORIES
WG186E.1 WG186E.92
Battery pack
(WA3014)
2 /
Charger (WA3883)
1 /
Spool
1 1
Safety guard
1 1
Brush cutter blade
1 1
Pole hedge trimmer
attachment (WA0220)
/ /
Pole saw attachment
(WA0222)
/ /
Edger attachment
(WA0223)
/ /
Shoulder strap
1 1
Hex key
1 1
Wrench
1 1
We recommend that you purchase your accessories
listed in the above list from the same store that
sold you the lawn trimmer. Refer to the accessory
packaging for further details. Store personnel can
assist you and offer advice.
ASSEMBLY & OPERATION
NOTE: Before using the tool, read the
instruction book carefully.
Action Figure
Assembly
Assembling theTrimmer Shaft
Insert the screw into the hole, then
tighten the locking knob See Fig. A
Assembling the Auxiliary Handle and
Safety-stop Handle See Fig. B1, B2
Assembling the Safety Guard
Insert the metal bracket into the slot
on the safety guard, then secure the
guard in place using the screw and
hex key.
See Fig. C
Assembling the Shoulder Strap See Fig. D
Installing and Removing the Battery
Pack
NOTE:
• This machine will only run
when 2 batteries are installed. It
is recommended to use the same
two batteries and charge the
two batteries at the same time.
• When two batteries are used
with different amp hours or
charge level, the machine will
run to the lowest common
denominator.
* It is recommended that using
4.0Ah or above battery pack for
better performance and longer
run time.
See Fig.
E1, E2
Checking the battery charge
condition
NOTE: Fig. E3 only applies for the
battery pack with battery indicator
light.
See Fig. E3
Charging the battery pack
NOTE:
•The batteries are shipped
uncharged. Each battery must be
fully charged before the first use.
• Always fully charge the two
batteries at same time. More details
can be found in charger’s manual.
See Fig. E4
Battery power indicator on the
machine
See details in BATTERY STATUS
section
See Fig. E5
Operation
To start
WARNING! The cutting head
continues to rotate after the
trimmer has been switched off; wait
until it has completely stopped then
lay down the tool.
Press the lock-off button first, then
press the switch trigger to start the
machine.
See Fig. F

Cordless Grass Line Trimmer &
Brushcutter, Attachment-Capable
20
EN
ECO Speed
For longer run time, press the ECO
button and switch trigger, then your
machine will operate at a low speed.
See Fig. G
Trimming See Fig. H
Bump feed See Fig. I
Assembling and removing the
trimmer head
Insert the hex key into the hole and
rotate the trimmer head until it stops
in a locked position.Then, rotate
counterclockwise to remove it, and
clockwise to assemble it.
See Fig. J
Winding the trimmer line
NOTE: The spool must be wound
while inside the trimmer head. The
spool cannot be wound with line,
then installed into the trimmer head.
See Fig. K
Assembling the brush cutter blade
Remove the trimmer head and the
skirt before assembling the brush
cutter blade.
Insert the hex key into the hole.
Place the brush-cutter blade on top
of the spacer, place washer on top of
the brush-cutter blade, place blade
housing over washer. After that, use
the wrench to tighten the lock-nut.
See Fig. L1,
L2, L3
Cutting See Fig. M
ATTACHMENT-CAPABLE ACCESSORIES
The below attachment accessories are sold
separately to convert the grass trimmer into a tool
for various applications.
1. Pole hedge trimmer attachment (WA0220)
This attachment is intended for cutting and
trimming hedges and bushes in domestic use.
2. Pole saw attachment (WA0222)
This attachment is intended for sawing of trees,
tree trunks, branches, limbs, etc. Cuts can be
sawed with or across the grain.This product is
not suitable for sawing mineral materials.
3. Edger attachment (WA0223)
This attachment is intended for edging around
walkways, driveways, flower beds, etc.
BATTERY STATUS (See Fig. E5)
Before starting or after use, press the button beside
the power indicator light on the machine to check
the battery capacity. During operation, the battery
capacity will be indicated automatically by the battery
power indicator.
The indicator constantly senses and displays the
battery condition as follows.
For the machine with 2 battery packs with different
power, the power indicator light displays the battery
condition with the lower one of the two batteries.
Battery power
indicator status Battery condition
Five green lights
( ) are
illuminated.
The two batteries are in a
highly charged condition.
Two, three or four
green lights are
illuminated.
The two batteries have a
remaining charge.The more
lights are illuminated, the
more battery capacity.
Only one green light
( ) is
illuminated.
At least one battery is
almost depleted and needs
to be charged.
No light is
illuminated. At least one battery is not fully installed or battery may
be defective.
Only one light is
flashing twice per
cycle.
At least one battery is
over discharged (please
refer to the battery charge
condition), please recharge
the two batteries at once
before use again or storage.
Only one light is
flashing three times
per cycle.
At least one battery is hot,
wait for them cool down
before start again.
Only one light is
flashing four times
per cycle.
The machine is over load.
Raise the cutting height or
push slowly.
OPERATION INSTRUCTIONS
WARNING! The charger and battery pack
are specially designed to work together so do
not attempt to use any other devices. Never insert or
allow metallic objects into your charger or battery
pack connections because of an electrical failure and
hazard will occur.
1. Bump-line feed system (See Fig. I)
The trimmer is equipped with a bump-line system.
Just bump the trimmer head while the machine is
running, new line will feed out.
2. Winding the trimmer line (See Fig. K)
Insert the replacement line through the eyelet and feed it
through the other side. Ensure both ends of the line are
even on each end of the trimmer head (max 3m) and cut
the line.Turn the dial clockwise to wind the line around the
spool until about 19cm remains on either side.
