Woxcon TPU4120 User manual

TPU4120
4K HDMI Extender w/IR &RS232
All Rights Reserved
Version: TPU4120_2017V1.0
User Manual

4K HDMI Extender w/IR &RS232
1
Statement
Read this user manual carefully before using the product. Pictures are shown in this manual for
reference only, different models and specifications are subject to real product.
This manual is only for operation instruction, please contact the local distributor for maintenance
assistance. The functions described in this version were updated till December 21, 2017. In the constant
effort to improve the product, we reserve the right to make functions or parameters changes without
notice or obligation. Please refer to the dealers for the latest details.
Safety Precaution
To insure the bes t f rom t he pr od uct, pleas e read al l i ns t ruction s caref ull y bef ore us i n g t he dev i c e. S av e
this manual for further reference.
l Follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
l Do not dismantle the housing or modify the module to avoid electrical shock or burn.
l Using supplies or parts not meeting the products’ specifications may cause damage, deterioration or
malfunction.
l Do not expose the unit to rain, moisture or install this product near water.
l Install the device in a place with fine ventilation.
l Do not twist or pull by force ends of the CAT5e/CAT6a cable. It can cause malfunction.
l Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before
cleaning.
l Unplug the power cord when left unused for a long period of time.
l Refer all servicing to qualified service personnel.
Customer Service
We provide limited warranty for the product within three years.
For more details, please contact your distributor.
Introduction
This TPU4120 is an HDBaseT Extender set consist of transmitter (TX) and receiver (RX). It distributes
HDMI signal via CAT5e/CAT6a cable at 70m/PoC, and enables IR and RS232 pass-through to control
local source device from remote or far-end display.

4K HDMI Extender w/IR &RS232
2
Features
l Supports HDMI1.4 & HDCP2.2.
l Maximum transmission distance is up to 40m for 4Kx2K, and 70m for 1080p.
l Supports bi-directional 5V IR and RS232 pass-through for long-distance control.
l Supports bi-directional PoC for simplified wiring.
l Supports CEC.
l Features DIP switcher for choosing Control or Update mode.
Package List
l 1 x Transmitter (TX)
l 1 x Receiver (RX)
l 2 x TX Mounting Ears with 2 Screws
l 2 x RX Mounting Ears with 2 Screws
l 4 x TX Plastic Cushions
l 4 x RX Plastic Cushions
l 1 x Power Adaptor (12VDC, 1A)
l 1 x User Manual
Panel Description
No.
Name
Description
①
Power LED
Illuminates red when power is applied.
②
RS232
Euroblock/Phoenix connector for connecting an RS232 data device.
③
HDMI IN (TX)
HDMI port for connecting the video source device (e.g. Blu-ray DVD)
HDMI OUT (RX)
HDMI port for connecting the video display.
④
CTRL/UPDATE
Switch for determining the behavior of the RS232 connection.
When in the CTRL position, it serves as an RS232 serial extender.
When in the UPDATE position, it allows you to update the Valens IC
program by connecting to a PC and running the batch file.
⑤
HDBT OUT (TX)
RJ45 jack for connecting the Cat5e/6 cable to the Receiver.
HDBT IN (RX)
RJ45 jack for connecting the Cat5e/6 cable to the Transmitter.
⑥
IR IN
3.5mm jack for connecting an IR Receiver (not included).
⑦
IR OUT
3.5mm jack for connecting an IR Emitter (not included).
⑧
DC 12V
DC barrel connector for connecting the included AC power adaptor.
Tx Rx
LINKHDCP
12345678
Front Rear

4K HDMI Extender w/IR &RS232
3
Specification
Model
Spec
Transmitter (TX)
Receiver (RX)
Input
HDMI IN
HDBT IN
Output
HDBT OUT
HDMI OUT
Control
IR IN, IR OUT, RS232
IR IN, IR OUT, RS232
General
Maximum Video Resolution
4K×2K@60Hz 4:2:0, including 1080p@60Hz
Transmission Mode
HDBaseT
Transmission Distance
1080p signal to 70m, 4K signal to 40m
Bandwidth
10.2Gbps
Video Standard
HDMI1.4 with HDCP2.2
Power Consumption
10 watts
Operating Temperature
0 ~ +40℃
Storage Temperature
-10 ~ +55℃
Operating Humidity
0% ~ 90%
Power Supply
Input Power: 12VDC 1A or Power over Cable (PoC);
AC Adaptor Input Power: 100~240VAC, 50/60Hz
Dimension (W*H*D)
106mm x 16mm x 84mm
Net Weight (g)
250g
System Diagram
Note: This picture is for reference only, the specific scheme is subject to real devices.
Blu-Ray DVD Projector
IR
Receiver
Blu-Ray Remote
IR
Emitter
Laptop
IR
Emitter
IR
Receiver
Projector
Remote
IR:
HDMI:
HDBaseT:
RS232:
1080P 70m
4K@60Hz 4:2:0 40m
