Woxcon TPUH422 User manual

TPUH422
Ultra-thin HDBaseT Extender
All Rights Reserved
Version: TPUH422_2017V1.2
User Manual

Ultra-thin HDBaseT Extender
Preface
Read this user manual carefully before using this product. Pictures shown in this
manual is for reference only, different model and specifications are subject to real
product.
This manual is only for operation instruction only, not for any maintenance usage. The
functions described in this version are updated till July 11, 2017. Any changes of
functions and parameters since then will be informed separately. Please refer to the
dealers for the latest details.
FCC Statement
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. It has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a commercial
installation.
Operation of this equipment in a residential area is likely to cause interference, in which
case the user at their own expense will be required to take whatever measures may be
necessary to correct the interference
Any changes or modifications not expressly approved by the manufacture would void
the user’s authority to operate the equipment.

Ultra-thin HDBaseT Extender
SAFETY PRECAUTIONS
To i n s u r e t h e best from the product , p l e a s e read all instr u c t i o n s carefully before u s i n g
the device. Save this manual for further reference.
l Unpack the equipment carefully and save the original box and packing material for
possible future shipment
l Follow basic safety precautions to reduce the risk of fire, electrical shock and injury
to persons.
l Do not dismantle the housing or modify the module. It may result in electrical shock
or burn.
l Using supplies or parts not meeting the products’ specifications may cause
damage, deterioration or malfunction.
l Refer all servicing to qualified service personnel.
l To prev e n t f i re or shock hazard, d o n o t e x p o s e the unit to rai n , m o i s ture or install
this product near water.
l Do not put any heavy items on the extension cable in case of extrusion.
l Do not remove the housing of the device as opening or removing housing may
expose you to dangerous voltage or other hazards.
l Install the device in a place with fine ventilation to avoid damage caused by
overheat.
l Keep the module away from liquids.
l Spillage into the housing may result in fire, electrical shock, or equipment damage.
If an object or liquid falls or spills on to the housing, unplug the module immediately.
l Do not twist or pull by force ends of the optical cable. It can cause malfunction.
l Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to
the device before cleaning.
l Unplug the power cord when left unused for a long period of time.
l Information on disposal for scrapped devices: do not burn or mix with general
household waste, please treat them as normal electrical wastes.

Ultra-thin HDBaseT Extender
Contents
1. Introduction .................................................................................................................. 1
1.1 Introduction to TPUH422 .................................................................................... 1
1.2 Feature ............................................................................................................... 1
1.3 Package Content ................................................................................................ 1
2. Panel Description ........................................................................................................ 2
2.1 TPUH422 Transmitter ......................................................................................... 2
2.2 TPUH422R Receiver .......................................................................................... 3
2.3 Twisted Pair Cable Description .......................................................................... 4
3. System Connection ..................................................................................................... 5
3.1 Usage Precautions ............................................................................................. 5
3.2 System Diagram ................................................................................................. 5
3.3 Connection Procedure ........................................................................................ 5
4. Specification ................................................................................................................ 7
5. Panel Drawing ............................................................................................................. 9
6. Troubleshooting & Maintenance ................................................................................ 10
7. After-sales Service ..................................................................................................... 11

Ultra-thin HDBaseT Extender
1
1. Introduction
1.1 Introduction to TPUH422
The TPUH422 is an ultra-thin HDBaseT Extender set consist of TPUH422T Transmitter
and TPUH422R Receiver.
It distributes HDMI signal via CAT5e/CAT6a cable at 100m/PoH, and enables IR and
RS232 pass-through to control remote displays. It also supports 4 Ethernet interface for
network.
It provides a perfect long range transmission solution.
1.2 Feature
l Ultra-thin design.
l The highest resolution is 4Kx2k@60Hz
l HDCP2.2 compliant.
l Maximum transmission distance is up to 70m for 4Kx2K
l Maximum transmission distance is up to 100m for 1080p
l Maximum extension distance is up to 100m for Ethernet.
l Support bi-directional PoH
l High bandwidth：10.2Gbps
l Support IR/RS232 pass-through.
l LED indicators show work status.
1.3 Package Content
Transmitter
l 1 x TPUH422 Transmitter
l 2 x Mounting Ears with 2 Screws
l 4 x Plastic Cushions
l 1 x RS232 Cable
l 1 x Power Adapter (DC 24V 1.25A)
Receiver
l 1 x TPUH422R Receiver
l 2 x Mounting Ears with 2 Screws
l 4 x Plastic Cushions
l 1 x RS232 Cable
l 1 x User Manual

Ultra-thin HDBaseT Extender
2
2. Panel Description
2.1 TPUH422 Transmitter
No.
Name
Description
①
LINK
HDBT Link status indicator:
l OFF: No Link
l GREEN:Link Successful
l Blinking GREEN: Link abnormal
②
HDCP
HDCP compliant indicator
l OFF: No HDMI traffic (no picture)
l GREEN: Traffic with HDCP.
l Blinking GREEN: Traffic without HDCP
③
Power
OFF: No power; RED: DC power present.
④
RS232
RS232 connector.
⑤
IR IN
Connect with 5V IR receiver (with carrier) to collect infrared
signal, work with far-end IR OUT port
⑥
IR OUT
Connect with 5V IR Emitter to send infrared signal, work with
far-end IR IN port
⑦
HDMI IN
Connect with HDMI source
⑧
HDBT OUT
Connect to the HDBT IN socket on the receiver via CAT5e/
CAT6a cable, support bi-directional PoH.
⑨
ETHERNET
100M Ethernet interface, when need to work in a LAN, one of
these 4 ports (both the Ethernet ports of transmitter and
receiver) should be used for internet access, and the others can
be connected with computers. If they are well connected, the
⑩
ETHERNET
RXTX
HDCPLINK
TX

Ultra-thin HDBaseT Extender
3
yellow LED indicators on the corresponding ports will keep blink
and the green ones will keep on when working.
⑪
DC 24V
Connect with DC24V 1.25A power adaptor. (Not necessary if
receiver connects with power).
2.2 TPUH422R Receiver
No.
Name
Description
①
LINK
HDBT Link status indicator:
l OFF: No Link
l GREEN:Link Successful
l Blinking GREEN: Link abnormal
②
HDCP
HDCP compliant indicator
l OFF: No HDMI traffic (no picture)
l GREEN: Traffic with HDCP.
l Blinking GREEN: Traffic without HDCP
③
Power
OFF: No power; RED: DC power present.
④
RS232
RS232 connector.
⑤
IR IN
Connect with 5V IR receiver (with carrier) to collect infrared signal,
work with far-end IR OUT port
⑥
IR OUT
Connect with 5V IR Emitter to send infrared signal, work with far-
end IR IN port
⑦
HDMI OUT
Connect with HDMI display
Tx Rx
HDCPLINK
RX

Ultra-thin HDBaseT Extender
4
⑧
HDBT IN
Connect to the HDBT OUT socket on the transmitter via CAT5e/
CAT6a cable.
⑨
ETHERNET
Ethernet ports, when need to work in a LAN, one of these 4 ports
(both the Ethernet ports of transmitter and receiver) should be
used for internet access, and the others can be connected with
computers. If they are well connected, the yellow LED indicators
on the corresponding ports will keep blink and the green ones will
keep on when working.
⑩
ETHERNET
⑪
DC 24V
Connect with DC24V 1.25A power adaptor (Not necessary if
transmitter connects with power).
2.3 Twisted Pair Cable Description
The twisted pair used in this extender MUST be a straight-through cable.
Notice: Cable connectors
MUST be metal one, the
shielded layer of cable
MUST be connected to the
connector’s metal shell, to
make a better
transmission.
TIA/EIA T568A
TIA/EIA T568B
Pin
Cable color
Pin
Cable color
1
green white
1
orange white
2
green
2
orange
3
orange white
3
green white
4
blue
4
blue
5
blue white
5
blue white
6
orange
6
green
7
brown white
7
brown white
8
brown
8
brown
1st
Ground
4--5
1st
Ground
4--5
2nd
Ground
3--6
2nd
Ground
1--2
3rd
Group
1--2
3rd
Group
3--6
4th
Group
7--8
4th
Group
7--8

Ultra-thin HDBaseT Extender
5
3. System Connection
3.1 Usage Precautions
l System should be installed in a clean environment and has a prop temperature and
humidity.
l All of the power switches, plugs, sockets and power cords should be insulated and
safety.
l All devices should be connected before power on.
l Use shielded straight-thru CAT5e/CAT6a cable with TIA/EIA T568B terminations for
good transmission effect.
3.2 System Diagram
3.3 Connection Procedure
Step1. Connect HDMI source (such as DVD player) to HDMI IN port of the transmitter
with HDMI cable.
Step2. Connect HDBT OUT port of transmitter and HDBT IN port of receiver with single
CAT5e/CAT6a cable.
Step3. Connect HDMI displayer (such as HDTV) to HDMI OUT port of receiver with
HDMI cable.
Step4. Both transmitter and receiver have IR IN and OUT. When one model use for IR
signal receiver, the IR signal must be sent out by the other model.

Ultra-thin HDBaseT Extender
6
For example: When “IR IN” of receiver connects with an IR receiver, the IR
Emitter must be connected to “IR OUT” of transmitter.
Step5. To s et as a LAN, one of t h e f o u r ETHE RN ET p o r t s of transmitter and receiver
should be used for Internet access, and the others can be connected with
computers.
Step6. Connect the RS232 port of the computer and the RS232 port of transmitter or
receiver (any one is able to work as the RS232 signal can be transmitted bi-
directionally) by using a RS232 cable.
Step7. Connect with DC24V power adaptor(s) separately or only connect power
adaptor to transmitter or receiver.

Ultra-thin HDBaseT Extender
7
4. Specification
TPUH422T Transmitter
Input
(1) HDMI; (1) IR; (1) RS232
Input Connector
(1) Female HDMI; (1) 3.5mm mini jack;
(1) 3p captive screw connector
Output
(1) HDBaseT (1) IR; (1) RS232
Output Connector
(1) RJ-45; (1) 3.5mm mini jack; (1) 3p captive screw
connector
Ethernet
(2) Black RJ45, with a dual color indicator(Green &
Yell ow)
Ethernet Transmission
Speed
Adaptive 10M/100M (max), full duplex or half duplex.
TPUH422R Receiver
Input
(1) IR; (1) HDBaseT; (1) RS232
Input Connector
(1) 3.5mm mini jack; (1) RJ-45;
(1) 3p captive screw connector
Output
(1) HDMI; (1) IR; (1) RS232
Output Connector
(1) Female HDMI; (1) 3.5mm mini jack;
(1) 3p captive screw connector
Ethernet
(2) Black RJ45, with a dual color indicator(Green &
Yell ow)
Ethernet Transmission
Speed
Adaptive 10M/100M (max), full duplex or half duplex.
General
Transmission Mode
HDBaseT
Resolution
Up to 4K×2K@60Hz
Transmission Distance
1080P ≤ 100m; 4K×2K ≤ 70m
Bandwidth
10.2Gbps
HDMI Standard
HDMI1.4 & HDCP2.2
Impedance
75Ω
Temperature
0~ 50℃
Humidity
0% ~ 90%
Power Consumption
10W
Power Supply
Input: 100VAC~240VAC, 50/60Hz; Output: 24VDC
1.25A

Ultra-thin HDBaseT Extender
8
Dimension (W*H*D)
152mmx16.2mmx104mm
Net Weight
Transmitter:235g; Receiver: 241g

Ultra-thin HDBaseT Extender
9
5. Panel Drawing
5-1 TPUH422T Transmitter
5-2 TPUH422R Receiver
HDCPLINK
TX
RS232 IR I N IR OU T HD MI I N HD BT O UT ETHERNET ETHERNET DC 2 4V
RXTX
152 mm
16.2 mm
104 mm
HDCPLINK
RX
RX
TX
RS232 IR I N IR OU T HD MI O UT HD BT I N ETHERNET ETHERNET DC 24 V
152 mm
16.2 mm
104 mm

Ultra-thin HDBaseT Extender
10
6. Troubleshooting & Maintenance
Problems
Causes
Solutions
Output image with
white noise.
Incorrect setting on the
display
Check the display’s
setting
A cable of bad quality
Try another high quality
connection cable
No output image when
switching
No signal at the input /
output end
Check with oscilloscope
or multimeter if there is
any signal at the input /
output end.
Fail or loose connection
Make sure the connection
is good
The extender is broken
Send it to authorized
dealer for repairing.
Cannot control the
device by control
device (e.g. a PC)
through RS232 port
Wrong RS232
communication parameters
Make sure the RS232
communication
parameters are correct.
The device has already
been broken
Send it to authorized
dealer for repairing.
Cannot recognize
device connected to
the ETHERNET port
The connected device has
the same IP address with
the extender
Change the IP address of
the extender or the
connected device.
Static becomes
stronger when
connecting the video
connectors
Bad grounding
Check the grounding and
make sure it is connected
well.
Cannot control the
device by RS232 / IR
The device has already
been broken
Send it to authorized
dealer for repairing.
If your problem persists after following the above troubleshooting steps, seek further
help from authorized dealer or our technical support.

Ultra-thin HDBaseT Extender
11
7. After-sales Service
If there appear some problems when running SCU91T, please check and deal with the
problems referring to this user manual. Any transport costs are borne by the users
during the warranty.
1) Product Limited Warranty: This product will be free from defects in materials and
workmanship for three years.
Proof of purchase in the form of a bill of sale or receipted invoice which is evidence
that the unit is within the Warranty period must be presented to obtain warranty
service.
2) What the warranty does not cover:
l Warranty expiration.
l Factory applied serial number has been altered or removed from the product.
l Damage, deterioration or malfunction caused by:
l Normal wear and tear.
l Use of supplies or parts not meeting our specifications.
l No certificate or invoice as the proof of warranty.
l The product model showed on the warranty card does not match with the
model of the product for repairing or had been altered.
l Damage caused by force majeure.
l Servicing not authorized by distributor.
l Any other causes which does not relate to a product defect.
l Delivery, installation or labor charges for installation or setup of the product.
3) Technical Support: Email to our after-sales department or make a call, please
inform us the following information about your cases.
l Product version and name.
l Detailed failure situations.
l The formation of the cases.
Remarks: For any questions or problems, please try to get help from your local
distributor.
