PRO SIGNAL PSG3308 User manual

PSG3308
HDMI H.264 WIRELESS EXTENDER
1

WHAT’s IN THE BOX
OVERVIEW
IMPORTANT SAFETY INFORMATION
INSTALLATION
• HDMI extender using standard Ethernet TCP/IP protocol, through wireless WIFI signal
transmits HD audio and video signal simultaneously, with infrared remote control for
added convenience.
• HDMI video and audio transmission range via WIFI, up to 100 meters depending on
objects in the signal path and other forms of interference.
• HDMI WIFI Transmitter
• HDMI WIFI Receiver
• PSU x 2
• IR-TX Transmitter
• IR-RX Receiver
• User Manual
Please read these instructions carefully before use and retain for future reference.
• Connect the signal source equipment to the input port of the transmitter using a
quality HDMI cable. Max 5m long for 1920x1080p HD resolution.
• An HDTV can be connected directly to the transmitter using an HDMI cable between
the output ports of the transmitter and the HDTV.
• Plug the IR-TX extender into the IR-TX port of the transmitter. Direct the extender
head towards the remote control sensor on the source device.
• Connect the PSU to the transmitter and connect to the mains supply.
• Connect an HDTV to the receiver output port using a quality HDMI cable. Max 5m
long for 1920x1080p HD resolution.
• Plug the IR-RX extender into the IR-RX port of the receiver. Direct the sender head
such that it can receive signals from the remote control for your source device.
• Connect the PSU to the receiver and connect to the mains supply.
• Power on the signal source and the display HDTVs.
• When using electrical appliances basic safety precautions should always be followed.
• Check that the voltage indicated on the rating plate corresponds with that of the local
network before connecting the power supply to the mains power supply.
Transmitter Panel Connections
2

• HDMI 1.3 compatible.
• Complies with standard HDCP 1.2 high-bandwidth digital content protection
technology.
• HD video signal resolution up to 1920x1080@60Hz.
• Supports transmitter with HDMI passthrough.
• H.264 format is used to compress and decompress the signal to effectively improve
the transfer rate to ensure smooth playback.
• Support use of source device remote control when viewing from an out of sight
location.
• Automatically identies and congures a variety of display modes.
• Built-in automatic stability system, for a clear and stable picture.
• Built-in electrostatic discharge protection circuit, offers comprehensive secure
protection.
• Simple and convenient plug and play installation, no setting up required.
FEATURES
Receiver Panel Connections
3
MAINTENANCE
• Clean the outside casing with a soft cloth lightly moistened with mild soap and water.
Never use any abrasive or solvents.
• Do not allow moisture to enter the casing.

INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF ELECTRICAL &
ELECTRONIC EQUIPMENT.
When this product has reached the end of its life it must be treated as Waste Electrical & Electronic
Equipment (WEEE). Any WEEE marked products must not be mixed with general household waste,
but kept separate for the treatment, recovery and recycling of the materials used. Contact your local
authority for details of recycling schemes in your area.
Made in China. PR2 9PP
Man Rev 1.0
SPECIFICATIONS
Parameter Description
Video
Standards HDMI 1.3, HDCP 1.2
Compression H.264
Max pixel clock 165MHz
Max Data Rate 6.75Gbps
Max Resolution 1920 x 1080p@60Hz
Impedance 100ohm
IR
Interface 3.5mm jack
Direction Unidirectional
Signal Digital
Frequency 20-60kHz
WIFI
Power 13dbm
Standard 8 02 .11ac
Direction Unidirectional
Frequency 5.8GHz
Range Up to 100m
Power Voltage 5V DC
Amperage 1.5A
Operating Conditions -5oC to +70oC
Operating Humidity 5% to 90% RH (no condensation)
Dimensions (W x D x H) 100 x 100 x 25mm (each unit)
4
