WRIGHT SVC-SWI-0014 User manual

Wright Manufacturing, Inc.
Work Inst. Name: Curved Baffle Style Mulch Kit
Instructions- 2 Blade Decks
Inst. Number: SVC-SWI-0014
Revision: 01
Issue Date: N/A
Author: Chris Sturtz
Date: 2/26/15
Reviewer: Chris Sturtz
Date: 2/26/15
Approver: Chris Sturtz
Date: 2/26/15
32”, 36”, 42” One Piece (2 Bladed) Mulch Kit Instructions
Curved Baffle Style Kit
Hardware 32” – 4ea. 3/8 x ¾ Flange Bolts
4ea. 3/8 Lock Flange Nuts
Hardware 36” – 4ea. 3/8 x ¾ Flange Bolts
4ea. 3/8 Lock Flange Nuts
Hardware 42” – 5ea. 3/8 x ¾ Flange Bolts
5ea. 3/8 Lock Flange Nuts
*NOTE: The Mulching kits are designed to function optimally with no less than 4-
blade washers.
1) Raise and secure machine.
2) Make sure to use all safety precautions.
3) Clean bottom of deck thoroughly.
4) For easier installation blades should be in horizontal position.
5) Put mulch baffle into place and mark holes. (Two people will make installation much
easier. One to hold part up to deck and the other to mark the holes. On newer model
units holes are pre-punched from the factory)
6) Using 25/64-drill bit, drill marked holes.
7) Install baffle and tighten. (Fig. 1) (Rotate blades by hand to make sure they do not hit
mulch kit baffle –adjust baffle if necessary).

DECK SIZE Reg. 5" deck ALL MODELS
32 Curved baffle style 95480003
36 Curved baffle style 95470002
42 Curved baffle style 95480002
** Block-Off kit onlyfor discharge chute is part number 93460031 and applies to all models w/ 5" decks.
Wright Mulch Kits

Revision Table
Name
Date
Reason for Changes
Version
Ed Wright
N/A
Initial Release
00
Chris Sturtz
2/26/15
Format Update
01
