Wyrestorm SP-0104-H2 User manual

1x4 / 1x8 4K HDMI 2.0 Splitter with HDCP 2.2
SP-0104-H2 | SP-0108-H2 v2 Quickstart Guide
In the Box
1x SP-0104-H2 or SP-0108-H2 Splitter
SP-0104-H2: 1x 12V DC 1A Power Supply
SP-0108-H2: 1x 12V DC 1.5A Power Supply
1x 3-pin Screw Down Phoenix Connector
2x Mounting Brackets
1x Quickstart Guide
Basic Wiring Diagram
KEY
HDMI
Power SP-0104-H2:
12V DC 1A
SP-0108-H2:
12V DC 1.5A
Power Supply
UHD Display
UHD Display UHD Display
UHD Display
HDMI to
display
HDMI to
display
UHD Source
HDMI to
display
IMPORTANT!
Disconnecting and connecting (hot plugging) HDMI or HDBaseT while devices
are powered on may cause damage. WyreStorm recommends powering off
devices before disconnecting these connections.
Additional Information
This Quickstart Guide provides the basic steps for the common uses of this
product. Refer to the Installation Guide and other documentation on the
product page for additional information.
Before Beginning
• WyreStorm recommends visiting the product page before installing this
product for updates to this Quickstart Guide as well as other information
about the product.
• Verify that all items are included in the packaging per the In the Box list.
Installation
1. Connect an HDMI source to the HDMI In on the splitter using an HDMI
cable from a high quality brand such as WyreStorm Express.
2. Connect HDTV displays to Output 1 using an HDMI cable from a high
quality brand such as WyreStorm Express.
3. Repeat step 2 for additional displays or additional splitters.
4. Connect the included 12V DC 1A power supply to the DC 12V jack.
5. Congure EDIDs per the EDID Settings section.
Copyright © 2015 WyreStorm Technologies | wyrestorm.com
SP-0104-H2 | SP-0108-H2 v2 Quickstart Guide | 161213
North America: 518-289-1294 | EMEA/ROW: 44 (0) 1793 230 343
[email protected]
1 of 4
WyreStorm recommends reading through this document in its entirety to become familiar with the product’s features prior to starting the
installation process.
Pure HDMI 1x4 or 1x8 splitter with support for full 4K resolutions and HDCP 2.2.
Note: The following information applies to version 2 of this product as identied by v2 after the model number on the product label.

Front Panel
Rear Panel
Input LED Solid: HDMI source is connected and powered On.
Off: HDMI source is not connected or is powered Off.
Output LEDs
SP-0104-H2: 1-4 | SP-0108-H2: 1-8
Solid: Display is connected and powered On.
Off: Display is not connected or is powered Off.
Power LED Solid: The splitter is powered On
Off: The splitter is powered Off
Power In
5.5mm Male Barrel Jack
Connect to the included 100~240V AC 50/60Hz power supply.
SP-0104-H2: 12V DC 1A | SP-0108-H2: 12V DC 1.5A
HDMI Outputs
19-pin type A HDMI female:
SP-0104-H2: 1-4 | SP-0108-H2: 1-8
Supports HDMI and DVI/D (requires adapter-not included). Limited to 600MHz pixel clock.
Input 19-pin type A HDMI female:
Supports HDMI and DVI/D (requires adapter-not included). Limited to 600MHz pixel clock.
EDID
Rotary Dial
Used to set EDIDs to correct resolution conflicts between the source and the display.
See EDID Settings.
RS-232 3-pin Screw Down Phoenix Connector
Used to update rmware on the SP-0104-H2. See RS-232 Wiring.
Copyright © 2015 WyreStorm Technologies | wyrestorm.com
SP-0104-H2 | SP-0108-H2 v2 Quickstart Guide | 161213
North America: 518-289-1294 | EMEA/ROW: 44 (0) 1793 230 343
[email protected]
2 of 4

HDMI Wiring
IMPORTANT! Wiring Guidelines
• The use of patch panels, wall plates, cable extenders, kinks in cables,
and electrical or environmental interference can have an adverse effect
on HDMI transmission limiting performance. Steps should be taken to
minimize these factors (or remove completely) during installation for best
results.
• WyreStorm recommends using HDMI cables from a high quality brand
such as WyreStorm Express.
• Active HDMI cables or extenders must be used for distances greater than
10m between the splitter and connected devices in order to maintain the
highest level of video performance.
RS-232 Wiring
RS-232 Connection Guidelines
The following wiring diagram shows the pinouts for the extender set. While
not shown, connect the TX (transmit) to RX (receive) pins at the control
system or PC side of the cable.
Most control systems and computers are DTE where pin 2 is RX, this can vary
from device to device. Refer to the documentation for the connected device
for pin functionally to ensure that the correct connections can be made.
Wire colors shown follow EIA-561 standard.
Pin 1:
Pin 2:
TX (Transmit)
RX (Receive)
Pin 3: Ground (GND)
1 2 3
EDID Settings
EDIDs can be congured to resolve issues with video output on displays that
may not accept the maximum resolution available from the source.
Note:
• Ensure that a display is connected and powered On to the selected output
before copying EDIDs or the copy will fail. When this occurs, EDID will be
set to 1080p 2ch.
• Power to the matrix must be cycled (Off/On) after changing dip switches in
order for the setting to take effect.
Position Video Resolution and Audio
0Copy EDID from HDMI output1 (default setting)
1 1080i 2ch
21080i Dolby/DTS 5.1ch
3 1080i, HD Audio
4 1080p 2ch
51080p Dolby/DTS 5.1ch
6 1080p HD Audio
73D 2ch
83D Dolby/DTS 5.1ch
9 3D HD Audio
A 1280x1024 DVI
B 1920x1080 DVI
C 1920x1200 DVI
D 4K@30HZ 2ch
E4K@60HZ 2ch
FCopy EDID from HDMI output2
Copyright © 2015 WyreStorm Technologies | wyrestorm.com
SP-0104-H2 | SP-0108-H2 v2 Quickstart Guide | 161213
North America: 518-289-1294 | EMEA/ROW: 44 (0) 1793 230 343
[email protected]
3 of 4

Warranty Information
This product is covered by a 2 year limited parts and labor warranty. During this period there will be no charge for unit
repair, component replacement or complete product replacement in the event of malfunction. The decision to repair
or replace will be made by the manufacturer. This limited warranty only covers defects in materials or workmanship
and excludes normal wear and tear or cosmetic damage. Visit the product page located at wyrestorm.com for
additional information on this product including important technical information not provided in this document and
warranty terms & conditions.
Copyright © 2015 WyreStorm Technologies | wyrestorm.com
SP-0104-H2 | SP-0108-H2 v2 Quickstart Guide | 161213
North America: 518-289-1294 | EMEA/ROW: 44 (0) 1793 230 343
[email protected]
4 of 4
Specications
Power
Power Supply
Input: 100~240V AC 50/60Hz
SP-0104-H2: 12V DC 1A
SP-0108-H2: 12V DC 1.5A
Max Power Consumption SP-0104-H2: 4W | SP-0108-H2: 6W
Environmental
Operating Temperature 32°F ~ 113°F (0°C ~ 45°C)
10% ~ 90%, non-condensing
Storage Temperature -4°F ~ 158°F (-20°C ~ +70°C)
10% ~ 90%, non-condensing
Maximum BTU SP-0104-H2: 13.64 BTU/hr
SP-0108-H2: 20.47 BTU/hr
Dimensions and Weight
SP-0104-H2 SP-0108-H2
Rack Units 0.4U 0.4U
Height 18mm/0.8in 18mm/0.8in
Width 167.2mm/6.59in 257.2mm/10.13in
Depth 69.7mm/2.75in 89.7mm/3.54in
Weight 0.32kg/0.7lbs 0.58kg/1.28lbs
Regulatory
Safety and Emission CE | FCC
Audio and Video
Inputs 1x HDMI 19-pin type A
Outputs SP-0104-H2: 4x HDMI 19-pin type A | SP-0108-H2: 8x HDMI 19-pin type A
Audio Formats 2ch PCM | Up to DTS-X and Dolby Atmos
Video Resolutions (Max)
HDMI
1920x1080p @60Hz 12bit (15m/49.2ft) | 16bit (15m/49.2ft)
3840x2160p @30Hz 4:4:4 8bit (15m/49.2ft) | @24Hz 4:2:0 HDR 10bit (15m/49.2ft)
4096x2160p @60Hz 8bit 4:2:0 (15m/49.2ft) | @60Hz 8bit 4:4:4 (3m/9.8ft)
Color Depth 1080p: 48bit | 4K UHD: 24bit | HDR @24p: 10bit BT.2020
Maximum Pixel Clock HDMI: 600mHz
Communication and Control
HDMI HDMI 2.0 | HDCP 2.2 | Congurable EDID | DVI/D supported with adapter (not included)
RS-232 1x RS-232 3-pin Phoenix Connector
Troubleshooting
No or Poor Quality Picture (snow or noisy image)
• Verify that power is being supplied to the splitter, sources, and display
devices.
• Verify that the splitter supports the output resolution of the source.
• Verify that the splitter and display devices support the output
resolution of the source.
• Congure EDID Settings to a lower resolution.
• If transmitting 3D or 4K, verify that the HDMI cables used are 3D or 4K
rated.
• Verify that all source and HDBaseT connections are not loose and are
functioning properly.
Troubleshooting Tips:
• WyreStorm recommends using a cable tester or connecting the cable
to other devices to verify functionality.
