WyreStorm recommends reading through this document in its entirety to become familiar with the product’s features before beginning the
installation process.
WyreStorm Essentials 1080p Plug-and-Play Video Conference
Kit with PTZ Camera, Speaker and Microphone
EXP-VC-KIT Quickstart Guide
IMPORTANT! Installation Requirements
• Read through the Wiring and Connections section for important wiring
guidelines before creating or choosing premade cables.
•Visit the product page to download the latest firmware, document
version, additional documentation, and configuration tools.
In the Box
1x EXP-VC-KIT-C 1080p Camera
1x EXP-VC-KIT-H Hub
1x EXP-VC-KIT-A Speakerphone
2x 10m 6-Pin DIN Data Cables
1x 12v DC 1.5A Power Supply
1x IR Remote
1x 3m USB 2.0 Cable
1x Quickstart Guide (This Document)
IP Settings
Default IP Address 192.168.11.143
Web UI Port 80
Communication Settings
The EXP-VC-KIT Camera contains a web UI that can be accessed by
connecting to a network and entering the IP address. We recommend that
the IP address is changed from default after accessing the web UI for the
first time.
The camera also supports the standardized VISCA control protocol for
issuing commands via a 3rd-party control system. See the full EXP-VC-
KIT API document for additional control details.
The speakerphone contains 3 custom preset buttons that are used to
program PTZ settings to quickly recall. To save a custom preset simply
adjust the camera manually to the desired position and hold any of the 3
preset buttons for a minimum of 5 seconds.
Basic Wiring Diagram
VISCA Port 1259

Copyright © 2020 WyreStorm Technologies | wyrestorm.com
EXP-VC-KIT Quickstart Guide | 200605
UK: [phone] | ROW: 844.280.WYRE (9973)
[email protected]
2 of 4
Troubleshooting
No Hub Connection to PC Camera Not Streaming Video on the Network
•Verify that the Hub has a mains connection and that the
power switch is turned on
•Avoid using a USB 3.0 connection on your PC. If
possible, move USB connection to a USB 2.0 port.
•The answer/end call buttons are designed to work with
a Bluetooth connection from a mobile device.
Conference software is not compatible with these
buttons due to varying commands between platform.
Answer/End Call Buttons Not Working
•Ensure the camera and the decoding software are on the same network.
•If using RTP Multicast, make sure the network switch being used is
configured to handle Multicast traffic properly.
•Double check the configuration settings in the camera's web UI to make
sure the protocol being used has been setup properly.
EXP-VC-KIT-C

Copyright © 2020 WyreStorm Technologies | wyrestorm.com
EXP-VC-KIT Quickstart Guide | 200605
UK: [phone] | ROW: 844.280.WYRE (9973)
[e-mail]
3 of 4
Specications
EXP-VC-KIT-C
Sensor 1/2.8 inch high quality HD CMOS sensor
Effective Pixels 2.07M, 16:9
Lens 5x optical zoom, 10x digital zoom, f=3.1~15.5mm
Viewing Angle 83.7 (wide), 20.9 (tele)
Aperature F1.8 - F2.8
Illumination 0.5 Lux (F1.8, AGC ON)
Connections 1x 6-Pin DIN (for connection to Hub) | 1x 8-Pin RJ45 (for network streaming)
White Balance Auto | Manual - 3000K, 3500K, 4000K, 4500K, 5000K, 5500K, 6000K, 6500K, 7000K
SNR >55dB
EXP-VC-KIT-A
Microphone
Acoustic Echo Cancellation (AEC) >65dB
Echo length cancellation: >400ms
Bidirectional noise compression (NC): <25dB
Intelligent Directional Technology
Automatic gain control
Frequency Response: 100Hz - 22KHz
Sound pick-up diameter: 6 meters | 10 meters with EXP-VC-KIT-MIC (Sold Separately)
Speaker
Frequency response: 100Hz - 22KHz
Max output: 95dB
Bluetooth Bluetooth 4.0
IR Angle: 360 degrees | Distance: 10m
Dimensions 200mm x 200mm x 55.9mm (LxWxH)
EXP-VC-KIT-H
Connections 2x 6-Pin DIN (for camera and speakerphone) | 1x Mini USB (for connection to PC)
OS Compatibility Windows, MacOS, Linux
Power 12V 1.5A DC
Dimensions 100mm x 62mm x 27mm (LxWxH)
Regulatory
Safety and Emission CE | FCC | RoHS
Rotation Angle Pan: -125 degrees ~ +125 degrees, Tilt: -30 degrees ~ +30 degrees
Rotation Speed Pan: 0.1 ~ 65 degree/sec, Tilt: 0.1 ~ 35 degree/sec
Dimensions 151.64mm x 131.25mm x 154.5 mm (LxWxH)
Output Encoding Network: H.264 | Protocol: RTP Multicast, RTSP, RTMP, HTTP
Weight 0.83Kg | 1.84lbs
Weight 1.10Kg | 2.43lbs
Video Resolutions (Max) 640x480 ~ 1920x1080 (5,10,15,20,25,30 FPS)
Connections 1x 6-Pin DIN (for connection to Hub) | 2x 4-Pin RJ11 (for EXP-VC-KIT-MIC)
Note: WyreStorm reserves the right to change specification, appearance or dimensions of the product at any time without prior notice.
Warranty Information
WyreStorm Technologies LLC warrants that its products to be free from defects in material and workmanship under normal use for a
period of two (2) years from the date of purchase. Refer to the Product Warranty page on wyrestorm.com for more details on our limited
product warranty.
