WyreStorm Essentials 4K HDR 4x1 HDMI Switcher with
Auto-Switching, HDCP 2.2 & Remote
EXP-SW-0401-H2
IMPORTANT! Installation Requirements
• Visit the product page to download the latest rmware, document version,
additional documentation, and conguration tools.
• Read through the Wiring and Connections section for important guidelines
before creating or choosing premade cables.
In The Box
1x EXP-SW-0401-H2 Switcher
1x 12V DC Power Supply (US/UK/EU/AU)
2x Mounting Brackets
1x IR Remote Control
1 x IR Receiver Cable
Basic Wiring Diagram
WyreStorm recommends reading through this document in its entirety to become familiar with the product’s features prior to starting the installation
process.
Wiring and Connections
WyreStorm recommends that all wiring for the installation is run and terminated prior to making connections to the switcher. Read through this section in its
entirety before running or terminating the wires to ensure proper operation and to avoid damaging equipment.
IMPORTANT! HDMI Wiring Guidelines
• The use of patch panels, wall plates, cable extenders, kinks in cables, and electrical or environmental interference will have an adverse effect on HDMI
transmission limiting performance. Steps should be taken to minimize or remove these factors completely during installation for best results.
• WyreStorm recommends using high quality HDMI cables such as WyreStorm Essentials to ensure the highest content performance available.
Installation and Operation
1. Connect HDMI sources to the HDMI IN ports using a good quality HDMI cable.
2. Connect an HDMI display devices to the HDMI OUT port of the switcher.
Note: The switcher is powered via mains power supply to the unit. WyreStorm recommend using only power adapter supplied.
3. Turn the power on ensuring LED power indicators are fully lit on the front of the switcher. If not, check power cable is rmly connected.
Quickstart Guide
4K Blu-ray Player
Display Device
Streaming Device
Remote
Control
4K Satellite Box
Games Console
KEY
HDMI
Control
Power

Troubleshooting
No or Poor Quality Picture (snow or noisy image)
• Verify that power is being supplied to all devices in the system and that they are powered on.
• Verify that all HDMI connections are not loose and are functioning properly.
• If transmitting 3D or 4K, verify that the HDMI cables used are 4K rated.
Troubleshooting Tips:
• WyreStorm recommends using a cable tester or connecting the cable to other devices to verify functionality.
Specications
Note: WyreStorm reserves the right to change product specication, appearance or dimensions of this product at any time without prior notice.
Audio and Video
Inputs 4x HDMI In: 19-pin type A
Outputs 1x HDMI Out: 19-pin type A
Video Encoding HDMI | TMDS
Encoding Data Rate NA
End to End Latency NA
Audio Formats 2ch PCM | Multichannel: LPCM and up to DTS-X and Dolby Atmos
Video Resolutions (Max)
Resolution HDMI
1920x1080p @60Hz 16bit
3840x2160p @60Hz 8bit 4:4:4 HDR
4096x2160p @60Hz 12bit 4:2:2 Dolby Vision/HDR10
7m/23ft
3m/12ft
3m/12ft
Supported Standards DCI | RGB | HDR | HDR10 | Dolby Vision | HLG | ALLM | VRR | BT.2020 | BT.2100
Maximum Pixel Clock 600MHz
Color Depth 12bit
Communication and Control
HDMI HDCP 2.2 | EDID | DVI-D supported with adapter (not included)
IR 1x IR Ext. Port
Push Button Front Panel Push Button
Power
Power Supply 12V DC 1A
Max Power Consumption 3.2W
Environmental
Operating Temperature 0 to + 45°C (32 to + 113 °F), 10% to 90%, non-condensing
Storage Temperature -20 to +70°C (-4 to + 158 °F), 10% to 90%, non-condensing
Maximum BTU 10.92 BTU/hr
Dimensions and Weight
Rack Units/Wall Box <1U
Height 16mm/0.62in
Width 175mm/6.9in
Depth 66.2mm/2.6in
Weight 0.25kg/0.55lbs
Regulatory
Safety and Emission CE | FCC | RoHS | EAC | RCM
