X-pole Lyrapole User manual

Instruction

Manual

www.XPOLE.com

Please Read Fully

Before Installation

LEADERS IN POLE & AERIAL FITNESS

Thank you for purchasing an X-POLE LyraPole.

We have spent countless hours researching, designing and

creating it. Designed to satisfy both the poler and aerialist

alike, the LyraPole combines both disciplines to produce a

new type of artistry.

The LyraPole is only designed to work in conjunction with the

X-STAGE range and is not recommended for use with any

other pole manufacturers stage.

We are constantly innovating and looking for ways to improve

our products; if you have constructive feedback on any

X-POLE products, please send it to [email protected].

Prior to installation, remove the

protective foam tubing around the

LyraPole. Do not use a sharp

instrument to do this, as you may

damage the product.

The LyraPole should only be used by a

maximum of two people at one time. If

used by two people they must balance

one another on the LyraPole.

You should select an appropriate space

for your LyraPole, which will be covered on

page four of this manual. Please be aware

that the LyraPole can reach fast speeds

when spinning.

It is mandatory that you check your

LyraPole & X-Stage before use. Regularly

check & maintain your aerial equipment.

Vertical Leisure Ltd, X-POLE International,

X-POLE US Inc., their distributors, sales

persons or any other persons or associated

companies cannot be held responsible for

any damage to property or injury to persons

or third parties during the use of this product.

By removing the LyraPole from its packaging

and/or any use of the product conﬁrms

acceptance of the preceding warning and

the users responsibility in using this product.

Contact any X-Pole ofﬁce for further details.

Welcome

Warnings

All X-Pole products have been UK tested

to meet stringent safety requirements.

LEADERS IN POLE & AERIAL FITNESS

The Lyrapole is fully compatible with both X-STAGE and X-STAGE LITE and is a great way to add a new

dimension to your X-Stage.

Product

A-Pole

Available in

sizes 950mm &

1050mm Diameter

Joint

(45mm Diameter)

950mm

1050mm

1500mm

CAUTION: The LyraPole is designed to work only witht he X-Stage range and you should not attempt to

use it with any other manufacturers products. X-Stage designs & speciﬁcations may vary from drawing

above, LyraPole attachment / installation remains the same.

LEADERS IN POLE & AERIAL FITNESS

Dance Area

To use the LyraPole with the X-Stage &

X-Stage Lite properly and safely, you need

to be able to fully rotate around the pole

with your arms outstretched and NOT be

able to touch/hit anything whilst doing so.

This will require an area greater than the

diameter of the stage itself all around the

stage.

Therefore, the required area should be a

minimum of 5m in diameter.

Before installing your LyraPole, you should check the ceiling height in the location you will be using. The

X-STAGE base and A-Pole will be 1500mm tall. To be able to manoeuvre the LyraPole into place above the

X-STAGE A-Pole, you will require a minimum ceiling height of 2700mm (8' 9" feet).

LyraPole Heights

2.5M

Fig. (1.1)

Fig. (2.1) Fig. (2.2)

X-Stage

CAUTION: The LyraPole is only compatible with an X-Stage 45mm diameter A-Pole and is designed to be

used with the A-Pole only.

Minimum Ceiling Height

3200mm (10'.5") or higher

2700mm (8'9")

X-Stage - Standard Format

320mm (12.6")

Available in sizes

950mm & 1050mm

Diameter

Minimum Ceiling Height

3200mm (10'.5") or higher

2700m (8'9")

X-Stage Lite - Standard Format

110mm (4.3")

Available in sizes

950mm & 1050mm

Diameter

CAUTION: With the X-STAGE on spin mode The LyraPole can spin at high speed, this can be dangerous

and cause injury.

LEADERS IN POLE & AERIAL FITNESS

Inserting LyraPole

‘A’ Pole

LyraPole

Retaining Stud

Weight Plate

Sandbag

Align the X-JOINT on the

bottom of your LyraPole

with the hole in the XSTAGE

A-POLE, so that the hex screw

can be accessed.

Insert the LyraPole to the

A-POLE and check for a snug

ﬁt using the keyway slots on

the X-JOINT and the

corresponding slots on the

inside of the A-POLE.

Using a 6mm hex key, tighten

the X-JOINT until the LyraPole

is securely attached to the

X-STAGE A-POLE. check by

lifting the hoop with sufﬁcent

pressure.

Remove one of the stage

plates and locate the weight

tray retaining caps on either

frame Leg – completely

unscrew the retaining caps

and remove.

Place the weight plate over the

exposed retaining screws and

replace the retaining cap.

Add the desired extra weight

(10kg-30kg per section).

Sandbags are available from

your X-POLE dealer or

standard gym weights are

suitable too.

Replace stage plates, ensuring

you have the spring pins under

the plate unlocked, slide the

stage plate under the central

plate of the stage and

continue until all plates are

back in place. Ensure spring

pins are in locked position.

45mm

Xstage Pole

34mm Hoop tube

Fig. (3.2)

‘A’ Pole

X-Joint

Aligned

Key & U slot

LyraPole

Fig. (3.1) Fig. (3.3)

Fig. (4.1) Fig. (4.2) Fig. (4.3)

Additional stage weights (Highly Recommended)

CLOCKWISE

to TIGHTEN

Gym Weight

LEADERS IN POLE & AERIAL FITNESS

UK & EUROPE

Email: [email protected]

Tel: +44 (0) 208 449 4400

www.x-pole.co.uk

LEADERS IN POLE & AERIAL FITNESS

USA

Email: [email protected]

Tel: +1 888 976 5387

www.xpoleus.com

LEADERS IN POLE & AERIAL FITNESS

Australia

Email: [email protected]

Tel: +61 (0) 2 9589 2645

www.x-pole.com.au

LEADERS IN POLE & AERIAL FITNESS

Asia

Email: [email protected]

Tel: +86 (21) 6236 6090

www.xpolecn.com

LEADERS IN POLE & AERIAL FITNESS

Korea

Email: [email protected]

Tel: +82 (0) 32 277 5882

www.xpolekorea.kr

LEADERS IN POLE & AERIAL FITNESS

New Zealand

Email: [email protected]

Tel: +64 (0) 9 528 0998

www.x-pole.co.nz

Warranty

This product has been manufactured and tested to the highest quality standards by X-POLE. This Limited Warranty offered by X-POLE

covers defects in material or workmanship in new X-POLE products for a period of 6 months.

This warranty extends to the original purchaser only and is non-transferable. Only consumers purchasing X-POLE products from authorised X-POLE

retailers or resellers or through the X-POLE website may obtain coverage under our limited warranties.

What is covered?

X-POLE warrants this product against defects in material or workmanship as follows:

X-POLE, at its own discretion, will replace at no charge for parts only or, at its option, replace any product or part of the product that proves defective

because of improper workmanship and/or material, under normal installation, use, service and maintenance. If X-POLE is unable to provide a

replacement and repair is not practical or cannot be made in a timely fashion, X-POLE may elect to refund the purchase price in exchange for the return

of the product.

How Long Does The Coverage Last?

Our warranty periods are 6 MONTHS from the documented date of purchase, depending on the type of product and where it was purchased. This does

not affect your statutory rights.

What Our Warranty Does Not Cover?

Our warranties do not cover any problem that is caused by:

A. Conditions, malfunctions or damage not resulting from defects in material or workmanship.

B. Conditions, malfunctions or damage resulting from (1) normal wear and tear, improper installation, improper maintenance, misuse, abuse, negligence,

accident or alteration.
