X10 PalmPad HR12A User manual

X10 Wireless Technology, Inc. LIMITED 1-YEAR WARRANTY
X10.com, a division of X10 Wireless Technology, Inc. (X10) warrants X10 products to be
free from defective material and workmanship for a period of one (1) year from the original
date of purchase at retail. X10 agrees to repair or replace, at it’s sole discretion, a defective
X10 product if returned to X10 within the warranty period and with proof of purchase.
If service is required under this warranty:
1. Call 1-800-675-3044 or visit www.x10.com, or e-mail [email protected] to obtain a
Return Merchandise Authorization (RMA) number.
2. Return the defective unit postage prepaid to X10 (see address on back).
3. Enclose a check for $4.00 to cover postage and handling.
4. Enclose a dated proof of purchase.
5. X10 is not responsible for shipping damage. Units to be returned should be packed
carefully.
Please visit www.x10.com/warranty
to complete your on-line warranty registration. Thank you.
For help or more information on setup, please visit: www.x10.com/support
Installation and operating instructions for HR12A PalmPad
The HR12A PalmPad Remote Control sends Wireless Radio
Frequency(RF)signalstoanX10Transceiver(RR501orTM751)
oranyX10securitysystembasereceiver.Thereceiverthenpasses
the signals onto your house wiring to control lights or appliances
around your home. You plug lights and appliances into X10
Modules (sold separately). The PalmPad also works with the
CM11ATwo-WayComputerInterfacetoinitiatemacros(routines)
soyoucansetupa“cominghome”routinewhichisinitiatedwhen
you press a button on the PalmPad.
1. Install 4 AAA alkaline batteries (sold separately) in the
PalmPad’s battery compartment.
2. Useadimeto set the Housecode dial to match theX10Modules
and Transceiver you want to control.
3. PluginanX10Transceiver(RR501orTM751,soldseparately).
4. Set the Palm Pad’s slide switch to 1-8 to control X10 Modules
set to Unit Codes 1 thru 8.
5. Set the slide switch to 9-16 to control X10 Modules 9 thru 16.
6. PressthecorrespondingONorOFFbuttontoturnX10Modules
on and off.
7. To brighten or dim lights connected to X10 Lamp Modules and
Wall Switch Modules, first press the corresponding number
button, then press the UP or DOWN (blue) buttons.
HR12A-9/01
F.C.C. CAUTION - THIS DEVICE COMPLIES WITH PART 15 OF THE
FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO
CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL
INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY
INTERFERENCERECEIVED,INCLUDINGINTERFERENCETHATMAY
CAUSE UNDESIRED OPERATION. NOTE: NO CHANGES OR
MODIFICATIONS MAY BE MADE TO THE UNITS. ANY CHANGES
MADE TO THE UNITS WILL VOID THE USER'S AUTHORITY TO
OPERATE THE EQUIPMENT.
