Xantrex Freedom XC PRO Series User manual

Freedom XC PRO Inverter/Charger
Owner’s Guide
Freedom XC PRO 2000818-2010
Freedom XC PRO 3000818-3010

ii Freedom XC PRO Owner's Guide
Copyright © 2019 Xantrex LLC. All Rights Reserved.
All trademarks are owned by Xantrex LLC and its affiliates.
Exclusion for Documentation
UNLESS SPECIFICALLY AGREED TO IN WRITING, SELLER
(A) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS
MANUALS OR OTHER DOCUMENTATION;
(B) ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSSES, DAMAGES, COSTS OR EXPENSES, WHETHER SPECIAL, DIRECT, INDIRECT,
CONSEQUENTIAL OR INCIDENTAL, WHICH MIGHT ARISE OUT OF THE USE OF SUCH INFORMATION. THE USE OF ANY SUCH INFORMATION WILL BE
ENTIRELY AT THE USER’S RISK; AND
(C) REMINDS YOU THAT IF THIS MANUAL IS IN ANY LANGUAGE OTHER THAN ENGLISH, ALTHOUGH STEPS HAVE BEEN TAKEN TO MAINTAIN THE
ACCURACY OF THE TRANSLATION, THE ACCURACY CANNOT BE GUARANTEED. APPROVED CONTENT IS CONTAINED WITH THE ENGLISH
LANGUAGE VERSION WHICH IS POSTED AT HTTP://WWW.XANTREX.COM/.
Document Number:975-0799-01-01 Rev B Date: May 2019
Product Name and Part Number
Freedom XC PRO 2000 (818-2010)
Freedom XC PRO 3000 (818-3010)
Contact Information
Telephone: (Toll Free USA/Canada) [phone] / (Outside USA/Canada) [phone]
Email: [e-mail],
http://www.xantrex.com/power-products-support/
Web: http://www.xantrex.com/

975-0799-01-01 iii
Information About Your System
As soon as you open your product, record the following information and be sure to keep your proof of purchase.
Serial Number ____________________________
Product Number ____________________________
Purchased From ____________________________
Purchase Date ____________________________
To view, download, or print the latest revision, visit the website shown under Contact Information.

This page is intentionally left blank.

975-0799-01-01 v
Purpose
The purpose of this Owner’s Guide is to provide explanations and
procedures for installing, operating, configuring, maintaining, and
troubleshooting a Freedom XC PRO Inverter/Charger for
Recreational, Commercial and Fleet Vehicle, or Marine
installations.
Scope
The guide provides safety and operating guidelines as well as
information on installing and configuring the inverter/charger. It
also provides information about troubleshooting the unit. It does
not provide details about particular brands of batteries. You need
to consult individual battery manufacturers for this information.
Audience
The guide is intended for users and operators of the Freedom XC
PRO Inverter/Charger.The Installation section starting on page 15
is intended for qualified personnel.
Qualified personnel have training, knowledge, and experience in:
lInstalling electrical equipment.
lApplying all applicable installation codes.
lAnalyzing and reducing the hazards involved in performing
electrical work.
lSelecting and using Personal Protective Equipment (PPE).
Abbreviations and Acronyms
A Amps
AC Alternating Current
ACC Accessory in vehicle ignition system
AGM Absorbed Glass Mat (a battery type)
BTS Battery Temperature Sensor
DC Direct Current
in-lb inch-pound force (a unit of torque)
kW Kilowatts (1000 watts)
LBCO Low Battery Cutout (or Cutoff)
LCD Liquid Crystal Display
LED Light Emitting Diode
LFP LiFePO4(lithium iron phosphate – a battery type)
N-m Newton-meters (a unit of torque)
PN Product Number
PPE Personal Protective Equipment
PV Photovoltaic (Solar)
V Volts
VAC Volts AC
VDC Volts DC
W Watts
Related Information
You can find more information about Xantrex products and
services at http://www.xantrex.com/.

This page is intentionally left blank.

975-0799-01-01 Freedom XC PRO Owner's Guide
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THIS OWNER’SGUIDE FOR FUTURE
REFERENCE.
This guide contains important safety instructions for the Freedom
XC PRO that must be followed during installation, operation,
maintenance, and troubleshooting.
Read these instructions carefully and look at the equipment to
become familiar with the device before installing, operating,
configuring, maintaining, and troubleshooting it. The following
special messages may appear throughout this documentation or
on the equipment to warn of potential hazards or to call attention
to information that clarifies or simplifies a procedure.
The addition of either symbol to a “Danger” or
“Warning” safety label indicates that an electrical
hazard exists which will result in personal injury if the
instructions are not followed.
This is the safety alert symbol. It is used to alert you to
potential personal injury hazards. Obey all safety
messages that follow this symbol to avoid possible
injury or death.
DANGER
DANGER indicates a hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING
WARNING indicates a hazardous situation which, if not avoided, could result
in death or serious injury.
CAUTION
CAUTION indicates a hazardous situation which, if not avoided, could result
in minor or moderate injury.
NOTICE
NOTICE is used to address practices not related to physical injury.

Product Safety Information
viii Freedom XC PRO Owner's Guide
Product Safety Information
1. Before using the inverter/charger, read all instructions and
cautionary markings on the unit, the batteries, and all
appropriate sections of this guide.
2. Use of accessories not recommended or sold by the
manufacturer may result in a risk of fire, electric shock, or
injury to persons.
3. The inverter/charger is designed to be connected to both DC
and AC electrical systems. The manufacturer recommends
that all wiring be done by a certified technician or electrician
to ensure adherence to the local and national electrical
codes applicable in your jurisdiction.
4. To avoid a risk of fire and electric shock, make sure that
existing wiring is in good condition and that wire is not
undersized. Do not operate the inverter/charger with
damaged or substandard wiring.
5. Do not operate the inverter/charger if it has been damaged in
any way.
6. This unit does not have any user-serviceable parts. Do not
disassemble the inverter/charger except where noted for
connecting wiring and cabling. See your warranty for
instructions on obtaining service. Attempting to service the
unit yourself may result in a risk of electrical shock or fire.
Internal capacitors remain charged after all power is
disconnected.
7. To reduce the risk of electrical shock, disconnect both AC
and DC power from the inverter/charger before attempting
any maintenance or cleaning or working on any components
connected to the inverter/charger. Do not disconnect under
load. Turning the inverter/charger to Standby mode using the
Power button on the front panel will not reduce an electrical
shock hazard.
8. The inverter/charger must be provided with an equipment-
grounding conductor connected to the AC input ground.
9. Do not expose this unit to rain, snow, or liquids of any type.
This product is designed for dry-locations-use only. Damp
environments will significantly shorten the life of this product
and corrosion caused by dampness will not be covered by
the product warranty.
10. To reduce the chance of short-circuits, always use insulated
tools when installing or working with this equipment.
11. Remove personal metal items such as rings, bracelets,
necklaces, and watches when working with electrical
equipment.
12. For marine applications, this unit must be installed with a
drip shield. Refer to Marine Installation on page 46 for
details.
DANGER
ELECTRICAL SHOCK AND FIRE HAZARD
Installation must be done by qualified personnel to ensure
compliance with all applicable installation and electrical codes and
regulations. Instructions for installing the Freedom XC PRO
Inverter/Charger are provided here for use by qualified personnel
only.
Failure to follow these instructions will result in death or serious
injury.

Product Safety Information
975-0799-01-01 ix
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, BURN, OR
ARC FLASH
lApply appropriate personal protective equipment (PPE) and
follow safe electrical work practices. See NFPA 70E or CSA
Z462.
lThis equipment must only be installed and serviced by
qualified electrical personnel.
lNever operate energized with the wiring compartment cover
removed.
lEnergized from multiple sources. Before removing the wiring
compartment cover - identify all sources, de-energize, and
wait 2 minutes for circuits to discharge.
lAlways use a properly rated voltage sensing device to
confirm all circuits are de-energized.
lReplace all devices, doors, and covers before turning on
power to this equipment.
Failure to follow these instructions will result in death or serious
injury.
WARNING
ELECTRICAL SHOCK HAZARD
lReplace the wiring compartment cover before turning on
power to this equipment.
lUse a torque screwdriver to tighten the captive nut panel
screw to 5 in-lb torque to ensure a proper ground connection
and a required tool access to the wiring compartment.
Failure to follow these instructions can result in death, serious
injury, or equipment damage.
WARNING
FIRE AND EXPLOSION HAZARD
lUnit’s components may produce arcs or sparks.
lDo not install near batteries, in machinery space, or in an
area in which ignition-protected equipment is required.
Failure to follow these instructions can result in death, serious
injury, or equipment damage.
Areas include any space containing gasoline-powered machinery,
fuel tanks, as well as joints, fittings, or other connections between
components of the fuel system.

Product Safety Information
x Freedom XC PRO Owner's Guide
CAUTION
ELECTRICAL SHOCK AND FIRE HAZARD
lDo not open. No serviceable parts inside. Provided with
integral protection against overloads. Bonding between
conduit connections is not automatic and must be provided
as part of the installation.
lRead guide before installing or using.
lDo not cover or obstruct ventilation openings.
lDo not mount in zero-clearance compartment – overheating
may result.
lDo not expose to rain or spray. This inverter/charger is
designed for marine applications only when additional drip
protection is installed in certain orientations. See “Approved
Mounting Orientations” on the Installation Guide for more
information.
lInstall GFCIs only as specified in this guide. Other types may
fail to operate.
lDo not connect AC OUT to any other source of power.
Damage to unit may occur.
lFor AC IN and AC OUT, use wires suitable for at least 75°C.
Failure to follow these instructions can result in injury or
equipment damage.
NOTES:
lFollow these instructions and those published by the battery
manufacturer and the manufacturer of any equipment you
intend to use in the vicinity of the battery. Review cautionary
markings on these products and on the engine.
lFreedom XC PRO Inverter/Charger products are designed
for deep cycle lead-acid batteries. See warning below when
connecting to lithium ion batteries.
lDo not use transformerless battery chargers in conjunction
with the inverter/charger due to overheating.
CAUTION
LITHIUM ION BATTERY TYPE HAZARD
Make sure to use a lithium ion battery pack that includes a certified
Battery Management System (BMS) with built-in safety protocols.
Follow the instructions published by the battery manufacturer.
Failure to follow these instructions can result in serious injury or
equipment damage.

Precautions When Working With Batteries
975-0799-01-01 xi
CAUTION
PHYSICAL INJURY HAZARD
This Freedom XC PRO Inverter/Charger is not intended for use by
persons (including children) with reduced physical, sensory, or
mental capabilities or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of
the appliance by a person responsible for their safety. Children
should be supervised to ensure that they do not play with the
appliance.
Failure to follow these instructions can result in injury or
equipment damage.
Precautions When Working With
Batteries
IMPORTANT: Battery work and maintenance must be done by
qualified personnel knowledgeable about batteries to ensure
compliance with battery handling and maintenance safety
precautions.
WARNING
BURN FROM HIGH SHORT-CIRCUIT CURRENT, FIRE
AND EXPLOSION FROM VENTED GASES HAZARDS
lAlways wear proper, non-absorbent gloves, complete eye
protection, and clothing protection. Avoid touching your eyes
and wiping your forehead while working near batteries. See
note #4.
lRemove all personal metal items, like rings, bracelets, and
watches when working with batteries. See notes #5 and #6
below.
lNever smoke or allow a spark or flame near the engine or
batteries.
lNever charge a frozen battery.
Failure to follow these instructions can result in death, serious
injury, or equipment damage.

Precautions When Placing the inverter/charger
xii Freedom XC PRO Owner's Guide
NOTES:
1. Mount and place the Freedom XC PRO Inverter/Charger unit
away from batteries in a well ventilated compartment.
2. Always have someone within range of your voice or close
enough to come to your aid when you work near a lead-acid
battery.
3. Always have plenty of fresh water and soap nearby in case
battery acid contacts skin, clothing, or eyes.
4. Keep battery terminals clean from corrosion. If battery acid
or corrosion deposit contacts skin or clothing, wash
immediately with soap and water. If battery acid or corrosion
deposit enters your eye, immediately flood it with running
cold water for at least twenty minutes and have someone
within range of your voice or close enough to get medical
attention immediately.
5. Use extra caution to reduce the risk of dropping a metal tool
on the battery. It could spark or short circuit the battery or
other electrical parts and could cause an explosion. Use
tools with insulated handles only.
6. Batteries can produce a short circuit current high enough to
weld a ring or metal bracelet or the like to the battery
terminal, causing a severe burn.
7. When removing a battery, always remove the negative
terminal from the battery first for systems with grounded
negative. If it is grounded positive, remove the positive
terminal first. Make sure all loads connected to the battery
and all accessories are off so you don’t cause an arc.
Precautions When Placing the
Inverter/charger
WARNING
FIRE HAZARD
lDo not install the inverter/charger or any part of its supplied
wiring in engine compartments.
lFor marine installation, always locate the inverter/charger
away from the battery and mounted separately in a well-
ventilated compartment with adequate space.
Failure to follow these instructions can result in death, serious
injury, or equipment damage.
CAUTION
BURN HAZARD
Avoid touching the external surfaces - heatsink may be hot.
Failure to follow these instructions can result in injury or
equipment damage.

Regulatory
975-0799-01-01 xiii
NOTICE
RISK OF INVERTER/CHARGER DAMAGE
lNever allow battery acid to drip on the inverter/charger when
reading gravity, or filling battery.
lNever place the Freedom XC PRO unit directly above
batteries; gases from a battery will corrode and damage the
inverter/charger.
lDo not place a battery on top of the inverter/charger.
Failure to follow these instructions can result in equipment
damage.
Regulatory
The Freedom XC PRO inverter/charger is certified to appropriate
US and Canadian standards. For more information see
Regulatory approvals on page 97.
The Freedom XC PRO inverter/charger is intended to be used for
mobile or commercial applications. This inverter/charger is
designed for marine applications only when additional drip
protection is installed in certain orientations. See the section on
Specifications for information.
FCC Information to the User
This equipment (the charge controller) has been tested and found
to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference
to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
nReorient or relocate the receiving antenna.
nIncrease the separation between the equipment and
receiver.
nConnect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
nConsult the dealer or an experienced radio/TV technician for
help.
CAUTION
Unauthorized changes or modifications to the equipment could
void the user’s authority to operate the equipment.

End of Life Disposal
xiv Freedom XC PRO Owner's Guide
End of Life Disposal
The Freedom XC PRO Inverter/Charger is designed with
environmental awareness and sustainability in mind. At the end of
its useful life, the Freedom XC PRO can be decommissioned and
disassembled. Components which can be recycled must be
recycled and those that cannot be recycled must be disposed of
according to local, regional, or national environmental regulations.
Many of the electrical components used in the Freedom XC PRO
Inverter/Charger are made of recyclable material like steel,
copper, aluminum, and other alloys. These materials can be
auctioned off to traditional scrap metal recycling companies who
resell reusable scraps.
Electronic equipment such as the circuit boards, connectors, and
fuses can be broken down and recycled by specialized recycling
companies whose goal is to avoid having these components end
up in the landfill.
For more information on disposal, contact Xantrex.

975-0799-01-01 Freedom XC PRO Owner's Guide
CONTENTS
Important Safety Instructions vii
Product Safety Information viii
Precautions When Working With Batteries xi
Precautions When Placing the inverter/charger xii
Regulatory xiii
FCC Information to the User xiii
End of Life Disposal xiv
Contents xv
Introduction 1
Materials List 2
Key Features 2
Power for Most Appliances 2
Back-up Capability 2
Configurable AC Transfer Speed 3
Overload Alarm and Shutdown 3
Over temperature Alarm and Shutdown 3
Built-in Charge Formulas 3
Manual Equalization 4
Dead Battery Charging 4
Ignition Control 4
Configurable AC Output Frequency and Voltage 4
Load Management 4
Features 5
Default Settings 6
AC/DC and GFCI Panel 7
Display Panel 10
Side Panel 11
Installation 13
Before You Begin the Installation 14
Installation Codes 14
Installation Tools and Materials 15
Basic Installation Procedures 16
Step 1: Designing the Installation 17
Step 2: Choosing a Location for the Unit 22
Step 3: Mounting the Unit 23
Step 4: Connecting the AC Input Wires 25

xvi Freedom XC PRO Owner's Guide
Step 5: Connecting AC Output to an Existing AC Circuit 29
Step 6: Connecting the DC Cables 33
Step 7: Connecting to Port(s) on the Freedom XC PRO 38
Step 8: Testing Your Installation 44
Marine Installation 46
Drip Shield Installation 47
Operation 49
Freedom XC PRODisplay Panel 50
Status LED Indicators 50
Function Buttons 51
LCD Screen 51
LCD Screen Icons 52
Operating in Battery Mode 54
Turning Inverter Operation ON and OFF 54
Power Save Timer 55
Checking Battery Status 55
Checking Output Power 55
Operating Several Loads at Once 55
Turning the Audible Alarm ON or OFF 56
Operating in Grid Mode 57
Battery Charger Functions 57
Battery Types 57
Custom Battery Settings Menu 61
Operating During Transition Between Grid Mode and Battery
Mode 62
Transitioning from Grid Mode to Battery Mode 62
Transitioning from Battery Mode to Grid Mode 63
Viewing Information During Battery Mode 66
Viewing Information During Grid Mode 68
Adjusting Feature Settings in Configuration Mode 70
Routine Maintenance 77
Freedom XC PRO Unit 78
Troubleshooting 79
Pre-service Checklist 80
Warning Messages 81
Troubleshooting Reference 84
Inverter Applications 88
Resistive Loads 88
Motor Loads 88
Specifications 89
Physical Specifications 90
Environmental Specifications 92
System Specifications 93
Regulatory Approvals 97

975-0799-01-01 Freedom XC PRO Owner's Guide
1 INTRODUCTION
The Freedom XC PRO Inverter/Charger is designed with
integrated inverting functions and power management features
suitable for marine, recreational, and commercial/fleet vehicle
installations.
Please read this section to familiarize yourself with the main
performance and protection features of the Freedom XC PRO.
This section includes:
Materials List 2
Key Features 2
Power for Most Appliances 2
Back-up Capability 2
Configurable AC Transfer Speed 3
Overload Alarm and Shutdown 3
Over temperature Alarm and Shutdown 3
Built-in Charge Formulas 3
Manual Equalization 4
Dead Battery Charging 4
Ignition Control 4
Configurable AC Output Frequency and Voltage 4
Load Management 4

Materials List
2 Freedom XC PRO Owner's Guide
Materials List
The Freedom XC PRO base package includes the following
items:
none Freedom XC PRO unit
none Owner’s Guide and extra safety labels
none pre-installed DC ground enclosure lug (not shown)
none set of plastic bushings for large DC cables (not shown)
ntwo AC knockout hole plugs (not shown)
Figure 1 What’s In The Box
NOTE: If any of the items are missing, contact Xantrex or any
authorized Xantrex dealer for replacement. See Contact
Information on page ii.
Key Features
Power for Most Appliances
The Freedom XC PRO inverter/charger provides up to 2000watts
(Freedom XC PRO 2000) or 3000watts (Freedom XC PRO 3000)
of continuous utility grade, sine wave power derived from a battery
bank. It is designed to handle loads such as microwave ovens,
TVs, DVD/Blu-ray players, and power tools. In addition, the
Freedom XC PRO’s high-surge capability lets you handle many
hard-to-start loads, including full size residential refrigerators.
The built-in transfer switch automatically transfers between
inverter power and shore power from recreational facilities such as
boat docks or campsites to ensure power is always available.
Back-up Capability
If incoming shore power is interrupted by external events like
brownouts, the Freedom XC PRO automatically becomes an
independent power source1that supplies utility grade AC power to
your loads.
1Assuming the inverter/charger is connected to a battery source with an adequate charge at the time of the
power interruption.

Materials List
975-0799-01-01 3
Comprehensive Protection
The Freedom XC PRO’s built-in protection features safeguard
your batteries (from unnecessary drain) such as the low battery
voltage alarm and shutdown and protect equipment such as a
configurable AC transfer speed.
nSelectable Low Battery Shutdown: The low battery
shutdown for the inverter/charger can be manually selected
by the user from 10.1 to 12.8VDC.
nLow Voltage Shutdown Delay Timer: Configurable from 1
to 300seconds to reduce an unnecessary shutdown of
inverter operation such as during cranking or other brief but
heavy discharge of battery.
nInverter Power Save: The Freedom XC PRO can be
programmed to automatically turn off after 1 to 25 hours of
continued operation of loads that are under 50watts. It is
designed, with LBCO (low battery cut off), to prevent the
battery from deep discharge.
Configurable AC Transfer Speed
The Freedom XC PRO allows two speed settings for the AC
transfer from Grid Mode to Battery Mode and vice versa which
avoids nuisance resetting of appliances. The normal transfer rate
is for common appliances and the faster transfer rate is designed
for more sensitive digital equipment like a desktop computer.
Overload Alarm and Shutdown
During Battery Mode (also called Inverter Mode), the Freedom XC
PRO automatically alerts you if the loads that are connected and
drawing power from the unit are close to approaching the
maximum operating limit. If so, the Freedom XC PRO
automatically shuts down when the maximum operating limit is
exceeded. See Troubleshooting Reference on page 84 for
precautions.
Over temperature Alarm and
Shutdown
During Battery Mode, the Freedom XC PRO automatically alerts
you if it is overheating and approaching the over-temperature
shutdown limit. The Freedom XC PRO automatically shuts down
when the limit is exceeded. See Troubleshooting Reference on
page 84 for precautions.
Built-in Charge Formulas
For the inverter/charger to perform at the highest level, the
batteries must be charged correctly. The Freedom XC PRO has
optimized algorithms for flooded, gel, AGM, custom, and lithium
iron phosphate [LFP (or LiFePO4)] batteries.

Materials List
4 Freedom XC PRO Owner's Guide
Manual Equalization
Over a period of time, the cells in a flooded battery can develop
uneven chemical states. This can result in a weak (undercharged)
cell which, in turn, can reduce the overall capacity of the battery.
To improve the life and performance of a non-sealed, flooded
battery, the Freedom XC PRO multi-stage charging cycle
includes a manual equalize mode that can be used, if
recommended by the battery manufacturer.
Dead Battery Charging
Another feature of the Freedom XC PRO is dead battery charging.
This is the ability to recharge batteries, even if the battery voltage
has reached zero volts.
Ignition Control
The Freedom XC PRO provides two user-selectable options for
ignition control:
nIgnition Auto-on: The Freedom XC PRO can automatically
turn the inverter/charger on and off in tandem with the
vehicle's ignition circuit or a manually operated remote
switch.
nIgnition Lockout: The Freedom XC PRO features the
ability to inhibit the inverter/charger from operating in the
absence of a voltage signal from a vehicle's ignition circuit.
This is particularly useful if the inverter/charger is required to
operate only when a vehicle's engine is running.
Configurable AC Output Frequency
and Voltage
The Freedom XC PRO is factory set to 60Hz AC output
frequency and 120V AC output voltage. It can be configured to
50Hz for use in regions outside the USA and Canada. The AC
voltage setting can also be configured to either of three settings:
108, 110, or 120volts.
Load Management
The Freedom XC PRO has a built-in 30A transfer relay (Freedom
XC PRO 2000) and 50A transfer relay (Freedom XC PRO 3000)
that connects the inverter/charger output or AC input from the AC
generator to the loads. Because the usual AC power sources such
as small generators often have limited current availability, having
the capability to manage your AC loads is extremely valuable. The
Freedom XC PRO provides a number of features to facilitate this.
nThe charger is power factor corrected to use AC current as
efficiently as possible. Minimizing the AC current used by
the charger means more current is available for your AC
loads.
nThe Freedom XC PRO has a power share feature which
prioritizes your AC loads by reducing the charge current and
maintaining the total input current to less than the breaker
setting.
