Xantrex XC Series User manual

The Easy Shunt™ (Part #: 808-8020-00) is an option that you can purchase for use with
your XC Series or BC Series battery charger. It is installed on Bank 1 and acts as a
temperature sensor during normal operation, providing improved battery voltage charge
control. It also provides an Amp-Hour usage indicator (a "fuel gauge" for your main
battery bank) via your XC Series or BC Series charger when the charger is off.
Precautions When Working With Batteries
1. Follow all instructions published by the battery manufacturer and the manufacturer
of the equipment in which the battery is installed.
2. Make sure the area around the battery is well ventilated.
3. Never smoke or allow a spark or flame near the engine or batteries.
4. Use caution to reduce the risk of dropping a metal tool on the battery. It could spark
or short circuit the battery or other electrical parts and could cause an explosion.
5. Remove all metal items, like rings, bracelets, and watches when working with lead-
acid batteries. Lead-acid batteries produce a short circuit current high enough to
weld metal, causing a severe skin burn.
6. Have someone within range of your voice or close enough to come to your aid
when you work near a lead-acid battery.
7. Have plenty of fresh water and soap nearby in case battery acid contacts skin,
clothing, or eyes.
8. Wear complete eye protection and clothing protection. Avoid touching your eyes
while working near batteries.
9. If battery acid contacts skin or clothing, wash immediately with soap and water. If
acid enters your eye, immediately flood it with running cold water for at least
twenty minutes and get medical attention immediately.
10. If you need to remove a battery, always remove the negative (ground) terminal from
the battery first. Make sure all accessories are off so you don’t cause a spark.
Easy Shunt™ Installation
Instructions
For Xantrex XC Series
and BC Series Battery
Chargers
975-0191-01-01
Revision C
WARNING: Explosion or fire hazard

Xantrex XC Series and BC Series Battery Charger
2975-0191-01-01
Installing the Easy Shunt™ Sensor
To install the Easy Shunt™:
1. Switch off all devices operating from the battery. Disconnect all the wires from the
negative terminal of the battery (which is connected to Bank 1 on the XC or BC
Series charger).
2. Connect the "battery end" of the shunt which has the "D" shaped cutout to the
negative battery stud. If you have a round-post style battery use the round post to
stud battery terminal adapter provided. If you have a battery with a threaded stud,
remove the post adapter.
3. Loosen the nut from the bolt located in the opposite "load side" shunt terminal.
Adjust the round-headed (carriage) bolt until it contacts the top of the battery case
to provide support against the weight of the heavy wiring and any vibration that
may be transmitted to it.
Battery Positive Ring
Connector
Battery Negative
Cable Connection
(battery terminal)
XC Series or BC Series
Negative Cable Connection
(load terminal)
Telephone-style Connector
(to Bank 1 Connector on
Rear Panel of XC Series or
BC Series)
Battery Negative
Terminal
Round Post to Stud
Battery Terminal
Adapter
Easy Shunt™

Easy Shunt™ Installation Instructions
975-0191-01-01 3
4. Attach all wires removed in step 1 back onto this new "load" shunt terminal.
5. Tighten the nuts to 8 – 9 Nm (6 – 7 ft-lbs) to secure these electrical connections.
6. Route the sensor cable to the charger and plug it into the Bank 1 connector on the
rear panel of the XC Series or BC Series Charger.
7. Connect the battery positive ring connector to the positive terminal of the battery, or
to another round post to stud battery terminal adapter if needed.
Using the Easy Shunt™ Sensor
In order to use the Easy Shunt™, AC power must be disconnected from the XC Series
or BC Series Charger. In addition, the Amp-Hours will only reset to zero and give an
accurate usage gauge if bank 1 has reached float (3 stage charging) or rest (2 stage
charging).
To display the Amp-Hours that have been used since Bank 1 was last fully
charged:
1. Ensure the charger is off and AC power has been disabled.
2. Press ON/STANDBY.
The remote display will scroll the following information, in order, for bank 1.
• Highest priority charger fault or warning (if present)
• Highest priority battery fault or warning (if present)
• Battery voltage
• Amp-hours used (the Ah units indicator light on the remote display will
illuminate)
Round-headed
carriage bolt

Xantrex XC Series and BC Series Battery Charger
4975-0191-01-01
3. The remote display will scroll the following information, in order, on Bank 2 and
then Bank 3:
• Highest priority charger fault or warning (if present)
• Highest priority battery fault or warning (if present)
• Battery voltage
Amp-hours used is not available for Bank 2 or Bank 3.
4. After running through the sequence once, the display will switch itself off. Press the
ON/STANDBY switch to show the sequence again at any time until AC is enabled.
Notice of Copyright
Easy Shunt™ Installation Instructions © August 2005 Xantrex International. All rights reserved.
Warranty
This product has a 24 month limited warranty from the date of first sale which covers defects in workmanship and materials.
Retain proof of purchase. For full details on this limited warranty visit our website at www.xantrex.com or call
1-800-670-0707.
It is important that you read the limited warranty as it restricts your legal rights. If you are not satisfied with the limited
warranty you may return this product to Xantrex with 30 days of the date of purchase for a full refund.
Date and Revision
August 2005 Revision C
