Freedom Xi Inverter
Owner’s Guide
Product image shown may vary from actual product. See features for comparisons.
Model Product Number
807-1000
807-2000
Freedom XI Owners Guide.book Page i Friday, September 18, 2015 2:57 PM

Freedom XI Owners Guide.book Page ii Friday, September 18, 2015 2:57 PM

975-0754-01-01 i
Copyright © 2015 Schneider Electric. All Rights Reserved. All trademarks are
owned by Schneider Electric Industries SAS or its affiliated companies.
Exclusion for Documentation
UNLESS SPECIFICALLY AGREED TO IN WRITING, SELLER
(A)MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY
TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER DOCUMENTATION;
(B)ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSSES, DAMAGES, COSTS OR EXPENSES,
WHETHER SPECIAL, DIRECT, INDIRECT, CONSEQUENTIAL OR INCIDENTAL, WHICH MIGHT ARISE
OUT OF THE USE OF SUCH INFORMATION. THE USE OF ANY SUCH INFORMATION WILL BE ENTIRELY
AT THE USER’SRISK; AND
(C)REMINDS YOU THAT IF THIS MANUAL IS IN ANY LANGUAGE OTHER THAN ENGLISH,
ALTHOUGH STEPS HAVE BEEN TAKEN TO MAINTAIN THE ACCURACY OF THE TRANSLATION, THE
ACCURACY CANNOT BE GUARANTEED. APPROVED CONTENT IS CONTAINED WITH THE ENGLISH
LANGUAGE VERSION WHICH IS POSTED AT WWW.XANTREX.COM.
Document Part Number
975-0754-01-01
Date and Revision
September 2015 Rev A
Product Numbers
807-1000 (Freedom Xi 1000 120VAC)
807-2000 (Freedom Xi 2000 120VAC)
Contact Information
Information About Your System
As soon as you open your product, record the following information and be sure to
keep your proof of purchase.
To view, download, or print the latest revision, visit the website shown under Contact
Information.
Telephone: [phone] 
[phone]
Web: www.xantrex.com
Serial Number _________________________________
Product Number _________________________________
Purchased From _________________________________
Purchase Date _________________________________
Freedom XI Owners Guide.book Page i Friday, September 18, 2015 2:57 PM

ii Freedom Xi Owner’s Guide
About This Guide
Purpose
The purpose of this Owner’s Guide is to provide explanations and
procedures for operating, maintaining, and troubleshooting a Freedom Xi
Sine Wave Inverter for Recreational, Fleet Vehicle, or Marine installations.
For complete information to help in installing a Freedom Xi Sine Wave
Inverter see the Freedom Xi Sine Wave Inverter Installation Guide (Doc.
Part Number: 975-0753-01-01).
Scope
The Guide provides safety and operating guidelines as well as information
on configuring the Inverter. It also provides information about
troubleshooting the unit. It does not provide details about particular brands
of batteries. You need to consult individual battery manufacturers for this
information.
Audience
The Guide is intended for users and operators of the Freedom Xi Sine Wave
Inverter.
Abbreviation or Acronym
AAmps
AC Alternating Current
DC Direct Current
ft-lbs Foot-pounds (a measure of torque)
kW Kilowatts (1000 watts)
LED Light Emitting Diode
Nm Newton-meters (a measurement of torque)
VVolts
VA C Volts AC
VDC Volts DC
WWatts
Related Information
You can find more information about Xantrex products and services at
www.xantrex.com.
NOTE: The Installation Guide (Document Part Number: Freedom Xi Sine
Wave Inverter Installation Guide (Doc. Part Number: 975-0753-01-01)) is
intended for qualified personnel. Qualified personnel have training,
knowledge, and experience in:
• Installing electrical equipment (up to 1000 volts).
• Applying all applicable installation codes.
• Analyzing and reducing the hazards involved in performing electrical
work.
• Selecting and using Personal Protective Equipment (PPE).
Freedom XI Owners Guide.book Page ii Friday, September 18, 2015 2:57 PM

975-0754-01-01 iii
Important Safety Instructions
IMPORTANT: READ AND SAVE THIS OWNER’SGUIDE
FOR FUTURE REFERENCE.
This guide contains important safety instructions for the Freedom Xi Sine
Wave Inverter that must be followed during operation and troubleshooting.
Read and keep this Owner’s Guide for future reference.
Read these instructions carefully and look at the equipment to become
familiar with the device before trying to install, operate, service or maintain
it. The following special messages may appear throughout this bulletin or
on the equipment to warn of potential hazards or to call attention to
information that clarifies or simplifies a procedure.
The addition of either symbol to a “Danger” or “Warning” safety
label indicates that an electrical hazard exists which will result in
personal injury if the instructions are not followed.
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that follow this
symbol to avoid possible injury or death.
DANGER
DANGER indicates an imminently hazardous situation, which, if not
avoided, will result in death or serious injury.
WARNING
WARNING indicates a potentially hazardous situation, which, if not
avoided, can result in death or serious injury.
CAUTION
CAUTION indicates a potentially hazardous situation, which, if not
avoided, can result in moderate or minor injury.
NOTICE
NOTICE indicates a potentially hazardous situation, which, if not avoided,
can result in equipment damage.
Important: These notes describe things which are important for you to
know, however, they are not as serious as a caution or warning.
Freedom XI Owners Guide.book Page iii Friday, September 18, 2015 2:57 PM

iv Freedom Xi Owner’s Guide
Safety Information
1. Before using the Inverter, read all instructions and cautionary
markings on the unit, the batteries, and all appropriate sections of
this manual.
2. Use of accessories not recommended or sold by the manufacturer may
result in a risk of fire, electric shock, or injury to persons.
3. The inverter is designed to be connected to your AC and DC electrical
systems. The manufacturer recommends that all wiring be done by a
certified technician or electrician to ensure adherence to the local and
national electrical codes applicable in your jurisdiction.
4. To avoid a risk of fire and electric shock, make sure that existing
wiring is in good condition and that wire is not undersized. Do not
operate the inverter with damaged or substandard wiring.
5. Do not operate the inverter if it has been damaged in any way.
6. This unit does not have any user-serviceable parts. Do not disassemble
the inverter except where noted for connecting wiring and cabling. See
your warranty for instructions on obtaining service. Attempting to
service the unit yourself may result in a risk of electrical shock or fire.
Internal capacitors remain charged after all power is disconnected.
7. To reduce the risk of electrical shock, disconnect both AC and DC
power from the inverter before attempting any maintenance or
cleaning or working on any components connected to the inverter.
Turning off the Inverter using the Inverter Power button n the front
panel will not reduce an electrical shock hazard.
8. The inverter must be provided with an equipment-grounding
conductor connected to the AC input ground.
9. Do not expose this unit to rain, snow, or liquids of any type. This
product is designed for indoor use only. Damp environments will
significantly shorten the life of this product and corrosion caused by
dampness will not be covered by the product warranty.
10. To reduce the chance of short-circuits, always use insulated tools when
installing or working with this equipment.
11. Remove personal metal items such as rings, bracelets, necklaces, and
watches when working with electrical equipment.
DANGER
ELECTRICAL SHOCK AND FIRE HAZARD
Installation must be done by qualified personnel to ensure compliance
with all applicable installation and electrical codes and regulations.
Instructions for installing the Freedom Xi Sine Wave Inverter are
provided here for use by qualified personnel only.
Failure to follow these instructions will result in death or serious injury.
Freedom XI Owners Guide.book Page iv Friday, September 18, 2015 2:57 PM

• Apply appropriate personal protective equipment (PPE) and follow
safe electrical work practices. See NFPA 70E or CSA Z462.
• This equipment must only be installed and serviced by qualified
electrical personnel.
• Turn off all power supplying this equipment before working on or
inside equipment.
• Always use a properly rated voltage sensing device to confirm power
is off.
• Replace all devices, doors, and covers before turning on power to this
equipment.
• Unit’s components may produce arcs or sparks.
•Do not install near batteries, in machinery space, or in an area in
which ignition-protected equipment is required.
975-0754-01-01 v
Areas include any space containing gasoline-powered machinery, fuel
tanks, as well as joints, fittings, or other connections between components
of the fuel system.
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
Failure to follow these instructions will result in death or serious injury.
WARNING
FIRE AND EXPLOSION HAZARD
Failure to follow these instructions can result in death or serious
injury.
Freedom XI Owners Guide.book Page v Friday, September 18, 2015 2:57 PM

• Do not open. No serviceable parts inside. Provided with integral
protection against overloads. Bonding between conduit connections
is not automatic and must be provided as part of the installation.
• Read manual before installing or using.
• Do not cover or obstruct ventilation openings.
• Do not mount in zero-clearance compartment – overheating may
result.
• Do not expose to rain or spray. This inverter is designed for marine
applications only when additional drip protection is installed in
certain orientations. See “Approved Mounting Orientations” on the
Installation Guide for more information.
• Use GFCIs only as specified in the manuals supplied with unit. Other
types may fail to operate when connected to this unit.
• Do not connect AC OUT to any other source of power. Damage to
unit may occur.
• For AC IN and AC OUT, use wires suitable for at least 75°C.
vi Freedom Xi Owner’s Guide
NOTES:
1. Follow these instructions and those published by the battery
manufacturer and the manufacturer of any equipment you intend to use
in the vicinity of the battery. Review cautionary markings on these
products and on the engine.
2. Freedom Xi inverter products are designed for deep cycle lead-acid
batteries only. The Freedom Xi does not support lithium-ion batteries.
3. Do not use transformerless batterychargers in conjunction with the
inverter due to overheating.
CAUTION
ELECTRICAL SHOCK AND FIRE HAZARD
Failure to follow these instructions can result in minor or moderate
injury.
CAUTION
PHYSICAL INJURY HAZARD
This Freedom Xi Sine Wave Inverter is not intended for use by persons
(including children) with reduced physical, sensory, or mental
capabilities or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a
person responsible for their safety. Children should be supervised to
ensure that they do not play with the appliance.
Failure to follow these instructions can result in minor or moderate injury.
Freedom XI Owners Guide.book Page vi Friday, September 18, 2015 2:57 PM

975-0754-01-01 vii
Precautions When Working With Batteries
Battery work and maintenance must be done by qualified
personnel knowledgeable about batteries to ensure compliance with battery
handling and maintenance safety precautions.
• Always wear proper, non-absorbent gloves, complete eye protection,
and clothing protection. Avoid touching your eyes and wiping your
forehead while working near batteries. See note #4.
• Remove all personal metal items, like rings, bracelets, and watches
when working with batteries. See notes #5 and #6 below.
• Never smoke or allow a spark or flame near the engine or batteries.
NOTES:
1. Mount and place the Freedom Xi Sine Wave Inverter unit away from
batteries in a well ventilated compartment.
2. Always have someone within range of your voice or close enough to
come to your aid when you work near a lead-acid battery.
3. Always have plenty of fresh water and soap nearby in case battery acid
contacts skin, clothing, or eyes.
4. If battery acid contacts skin or clothing, wash immediately with soap
and water. If acid enters your eye, immediately flood it with running
cold water for at least twenty minutes and get medical attention
immediately.
5. Use extra caution to reduce the risk of dropping a metal tool on the
battery. It could spark or short circuit the battery or other electrical
parts and could cause an explosion.
6. Batteries can produce a short circuit current high enough to weld a ring
or metal bracelet or the like to the battery terminal, causing a severe
burn.
7. When removing a battery, always remove the negative terminal from
the battery first for systems with grounded negative. If it is grounded
positive, remove the positive terminal first. Make sure all loads
connected to the battery and all accessories are off so you don’t cause
an arc.
Important:
WARNING
BURN FROM HIGH SHORT-CIRCUIT CURRENT, FIRE AND
EXPLOSION FROM VENTED GASES HAZARDS
Failure to follow these instructions can result in death or serious injury.
Freedom XI Owners Guide.book Page vii Friday, September 18, 2015 2:57 PM

viii Freedom Xi Owner’s Guide
Precautions When Placing the Inverter
• Never allow battery acid to drip on the inverter when reading gravity,
or filling battery.
• Never place the Freedom Xi Sine Wave Inverter unit directly above
batteries; gases from a battery will corrode and damage the inverter.
• Do not place a battery on top of the inverter.
Regulatory
The Freedom Xi Sine Wave Inverter is certified to appropriate US and
Canadian standards. For more information see “Regulatory Approvals” on
page 32.
The Freedom Xi Sine Wave Inverter is intended to be used for mobile or
commercial applications. This Inverter is designed for marine applications
only when additional drip protection is installed in certain orientations. See
the section on Specifications for information.
WARNING
FIRE HAZARD
Do not install the inverter or any part of its supplied wiring in engine
compartments.
Failure to follow these instructions can result in death or serious injury.
CAUTION
BURN HAZARD
Avoid touching the external surfaces - heatsink may be hot.
Failure to follow these instructions can result in minor or moderate injury.
NOTICE
RISK OF DAMAGE TO THE INVERTER
Failure to follow these instructions can damage the unit and/or equipment.
Freedom XI Owners Guide.book Page viii Friday, September 18, 2015 2:57 PM

975-0754-01-01 ix
FCC Information to the User
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION
Unauthorized changes or modifications to the equipment could void the
user’s authority to operate the equipment.
Freedom XI Owners Guide.book Page ix Friday, September 18, 2015 2:57 PM

Freedom XI Owners Guide.book Page x Friday, September 18, 2015 2:57 PM

Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Freedom Inverter Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Freedom Inverter Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Operating in Shore Power Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Operating in Inverter Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Operating During Transition Between Shore Power and Inverter Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Invert Power Derating vs. Ambient Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Warning Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Troubleshooting Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Inverter Applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Contents
Freedom XI Owners Guide.book Page i Friday, September 18, 2015 2:57 PM

Freedom XI Owners Guide.book Page ii Friday, September 18, 2015 2:57 PM

975-0754-01-01 1
Introduction
The Freedom Xi Sine Wave Inverter (Freedom Xi) is designed with
integrated inverting functions and power management features
suitable for marine, recreational, and commercial vehicle
installations.
Please read this chapter to familiarize yourself with the main
performance and protection features of the Freedom Xi.
Materials List
The Freedom Xi base package includes the minimum following items:
• one Freedom Xi unit
• one set of owner’s and installation guides
• one display panel with 7-inch (0.17 m) cable
• one 25-foot (7.5 m) communications cable
• two DC terminal covers
• two strain-relief bushings
• one GFCI cover plate
• one pair AC compartment cover plates
• one display panel blanking plate (not shown)
• one display panel mounting bezel (not shown)
• one set of lock washers and nuts (not shown)
NOTE: If any of the items are missing, contact Xantrex or any
authorized Xantrex dealer for replacement. See “Contact
Information” on page i.
Other Freedom Xi OEM models may include other DC and/or AC
connectors. Figure 1 What’s In The Box
Display panel is
attached to the unit.
Freedom Xi unit
communications
cable
DC terminal
covers
GFCI cover
plate
strain-relief
bushings
Owner’sGuide
InstallationGuide
Product image shown may vary from actual
product. See “Features” for comparisons.
Freedom Xi 1000 120VAC
shown.
Owner’s and Installation
Guides
AC compartment
cover plates
Freedom XI Owners Guide.book Page 1 Friday, September 18, 2015 2:57 PM

2Freedom Xi Owner’s Guide
Introduction
Key Features
Power for Most Appliances The Freedom Xi inverter provides
up to 1000 wattsaor up to 2000 wattsbof continuous utility grade,
sine wave power derived from a battery bank. It is designed to
handle loads such as microwave ovens, TVs, DVD/Blu-ray players,
and power tools. In addition, the Freedom Xi’s high-surge capability
lets you handle many hard-to-start loads, including large TVs and
small refrigerators.
The built-in transfer switch automatically transfers between inverter
power and shore power from recreational facilities such as boat
docks or campsites to ensure power is always available.
Comprehensive Protection The Freedom Xi’s built-in protection
features safeguard your batteries and equipment, such as:
• the low battery voltage alarm and shutdown prevents your
batteries from becoming completely discharged
• when shore power is available, inverter power switches
automatically to shore power in milliseconds allowing
continuous operation of connected equipment
Back-up Capability If incoming shore power is interrupted by
external events like brownouts, the Freedom Xi automatically
becomes an independent power sourcecthat supplies utility grade
AC power to your loads.
Overload Alarm and Shutdown During inverter mode, the
Freedom Xi automatically alerts you if the loads that are connected
and drawing power from the unit are close to approaching the
maximum operating limit. If so, the Freedom Xi automatically shuts
down when the maximum operating limit is exceeded.
a.Freedom Xi 1000 120VAC (PN: 807-1000)
b.,Freedom Xi 2000 120VAC (PN: 807-2000)
c.Assuming the inverter is connected to a battery source with an adequate charge at
the time of the power interruption.
Freedom XI Owners Guide.book Page 2 Friday, September 18, 2015 2:57 PM

975-0754-01-01 3
Introduction
Over temperature Alarm and Shutdown During inverter mode,
the Freedom Xi automatically alerts you if it is overheating and
approaching the over-temperature shutdown limit.
The Freedom Xi automatically shuts down when the limit is
exceeded.
Low Power Consumption When the Freedom Xi is inverting
without a load, it draws less than 0.6 amp of current from the battery
(or battery bank).
This feature allows the unit to operate without draining too much
stored energy.
Selectable Low Battery Shutdown The low battery shutdown
for the inverter can be manually selected by the user by choosing a
low (10.5 V), middle (11.8 V), or high (12.1 V) setting.
Ignition Control The Freedom HFS provide two user-selectable
ignition control method:
•Ignition Lockout: The Freedom Xi features the ability to
inhibit the inverter from operating in the absence of a
voltage signal from a vehicle's ignition circuit. This is
particularly useful if the inverter is required to operate only
when a vehicle's engine is running.
•Ignition Auto-on: The Freedom Xi can automatically turn
the inverter on and off with the vehicle's ignition circuit.
Inverter Power Save The Freedom Xi has the ability to
automatically turn off after 25 hours of continued operation of loads
that are under 50 watts. It is designed to, in conjunction with LBCO,
to prevent the battery from deep discharge.
Freedom XI Owners Guide.book Page 3 Friday, September 18, 2015 2:57 PM

4Freedom Xi Owner’s Guide
Features
Table 1 lists the default settings for the Freedom Xi system.
You may record your settings in the right-hand column after you
have configured the Freedom Xi.
Table 1 Freedom Xi Default Values
Item Default Setting Your Setting
Alarm* ON ()
Low Voltage
Shutdown*

Invert Mode* 
Inverter Ignition
Control
OFF
* adjustable from the display panel
Front Panel (All Models)
2
1
3a 3b
Freedom Xi 1000 120VAC
4 4
Feature Description
1Display panel displays inverter status and battery status information on the
screen. The panel can be detached to extend and mount the panel on a wall or
other location.
2GFCI receptacles during inverter mode provide 1000 watts (Freedom Xi
1000 models) or 2000 watts (Freedom Xi 2000 models) of power to operate
AC devices.
3 WA G O a
a. WAGO manufactures connection devices such as terminal blocks and related accessories.
Freedom Xi models indicated above use WAGO terminal blocks as AC input and output con-
nections.
AC terminals (with terminal inspection covers) for connecting
AC input (3a)and AC output (3b) wiring.
4Mounting flange allows you to mount the inverter permanently.
Freedom XI Owners Guide.book Page 4 Friday, September 18, 2015 2:57 PM

975-0754-01-01 5
Features
Rear Panel (All Models)
4
1
23
Freedom Xi 1000 shown
Feature Description
1Negative DC cabling terminal connects to the negative terminal of the
battery using a battery cable.
2Ventilation grille (openings) must not be obstructed for the proper operation
of the cooling fan and inverter. When the inverter is mounted, the ventilation
grille must not point up or down.
3Positive DC cabling terminal connects to the positive terminal of the battery
using a battery cable.
4Serial number of your unit.
Display Panel (All Models)
4
12
3
Feature Description
1Inverter Power button is the main unit switch that turns the Freedom Xi’s
inverter mode ON or OFF. See page 11 for additional information.
2Three-digit LED display screen shows status information and fault codes.
See page 11 for additional information.
3Status LED indicates the mode of operation with a three-color LED. See
page 11 for additional information.
4Select button changes status information displayed on the display screen. See
page 11 for additional information.
IMPORTANT:See “Display Panel Operation” on page 11 for detailed information on operating
the panel’s buttons.
Freedom XI Owners Guide.book Page 5 Friday, September 18, 2015 2:57 PM

6Freedom Xi Owner’s Guide
Features
Side Panel
12
3
Feature Description
120 A supplementary protector (PN: 807-2000) provides overload
protection for the GFCI receptacles. In a hard wired installation, the
supplementary protector does not protect output wiring.
15 A supplementary protector (PN: 807-1000) provides overload
protection for the GFCI receptacles. In a hard wired installation, the
supplementary protector does not protect output wiring.
2Grounding stud provides a ground path for the Freedom Xi chassis to the
DC system ground.
3Main cooling fan turns on when powering loads above 500 watts or when the
internal temperature reaches a set point temperature.
Freedom XI Owners Guide.book Page 6 Friday, September 18, 2015 2:57 PM
