RS2000 Sine Wave Inverter/Charger
Installation Guide
RS2000

RS2000 Sine Wave Inverter/Charger
Installation Guide

About Xantrex
Xantrex Technology Inc. is a world-leading supplier of advanced power electronics and controls with products from
50 watt mobile units to one MW utility-scale systems for wind, solar, batteries, fuel cells, microturbines, and backup
power applications in both grid-connected and stand-alone systems. Xantrex products include inverters, battery
chargers, programmable power supplies, and variable speed drives that convert, supply, control, clean, and distribute
electrical power.
Trademarks
RS2000 Sine Wave Inverter/Charger is a trademark of Xantrex International. Xantrex and Xanbus are registered
trademarks of Xantrex International.
Other trademarks, registered trademarks, and product names are the property of their respective owners and are used
herein for identification purposes only.
Notice of Copyright
RS2000 Sine Wave Inverter/Charger Installation Guide © June 2004 Xantrex International. All rights reserved.
Disclaimer
UNLESS SPECIFICALLY AGREED TO IN WRITING, XANTREX TECHNOLOGY INC. (“XANTREX”)
(a) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY
TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER DOCUMENTATION.
(b) ASSUMES NO RESPONSIBILITY OR LIABILITY FOR LOSS OR DAMAGE, WHETHER DIRECT,
INDIRECT, CONSEQUENTIAL OR INCIDENTAL, WHICH MIGHT ARISE OUT OF THE USE OF SUCH
INFORMATION. THE USE OF ANY SUCH INFORMATION WILL BE ENTIRELY AT THE USER’S RISK.
Date and Revision
June 2004 Rev A
Part Number
975-0126-01-01
Contact Information
Telephone: [phone] (toll free North America)
1 360 925 5097 (direct)
Fax: [phone] (toll free North America)
1 360 925 5143 (direct)
Email: [email protected]
Web: www.xantrex.com

975-0126-01-01 i
About This Guide
Purpose
The RS2000 Sine Wave Inverter/Charger Installation Guide describes the
procedure for installing the RS2000 Sine Wave Inverter/Charger
(RS2000).
Scope
The Installation Guide provides safety guidelines, detailed planning and
setup information, and procedures for installing the inverter/charger. It
does not provide information on operation, configuration,
troubleshooting, and warranty and product information. Refer to the
RS2000 Sine Wave Inverter/Charger Operation Guide.
This guide does not provide details about particular brands of batteries.
You need to consult individual battery manufacturers for this information.
Audience
The Installation Guide is intended for qualified installers who need to
install the RS2000. Installers should be certified technicians or
electricians.

About This Guide
ii 975-0126-01-01
Conventions Used
The following conventions are used in this guide.
Symbols Used
The following symbols are used on the product labels or in this guide.
Abbreviations and Acronyms
For a listing of abbreviations and acronyms, refer to the RS2000 Sine
Wave Inverter/Charger Operation Guide.
WARNING
Warnings identify conditions or practices that could result in personal injury or
loss of life.
CAUTION
Cautions identify conditions or practices that could result in damage to the unit or
other equipment.
Important: These notes contain information that is important for you to know,
but is not as critical as a caution or warning.
In this guide: Important information, warnings or
cautions.
On the product: Important information, warnings or
cautions with further explanation in the product guides.
AC – Alternating current
DC – Direct current
!
"
#

About This Guide
iii 975-0126-01-01
Related Information
For related materials on this Xanbus-enabled product and its available
accessories, see also:
RS2000 Sine Wave Inverter/Charger Operation Guide (975-0125-01-01)
Automatic Generator Start Owner’s Guide (975-0082-01-01)
System Control Panel Owner’s Guide (975-0083-01-01)
Xanbus System Installation Guide (975-0136-01-01)
More information about Xantrex Technology Inc. as well as its products
and services, including a complete list of Xanbus-enabled devices, is
available at www.xantrex.com
Contact Information
Telephone: [phone] (toll free North America)
1 360 925 5097 (direct)
Fax: [phone] (toll free North America)
1 360 925 5143 (direct)
Email: [email protected]
Web: www.xantrex.com

iv 975-0126-01-01

975-0126-01-01 v
Important Safety Instructions
READ AND SAVE THESE INSTRUCTIONS
The RS2000 Sine Wave Inverter/Charger Installation Guide contains
important safety instructions.
Before you install and use your RS2000 Sine Wave Inverter/Charger, be
sure to read, understand, and save these safety instructions and those in
the other product guides.
Read all cautionary markings on the inverter/charger, the batteries, and all
appropriate sections of this guide.
1. Use of accessories not recommended or sold by Xantrex Technology,
Inc. may result in a risk of fire, electric shock, or injury to persons.
2. The inverter/charger is designed to be permanently connected to your
AC and DC electrical systems. Xantrex recommends that all wiring
be done by a certified technician or electrician to ensure adherence to
the local and national electrical codes applicable in your application.
3. To avoid a risk of fire and electric shock, make sure that the existing
wiring is in good condition and that the wire is not undersized. Do not
operate the inverter/charger with damaged or substandard wiring.
4. To reduce risk of damage and injury, charge only rechargeable
lead-acid batteries (flooded, gel, or absorbed glass mat (AGM) types).
Other types of batteries may burst causing personal injury and
damage.
WARNING: Risk of injury or loss of life
The RS2000 Sine Wave Inverter/Charger shall not be used in connection with life
support systems or other medical equipment or devices.
WARNING
The following warnings identify conditions or practices that could result in
personal injury or loss of life.

Safety
vi 975-0126-01-01
5. Do not operate the inverter/charger if it has received a sharp blow,
been dropped, or otherwise damaged in any way. If the unit is
damaged, see the Warranty and Product Information section in the
RS2000 Sine Wave Inverter/Charger Operation Guide.
6. Do not disassemble the inverter/charger; it does not contain user
serviceable parts. Take it to a qualified service person when service or
repair is required. Incorrect reassembly may result in a risk of
electrical shock or fire. Internal capacitors remain charged after all
power is disconnected. For instructions on obtaining service, see the
section in the RS2000 Sine Wave Inverter/Charger Operation Guide.
7. Do not expose the inverter/charger to rain, snow, or water.
8. To reduce the risk of electric shock, disconnect all sources of AC and
DC power from the Inverter/Charger before attempting any
maintenance or cleaning. Turning off controls will not reduce this
risk.
9. The inverter/charger must be provided with equipment grounding
conductors connected to the AC input ground and chassis ground
terminals.
To reduce the risk of overheating, keep the ventilation openings clear and
do not install the inverter/charger in a compartment with limited airflow
or inadequate clearances around the unit. Refer to the RS2000 Sine Wave
Inverter/Charger Installation Guide for required clearance.
CAUTION
Cautions identify conditions or practices that could result in damage to the unit or
other equipment.
