Xerox Regal 5790 User manual

©1996 Xerox Corporation. All rights reserved.
Copyright protection claimed includes all forms and matters of
copyrightable material and information now allowed by statutory or
judicial law or hereinafter granted, including without limitation,
material generated from the software programs which are displayed
on the screen such as styles, templates, icons, screen displays,
looks, etc.
Xerox®, The Document Company®, the digitized X, and all Xerox
product names and product numbers mentioned in this publication
are trademarks of Xerox Corporation®. Other company trademarks
are also acknowledged.
Changes are periodically made to this document. Technical updates
will be included in subsequent editions.
Printed in the United States of America.

REGAL 5790 MATERIALS USAGE GUIDE iii
Table Of Contents
Introduction 1
Conventions 2
Recommended Materials 3
Not Recommended Materials 6
Applications 7
Usage Guidelines 8
Heavy-Weight Papers 8
Recycled Papers 10
Hole-Punched Papers 11
Pressure-Sensitive Labels 12
Coated Papers 13
Preprinted Papers 16
Single-Step Transfer Paper 17
Transparencies 19
Xerox Docupac Folders 21
Applications 23
Duplex Copies 23
Color Inserts 25
About Paper 27
Paper Weight 28
Grade 31
Moisture Content 32
Curl 33
Grain 35
Smoothness 36

TABLE OF CONTENTS
iv REGAL 5790 MATERIALS USAGE GUIDE
Paper Storage 37
Stacking 38
Temperature and Humidity 38
Conditioning Paper 39

REGAL 5790 MATERIALS USAGE GUIDE 1
Regal 5790 Materials Usage Guide
Introduction
This guide provides the information and guidelines that should be
used when selecting papers or other materials to be used in a 5790
Digital Color Copier/Printer. The feeding reliability and the
performance characteristics that can be expected from the 5790
when using the specified paper stocks and other selected materials
are also provided. In addition, techniques related to the use of these
specific materials are given.
The first section, Recommended Materials,contains a chart
which lists all materials that are recommended for use in the 5790.
Following this chart, a second section, Usage Guidelines,
includes guidelines for selecting and using various materials, such
as transparencies, heavy-weight paper, and the transfer paper used
for T-shirts.
The third section, Applications,provides step-by-step procedures
to use when running certain types of jobs.
The fourth section, About Paper,gives you information about
some of the properties of paper that are important to the operation of
the 5790 and the quality of the copies produced.
The last section, Paper Storage,provides useful tips for the proper
handling and storage of paper.
Xerox has an on-going materials testing program for the 5790. As
new information, materials, or recommendations become available,
they will be included in revisions to this guide. Your Xerox
representative may also advise you of materials usage information
before it can be included in a revision to this guide.
The materials with Xerox part numbers, listed in this guide, can be
purchased by calling the Xerox Supply Net at 1-800-822-2200 (in
U.S. and Canada).

INTRODUCTION
2REGAL 5790 MATERIALS USAGE GUIDE
Conventions
The following symbols are used in this guide to assist you in quickly
locating information.
The Key symbol indicates information that is important to
remember.
The 1, 2, 3 symbol directs you to specific guidelines that should be
followed to obtain the best performance.
The Checkedsymbol indicates that a material has an unqualified
recommendation for use in the 5790.
This Book and Magnifying Glassprompts you to look for the
detailed information and usage guidelines provided for the specific
material type.
A WARNINGalerts you to an operating or maintenance procedure,
practice, or condition, that, if not strictly observed, could result in
injury or loss of life.
The HOT AREAsymbol cautions you to be careful when working in
areas with this symbol. These areas may be very hot and could
cause personal injury.
A CAUTIONalerts you to an operating or maintenance procedure,
practice, or condition that, if not strictly observed, could result in
damage to equipment, destruction of equipment, or loss of data.
123. . .

RECOMMENDED MATERIALS
REGAL 5790 MATERIALS USAGE GUIDE 3
Recommended Materials
This symbol is used to indicate materials that will provide optimum
performance. The Regal 5790 was designed to provide optimum
performance with 16 to 28 lb bond paper (60 to 105 gsm).
Other materials can be used with varying degrees of success. Some
materials will run better if specific guidelines are followed.
This symbol prompts you to refer to the Usage Guidelines later in
this Guide for the type of material shown.
When using materials shown with this symbol, you should expect a
higher jam rate than when using 16 to 28 lb (60 to 105 gsm) paper.
Some of these materials will also cause image quality problems (i.e.
mottle) with certain images.
If you are uncertain of the ability of a specific material to perform well
in your Regal 5790, consult with your Xerox representative and test
the material before purchasing a large quantity.
Order Xerox materials from Xerox Supply Net, 1-800-822-2200 (in
U.S. and Canada).
Regal 5790 Recommended Materials
Material Type Description and order number
Standard Weight Papers:
24 lb Bond (90 gsm) USA and Canada:
•Xerox 24 lb Image Series LX, 8.5 x 11”, 3R3874
•Xerox 24 lb Image Series LX, 11 x 17”, 3R3877
20 lb Bond (80 gsm) USA and Canada:
•Xerox 20 lb Image Series DP, 8.5 x 11”, 3R2950
•Xerox 20 lb Image Series Smooth, 8.5 x 11”, 3R54
28 lb Bond (105 gsm) USA and Canada:
•Xerox 28 lb 4024 DP, 8.5 x 11”, 3R2353
•Xerox 28 lb 4024 DP, 11 x 17”, 3R3873

RECOMMENDED MATERIALS
4REGAL 5790 MATERIALS USAGE GUIDE
Pages 8-9
Heavy-Weight Papers:
32 lb Bond (120 gsm) USA and Canada:
•Xerox 32 lb LXC, 8.5 x 11”, 3R4811
•Xerox 32 lb LXC, 11 x 17”, 3R4813
90 lb Index (163 gsm) USA and Canada:
•Xerox 90 lb Index, 8.5 x 11”, 3R3004
•Xerox 90 lb Index, 17 x 11”, 3R5102
Other Heavy-Weight Papers •Hammermill 32 lb Laser Print, 8.5 x 11”, 10464-6
•Jupiter Thinplate 7 pt. (181 gsm) 8.5 x 11”
•Jupiter Thinplate 7 pt. (181 gsm) 17 x 11”, short grain
•Canon 90 lb, 157 gsm
Page 10
Recycled Papers:
20 lb Bond •Xerox 20 lb Recycled, 8.5 x 11”, 3R5130
•Xerox 20 lb Recycled, 11 x 17”, 3R5133
Pages 11-12
Hole-Punched Paper •Xerox 24 lb Image Series LX, 3 hole drilled, 8.5 x
11”, 3R3875
•Xerox 20 lb 4024DP, 3 hole drilled, 8.5 x 11”,
3R2193
•Xerox 20 lb Image Series DP, 3 hole drilled, 8.5 x
11”, 3R3016
•Xerox 20 lb Recycled, 3 hole drilled, 8.5 x 11”,
3R5131
Pages 12-13
Pressure Sensitive Labels Xerox Copier/Printer Labels 8.5 x 11”:
•1 up 3R4473
•8 up 3R4472
•24 up 3R4471
•30 up 3R4470
•33 up 3R4469
Pages 13-15
Coated Papers
32 lb Ultra Spec (120 gsm)
60 lb Ultra Spec (162 gsm)
USA and Canada:
•Xerox 32 lb Ultra Spec Series, 8.5 x 11”, 3R5093
•Xerox 32 lb Ultra Spec Series, 11 x 17”, 3R5094
•Xerox 60 lb Ultra Spec Series, 8.5 x 11”, 3R5095
•Xerox 60 lb Ultra Spec Series, 11 x 17”, 3R5096
Regal 5790 Recommended Materials
Material Type Description and order number

RECOMMENDED MATERIALS
REGAL 5790 MATERIALS USAGE GUIDE 5
Pages 17-18
Single-Step Transfer Papers USA:
•Xerox Image Transfer Paper, 8.5 x 11”, 3R5811
•Xerox Image Transfer Paper, 11 x 17”, 3R5812
Canada:
•Xerox Image Transfer Paper, 8.5 x 11”, 3R5025
•Xerox Image Transfer Paper, 11 x 17”, 3R5026
Other Single-Step
Transfer Papers •Air Waves Elite
•Magic Touch Mirror Image SS 500
•Paropy CL
Pages 19-20
Transparencies USA:
•Xerox Good Quality Removable Stripe, 11”, 3R3108
•Xerox Good Quality Removable Stripe 17”, 3R5821
•Xerox Premium Quality Removable Stripe, 11”,
3R5765
•Xerox Good Quality Painted Stripe, 11”, 3R5775
Canada:
•Xerox Good Quality Removable Stripe, 11”, 3R3108
•Xerox Good Quality Removable Stripe 17”, 3R5821
•Xerox Premium Quality Removable Stripe, 11”,
3R5765
•Xerox Good Quality Painted Stripe, 11”, 3R4894
Pages 21-22
Docupac Folders Xerox Docupac Folders
•White = 3R4885
•Gray = 3R4927
•Ivory = 3R4928
Regal 5790 Recommended Materials
Material Type Description and order number

RECOMMENDED MATERIALS
6REGAL 5790 MATERIALS USAGE GUIDE
Not Recommended Materials
Testing of the following materials by Xerox engineers has shown
unsatisfactory results:
Note: There are thousands of other materials available today. Most
of these have not been tested and good performance cannot be
guaranteed. If you intend to run a material that has not been
mentioned in this guide, consult with your Xerox Representative and
test the material before purchasing a large quantity.
Material Type Test Results
Dry Gum Labels Unacceptable jam rate
Paper Backed
Transparencies Unacceptable jam rate
Envelopes Unacceptable jam rate &
fuser damage
Papers heavier than 163 gsm Unacceptable jam rate
65 lb Xerox Docupac Folders Unacceptable jam rate
67 lb Vellum Bristol Cover High jam rate and poor image
quality
Xerox 3R2780 transparencies Unacceptable jam rate
