Xerox 4213 User manual

rrrr XEROX
Xerox 4213 Laser Printer
User Guide
720P40010
June 1992

Rank Xerox Limited
Parkway
Marlow
Buckinghamshire S17 1YL
England
© 1992 by Rank Xerox Limited. All rights reserved.
Copyright protection claimed includes all forms and matters of
copyrightable material and information now allowed by statutory
or judicial law or hereinafter granted, including without limitation,
material generated from the software programs which are
displayed on the screen such as styles, templates, icons, screen
displays, looks, etc.
June 1992
720P40010
Printed in the EEC.
Xerox®, Rank Xerox®, 4213 and all Xerox products mentioned in
this publication are trademarks of Xerox Corporation and Rank
Xerox Limited. Other company trademarks are also
acknowledge.
Centronics and all Centronics products mentioned in this
publication are trademarks of Centronics Data Computer
Corporation.
Data Products and all Data Products products mentioned in this
publication are trademarks of Hewlett-Packard Company.
IBM and all other IBM products mentioned in this publication are
trademarks of International Business Machines.
Hewlett-Packard and HP are registered trademarks of Hewlett-
Packard Company.
Microsoft is a U.S. registered trademark of Microsoft
Corporation.
PostScript® and all PostScript products mentioned in this
publication are trademarks of Adobe Systems.
PostScript font trademarks: Times, Helvetica, New Century
Schoolbook, and Palatino are registered trademarks of Linotype
Corporation.
ITC Avant Garde Gothic, ITC Zapf Chancery, ITC Zapf Dingbats,
and ITC Bookman are registered trademarks of International
Typeface Corporation.
WordPerfect is a registered trademark of WordPerfect
Corporation.
Changes are periodically made to this document. Technical
updates will be included in subsequent editions.
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––

European EME regulations
The Xerox 4213 laser printer meets the requirements of EN55022
Class B.
WARNING: Use of controls, adjustments or performance of
procedures other than those specified herein may result in a
hazardous radiation exposure.
This product will produce ozone during normal operation. The
ozone produced is dependent on copy volume and is heavier
than air. Providing the proper environmental parameters as
specified in Xerox installation procedures will ensure that
concentration levels meet safe limits.
The 4213 has an ozone filter built into the print cartridge.
Laser safety
The following note is to meet the local requirements of Finland
and Sweden.
LUOKAN 1 LASERLAITE
KLASS 1 LASER APPARAT
VAROITUS:
LAITTEEN KÄYTTÄMINEN MUULLA KUIN TÄSSÄ
KÄYTTÖOHJEESSA MAINITULLA TAVALLA SAATTAA ALTISTAA
KÄYTTÄJÄN TURVALLISUUSLUOKAN 1. YLITTÄVÄLLE
LASERSÄTEILYLLE.
VARNING:
OM APPARATEN ANVÄNDS PÅ ANNAT SÄTT ÄN I DENNA
BRUKSANSVISNING SPECFICERADE, KAN ANVÄNDAREN
UTSÄTTAS FÖR O SYNLIG LASERSTRÄLNING, SOM ÖVERSKRIDER
GRÄNSEN FÖR LASERKLASS 1.
Operational safety
Your Xerox equipment and supplies were designed and tested to
meet strict safety requirements. These include safety agency
examination, approval, and compliance with established
environmental standards.
XEROX 4213 LASER PRINTER USER GUIDE iii

WARNING: Improper connection of the equipment grounding
conductor can result in electrical shock.
Attention to the following notes ensures the continued safe
operation of your equipment.
Never use a multi-plug adaptor to plug multiple power plugs into
the same outlet.
Never attempt any maintenance function that is not specifically
described in this guide.
Never operate the equipment if you notice unusual noises or
odours. Disconnect the power cord from the power source
receptacle and call your Xerox customer service engineer to
correct the problem.
If you need any additional safety information concerning the
equipment or Xerox supplied materials, call your RX sales
representative.
Notice
Specifications described in this publication are subject to change
without notice. Use of some features may be limited by your
hardware or software configuration. Consult your sales
representative for details.
iv XEROX 4213 LASER PRINTER USER GUIDE

Related publications
Title
Xerox 4213 Laser Printer Programmer Reference
Xerox 4213 Laser Printer Quick Reference Guide
Xerox Coax/Twinax Option (XCTO) Programmer Reference
Helpful Facts About Paper
Xerox 4213 XES Quick Reference Card
PostScript Language Reference Manual, 1985, Adobe Systems
Incorporated, Addison-Wesley Publishing Company, Inc., Sixth
printing April, 1987
PostScript Language Design, 1988, Adobe Systems Incorporated,
Glenn C. Reid, Addison-Wesley Publishing Company, Inc., Sixth
printing April, 1988
PostScript Language Tutorial and Cookbook, 1985, Adobe
Systems Incorporated, Addison-Wesley Publishing Company, Inc.,
Fifth printing March, 1987
XEROX 4213 LASER PRINTER USER GUIDE v

Table of contents
European EME regulations iii
Laser safety iii
Operational safety iii
Notice iv
Related publications iv
Introduction xv
Conventions used in this guide xv
Variances xvi
1. Installation 1-1
Installation planning 1-1
Environmental conditions 1-1
Operating environment 1–1
Environmental conditions to avoid 1–2
General cautions 1-2
Cautions while printing 1-2
Cautions for maintenance and inspection 1-3
Cautions for the power cord 1-3
Space requirements 1-3
Power requirements 1-5
Installation procedure 1-5
Unpack and confirm the parts 1-6
Install the developer and toner cartridges 1-11
Connect the printer to the host 1-15
Connect the power cord 1-16
Install the paper trays 1-18
Print a configuration sheet 1-20
XEROX 4213 LASER PRINTER USER GUIDE vii

TABLE OF CONTENTS
2. Overview 2-1
Features 2-1
Options 2-2
Downloadable fonts 2-2
Font cartridges 2-2
Host interface options 2-2
Emulation options 2-2
Additional paper trays 2-2
High capacity feeder 2-2
Printer components 2-3
Control panel 2-7
3. Using the 4213 menus 3-1
Menu maps of the 4213 3-1
Main Menu map 3-2
Printer configuration at the Main Menu 3-4
Accessing the Main Menu 3–4
Saving the printer configuration as defaults 3–4
Resetting the printer configuration to factory defaults 3–6
Main Menu items 3-7
Printer language 3–7
Emulation 3–8
Adjustable Paper Size 3–8
Configuration Sheet 3–9
Chime 3–10
Output Offset 3–10
Auto Continue 3–11
Host Interface 3–11
Baud Rate 3–12
Parity 3–12
viii XEROX 4213 LASER PRINTER USER GUIDE

TABLE OF CONTENTS
Flow Control 3–12
Metered Data (Parallel Centronics) 3–13
Main Menu map (level 1 headings) 3–13
Printer configuration examples 3-14
A. Changing the default printer emulation 3-15
B. Changing the host interface setting 3-16
The XES submenu map 3-17
Emulation configuration 3-19
Changing the XES emulation configuration at the Main Menu 3-19
Accessing the Main Menu and selecting XES 3–20
Selecting the XES emulation configuration options 3–20
Saving the XES emulation configuration 3–21
Emulation settings for XES 3-22
XES emulation items 3-23
Number of Copies 3–23
Tray Sequence 3–23
2-sided Print Mode 3–24
Font Number Selection 3–26
Data Encoding 3–26
Line Ending 3–27
Font Rotation 3–27
Summary Sheet 3–28
Page Buffers 3–28
Language 3–30
Format Margins 3–30
Format Defaults 3–31
The LJ2D submenu map 3-31
Changing the LJ2D emulation configuration
at the Main Menu 3-33
XEROX 4213 LASER PRINTER USER GUIDE ix

TABLE OF CONTENTS
Accessing the Main Menu and selecting LJ2D 3–33
Selecting the LJ2D emulation configuration options 3–34
Saving the LJ2D emulation configuration 3–34
Resetting the LJ2D emulation configuration 3–35
Emulation settings for LJ2D 3-36
LJ2D emulation items 3-36
Number of Copies 3–37
Tray Sequence 3–37
2-Sided Print Mode 3–38
Font Number Selection 3–39
Paper Size 3–40
Orientation 3–41
Form Length 3–42
Page Buffers 3–42
Symbol Set 3–42
Emulation configuration examples 3-44
A. Changing the current emulation from XES to LJ2D 3-45
B. Temporarily placing the printer in 2-sided
printing mode for XES 3-46
C. Changing the tray sequencing mode for XES and LJ2D 3-47
Test Menu 3-48
Test Menu map 3-48
Making selections at the Test Menu 3-49
Accessing the Test Menu 3–49
Selecting Test Menu options 3–49
Test Menu items 3-50
Configuration sheet 3–50
Font Status Sheet 3–50
Start Data Monitor Mode 3–51
Stop Data Monitor Mode 3–51
x XEROX 4213 LASER PRINTER USER GUIDE

TABLE OF CONTENTS
Reset Menu 3-52
Reset Menu map 3-52
Making selections at the Reset Menu 3-52
Accessing the Reset Menu 3–53
Selecting the Reset Menu options 3–53
Reset Menu items 3-53
Emulation Reset (LJ2D and XES) 3–53
Recall Factory Defaults 3–54
Recall User Defaults 3–54
Save Defaults 3–54
Consumables Menu 3-55
Consumables Menu map 3-55
Accessing and displaying the Consumables Menu 3-55
Consumables Menu items 3-56
Reorder Cartridges (A, B, or C) 3–56
Insert Tray (1 or 2) 3–56
Add Paper to Tray (1, 2 or feeder) 3–57
4. Printing with the 4213 4-1
Printing a configuration sheet 4-1
Printing a configuration sheet manually 4-1
Reading the configuration sheet 4-4
Printing a font status sheet 4-8
Selecting the emulation 4-8
Printing an XES font status sheet 4-8
Reading the XES font status sheet 4-8
Printing the LJ2D font status sheet 4-10
Reading the LJ2D font status sheet 4-11
Selecting fonts 4-14
Selecting a default font 4-15
Saving your font selection as the default font 4-16
Font characteristics 4-17
XEROX 4213 LASER PRINTER USER GUIDE xi

TABLE OF CONTENTS
Sending a print job 4-18
Printing a full page of graphics 4-18
Last page is not ejected 4-18
2-sided printing 4-19
To return to the 1-sided printing mode 4-20
Printing from the bypass tray 4-20
Handling special papers in the bypass slot 4-21
How to use the bypass tray 4-21
Selecting the bypass tray at the printer 4-21
Setting the paper size at the Main Menu for XES 4-23
Setting the paper size at the LJ2D submenu 4-25
Using the bypass tray 4-26
Feeding paper through the bypass slot 4-26
When the manual print job is finished 4-27
Preventing manual feed problems 4-27
Printing on envelopes 4-28
Setting the envelope size at the LJ2D submenu 4-30
Selecting a landscape font for LJ2D 4-31
Using the bypass tray for envelopes 4-33
When the envelope print job is finished 4-36
Recommended image area for envelopes 4-36
Printing with transparencies 4-38
5. Care and maintenance 5-1
Paper: Important information 5-1
Label restrictions 5-2
Improper paper types 5-3
Paper curl in paper loading 5-4
Finding the paper curl 5-4
Paper loading 5-5
Changing or adding paper procedure 5-6
Handling special papers in paper trays 5-8
Handling special papers in the bypass tray slot 5-9
Paper storage 5-10
Clearing a paper jam and resuming the job 5-10
xii XEROX 4213 LASER PRINTER USER GUIDE

TABLE OF CONTENTS
Paper jam error codes 5-11
CLEAR PAPER PATH - 0820 5-11
CLEAR PAPER PATH - 0821 5-13
CLEAR PAPER PATH - 0822 5-15
CLEAR PAPER PATH - 0823 5-18
CLEAR PAPER PATH - 0824 5-19
CLEAR PAPER PATH - 0826 and 0827 5-21
CLEAR PAPER PATH - 0830 5-24
CLEAR PAPER PATH - 0831 5-27
CLEAR PAPER PATH - 0832 5-31
CLEAR PAPER PATH - 0833 5-34
CLEAR PAPER PATH - 0834 5-35
CLEAR PAPER PATH - 1020, 1021, 1022, 1023, and 1024 5-35
CLEAR PAPER PATH - 1025 and 1026 5-38
Print cartridge replacement procedures 5-41
Task 1. Cleaning the corotron 5-42
Task 2. Replacing the print cartridge 5-47
Task 3. Replacing the fuser wick 5-49
Replacing the toner cartridge 5-52
Toner cartridge replacement procedure 5-52
Replacing the developer cartridge 5-56
Developer cartridge replacement procedures 5-57
Adjusting the print density 5-63
Cleaning the printer 5-64
6. Troubleshooting 6-1
Introduction 6-1
Types of problems 6-1
Deterioration in print quality 6-1
Incomplete graphic data 6–1
Character line limit 6–5
Paper transport problems 6-6
Printer operation problems 6-9
XEROX 4213 LASER PRINTER USER GUIDE xiii

TABLE OF CONTENTS
7. Supplies: ordering information 7-1
Downloadable fonts 7-1
Downloading fonts 7-2
Font cartridges 7-3
Installing the font cartridges 7-3
Memory upgrades 7-10
Interface cable ordering information 7-11
PC compatible computers 7-12
AT compatible computers 7-12
Data set/modem and null modem 7-12
Paper tray ordering information 7-13
Supplies 7-14
Ordering supplies 7-14
Appendices A. Options for the 4213 A-1
A1. Adjustable tray A1-1
A2. High capacity feeder A2-1
A3. Xerox Coax/Twinax option A3-1
A4. PostScript emulation A4-1
A5. SIMM kit installation and removal instructions A5-1
A6. Multi Media Feeder A6-1
Glossary GLOSSARY-1
Index INDEX-1
Updates
xiv XEROX 4213 LASER PRINTER USER GUIDE

Introduction
The 4213 Laser Printer User Guide identifies the requirements for
installation and discusses printing preparations and procedures,
with examples for those procedures. It provides information on
configuring your printer to suit your individual environment.
Conventions used in this guide
Conventions used in this guide are as follows:
•WARNING: Warnings are associated with the safety of
people.
•Caution: Cautions are associated with equipment safety.
•Note designates important information that should be noted
before performing an operation or procedure.
•Keys pressed on the keyboard are shown by the applicable
symbol:
—AMenu
—B Test
—C Last Page
—D Select
—H Online
—G Reset buttons.
•Names of display screens and menus are shown in initial
capitals (for example, Main Menu).
•The terms 4213, printer, and 4213 laser printer are
interchangeable.
•The message display items are shown in all uppercase letters.
•Titles of books and related publications are italicised.
XEROX 4213 LASER PRINTER USER GUIDE xv

INTRODUCTION
•The symbol points to actions and options that do not have
numbers available within the Main Menu and submenu maps.
•In the index, the use of the lowercase “i” denotes an
illustration, the lowercase “f” means a figure and the
lowercase “t ”refers to a table.
Variances
The following differences exist between the 4213 and 4045
Model 150 laser printers:
•Pages may break differently on the two printers.
•To match rotation on the 4213, the 4045 must have an
XGRAPH cartridge installed.
•Set the page buffer to “FULL” to correctly print complex
pages.
•In XES mode, the underline character prints at the baseline
on the 4045; on the 4213, this prints under the character
descender.
xvi XEROX 4213 LASER PRINTER USER GUIDE

1. Installation
This chapter identifies the requirements for installation. The
following material is discussed:
•Installation requirements
•Checklist for contents
•Installation procedures
•Power up.
Installation planning
To help you determine the best possible location for your new
4213 laser printer, this section contains information on the
following topics:
•Environmental conditions
•Space requirements
•Power requirements.
Environmental conditions
Your printer has certain environmental requirements you must
accommodate. These requirements, as well as environmental
conditions you should avoid, are listed in this section.
Operating environment
Consider the required operating environment listed below when
planning the location of your printer. Your printer operates more
efficiently when the following environmental conditions are
maintained:
Temperature 10oC to 32oC (50°F to 90°F)
Humidity 15 to 85% relative humidity
Altitude Up to 6,560 feet above sea level (2000 metres).
XEROX 4213 LASER PRINTER USER GUIDE 1-1

INSTALLATION
Environmental conditions to avoid
You should avoid the following environmental conditions as you
plan the location of your printer:
•Direct sunlight
•Rapid temperature changes
•Direct air flow
•Heat-emitting devices
•High temperature or humidity
•Dust dirt, or poor ventilation
•Volatile gas or liquids
General cautions
•Do not put anything on the printer, such as: a flower vase, or
a filled cup or glass. Water inside the printer unit not only
results in malfunction, but also causes damage to the printer.
•Do not drop paper clips or staples inside the printer unit.
This can cause a short-circuit or malfunction.
•Do not apply mechanical shocks to the printer.
•Do not use flammable aerosol products near the printer.
•Do not disassemble or modify the printer
•Never open covers which you are not intended to open.
•Make sure the area is well ventilated, if the location of the
printer is in a closed or crowded room.
•Turn off the power and unplug the power cable immediately
in you perceive smoke or an abnormal sound or odour.
Cautions while printing
•While printing, do not turn off the power or open the top
cover or any of the doors. A paper jam or malfunction will
occur.
1-2 XEROX 4213 LASER PRINTER USER GUIDE

INSTALLATION
Cautions for maintenance and inspection
For your personal safety, you should always keep the following
cautions and directions in mind when you perform normal printer
maintenance:
•There are high voltage areas and high temperature areas
inside the printer.
•See chapter 5, “Care and maintenance,” for paper jam
clearance, maintenance and inspection of the printer, and
replacement of consumable supplies.
•Do not perform any operation other than those stated in this
manual. Any modification to the printer can cause a
malfunction or damage.
Cautions for the power cord
For your personal safety, you should always keep in mind the
following cautions and directions when handling the power cord:
•Before you plug in or unplug the cord, turn off the printer
power.
•To plug in or unplug the cord, hold the plug instead of the
cord.
WARNING: Do not touch the plug, connector, or cord with
wet hands.
•Periodically check that the following situations are stable:
— The power cord is plugged firmly into the AC outlet and
the AC inlet on the printer.
— The power cord generates no abnormal heat.
— The power cord has no worn places.
Space requirements
Allow enough open space around the printer to make operation,
supply replacement, and maintenance possible.
Printer dimensions Printer dimensions with paper trays:
Height: 48.45 cm (19.5 inches)
Width: 52 cm (20.8 inches)
Depth: 49.25 cm (19.7 inches).
XEROX 4213 LASER PRINTER USER GUIDE 1-3

INSTALLATION
Printer weight Approximately 84.7 pounds (38.12 kg), with customer
replaceable unit (CRU) cartridges and empty paper trays.
Floor space requirements Figure 1-1 shows the minimum floor space requirements for the
printer with the bypass tray.
Figure 1-1. Space requirements around printer
The dimensions of the printer with the bypass tray are:
•A = 48.25 cm (19.3 inches)
•B = 10 cm (04.0 inches)
•C = 40 cm (16.0 inches)
•D = 61 cm (24.4 inches)
•E = 133.25 cm (53.3 inches)
•F = 120.25 cm (48.1 inches)
1-4 XEROX 4213 LASER PRINTER USER GUIDE
