Installation Preparation Document (for physical installation of the product only)
Xerox DocuTech 128/155/180 HighLight Color
701P46159
October 2006
The main DocuTech 128/155/180 HLC components are:
• Sun BladeTM 2500 Controller
• CD/DVD combo drive
• color flat panel monitor
• keyboard and mouse
• Ethernet interface (10/100/1000 BaseT)
• Three printer interface cards
• Controller Stand
• Options
• 18/36 track tape drive
• Online connection
• QIC tape
• USB floppy disk drive
or
• Sun W1100Z (AMD) contoller
• CD/DVD combo drive
• color flat panel monitor
• keyboard and mouse
• Ethernet interface (10/100/1000 BaseT)
• Three printer interface cards
• Controller Stand
• Options
• 18/36 track tape drive
• Online connection
• QIC tape
• USB floppy disk drive
• Solaris 10 and DocuSP print services software
• Printer
• Black plus one highlight color*
• Xerographic engine with laser raster imaging system for
black and Light Emitting Diode for color
• Permanent housing for black dry ink; customer changeable
unit (CCU) for color dry ink
• Prints simplex or duplex
• Inverter Feeder/Stacker and up to 3 additional
feeder/stackers
• Optional Bypass Transport to provide connection to
additional finishers
* Additional dry inks, not listed on this document, will be customer
options as they become available, and will be offered under standard
Xerox terms and conditions.
Space Requirements / Service Space Envelope
The dimensions shown below are absolute minimums.
Configuration Width Depth Min total
req’d
Width x
depth
Weight
With inverter
feeder/stacker
and one
feeder/stacker
173.3
(in)
433.3
(cm)
48.8 (in)
122
(cm)
262.5 x
131.5 (in)
631.3 x
328.8
(cm)
3164 lbs
1438 kg
With inverter
feeder/stacker
and two feeder
stackers
205.6
(in)
511.3
(cm)
48.8 (in)
122
(cm)
294.8 x
131.5 (in)
737 x
328.8
(cm)
3685 lbs
1675 kg
With inverter
feeder/stacker
and three
feeder/stackers
237.9
(in)
594.4
(cm)
48.8 (in)
122
(cm)
327.1x
131.5 (in)
817.8 x
328.8
(cm)
4206 lbs
1912 kg
Optional Bypass
Transport* 20.4 (in)
51 (cm) 28.3 (in) 71 (cm) 176 lbs 80 kg
• The minimum total space required includes the required space
necessary for the Xerox service personnel to service the printer.
• A minimum of 78 inches/198 cm clearance from the floor to the
nearest overhead obstruction must be maintained.
• The printing system must be installed in a fixed location.
• Space requirements for the controller stand are 36 x 36
inches/91 x 91 cm.
• For proper operation, the printer must be perfectly level. On
floors less than two degrees out of level, a leveling kit must be
used to level the equipment. The printer will not function
properly on floors more than two degrees out of level.
• For detailed space requirements and diagrams, refer to the
DocuTech 128/155/180 HighLight Color Installation Planning
Guide.
Electrical Requirements (printer)
The printer requires:
• 60 HZ service (2 cords required)
MultiSource
2-phase, dual power cord
configuration
Voltage 208/240(4 wire) 208/240 (4 wire)
Amperage (dedicated) 50 30
Cycles 60 Hz 60 Hz
Receptacle Xerox Part No.
Receptacle NEMA Part No. 14-50R 14-30R
Receptacle Diagram
Power Cord Kit Number
Power Cord Length 15 feet 15 feet

Installation Preparation Document (for physical installation of the product only)
Xerox DocuTech 128/155/180 HighLight Color
701P46159
October 2006
• 50 Hz service
• 30 amp dedicated service (WYE): 220/380 VAC or 230/400
VAC or 240/415 VAC (3 phase)
Agency certifications: UL, cUL, CE Mark, FCC
Electrical Requirements (Controller)
The Controller requires 20 AMP dedicated service. The information
for the 20 Amp electrical service is identified below.
Controller 36 Track Tape
(Optional)
Line Options Dedicated Dedicated
Voltage 115vac 115vac
Amperage 20 20
Cycles 60 Hz 60 Hz
Xerox Receptacle Part No. 600S3703 600S3703
Receptacle NEMA Part No. 5-20R 5-20R
Power Cord Xerox Part No. 98K19950 98K19950
Receptacle Diagram
97S02370 97S02370
Installation Considerations
1. DocuTech HLC printers built in 2004 may require specific
delivery cooperation between the Xerox Service Representative
and the delivering Rigger for any doorway or hall that is smaller
than 37 inches. Please ensure that Xerox Service is informed
during the preinstallation planning process if any opening
through which the printer is to be moved is smaller than 37
inches.
2. Dedicated service is required for each component.
3. The controller can be connected to a 15 amp or 20 amp outlet.
4. The length of the cable from the controller to the printer is 16
feet (4.8 metres).
5. Do not use an adapter to connect the controller to an electrical
outlet that lacks a ground connection terminal.
6. The customer is responsible for providing the network and the
client workstation(s). The Ethernet interface on the DocuSP
controller is a auto-sensing 10/100/1000 - MB/sec twisted pair
standard (BaseT).
7. The Ethernet connection to the DocuSP controller must be
compatible with the Institute of Electrical and Electronics
Engineers (IEEE) 802.3 standard.
Paper Handling
• 16 to 110 lb. (60 to 200 gsm) cut sheet paper weights
• 8 by 10 in. to 14 x 17 in. (203 by 254 mm to 356 by 432 mm)
including A4, A3, and B4 paper sizes
• 7 by 10 in. (178 by 254 mm) optional enablement kit
• Transparencies, label stock, tab stock, carbonless paper, pre-
perforated stock
• Paper stock weights less than 16 lb. are not recommended.
• Textured stocks are not recommended.
• Some 65 lb. stocks may not fully fuse.
Input
Tray Capacity
Main tray (tray 1) 1,100 sheets 20 lb (75
gsm)
Auxiliary tray (tray 2) 600 sheets 20 lb (75 gsm)
High capacity feeders (trays 3
and 4) 2,600 sheets each 20 lb (75 gsm)
Additional high capacity feeders
(up to two optional) 2,600 sheets each 20 lb (75 gsm)
Output
Tray Capacity
Two high-capacity stackers 2,500 sheets each 20 lb
(75 gsm)
Sample tray 100 sheets 20 lb (75 gsm)
Purge tray 100 sheets 20 lb (75 gsm)
Environmental Requirements
Temperature 50 to 85 oF
(10oto 29o C)
Humidity
Non-condensation 30 to 65% RH
Heat Emission - printer 4454 BTU/Hr
(Standby)
32,770 BTU/Hr
(Operating)
Altitude (above sea level) Up to 6,000 ft
(1830 m)
Operating Supplies
Reorder No.
Dry Ink - Black 6R206 (US/CA)
Dry Ink – Blue 6R1191 (US/CA)
6R90343 (XE)
Dry Ink – Red 6R1192 (US/CA)
6R90344 (EU)
Dry Ink – Green 6R1193 (US/CA)
6R90345 (EU)
Dry Ink – Royal Blue 6R1255 (US/CA)
6R90356 (XE)
Dry Ink – Cardinal Red 6R1277(US/CA)
6R90358(XE)
Dry Ink – Cyan 6R1284(US/CA)
6R90359(XE)
Dry Ink – Magenta 6R1296 (US/CA)
6R90360 (XE)
Dry Ink – Yellow* 6R1299 (US/CA)
6R90361 (XE)
Developer (Black, Red,
Blue, Green, Royal Blue,
Cardinal Red, Cyan,
Magenta, Yellow)
NA
Fuser Blend 8R12938 (1 bottle)
8R12939 (6 bottles)
Fuser Shield 8R4077 (1 bottle)
8R7618 (6 bottles)
Dry ink waste container 93K1393
HLC developer waste bottle 604K24870 (4 bottles)
* Will be available in the near future.

Installation Preparation Document (for physical installation of the product only)
Xerox DocuTech 128/155/180 HighLight Color
701P46159
October 2006
NOTE: The formula for the DocuTech HLC fuser lubricant was
changed in 2006 to provide better image quality and to prevent image
transfer. The new fuser formula is called Fuser Shield. The Fuser
Blend and the Fuser Shield CANNOT be intermixed in a DocuTech
HLC. To change from one fuser lubricant to another requires a
service call and cleaning or replacing components. The two fuser
formulas are identified with different color bottles and caps.
PDL Compatibility
The system interprets the following data streams:
• PostScript Level 3
• HP PCL5c / HP PCL6
• ASCII
• PDF
• TIFF
If a machine is running with in-line finishing equipment, the new Fuser
Shield may contribute to poor binding at the binder glue seam.
Customers experiencing this problem can have their equipment
returned to using Fuser Blend by placing a service call to clean
and/or replace components. Do NOT place Fuser Blend in a
machine that has been using Fuser Shield.
• VIPP
• PPML
• LCDS/Metacode and IPDS will be customer options which may
be acquired as they become available, and will be offered under
standard Xerox terms and conditions.
Printing Considerations
• Monthly duty cycle is up to 4 million (DT 128 HLC), 4.5 million
(DT 155 HLC) or 6 million (DT 180 HLC). Not all features and capabilities are available with every print driver
and OS/Protocol combination. Custom software applications may
produce unexpected results.
• The Xerox Supplies Marketing Center, 1-800-822-2200, is
available for ordering Xerox supplies, including paper and other
throughput material. Other Considerations
• The Dry ink waste container supply is maintained at the
customer site by the Xerox Service Representative and is not
orderable by the customer.
• The Xerox Welcome Center at 1-800-821-2797 is available to
provide customer support.
Network Connectivity
The DT 1xx HLC supports the following connectivity:
Network Operating
System Protocol Topology
Novell 3.x / 4.x
(NDS or Bindery
mode)
IPX / SPX Ethernet
Windows NT 4.0 /
Win2000 / WinXP TCP / IP LPR Ethernet / Token Ring
AppleTalk EtherTalk Ethernet
LPD Server
(Unix Systems) TCP / IP Ethernet / Token Ring
Online Channel IBM
3211/4245 Ethernet / Token Ring
Bus and Tag
NOTE: Token Ring is not available for AppleTalk or Novell
environments.
The system supports Port Printing, and HTTP and IPP Printing
modes. Additionally, SNMP Services and DocuSP Remote Workflow
can be enabled on the customer’s network.
Print Drivers - Environments
The DT 1xx HLC supports the following print drivers:
• Windows 95/98/ME/2000/XP
• Windows NT 4.0
• MAC OS 8.6 & higher
• Solaris 2.8
Additional Optional Interface Requirements
Online – Bus and Tag supporting IBM 3211/4245 interface.
