Phaser 740 Online Service Information
1
Field Replaceable Parts
MAIN FRU LIST
It is important when ordering parts to include the following information:
■
Component's part number
■
Product type or model number
■
Serial number of the printer
Serial numbering. Particular fields in the serial number indicate the modification level of the
printer, the date of its manufacture and the sequence number of the printer produced on that
day. The serial number is coded as follows:
J LxxDMY
J indicates the headquarter country of the manufacturing company, Japan.
L indicates the modification level of the printer, ranging alpha-numerically from 0 to Z.
xx alpha-numerically indicates the sequence of the printer among the printers produce on that
day of manufacture, ranging from 01 to ZZ representing 1 to 1296 (the letters I and O are not
used).
D
alpha-numerically indicates the day of manufacture, ranging from 1 to X representing 1 to
31 (the letters I and O are not used).
M alpha-numerically indicates the month of manufacture, ranging from 1 to C representing 1
to 12.
Y numerically indicates the last digit of the year of manufacture, ranging from 0 to 9.

Phaser 740 Online Service Information
2
BACKTO MAIN
Figure 1 Front Cabinet FRUs
3102-26
1
4
2
65
4
3
7

Phaser 740 Online Service Information
3
BACKTO MAIN
Figure 2 Rear Cabinet FRUs
3102-27
3
4
6
5
2
1

Phaser 740 Online Service Information
4
BACKTO MAIN
Figure 3 Motor and fan FRUs
3102-37
1
10
9
5
87
2
6
4
3

Phaser 740 Online Service Information
5
BACKTO MAIN

Phaser 740 Online Service Information
6
BACKTO MAIN
Figure 4 Sensor, switch and flag FRUs
3102-40
1
7
2
3
4
8
5
6

Phaser 740 Online Service Information
7
BACKTO MAIN
Figure 5 Circuit board and electronic FRUs
3102-38
8
2
1
5
6
4
7
3
12
9
10
11
13
14 15 16
17
6
4
15
3

Phaser 740 Online Service Information
8
BACKTO MAIN
Figure 6 Imaging and paper feed component FRUs
3102-39
12
3
7
9
4
6
8
5

Phaser 740 Online Service Information
9
BACKTO MAIN
Kits and other hardware
Fig 1
parts Part number Serial number Effective Discont’dQty Name and description
118-9560-00 1 Spring, toner cartridge, front and
rear
2 rear springs (thick-CMYK)
1 front spring (thin-black only)
2 front springs (thin-CMY
118-9520-00 1 Hardware kit
Screws
E-rings
C-rings
Front and rear guide springs
Laser Scanner shaft and spring
(under laser scanner)
Supplies and accessories
Part
number Serial number Effective Discont’dQty Name and description
Supply 016-1684-00 1 Black toner standard cartridge
Supply 016-1685-00 1 Cyan toner standard cartridge
Supply 016-1686-00 1 Magenta tonerstandard
cartridge
Supply 016-1687-00 1 Yellow toner standard cartridge
Supply 016-1656-00 1 Black toner extended cartridge
Supply 016-1657-00 1 Cyan toner extended cartridge
Supply 016-1658-00 1 Magenta toner extended
cartridge
Supply 016-1659-00 1 Yellow toner extended cartridge
Supply 016-1663-00 1 Fuser Roll

Phaser 740 Online Service Information
10
BACKTO MAIN
Supply 016-1662-00 1 Color imaging unit
Supply 016-1660-00 1 Fuser (110 VAC)
Supply 016-1661-00 1 Fuser (220 VAC)
Supply 016-1664-00 1 Transfer roller kit
Supply 016-1665-00 1 Main charge grid
Supply 436-0282-01 1 Paper tray, Letter-size
Supply 436-0283-01 1 Paper tray, A4-size
Supply 436-0314-01 1 Paper tray, Legal-size
Supply 436-0284-01 1 Transparency tray, Letter-size
Supply 436-0285-01 1 Transparency tray, A4-size
Supply 016-1654-00 1 Transparency, Letter-size,
50 sheets
Supply 016-1655-00 1 Transparency, Metric-size,
50 sheets
Supply 016-1368-00 1 Paper, A-size, 500 sheets
Supply 016-1369-00 1 Paper, A4-size, 500 sheets
Supply 016-1704-00 1 Coated Paper, A-size, 100 sheets
Supply 016-1705-00 1 Coated Paper, A4-size, 100
sheets
Supply 016-1637-00 1 T-shirt transfer material, A-size,
100 sheets
063-3100-00 Phaser 740 User Guide (English)
063-3100-10 Phaser 740 User Guide (French)
063-3100-20 Phaser 740 User Guide (Italian)
063-3100-30 Phaser 740 User Guide
(German)
Supplies and accessories
Part
number Serial number Effective Discont’dQty Name and description

Phaser 740 Online Service Information
11
BACKTO MAIN
063-3100-40 Phaser 740 User Guide
(Spanish)
063-3100-05 Phaser 740 User Guide
(Russian)
063-3101-00 Phaser 740 Setup Guide
(English)
063-3101-10 Phaser 740 Setup Guide
(French)
063-3101-20 Phaser 740 Setup Guide (Italian)
063-3101-30 Phaser 740 Setup Guide
(German)
063-3101-40 Phaser 740 Setup Guide
(Spanish)
063-3101-05 Phaser 740 Setup Guide
(Russian)
071-0236-00 Advanced Features and
Troubleshooting (English)
063-3116-00 PhaserShare Setup Guide
(English)
063-3116-10 PhaserShare Setup Guide
(French)
063-3116-20 PhaserShare Setup Guide
(Italian)
063-3116-30 PhaserShare Setup Guide
(German)
063-3116-40 PhaserShare Setup Guide
(Spanish)
063-3102-00 Phaser 740 Service Quick
Reference Guide
063-3079-00 CD-ROM, English
Supplies and accessories
Part
number Serial number Effective Discont’dQty Name and description

Phaser 740 Online Service Information
12
BACKTO MAIN
063-3079-10 CD-ROM, French
063-3079-20 CD-ROM, Italian
063-3079-30 CD-ROM, German
063-3079-40 CD-ROM, Spanish
063-3079-70 CD-ROM, Simplified Chinese
063-3079-80 CD-ROM, Traditional Chinese
063-3079-90 CD-ROM, Korean
063-3132-00 Adobe Type Manager
063-3078-00 Drivers and Utilities, English
063-3078-70 Drivers and Utilities, Simplified
Chinese
063-3078-80 Drivers and Utilities,Traditional
Chinese
063-3078-90 Drivers and Utilities, Korean
012-1379-00 Cable Serial, 9-pin to 9-pin
012-1299-00 Cable, interconnect., 2.5 m
50-pins. to 25-pins
012-1468-00 Cable, Parallel w/IEEE 1284C
(mini)
012-1465-00 Cable, SCSI II to 50-pin SCSI
012-1380-00 Cable, Serial, 9-pin to 25-pin
013-0299-00 Parallel cable adapter (standard
to mini)
003-1496-00 1 Toner Vacuum (115 VAC)
003-1497-00 1 Toner Vacuum (220 VAC)
003-1498-00 Filter for 3M Toner Vacuums
Supplies and accessories
Part
number Serial number Effective Discont’dQty Name and description

Phaser 740 Online Service Information
13
BACKTO MAIN
003-1623-00 Spring removal tool
003-0619-00 1 DIP IC removal tool
003-1633-00 PLCC IC removal tool
013-0297-00 1 SCSI cable adapter, 50-pin to
SCSI II
103-0030-00 1 Adapter, T-Connector, BNC
011-0123-00 1 Coaxial Term. 50 ohms, BNC
161-0066-00 1 Power cord, domestic
016-1710-00 1 Cleaning kit
161-0066-09 1 Power cord, 220V Euro
161-0066-10 1 Power cord, U.K.
161-0066-11 1 Power cord, Australian
161-0154-00 1 Power cord, Swiss
161-0240-00 1 Power cord, Danish
006-7998-00 1 Conductive grease, silicon
006-7971-00 1 Imaging unit light shield/drape
065-0576-00 1 Shipping box, replacement kit
pallet, shipping carton, cushions,
rebanding kit
650-3572-00 1 Carton bands
004-4844-00 1 Shipping carton
039-0029-00 1 Copy unit, A-size
119-6003-01 1 External SCSI ZDISK Hard Disk
Supplies and accessories
Part
number Serial number Effective Discont’dQty Name and description

14
3102-26
1
4
2
65
4
3
7
Item: Part Number: Serial number: Quantity: Description:
MAIN FRU LIST
1
118-9893-00
116-0852-00
1
1
Front door with hinges (Phaser 740)
Front door with hinges (Phaser 750)

15
3102-26
1
4
2
65
4
3
7
Item: Part Number: Serial number: Quantity: Description:
MAIN FRU LIST
2
118-9892-00
1
Upper front cover (operation panel) w/
display board

16
3102-26
1
4
2
65
4
3
7
Item: Part Number: Serial number: Quantity: Description:
MAIN FRU LIST
3
118-9537-00
1
Right side cover rear

17
3102-26
1
4
2
65
4
3
7
Item: Part Number: Serial number: Quantity: Description:
MAIN FRU LIST
4
118-9208-00
1
Right side cover front

18
3102-26
1
4
2
65
4
3
7
Item: Part Number: Serial number: Quantity: Description:
MAIN FRU LIST
5
118-9894-00
1
Right side cover lower

19
3102-26
1
4
2
65
4
3
7
Item: Part Number: Serial number: Quantity: Description:
MAIN FRU LIST
6
118-9541-00
1
Bottom front cover

20
3102-26
1
4
2
65
4
3
7
Item: Part Number: Serial number: Quantity: Description:
MAIN FRU LIST
7
116-0024-00
1
Output tray (standard)
