Xomax XM-2DTSBN6220BT User manual

XM-2DTSBN6220BT
ENGLISH
XOMAX
User's Manual

2
XM-2DTSBN6220BT
XOMAX
Thank you for purchasing one of our XOMAX products! We appreciate your con-
dence. Enjoy your brand new multimedia unit!
Please read the following manual carefully before you install and use the unit.
Please save this manual in case you will need to clarify further possible ques-
tions regarding installation and usage of our product.
We are constantly trying to keep our online-library of user's manuals for our
products up-to-date. In case you miss some information or if something should
be unclear, please visit our homepage www.xomax.de for a current version of
user's manual or contact our customer service.
i
Version 1.0
Last update 14.12.2015
Manual's version
We appreciate our environment, so to keep it safe and clean, we
do not print our manuals on paper but provide our products with
manuals in digital version created in *.pdf format.
You can nd and download them anytime on our homepage www.
xomax.de, view them on your mobile devices and print them for
yourself if needed.
Please note: Any alternations and changes of technical data or/and design
due to technical update of some models need no advertisement.
XOMAX
XM-2DTSBN6220BT

3
XM-2DTSBN6220BT
XOMAX
DE
Thema:
Index
Index 3
Safety instructions and precau-
tions 6
Specications................................. 8
Package content ............................. 9
Operating elements of the unit ........10
Operating elements .......................10
Remote control..............................12
Installation 14
Installation notes...........................14
Before the installation ....................14
Connection schedule – ISO
plug 16
ISO plug conguration 17
Socket A (power supply).................17
Socket B (loud speakers)................17
ISO cable connections 18
ISO cable .....................................18
Please note...................................18
Connection schedule – Cinch
multicore 19
ISO cable connections 20
Startup operations 21
Usage of the remote control............21
Replacement of the battery.............21
Unit on/off....................................22
Insert a microSD card ....................22
Insert a USB ash drive..................22
Insert a CD/DVD ...........................22
Factory settings.............................22
Sart the navigation ........................22
Basic functions 23
Main menu ...................................23
Scroll the pages ............................23
Scroll the lists ...............................23
Volume ........................................23
Mute............................................23
Back to the current mode ...............23
Einstellungen 24
Time Setting .................................24
Sound setting ...............................24
Equalizer ...................................24
Preset Equalizer .........................25
Fader und Balance ......................25
Wallpaper .....................................26
SWC setting..................................26
Factory Settings ............................26
Calibration....................................27
Language setting...........................27
Brightness ....................................27
Set the GPS-Path 27
Storage media 29
Index

4
XM-2DTSBN6220BT
XOMAX
DE
Thema:
Index
Supported media...........................29
Supported formats.........................29
ID3 tag (Title, Interpretor)..............30
Handling the CDs and DVDs ............30
Notes........................................30
Cleaning the discs.......................30
Radio mode 31
Radio mode ..................................31
Automatic frequency scan...............31
Store the found stations .................31
Switch AM/FM ...............................31
LOC signal sensitivity .....................32
AF funktion (Alternative Frequency) ......32
TA funktion (Trafc Announcement).......32
PTY Funktion (Programme Type) .........32
USB-, SD- and Disc- modes 33
Start the playback mode.................33
Files list .......................................33
Start the playback .........................33
Music playback mode 34
Play/Pause....................................34
Previous / next track......................34
FF / Rewind ..................................34
Repeat track .................................34
Random playback ..........................34
Video playback 35
Display the OSD Video menu...........35
Start DVD playback........................35
Play/Pause....................................35
Previous / next track......................35
FF / Rewind ..................................35
Select track directly (GOTO)............35
Repeat track .................................35
Random playback ..........................35
Switch the subtitles .......................36
Switch the soundtracks ..................36
Call up the DVD menu....................36
DVD video zoom in / out.................36
Picture viewer mode 37
Open the picture ...........................37
Display the options ........................37
Pause / resume the slide show ........37
Previous / next picture ...................37
Select le directly (GOTO) ..............37
Zoom in / out................................37
Bluetooth connection 38
Start Bluetooth mode.....................38
Pairing the unit with an external
device..........................................38
Common information .....................38
Make a call ...................................38
Take a call ....................................39
End / reject the call .......................39
Phone book...................................39
Load the data from the external
phone .......................................39
Dial the number from the book.....39
Search within the book................39
Phone protocol ..............................40
Bluetooth music 40
Common information .....................40
Start Bluetooth music ....................40

5
XM-2DTSBN6220BT
XOMAX
DE
Thema:
Index
Rear view camera
(optional) 41
Common information .....................41
Connection ...................................41
Start the rear view camera mode.....41
AV-IN Mode 42
Common information .....................42
Start the AUX mode .......................42
Common solutions 43
Disposal / recycling
information 45
Disposal of an old unit / battery.......45

6
XM-2DTSBN6220BT
XOMAX
DE
Thema:
Safety instructions and precautions
Safety instructions and
precautions
!
Handling by stop only
To avoid any accidents please don't
handle the unit while you driving.
Please stop and park the vehicle
at safety place and handle the unit
casually.
!
Installation
Please read the following manual
carefully before you install the
unit. We recommend you to let the
technician install the unit in your
vehicle.
!
Regular loudness
Please set the loudness of the unit
to the appropriate level so you were
still able to hear exterior noises
especially trafc warning signals.
Furthermore the higher loudness
level can damage your hearing
organs.
!
Repair of the unit
Do not open the unit. Do not try to
repair the unit by yourself due to
any emerging technical problems.
While opening the unit by yourself
exists the danger to be electrocuted.
Do not use the unit any further since
you detect any kind of technical
problems. Leave all the repair opera-
tions to professional technicians.
Due to awed warranty seal the
warranty becomes invalid.
!
Power supply
Use the unit connected only to 12 Volt
on-board power supply. The minus (-)
should be connected with the ground
(GND) (negative).
Due to the wrong grounding exists the
danger of re. In case of doubt please
consult with professional technicians.
!
Replacement of fuses
While replacing the fuse please make
sure that the new fuse has the same
properties as the old one, especially the
amperage.
!
Overheating
Do not occlude the vent holes to avoid
the heat generation and accumulation
in the unit. Otherwise exists the danger
of re.
!
Regular temperature
Please make sure that the temperature
inside the vehicle amounts to not more
than +60 C. If it's too hot inside the
vehicle, do not turn the unit on until
the inside temperature of the cabin
descends.
!
Cleaning of the unit
!

7
XM-2DTSBN6220BT
XOMAX
DE
Thema:
Safety instructions and precautions
Please keep the unit clean and remove
the dust from it regularly. Please use for
that a soft and dry cleaning rag.
Major soilings can be removed carefully
with the wet cleaning rag. Do not use
any chemical or alcohol-containing
detergents to avoid the damage of the
unit's varnish.
!
Handling the touchscreen
Do not press the touch keys or other
symbols too hard – it may lead to image
distortions, unit malfunctions and
touchscreen damages.
Do not use any sharp articles to use
the touchscreen. Please handle the
touchscreen with your nger or with the
appropriate stylus.
!
Moisture
To avoid the danger of re or the
electric shock do not put the unit in to
the moist environment (e.g. adverse
weather conditions, inappropriate wet
cleaning etc.)

8
XM-2DTSBN6220BT
XOMAX
DE
Thema:
Safety instructions and precautions
Any alternations and changes of
technical data or/and design due
to technical update of some mo-
dels need no advertisement. Errors
expected.
Specifications
Allgemeine Daten
Operating voltage ........................... 12V DC
Fuse ................................................... 15 A
Button illumination color ....................... blau
Installation size .............. 2DIN (Doppel DIN)
Audio
Output power ........................... 4 x 60 Watt
Loudspeaker impedance ..................... 4 Ohm
TFT LCD Bildschirm
Diagonal ........................ 6,2 Zoll (ca.16 cm)
Image ratio ................... 16:9 Breitbildformat
Resolution ........................... 800 x 480 Pixel
Typ .................. TFT LCD Touchscreen Monitor
FM-Radio Receiver
Frequency range .................. 87.5 - 108 MHz
AM-Radio Receiver
Frequency range .................. 522 - 1620 KHz
USB-port
Plug type ........................................... Typ A
Max. supported volume ..................... 128 GB
Filesystem ............................... exFAT, FAT32
SD-card slot
Plug type ..... MicroSD, MicroSDHC, MicroSDXC
Max. supported volume ..................... 128 GB
Filesystem ............................... exFAT, FAT32
Bluetooth
Version ..................................... 2.0 Class 2
Prole ............................ Freisprechen, A2DP
Frequency ........................ 2.4GHz Spektrum
Navigation
Maps .............................................. Europa

9
XM-2DTSBN6220BT
XOMAX
DE
Thema:
Safety instructions and precautions
Package content
Please check the accessories on
completeness:
A radio
B remote control and Stylus
C 2DIN cage and trim
D installation manual
E GPS-aerial
F Navigation software on the micro SD
memory card
G ISO cable
H Mounting material
A C
FED
G
H
B
The images serve as example. Optically the may vary from the original.
Please note: the package content
may vary due to technical updates.
i

10
XM-2DTSBN6220BT
XOMAX
DE
Thema:
Safety instructions and precautions
Operating elements of the unit
Operating elements
1PWR / VOL / MENU Power/volume/
main menu
Press this button will turn on power,
during working longer press this button
will turn offpower.
On any mode, shortly press will return
main menu.
2GPS navigation mode
Switches to navigation mode.
3MUTE
Press this button to turn off volume
output, press it again to restore the
previous volume level.
Long press MUTE button to turn off TFT
screen, and short press it so that TFT
screen shall be re-lit.
4SD CARD microSD card slot
The indicated with "SD" card slot is
reserved for the user's own micro SD-/
SDHC- memory cards (in exFat or Fat32
le system, 128GB max.) with the
customer's personal multimedia content
such as music, pictures, videos.
5USB USB slot
Insert USB removable device so as to
read audio/video files.
Warning: You can only use either front
or rear USB at a time. Never connect
both front and rear USB at the same
time! This could cause malfunctions.

11
XM-2DTSBN6220BT
XOMAX
DE
Thema:
Safety instructions and precautions
6AUX AUX
To input external audio.
Warning: You can only use either front
or rear AUX at a time. Never connect
both front and rear AUX at the same
time.
7RST reset
Deletes all the customer's adjustments
and sets the unit back to factory
settings.
8IR Infrared
9MIC bluetooth microphone
Is used during hand-free phone calling
via Bluetooth. The microphone should not
be blocked to achieve the best possible
sound quality.
AMAP GPS MicroSD-Slot
Insert map card to read navigation map
data.
B1eject
When there is a disc inside the unit,
press the button can eject the disc.
CFM/AM Radio band switch
Press the button to switch to the radio
mode. In radio mode, band is switched
when the button is pressed.

12
XM-2DTSBN6220BT
XOMAX
DE
Thema:
Safety instructions and precautions
Remote control
1. PWR Press once to switch on, press
again to switch off.
2. MUTE Press once to turn off audio
output, press again to resume
volume level.
3. NAVI Press it to enter to exit the
navigation.
4. SOURCE Press this button to
choose audio sources.
5. EQ Press this button to choose
POP, ROCK, CLASSIC, EQ off.
6. SEEK-/8 and SEEK+/7
In normal playback MP3, USB, SD
songs, press this button to previous
song or next song.
7. VOL- / VOL+ Press this button to
increase or decrease volume level.
8. SEL Press this button to choose
sound feature.
9. LOUD Press this button to startup
LOUD function.
10. BAND In radio mode, press this
button to choose band.In VCD, DVD
mode, press this button to choose
AUTO, PAL or NTSC system.
11. LOC/RDM In radio mode, press this
button to switch between local and
direction, In VCD, CD mode, press
this key to randomly play.
12. • Press this button to stop
playing.
13. < Press this button to switch
between play and pause, In stop
mode, press this button to play.
14. ST In radio mode, press this button
to choose stereo or mono station. In
audio mode, it can help stop button
to programmed play.
15. 0-9 Press this button to choose
desired song, section, preset
stations. Decimal numbers, for
example the 19th song, press 10+
and 9 button.
16. AMS/RPT In radio mode, press this
button to browse stored stations.

13
XM-2DTSBN6220BT
XOMAX
DE
Thema:
Safety instructions and precautions
In audio mode, press this button to
play repeatedly.
17. TITLE In DVD mode, press this
button to play back to the top menu
of disc.
18. AUDIO In DVD mode, press this
button to switch language of
dialogue. In VCD mode, press this
button to choose left track, right
track,and stereo.
19. GOTO In DVD mode, press this
button, you can dene playing time.
20. SUB-T In DVD mode, press this
button to switch language of subtitle.
21. PBC In VCD mode, press this
button to display all song menus,
work with number button to choose
songs.
22. Š > ‰ ‹ When playing MP3, USB,
SD returns to song menu, up, down
selections can be up ‰ button or
down ‹ key to select up and down,
select and press ENTER key to
conrm. The selected tracks can be
played. Press the left or right arrow
keys to Š or > key, can be on the
next page function operation.
23. SLOW In audio mode, press this
button to slow backward and slow
forward.
24. ANGLE In DVD mode, press this
button to change play angle.
25. SETUP In audio mode, press this
button to choose different set items.
26. OSD Press this button to display
the title chapter and the left time.
27. ZOOM In DVD/VCD mode, press
this button to ZOOM in/out.
28. MENU Press button to back to the
main menu.

14
XM-2DTSBN6220BT
XOMAX
DE
Thema:
Installation
Installation
Installation notes
Here you can nd relevant installation
notes and common information.
Before the installation
WARNING!
Please read the following manual care-
fully before you install the unit.
Damages caused due to an inapprop-
riate installation will not be covered by
warranty.
If you do not want to risk your warranty
entitlement, please let the technician
install the unit in your vehicle.
»To avoid a short circuit please
disconnect the vehicle battery before
the installation. To do it properly please
read the manual of your vehicle.
The detailed installation manual
you can nd on our homepage www.
xomax.de.
The printed version of a common
installation manual you can nd in
the package.
i
!
»Make sure that your vehicle is
equipped with a car radio slot of
required size (2DIN)
»As may be the case you will need a
suitable faceplate, adapter or other
accessories. These could be provided
from your local specialist supplier.
»The connection cables may not be cutted
or short-circuited. Otherwise the warranty
becomes invalid.
»Before the installation please make
sure that your vehicle has the 12 Volt
on-board power supply.
»The minus (-) should be connected
with the ground (GND) (negative).
»Please tag the polarity of the avai-
lable speakers before you disconnect
the vehicle battery.
»A proper grounding of the unit's
housing requires a clean ground
connection. Thus the grounding area
should be rust-, stain- and dust-free.
»Please ground the cable separately
from other heavy current devices such
as an amplier etc.
»Please ensure that the colored cables
are connected according to the wiring
diagram. The wrong wiring may lead to
malfunctions or even damages of the
electric elements of the vehicle.
»Please note that the connection
cables of this unit and of the other
devices may have the same purpose
but the different color. For this reason
while connecting this unit with the
We recommend you to let the
technician install the unit in your
vehicle.
!

15
XM-2DTSBN6220BT
XOMAX
DE
Thema:
Installation
other devices please ensure that both
of the cables in each case have the
same purpose. To connect everything
correctly please refer to the manuals of
the both devices.
»Please ensure that the negative
speaker cable is in each case connected
with the negative speaker terminal of
the ISO port. Do not ever connect the
negative speaker cables with the vehicle
body.
»This unit is designed and construed
for connection with 4 speakers. Do not
combine this unit with devices that are
designed and construed for connection
with 2 speakers.
»The speakers should feature the
impedance of 4-8 Ohm and a sufcient
wattage.
»Please ensure that the speakers you
are connecting with the unit are intact.
Damaged speakers can impair the unit.
»To avoid a short circuit please isolate
all cable junctions and endings of the
unused cables with the electrical tape.
»All the cables should be layed and
xated tidy and properly. The cables
should not contact any movable or hot
objects.
»If your vehicle doesn't have an "ACC"
ignition position, please connect the red
cable with the ignition switch. Other-
wise the unit will not turn off automati-
cally, causing the discharging of the
vehicle battery.
»To avoid a rogue and hazardous
short circuit do not lay the yellow cable
through the engine bay in order to
connect it with the vehicle battery.
»Do not ever connect speaker cables
among one another. In case you do not
want to connect all the 4 speakers with
the unit please isolate the endings of
unused cables with the electrical tape
to prevent a short circuit.
»Do not ever connect the negative
speaker cables with the vehicle body.
»To ensure a awless performance of
the unit the intergration angle should
amount to +/- 30.

16
XM-2DTSBN6220BT
XOMAX
DE
Thema:
Connection schedule – ISO plug
Connection schedule – ISO plug

17
XM-2DTSBN6220BT
XOMAX
DE
Thema:
ISO plug configuration
2 1 2 1
4 3 4 3
6 5 6 5
8 7 8 7
A
B
Socket A (power supply)
On the A side you can nd the socket
for power supply.
A1 – spare
A2 – spare
A3 – spare
A4 - +12V battery / steady plus (yello)*
A5 – (+) electric antenna (blue)
A6 – spare
A7 - +12Volt ignition plus (red)*
A8 – (-) minus / ground (black)
* - Some vehicle manufacturers use
their own pin assignment. Especially
the terminals A7 (ignition plus) and A4
(steady plus) are often interchanged.
The incorrect connection in this case
leads to following problem: the unit
can not be turned on if the ignition is
off and all the saved settings are lost
as soon as the unit will be turned off. If
these problems appear the connections
A4 and A7 should be interchanged.
Socket B (loud speakers)
On the B side you can nd the speakers
terminals.
B1 – (+) rear right (violet)
B2 – (-) rear right (violet/black)
B3 – (+) front right (white)
B4 – (-) front right (white/black)
B5 – (+) front left (gray)
B6 – (-) front left (gray/black)
B7 – (+) rear left (green)
B8 – (-) rear left (green/black)
The terminals are coloured by pairs, in
each case one (+) and one (-).
Though the design of ISO plug is
standardized, it's pin assigment is not
and may vary. Thus in case of mis-
match of connections due to different
pin assignments a simple plug'n'play
connection may lead to grievous errors.
!
ISO plug configuration

18
XM-2DTSBN6220BT
XOMAX
DE
Thema:
ISO cable connections
12
We recommend you to let a
professional technician install the
unit in your vehicle.
!
ISO cable connections
ISO cable
1. Terminal plug
This plug connects the ISO cable
with the unit.
2. ISO plug
This plug connects the ISO cable
with the vehicle. The ISO cable as
such serves as an extension cable
for an eased connection of the unit
to the vehicle provided that the
vehicle has a standardized ISO plug
with the appropriate pin assignment.
Please note
»The multicore cable may vary depen-
ding on the current model. Though the
conguration of the loud speakers- and
power supply- cables (steady plus,
ignition plus, ground) is consistent.
»Certain patches could be possibly
found not only on the ISO interface
(socket/plug), but immediately on the
device, e.g. ports for the handbrake,
rearview camera, steering wheel
remote control etc.
»The ISO port may be already inte-
grated in certain units. In this case
an additional ISO cable becomes
unnecessary.

19
XM-2DTSBN6220BT
XOMAX
DE
Thema:
Connection schedule – Cinch multicore
Connection schedule – Cinch multicore

20
XM-2DTSBN6220BT
XOMAX
DE
Thema:
ISO cable connections
ISO cable connections
We recommend you to let a
professional technician install the
unit in your vehicle.
!
ISO plug
This plug connects the ISO cable with
the vehicle. The ISO cable as such
serves as an extension cable for an
eased connection of the unit to the
vehicle provided that the vehicle has a
standardized ISO plug with the approp-
riate pin assignment.
Terminal plug
This plug connects the ISO cable with
the unit.
