Xpand DLP LINK X102 User manual

XPAND DLP® LINK™3D GLASSES
Model No X102
User Guide

© Xp a n D, All Rights Reserved. 3 www.xpandcinema.com
What’s Included
Glasses »
Extra battery »
Battery key »
»
Getting to Know Your Xp a n D 3D Glasses
Picture 1: X102 Overview
Xp a n D DLP-Link™ 3D Glasses can only be used with DLP-Link™ 3D ready
TV Sets and DLP-Link™ Projectors. For the current list of supported systems
please visit our web site: www.xpandcinema.com. This product can be worn
over prescription glasses, but it cannot be used as sunglasses.

© Xp a n D, All Rights Reserved. 3 www.xpandcinema.com
What’s Included
Glasses »
Extra battery »
Battery key »
»
Getting to Know Your Xp a n D 3D Glasses
Picture 1: X102 Overview
Xp a n D DLP-Link™ 3D Glasses can only be used with DLP-Link™ 3D ready
TV Sets and DLP-Link™ Projectors. For the current list of supported systems
please visit our web site: www.xpandcinema.com. This product can be worn
over prescription glasses, but it cannot be used as sunglasses.

© Xp a n D, All Rights Reserved. 4 www.xpandcinema.com
© Xp a n D, All Rights Reserved. 5 www.xpandcinema.com
Getting Started
Set your playback device to 3D mode.1.
Turn on your 2. Xp a n D 3D glasses (refer to Picture 1) and place them on
your head. That’s it! You are ready to start enjoying your 3D experience.
Stereoscopic Vision and 3D
When you see the world through both eyes, you are actually looking at two
pictures merged into one. Your right eye and your left eye each deliver a
separate image to your brain, which meshes these two images into one
three-dimensional picture.
Most movies in the past were only able to provide one image on the screen.
Thus 3D effects have to be simulated by other means. Your Xp a n D 3D
glasses, however, are able to provide a different view for each eye, more
closely simulating true 3D vision.
Each scene of your 3D content has two images, one drawn from a right-eye
view and the other from a left-eye view. Your display shows these alternating
views so fast that your eyes cannot see the change.
Your Xp a n D 3D glasses are equipped with shutters in each lens. So, when
the right-eye image is displayed on the screen, the left lens of your Xp a n D
3D glasses is closed, allowing only the right eye to see the image. When
the left-eye image is displayed, the process is reversed and only the left
eye can see the image. These images alternate so quickly that the eye sees
only one smooth picture, making it look like you are actually inside a 3D
environment.
What do I need for viewing 3D?
3D content (movies, video games, etc.) »
A 3D Playback Device (PC, gaming console, Blu-Ray player, etc) that »
matches the requirements of your display or projector
A 3D Enabled DLP-Link™ or a 3D Enabled DLP projector »
Xp a n D » DLP® Link™ 3D glasses

© Xp a n D, All Rights Reserved. 4 www.xpandcinema.com
© Xp a n D, All Rights Reserved. 5 www.xpandcinema.com
Maintenance of Your Xp a n D 3D Glasses
Your Xp a n D 3D glasses represent the state of the art in high-speed optical
switching technology. With proper care they should give you many years of
trouble-free operation of 3D viewing enjoyment.
Turning On/Off Your Glasses
To turn your glasses ON lightly pass or brush your fingers along the right
side (outside) of your glasses frame over the Xp a n D logo (see the power on
logo). The glasses will turn off automatically after 5 minutes when they stop
receiving the stereo synchronization signal from your TV or projector.
Low Battery Warning (see also Storing your glasses, page 4)
The battery warning is intended to trigger when the battery level falls below
2.6V.
The battery level is tested when entering either the off mode or the turn on
mode. (1) If a low battery is detected when entering the off mode, the lens
will flash in an alternating pattern from one to the other at about 1 cycle per
second. (2) If a low battery is detected when entering the turn on mode the
lens will flash alternating clear three times. Since turn on is accomplished
when the lenses are dark, the light flashes are kept to a minimum. So the
flashes are only long enough to be seen; for a few seconds.
Handling
As with any optical device you should use care to prevent damage to the
optical elements of your Xp a n D 3D glasses. The lenses are sensitive and
can be cracked if the glasses are rotated or twisted. The glasses should
be held by the frame in order to avoid getting fingerprints on the lenses or
scratching them.
Don’t leave your Xp a n D 3D glasses unprotected. Store the 3D glasses away
from dust and moisture.
Avoid stressing the Xp a n D 3D glasses, frames, and lenses. Do not stretch
or bend the frames.
Do not scratch the lenses.

© Xp a n D, All Rights Reserved. 6 www.xpandcinema.com
© Xp a n D, All Rights Reserved. 7 www.xpandcinema.com
Storing Your Xp a n D 3D Glasses
It is recommended that the glasses be stored away from any light sources
such as fluorescent lights or be covered so that unintended light does not
keep the glasses in the on-mode, thus draining the battery. Under certain
2D viewing conditions the glasses may flicker randomly if the projector is
not in 3D Sync mode. The storage temperature should be standard room
temperatures as high temperature environments can reduce battery life.
Changing the Battery
The lenses of your glasses will cease to turn on when the battery is
discharged. For the optimal viewing experience, please replace the battery
when this happens.
Step by step replacement:
Place the key as shown below. 1.
Turn the key counterclockwise (left) about 1/8 of a turn.2.
Remove the old battery. 3.
Insert the new battery inside the compartment.4.
Place the key on the battery and turn it clockwise (right) about 5.
1/8 of a turn.
Remove the key.6.
Each battery will last for approximately 120 hours depending on your
usage.
Your glasses come with an extra battery. Please store it in a dry, safe place.
Additional batteries can be ordered at www.Xp a n D3dtv.com or purchased
locally from Xp a n D dealers.
Glasses Range
The range of your glasses, how far you can sit from your screen, is based on
several factors including:
Ambient light: other light sources in the room »
If you are using a projector, the gain level of your screen »
Note – this will affect off-axis performance as you get further off to the »
side.
The ANSI Lumens (brightness) rating of your projector Below is a chart »
that provides range estimates based upon a projector screen gain of
1.0:
Extended white-light range: this range can vary from 50’ »
to 100’. »
Example: 100 ANSI Lumens = 2 feet (extended range model - 1/2 for SUBA
or SUBB serial number code).
ANSI Lumens*Range in feet
2500 40-50
3000 50-60
3500 60-70
4000 70-80
5000 90-100
* consult your projector or TV manual for your device’s ANSI Lumens rating. Actual
ranges may vary due to projector output.

© Xp a n D, All Rights Reserved. 6 www.xpandcinema.com
© Xp a n D, All Rights Reserved. 7 www.xpandcinema.com
Your glasses come with an extra battery. Please store it in a dry, safe place.
Additional batteries can be ordered at www.Xp a n D3dtv.com or purchased
locally from Xp a n D dealers.
Glasses Range
The range of your glasses, how far you can sit from your screen, is based on
several factors including:
Ambient light: other light sources in the room »
If you are using a projector, the gain level of your screen »
Note – this will affect off-axis performance as you get further off to the »
side.
The ANSI Lumens (brightness) rating of your projector Below is a chart »
that provides range estimates based upon a projector screen gain of
1.0:
Extended white-light range: this range can vary from 50’ »
to 100’. »
Example: 100 ANSI Lumens = 2 feet (extended range model - 1/2 for SUBA
or SUBB serial number code).
ANSI Lumens*Range in feet
2500 40-50
3000 50-60
3500 60-70
4000 70-80
5000 90-100
* consult your projector or TV manual for your device’s ANSI Lumens rating. Actual
ranges may vary due to projector output.

© Xp a n D, All Rights Reserved. 8 www.xpandcinema.com
© Xp a n D, All Rights Reserved. 9 www.xpandcinema.com
Limited Warranty Coverage
What IS Covered
If your product does not work properly because of a defect in materials or
workmanship, Xp a n D (referred to as “the warrantor”) will, for the length of the
period on the chart below, which starts with the date of original purchase
(“warranty period”), at its option either (a) repair your product with new or
refurbished parts, (b) replace it with a new or a refurbished equivalent value
product, or (c) refund your purchase price. The decision to repair, replace
or refund will be made by the warrantor.
Product Parts Labor
XpanD DLP® Link™
3D Glasses
12 Months Not Applicable
During the “Parts” warranty period, there will be no charge for parts. This
Limited Warranty excludes both parts and labor for non-rechargeable
batteries and frame. This warranty is extended only to the original purchaser
of a new product which was not sold “as is”.
What IS NOT Covered
This warranty ONLY COVERS failures due to defects in materials or
workmanship, and DOES NOT COVER normal wear and tear or cosmetic
damage. The warranty ALSO DOES NOT COVER damages which occurred
in shipment, or failures which are caused by products not supplied by
the warrantor, or failures which result from accidents, misuse, abuse,
neglect, mishandling, misapplication, alteration, faulty installation. set-up
adjustments, misadjustment of consumer controls, Improper maintenance,
power line surge, lightning damage, modification, introduction of sand,
humidity or liquids, commercial use such as hotel, office, restaurant, or
other business or rental use of the product, or service by anyone other than
a Factory Service Center or other Authorized Servicer, or damage that is
attributable to acts of God.
THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER
“LIMITED WARRANTY COVERAGE”.
THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGE RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING
OUT OF ANY BREACH OF THIS WARRANTY.

© Xp a n D, All Rights Reserved. 8 www.xpandcinema.com
© Xp a n D, All Rights Reserved. 9 www.xpandcinema.com
(As examples. this excludes damages for lost time, travel to and from the
servicer, loss of or damage to media or images, data or other memory or
recorded content. The items listed are not exclusive, but for illustration
only.)
ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRANTY
OF MERCHANTABILITY, ARE LIMITED TO THE PERIOD OF THE LIMITED
WARRANTY.
Some states do not allow the exclusion or limitation of incidental or
consequential damages, or limitations on how long an implied warranty
lasts, so the exclusions may not apply to you. This warranty gives you
specific legal rights and you may also have other rights which vary from state
to state. If a problem with this product develops during or after the warranty
period, you may contact your dealer or Service Center. If the problem is not
handled to your satisfaction, then write to the warrantor’s Consumer Affairs
Department.
PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED
WARRANTY, ARE YOUR RESPONSIBILITY.
Length of Warranty
The above limited warranties extend for 12 months from the date the Xp a n D
3D glasses are delivered to you as the original purchaser.
What You Must Do
You must inspect your Xp a n D 3D glasses for damage before using them. If
the Xp a n D 3D glasses have been damaged in shipping, please return them
immediately to the place of purchase for replacement.
To be eligible for warranty service, you must return the Xp a n D 3D glasses
within 12 months of purchase accompanied by proof of purchase to: ATTN:
RMA Department, Xp a n D, 1017 Cole Ave, Los Angeles, CA 90038
Before returning the Xp a n D 3D glasses for warranty repair, you must obtain
a Return Material Authorization (RMA) number by contacting our Technical
Support staff at rma@Xp a n Dcinema.com. Please pack the Xp a n D 3D glasses
carefully, showing the RMA# on the outside of the box. Prepay and insure
them, because we are not responsible for them while en route to us. If you
do not insure the Xp a n D 3D glasses, you assume the risk of loss or damage
in transit. We will pay return shipping.

© Xp a n D, All Rights Reserved. 10 www.xpandcinema.com
© Xp a n D, All Rights Reserved. 11 www.xpandcinema.com
Other Conditions
The warranties set forth above are in lieu of all other implied and express
warranties, whether oral or written. The agents, employees, distributors, and
dealers of Xp a n D, are not authorized to make modifications to the warranties,
nor are any additional warranties binding on Xp a n D.
Accordingly, additional statements such as dealer advertising or
presentations, whether oral or written, do not constitute warranties by
Xp a n D, and should not be relied upon as a warranty of Xp a n D.
Warning!
Carefully read and follow all warnings in the User’s Guide to reduce health
risks associated with viewing media in 3D. Before allowing a child to view 3D
media, Parents or Guardians must read and follow the warnings and ensure
that the child understands and follows the warnings.
May Cause Epilepsy and Seizures
Some people have a condition that can cause them to experience seizures
or lose consciousness momentarily while viewing certain kinds of flashing
lights or patterns. These persons may have seizures while watching some
kinds of television pictures or playing certain video or computer games.
Persons who have not had any previous seizures may still have an undetected
seizure condition.
If you or anyone in your family has experienced symptoms linked to a seizure
condition, including experiencing seizures or a loss of awareness, consult
your physician before viewing 3D media.
We recommend that Parents or Guardians observe their children while the
children use 3D glasses. Discontinue use immediately and consult your
physician if you or your child experience any of the following symptoms:
dizziness, altered vision, eye or muscle twitching, involuntary movements,
loss of awareness, unconsciousness, disorientation, or seizures. Do not
use 3D glasses for extended periods of time.
May Cause Eye Fatigue
Some users have reported dizziness, headaches, or eye fatigue as a result
of viewing media in 3D. Discontinue use if you or your child experience any

© Xp a n D, All Rights Reserved. 10 www.xpandcinema.com
© Xp a n D, All Rights Reserved. 11 www.xpandcinema.com
of these conditions. Do not use 3D glasses for extended periods of time.
Parents or Guardians should limit use by children to no more than a few
hours per day.
Not for Use by Young Children
This product is not designed for use by children under the age of six.
Artificial stereo vision may not be safe for very young children and may cause
serious, permanent damage to their vision.
Choking Hazard: Keep Out of Reach of Small Children
Babies and young children could choke on small pieces associated with 3D
glasses. Keep the 3D glasses out of reach of small children.
Stereoscopic Viewing May Cause a Slight After-Effect in
Your Vision
Your eyes change to accommodate viewing through stereoscopic glasses.
Wait a few moments after you remove the 3D glasses for your eyesight to
return to normal before resuming your regular activities.
Don’t Use the Glasses Where Loss of Balance or Limiting
Your Field of Vision May be Dangerous to You
Do not use near staircases, ledges or balconies. You may risk falling during
or after use. Never use the 3D glasses if you already feel tired or ill.
3-D Glasses Are Only Intended for Indoor Use With
Televisions or Computers
Any other use could result in serious injury or death. Do no wear 3D Glasses
as sunglasses or safety glasses. Never wear 3D glasses while driving,
swimming, or operating machinery.

© Xp a n D, All Rights Reserved. 12 www.xpandcinema.com
© Xp a n D, All Rights Reserved. 13 www.xpandcinema.com
Optional Accessories
Xp a n D DLP® Link™ 3D Glasses Model No X102
FAQ
How do I turn the glasses ON?
Lightly brush your fingers along the outside right side of the glasses frame
over the XpanD logo. The glasses are “ON” when the lenses turn light grey
in color.
How do I turn the glasses OFF?
The glasses will turn “OFF” automatically after 5 minutes when they stop
receiving the DLP® Link™ signal from your 3D-ready projector or 3D-ready
TV and the lenses will turn green in color.
How do I know when the battery is dying or dead?
When the X102 DLP® Link™ glasses reach 20 hours of battery life, the
glasses will slowly blink, left-to-right to indicate the battery is low in power.

© Xp a n D, All Rights Reserved. 12 www.xpandcinema.com
© Xp a n D, All Rights Reserved. 13 www.xpandcinema.com
When the glasses are off, why are there spots on the lenses?
Spots on the lenses are a normal operation of liquid crystal.
Which projectors can I use the X102 DLP® Link™ glasses
with?
A projector that has the DLP® Link™ 3D ready logo. Please check with your
local dealer for an extensive list of DLP® Link™ 3D ready projectors.
Are these glasses compatible with any TV or computer?
The X102 DLP® Link™ glasses only work with Mitsubishi and Samsung
DLP® Link™ 3D ready TVs. The X102 DLP® Link™ glasses are not
compatible with any computer screens, 3D LCD TV’s or any other product
that does not bear the DLP® Link™ 3D ready logo.
Do the X102 DLP® Link™ glasses work in the movie
theatre?
They will not work in movie theaters, and movie theater glasses will not work
with your DLP® Link™ 3D ready projectors and TVs.
What can I watch with the X102 DLP® Link™ glasses?
3D Content (movies, video games, educational), 3D Playback Device (PC,
gaming console, Blu-Ray player) that match 3D Enabled Rear Projection or
DLP® Link™ 3D ready projector or TV.
Are all 3D products cross-compatible?
No, they are not, so make sure when you purchase a DLP® Link™ 3D ready
projector or TV they are designed to work with each other.
Xp a n D
1017 Cole Avenue
Los Angeles, CA 90038
[phone]
Optional Accessories
Xp a n D DLP® Link™ 3D Glasses Model No X102
FAQ
How do I turn the glasses ON?
Lightly brush your fingers along the outside right side of the glasses frame
over the XpanD logo. The glasses are “ON” when the lenses turn light grey
in color.
How do I turn the glasses OFF?
The glasses will turn “OFF” automatically after 5 minutes when they stop
receiving the DLP® Link™ signal from your 3D-ready projector or 3D-ready
TV and the lenses will turn green in color.
How do I know when the battery is dying or dead?
When the X102 DLP® Link™ glasses reach 20 hours of battery life, the
glasses will slowly blink, left-to-right to indicate the battery is low in power.
