XtraLight UV-C MOBILE Operating manual

UVCM8320254WH
UV-C MOBILE
Page 1
XtraLight Manufacturing, LTD. 8812 Frey Rd. Houston, TX 77034 [phone] F [phone] www.XLM.com
OPERATIONAL & MAINTENANCE GUIDE
UV-C MOBILE HIGH POWER ULTRAVIOLET DISINFECTION SYSTEM
All guidelines must be reviewed prior to use of equipment.
GENERAL INFORMATION
This product emits 254 nm wavelength of UVC energy. The mobile system is a germicidal
ultraviolet system that is intended to disinfect high touch surfaces and areas.
CAUTION: Observe basic safety precautions including the use of personal protective
equipment (PPE) while operating and handling the system. Please read and follow all
instructions, warnings, and safety notices. Do not expose skin or eyes to direct or indirect
UVC rays as UVC energy can be harmful to these areas.
Figure 1

UVCM8320254WH
UV-C MOBILE
Page 2
XtraLight Manufacturing, LTD. 8812 Frey Rd. Houston, TX 77034 [phone] F [phone] www.XLM.com
IMPORTANT SAFETY WARNINGS
Please read and review all safety warnings prior to use of equipment.
• WARNING – UVC Light Hazard: Direct and indirect exposure to UVC rays can cause
temporary loss of vision and sunburn. Take proper safety precautions to protect the
eyes and skin from any exposure.
• WARNING – UVC Light Hazard: The operator must cover any exposed skin and
eyes while equipment is in use. The operator should never direct the UVC rays
towards themselves or any other person.
o UVC Rated safety glasses are provided with each mobile system along with
gloves, face shield and warning sign. PPE should be used while system is in
operation. It is important to protect yourself and others from any exposure.
o People and animals without the proper PPE are forbidden to occupy any
room with this device while it is in operation.
• WARNING – Burn Hazard: Unplug the power source before replacing lamps.
• Allow lamps to cool down at least 10 minutes before removing them. Personal injury
may result otherwise.
• WARNING – Mercury Hazard: Do not break UVC lamps. Each UVC lamp contains small
amounts of mercury that can have harmful effects if exposed or ingested.
o Exposure to mercury may cause redness or irritation.
o In the case of a broken UVC lamp, sweep up the broken glass and debris into a
plastic bag and secure it with a seal.
o Dispose of used or broken UVC lamp debris at a local recycling center.
o Do not use a vacuum cleaner or incinerator to collect or dispose of any lamp
debris.
• Unplug the power source during maintenance or when system is not in use.
• Store device in a dry area.
INCLUDED IN THE BOX
• 1 UV-C Mobile High Power Ultraviolet Disinfection System with power cord
• 1 Pair UVC gasses with protective case
• 1 Pair UVC gloves
• 1 UVC face shield
• 1 UVC warning sign
• 20 Dosimeter Cards
• 8 UVC quartz lamps
• 1 Window Cling
See our YouTube Channel to access our step by step video

UVCM8320254WH
UV-C MOBILE
Page 3
XtraLight Manufacturing, LTD. 8812 Frey Rd. Houston, TX 77034 [phone] F [phone] www.XLM.com
For visual aids, please visit our YouTube Channel
UVC LAMP INSTALLATION
1. Make sure the disinfection system is disconnected from any power source before
installing the UVC lamps.
2. When handling UVC lamps, wearing lint free gloves is strongly advised. Oils from
skin contact can reduce lamp life and output if not removed prior to installation.
3. Remove the lamps from their protective sleeves.
4. Clean each lamp prior to installation to maximize the efficiency of use and lamp life.
Use isopropyl alcohol and a soft cotton cloth to wipe dust and fingerprints from the
lamp.
5. Gently insert the lamp into the lamp holder / tombstone and secure the lamps into
position on the lamp sockets by rotating the lamp until the lamp holder / tombstone
locks.
6. To complete installation, replace the wire guard and secure the securing clips to the
housing.
7. A soft, lint free cloth can be used to wipe off the reflector and lamp area to remove
any dirt, dust or fingerprints after installation.
Figure 2
For more infomation on
UV-C Systems

UVCM8320254WH
UV-C MOBILE
Page 4
XtraLight Manufacturing, LTD. 8812 Frey Rd. Houston, TX 77034 [phone] F [phone] www.XLM.com
UV-C DISINFECTION SYSTEM USE
1. The Mobile UV-C System should always be stored in its protective cover. Before
use, inspect the system for any damage. Do not use the system if lamps or cord is
broken or appear to be damaged.
2. Put on all provided PPE and roll the system into the desired location and lock the
rear wheels to keep the mobile system from movement.
3. Plug the system into a compatible power source and turn on primary system power.
A visual indicator will notify that a power source has been connected.
4. The secondary power switch Is connected to an occupancy sensor. The WiFi
enabled smart switch allows for remote system control through app connectivity.
The app is compatible with both Android and IOS and can be downloaded at
my.leviton.com, Google Play, or the Apple Store. See Figure 4 for app setup
instructions. Download the full instruction manual located on our website.
5. If you choose not to enable the WiFi switch, simply turn the power switch on and
walk away. After 30 seconds if no motion is detected, the fixture will turn on and
remain on unless motion is detected.
Figure 3

UVCM8320254WH
UV-C MOBILE
Page 5
XtraLight Manufacturing, LTD. 8812 Frey Rd. Houston, TX 77034 [phone] F [phone] www.XLM.com
Figure 4

UVCM8320254WH
UV-C MOBILE
Page 6
XtraLight Manufacturing, LTD. 8812 Frey Rd. Houston, TX 77034 [phone] F [phone] www.XLM.com
6. The onboard motion sensor is pre-programmed for a 30-second delayed start and
full motion sensor range. Knob setting can be customized following the adjustment
settings recommendations. See Figure 5 for custom settings instructions.
7. Direct the UVC energy towards specified areas and apply the recommended dosage
information required.
8. Use the Dosimeter cards to validate dosage and a visual indicator of UVC delivered
onto the target area.
The sensor instructions and My Leviton App Guide can be downloaded from our
website: https://www.xtralight.com/products/uvc-high-power-ultraviolet-disinfection-system-mobile/
Figure 5

UVCM8320254WH
UV-C MOBILE
Page 7
XtraLight Manufacturing, LTD. 8812 Frey Rd. Houston, TX 77034 [phone] F [phone] www.XLM.com
GENERAL MAINTENANCE & LAMP REPLACEMENT
• A convenient power switch is located on the device and should be turned off before
any maintenance.
• To clean, UVC lamps and reflector surfaces can be wiped down with a soft, lint free
cloth and isopropyl alcohol.
• UVC lamps should be replaced and changed annually or every 9,000 hours of
operation to maintain maximum output and effectiveness.
• To replace lamps:
1. Obtain the correct replacement lamp for your model.
2. Disconnect equipment from power source.
3. Allow lamp to cool down at least 10 minutes before removing. Personal
injury may result otherwise.
4. Carefully remove the used UVC lamp and replace with the new lamp. Refer
to the Lamp Installation Instructions above listed 1 through 8. See Figure 2.
• For broken lamps and proper disposal, follow your local safety information
regarding hazardous waste and material related to broken lamps.
https://www.epa.gov/cfl/cleaning-broken-cfl
Figure 6

UVCM8320254WH
UV-C MOBILE
Page 8
XtraLight Manufacturing, LTD. 8812 Frey Rd. Houston, TX 77034 [phone] F [phone] www.XLM.com
UV DOSE
1. Reference XtraLight’s UV Dose and Log Reduction Guide for help with determining
degree of inactivation and exposure time required to deactivate targeted
microorganisms.
https://info.xtralight.com/ultraviolet-disinfection
2. For further information regarding XtraLight's recommended steps for disinfection,
please visit https://blog.xtralight.com/uv-dosage-for-disinfection
UV-C QUESTIONS & ADDITIONAL INFORMATION
• Contact our Customer Service department at 800-678-6960 or email
[email protected]
• Visit https://info.xtralight.com/en-us/uvc-ultraviolet-disinfection-system
• FAQ https://info.xtralight.com/faq-ultraviolet-disinfection-system
• Learn More about UV https://info.xtralight.com/ultraviolet-disinfection
• Effects on Coronavirus https://blog.xtralight.com/does-uv-light-kill-the-covid19-
coronavirus
Figure 7
