NetworkXtremeRackTowerSeries
(NXRT)



User’s&InstallationManual


XtremePowerConversion™Corporation

NXRT‐1000,NXRT‐1500,NXRT‐2000,NXRT‐3000USER’SMANUALUNINTERRUPTIBLEPOWERSUPPLY(UPS)
TableofContents
IMPORTANTSAFETYINSTRUCTIONS:.................................................4
INTRODUCTION...........................................................................................6
PRODUCTDESCRIPTION..........................................................................6
SYSTEMCONFIGURATION........................................................................7
DETERMININGTHEPOWERREQUIREMENTSOFYOUR
EQUIPMENT...............................................................................................12
HARDWAREINSTALLATIONGUIDE...................................................12
RACKMOUNTINSTALLATIONSTEPS...............................................19
INITIALCONNECTIONANDSTARTUP:..............................................22
USER’SOPERATIONS..............................................................................24
TROUBLESHOOTING...............................................................................29
SPECIFICATIONS......................................................................................31
SHIPPINGLIST..........................................................................................34
OBTAININGSERVICE...............................................................................35
XTREMEPOWERCONVERSION™(XPC)CORPORATIONLIMITED
WARRANTY...............................................................................................36
APPENDIXA:EXTENDEDBATTERYPACKUSERGUIDE.............37

Thankyouforselectingthisuninterruptiblepowersupply(UPS).Itprovidesyouwithprotectionfor
connectedequipment.PleasereadthismanualbeforeinstallingtheNXRT‐SeriesUPSmodelsNXRT‐
1000,NXRT‐1500,NXRT‐2000andNXRT‐3000asitprovidesimportantinformationthatshouldbe
followedduringinstallationandmaintenanceoftheUPSandbatteries,allowingyoutocorrectlysetup
yoursystemforthemaximumsafetyandperformance.Includedisinformationoncustomersupport
andservice,ifitisrequired.IfyouexperienceaproblemwiththeUPS,pleaserefertothe
Troubleshootingsectioninthismanualtocorrecttheproblem.Iftheproblemisnotcorrected,please
collectinformationsothattheTechnicalSupportpersonnelcanmoreeffectivelyassistyou.
[2]

NXRT‐1000,NXRT‐1500,NXRT‐2000,NXRT‐3000USER’SMANUALUNINTERRUPTIBLEPOWERSUPPLY(UPS)
EMCStatements‐FCCPart15
Notice:Pursuanttosection15oftheFCCrules,thisproducthasbeentestedandtherebycomplies
totheconditionsofaClassB(NXRT‐1000,NXRT‐1500)andClassA(NXRT‐2000,NXRT‐3000)digital
device,whichhavebeenestablishedforofferingsufficientprotectionagainstdangerousinterferencefor
installationinaresidentialarea.Installationanduseoftheequipmentshouldcomplywiththe
instructionsprovidedinordertoavoidsuchinterferenceduetotheamountofradiofrequencyenergy
thatisradiatedandgeneratedbytheequipment.Inspiteofthis,wecannotassurethatacertain
amountofinterferencemaynotoccurinsomeinstallations.If,byturningonandoff,itcanbededuced
thatyourradioortelevisionreceptionisfoundtobeinfluencedbyharmfulinterferencefromthe
equipment,itisrecommendedtouseoneofthefollowingpreventivemeasures.
•Placethereceivingantennainaseparatelocationororientation.
•Ensureagreaterdistanceisachievedbetweenthereceiverandtheequipment.
•Ensurethatyourequipmentisconnectedtoanoutletonaseparatecircuitthanthe
receiver.
•ContactatechnicianexperiencedwithradioandTVoradealerforfurtherassistance.
ICES‐003
ThisClassBInterferenceCausingEquipmentmeetsallrequirementsoftheCanadianInterference
CausingEquipmentRegulationsICES‐003.CetappareilnumeriquedelaclasseBrespectetoutesles
exigenciesduReglementsurlematerielbrouilleurduCanada.
DeclarationofConformityRequest
UnitslabeledwithaULmarkcomplywiththefollowingstandardsanddirectives:
•UL1778
CAUTION:Ashielded‐typepowercordisrequiredinordertomeetFCCemissionlimitsandto
preventinterferencetothenearbyradioorTVreception.Itisessentialthatonlythesuppliedpower
cordbeused.UseonlyshieldedcablestoconnectI/Odevicestothisequipment.
WARNING:Anychangesormodificationsnotexpresslyapprovedbythemanufacturerofthis
devicecouldvoidtheuser’sauthoritytooperatetheequipment.
[3]

NXRT‐1000,NXRT‐1500,NXRT‐2000,NXRT‐3000USER’SMANUALUNINTERRUPTIBLEPOWERSUPPLY(UPS)
IMPORTANTSAFETYINSTRUCTIONS:
(SAVETHESEINSTRUCTIONS)
CAUTION!(UPShavingInternalBatteries):Riskofelectricalshock–Hazardouslive
partsinsidethisunitareenergizedfromthebatterysupplyevenwhentheinputACpoweris
disconnected.
CAUTION!(NoUserserviceableParts):Riskofelectricalshock,donotremovecover.
Nouserserviceablepartsinside.Referservicingtoqualifiedservicepersonnel.
CAUTION!(Non‐isolatedBatterysupply):Riskofelectricshock,batterycircuitisnot
isolatedfromACinput,hazardousvoltagemayexistbetweenbatteryterminalsandground.Testbefore
touching.
WARNING!(Fuses):Toreducetheriskoffire,replaceonlywiththesametypeandsizeoffuse.
WARNING!Unitintendedforinstallationinacontrolledenvironment.
CAUTION!Donotdisposeofbatteriesinafire,thebatterymayexplode.
CAUTION!Donotopenormutilatethebattery,releasedelectrolyteisharmfultotheskinandeyes.
CAUTION!Abatterycanpresentariskofelectricshockandhighshortcircuitcurrent.Thefollowing
precautionshouldbeobservedwhenworkingonbatteries:
•Removewatches,ringsorothermetalobjects.
•Usetoolswithinsulatedhandles.
Toreducetheriskofelectricshock,disconnecttheUPSfromthemainsupplybeforeinstallinga
computerinterfacesignalcable.Reconnectthepowercordonlyaftersignalinginterconnectionshave
beenmade.
Servicingofbatteriesshouldbeperformedorsupervisedbypersonnelwithknowledgeofbatteriesand
therequiredprecautions.Keepunauthorizedpersonnelawayfrombatteries.
TheseUPSunitsareextremelyheavy.DonotinstalltheUPSinarackorenclosurebyitsfronttwoears
only.Adjustablerackrailsarerequiredforthistypeofinstallation.
Theinstructionscontainedwithinthissafetymanualaredeemedimportantandshouldbeclosely
followedatalltimesduringinstallationandfollow‐upmaintenanceoftheUPSandbatteries.
[4]

NXRT‐1000,NXRT‐1500,NXRT‐2000,NXRT‐3000USER’SMANUALUNINTERRUPTIBLEPOWERSUPPLY(UPS)

 CAUTION
Theunithasadangerousamountofvoltage.IftheUPSindicatorison,theunit’soutletsmayhavea
dangerousamountofvoltageevenwhennotpluggedintothewalloutletbecausethebatterymay
continuetosupplypower.
Careshouldbetakentoundertakeinstallationindoors,freefromelectrically‐conductiveparticles
whichareundertemperatureandhumiditycontrol,inordertoreducetheriskofelectricshock.
Itisbesttodisconnectthedeviceusingthepowersupplycord.Ensurethattheequipmentisplacedin
apositionneartheoutletwhereeasilyaccessible.
Exceptforreplacingthebatteries,allservicingonthisequipmentmustbecarriedoutbyqualified
servicepersonnel.
Beforeconductinganymaintenance,repair,orshipment,firstensurethateverythingisturnedoff
completelyanddisconnected.
Foradditionalsafetyinstructions,pleaseusetheSafetyManualasareference.
SpecialSymbols
ThefollowingsymbolsusedontheUPSwarnyouofprecautions:
RISKOFELECTRICSHOCK‐Pleaseobservethewarningthatariskofelectricshockispresent

CAUTION:REFERTOOPERATOR’SMANUAL‐Refertotheoperator’smanualforadditional
information,suchasimportantoperatingandmaintenanceinstructions.

SAFEGROUNDINGTERMINAL‐Indicatesprimarysafeground

LOADON/OFF–Pressingthebuttonturnson/offtheoutputreceptaclesandtheindicator
light.
RJ45RECEPTACLE–Thereceptacleprovidesnetworkinterfaceconnectionsandtelephoneor
telecommunicationsequipmentshouldnotbepluggedintoit.
PleasedonotdiscardoftheUPSortheUPSbatteriesastheUPSmayhavevalve‐regulated
lead‐acidbatteries.Pleaserecyclebatteriesappropriately.



[5]

NXRT‐1000,NXRT‐1500,NXRT‐2000,NXRT‐3000USER’SMANUALUNINTERRUPTIBLEPOWERSUPPLY(UPS)
INTRODUCTION
Theinformationprovidedinthismanualcoverssinglephase1000‐3000VAuninterruptiblepower
systems,theirbasicfunctions,operatingprocedures,optionsavailableandemergencysituations.Italso
includesinformationonhowtoship,store,handle,andinstalltheequipment.Onlydetailed
requirementsoftheUPSunitsaredescribedherein,andinstallationmustbecarriedoutinaccordance
withthismanual.Electricalinstallationmustalsocarefullyfollowlocallegislationandregulations.Only
qualifiedpersonnelshouldconducttheseinstallationsasfailuretoacknowledgeelectricalhazardscould
provetobefatal.
PRODUCTDESCRIPTION
ManydifferentkindsofsensitiveelectricalequipmentcanbeprotectedbyanUninterruptiblePower
Supply(UPS)includingcomputers,workstations,processcontrolsystems,telecommunicationssystems,
salesterminals,othercriticalinstrumentation,etc.ThepurposeoftheUPSistoprotectthesesystems
frompoorqualityutilitypower,completelossofpower,orotherassociatedproblems.
Electricalinterferenceexistsinmanyforms,causingproblemsinACpower,fromlightning,power
companyaccidentsandradiotransmissionmotors,airconditioners,andvendingmachines.Protection
ofsensitiveelectricalequipmentisvitaltoprotectagainstpoweroutages,loworhighvoltage
conditions,slowvoltagefluctuations,frequencyvariations,differentialandcommon‐modenoise,
transients,etc.
Topreventpowerlineproblemsfromreachingcriticalsystemscausingdamagetosoftware,hardware,
andequipmentmalfunctions,theUPSmaintainsconstantvoltage,isolatingcriticalloadoutputand
cleaningtheutilityACpower.
DoubleConversionOn‐LineTechnology
Adoubleconversionon‐linetechnologyUPSprovidescompletelyisolated,clean,uninterruptedsingle‐
phasepowertoyourcriticalsystems,whilemaintainingthebatteriesfortheirmaximumpotential.In
theeventthatthepowerfailurelastslongerthantheUPSbackuptime,theUPSwillshutdownavoiding
batterydamage.WhentheinputACvoltagereturns,theUPSwillautomaticallyreturnonlineto
rechargethebatteries.
Asshowninfig.1blockdiagram:
•Aninputfilterreducestransientsontheincomingutility.
•Tomaintainfullbatterycharge,theACinputpowerisrectifiedandregulatedintherectifier
feedingpowertothebatteryconverterandinverter.
•DCpowerisconvertedtoACintheinverter,passingitontotheload.
•Powerismaintainedfromthebatteryduringapowerfailure.
•Theconverterincreasesvoltageappropriatelyfortheinverter.
[6]

NXRT‐1000,NXRT‐1500,NXRT‐2000,NXRT‐3000USER’SMANUALUNINTERRUPTIBLEPOWERSUPPLY(UPS)

Figure1–BlockDiagram
DiagnosticTests
WhentheUPSisstarted,adiagnostictestisautomaticallyexecuted,checkingtheelectronicsand
batteries,reportinganyproblemsontheLCDdisplay.Adiagnostictestcanalsobeperformedmanually
fromthefrontpanelatanytime.
SYSTEMCONFIGURATION
TheUPSdeviceandtheinternalbatteriesmakeupthesystem.Dependingonthesiteandload
requirementsoftheinstallation,certainadditionaloptionsareavailableforthesolution.
PlanningaUPSsystem,thefollowingshouldbetakenintoconsideration:
•Thetotaldemandoftheprotectedsystemshalldictatetheoutputpowerrating(VA).Allowa
marginforfutureexpansionorcalculationinaccuraciesfrommeasuredpowerrequirements.
•Backuptimerequiredwillindicatethebatterysizeneeded.IftheloadislessthantheUPS
nominalpowerrating,thenactualbackuptimeislonger.
•Thefollowingoptionsareavailable:
oExtendedBatteryPacks
NXRT‐EBP1for1000
NXRT‐EBP2for1500
NXRT‐EBP3for2000/3000
oConnectivityOptions–SNMP/WEBcard
oXtremePowerDistributionUnits(XPDU)
SeetheSpecificationsectionofthismanualforadditionalmodelinformation.
[7]

NXRT‐1000,NXRT‐1500,NXRT‐2000,NXRT‐3000USER’SMANUALUNINTERRUPTIBLEPOWERSUPPLY(UPS)



[8]

NXRT‐1000,NXRT‐1500,NXRT‐2000,NXRT‐3000USER’SMANUALUNINTERRUPTIBLEPOWERSUPPLY(UPS)


LEDDescription
TheUPShasthreeLED’sonthefrontcontrolpanel.TheseLED’sallowtheusertoquicklyunderstandif
anyactionisneeded.
RedLED
IfthisLEDisilluminateditindicatesafaultandtheUPSwillhavenooutput.Faultsthatwouldindicate
thisalarmconditioninclude:
•Overload
•Inverterfault
•BUSfault
•Overtemperaturefault

[9]

NXRT‐1000,NXRT‐1500,NXRT‐2000,NXRT‐3000USER’SMANUALUNINTERRUPTIBLEPOWERSUPPLY(UPS)
YellowLED
IfthisLEDisilluminateditindicatestheuserneedstotakesomeaction,andincluded:
•UPSinBypassMode
•BatteriesOvercharged
•Chargerfault
•Fanfault
•Batteriesdischargedtolowvoltagelevel
GreenLED
IfthisLEDisilluminateditindicatesthateverythingisnormalandtheUPSisbeingpoweredbyincoming
ACutilityorbythebatteries.
LCDDescriptions
TherearefourlinesofinformationintheLCDdisplay.Eachlineprovidesspecificinformationrelatedto
theunitstatusand/oroperation.Lineinformationwillbedescribedfromtoptobottomwiththetop
beinglineone.
LineOne
Providesdataintonumericsections,withthedatacorrespondingtotheapplicablecategoryinlineone
andtwo
LineTwo
Allowstheusertoidentifywhichvariableinformationisbeingdisplayed.
•Input
•Output
•Battery
•Load
•Temperature
LineThree
Thisisagraphicssectionwithloadgraphicsontheleftandbatterygraphicsontheright.Thefailureicon
willappearinthissectionwhenafailureoccurs.

[10]

NXRT‐1000,NXRT‐1500,NXRT‐2000,NXRT‐3000USER’SMANUALUNINTERRUPTIBLEPOWERSUPPLY(UPS)
LineFour
ThisindicatesthestatusoftheUPS.
•ONLINE=utilitymode
•ONBATT=batterymode
•ONBPS=bypassmode
•UPSOFF=standbymode
RS‐232StandardInterface
TheRS‐232interfaceusesa9‐pinfemaleD‐subconnector.Informationprovidedincludesdataabout
utility,loadandtheUPS.Theinterfaceportpinsandtheirfunctionsareidentifiedinthefollowingtable:

PIN#FUNCTIONS
1,4,6,7,8NOTUSED
2TRANSMIT
3RECEIPT
5GND
9REMOTEWAKEUP
CAUTION:MAXRATEDVALUES12VDC
SNMPCommunicationsOption
TheUPSprovidesanintelligentslotforinternalorexternalnetworkcard.Thisspecialintelligentnetwork
cardcanbecompatiblewithpopularsoftwareandhardwarefoundonthewebandinoperating
systems.ItcansupportoperatingsystemssuchasHPOpenView,IBMNetview,SUNNetmanager,etc.
ThisenablestheUPStoprovideinstantUPSandpowerinformationoverthenetwork.Pleasecontact
yourresellerforadditionaldetails.
Notes
TheUPScanbemonitoredthroughtheRS232interfaceortheSNMPcard,butonlyonewayatatime.
TheusercanchooseRS232orSNMPcommunicationsthroughthecommunicationsswitchontherear
paneloftheUPS.RS232ischoseniftheswitchisdepressedtotheRS232position,andSNMPischosenif
theswitchisdepressedtotheSNMPposition.Whentherearetwoormoremonitoredpiecesof
equipment,thegroundofeachpieceofequipmentshouldbeshared.TheSNMPcardisconfiguredas
DHCPbydefaultIPsetting.

[11]

NXRT‐1000,NXRT‐1500,NXRT‐2000,NXRT‐3000USER’SMANUALUNINTERRUPTIBLEPOWERSUPPLY(UPS)
RemoteEmergencyPowerOff(REPO)Port
AcustomersuppliedswitchlocatedremotelycanbeusedtoopentheREPOconnectionandallowsthe
UPSoutputreceptaclestobeswitchedoff.SincetheREPOshutsdowntheequipmentimmediately,
orderlyshutdownproceduresarenotfollowedbyanypowermanagementsoftware.TheUPSwillhave
tobemanuallyrestartedinordertoregainpowertotheoutletsontheUPS.
DETERMININGTHEPOWERREQUIREMENTSOFYOUR
EQUIPMENT
1. MakesurethetotalVolt‐Amp(VA)requirementsofyourconnectedequipmentdoesnotexceed
themaximumVAratingfortheUPS.ThemaximumVAratingsareshownintheSpecifications
sectionofthisdocument.
2. Ensurethattheequipmentpluggedintothebattery‐poweredoutletsdoesnotexceedtheUPS
ratedcapacity.IfUPSratedcapacitiesareexceeded,anoverloadconditionmayoccurandcause
theUPStoshutdownandtripthecircuitbreaker.
3. IfthepowerrequirementsofyourequipmentarelistedinvaluesotherthanVolt‐Amps(VA),
convertWatts(W)orAmps(A)intoVAbydoingthecalculationsbelow.Note:Theequation
belowonlycalculatesthemaximumamountofVAthattheequipmentcanuse,notwhatis
typicallyusedbytheequipmentatanygiventime.Usersshouldexpectusagerequirementsto
beapproximately60%ofthevaluetoestimatepowerrequirements:
Watts(W)x1.43=_____VAor_____Amps(A)x120=_____VA
Addthetotalsforalloftheequipmentandmultiplythistotalby0.65tocalculateactualpower
requirements.
Note:Manyfactorscanaffecttheamountofpowerthatyourcomputersystemwillrequire.The
totalloadthatyouwillbeplacingonthebattery‐poweredoutletsshouldnotexceed85%ofthe
UPScapacity.
HARDWAREINSTALLATIONGUIDE
InspecttheUPSuponreceipt.Thepackagingisrecyclable;keepitforreuseordisposeofproperly.
SafetyInformation
Informationpresentedhereisvitaltoallpersonnel.PleasereadallSafetyinformation.
StorageandTransportation
[12]

NXRT‐1000,NXRT‐1500,NXRT‐2000,NXRT‐3000USER’SMANUALUNINTERRUPTIBLEPOWERSUPPLY(UPS)
PleasehandletheUPSandassociatedequipmentwithextremecautionsinceahighamountofenergyis
containedinthebatteries.Alwayskeeptheunitinanuprightpositionasmarkedonthepackaging,and
neverdroptheunit.
PleaseadheretothefollowinginstructionsiftheUPSisnotinstalledimmediately:
•Storetheequipmentasisinitsoriginalpackingandshippingcarton.
•Donotstoreintemperaturesoutsidetherangeof‐15°Cto+25°C
•Ensurethattheequipmentisfullyprotectedfromwetordampareasandfrommoistair.
Inordertomaintainthebatteries,theUPSshouldberechargedevery6monthsforatleast8hours.
Ifflammablesubstancessuchasgasesorfumesarepresent,oriftheroomisairtight,ahazardous
situationmayexistinwhichnoelectricalequipmentshouldbeoperated.
TheinstructionsinthismanualexplainhowtoinstalltheUPSsafely.Notacknowledgingsuchelectrical
hazardsmaybefatal–keepthismanualforfuturereference.
WARNING!
ItisstronglyrecommendedthattheUPScabinetnotbeopenedascomponentshavevery
highvoltageandtouchingthosecomponentsmaybefatal.Onlyaqualifiedtechnicianor
authorizedagentmayservicetheunit.
TheUPSunit’soutputreceptaclescarrylivevoltageevenwhennotconnectedtoaninput
voltagesource.TheUPShasitsowninternalenergysource.
Environment
Ensurethatallenvironmentalconcernsandrequirementsaremetaccordingtospecificationslistedin
thisdocument,otherwisethesafetyofinstallationpersonnelcannotbeguaranteed,andtheunitmay
malfunction.
EnsurethatyourememberthefollowingwhenlocatingtheUPSsystemandbatteryoptions:
•Avoidextremesoftemperatureandhumidity.Maximumbatterylifecanbeattainedwitha
recommendedtemperaturerangeof+15°Cto+25°C.
•Provideprotectionfortheequipmentfrommoisture.
•Spaceandventilationrequirementsmustbemet.Ensurethereis100mmbehindand50mmon
thesidesoftheUPSforproperventilation.
•EnsurethatthefrontoftheUPSremainsclearforuseroperation.
[13]

NXRT‐1000,NXRT‐1500,NXRT‐2000,NXRT‐3000USER’SMANUALUNINTERRUPTIBLEPOWERSUPPLY(UPS)
Installation
Standardbrackets


[14]

NXRT‐1000,NXRT‐1500,NXRT‐2000,NXRT‐3000USER’SMANUALUNINTERRUPTIBLEPOWERSUPPLY(UPS)
19”CabinetEarInstallation



[15]

NXRT‐1000,NXRT‐1500,NXRT‐2000,NXRT‐3000USER’SMANUALUNINTERRUPTIBLEPOWERSUPPLY(UPS)
VerticalInstallationSteps



[16]

NXRT‐1000,NXRT‐1500,NXRT‐2000,NXRT‐3000USER’SMANUALUNINTERRUPTIBLEPOWERSUPPLY(UPS)
Wall‐mountedInstallationSteps



[17]

NXRT‐1000,NXRT‐1500,NXRT‐2000,NXRT‐3000USER’SMANUALUNINTERRUPTIBLEPOWERSUPPLY(UPS)
19”Rackmountusing5in1bracket




[18]

NXRT‐1000,NXRT‐1500,NXRT‐2000,NXRT‐3000USER’SMANUALUNINTERRUPTIBLEPOWERSUPPLY(UPS)
RACKMOUNTINSTALLATIONSTEPS
UPSRailInstallationInstructionsto19”Cabinet
1. 

2. 


3. 

[19]

NXRT‐1000,NXRT‐1500,NXRT‐2000,NXRT‐3000USER’SMANUALUNINTERRUPTIBLEPOWERSUPPLY(UPS)
4. 

5. 

[20]
