Yada BT532981 User manual

User Manual
Important, retain for future reference:
Read carefully
BT532981
1080PMIRROR ROADCAM
with 4.3” LCD Monitor

TF Card
8 GB
2
QUICK INSTALLATION GUIDE
1. Mount the Roadcam
Before you begin... Gather these items.
1
1
2
2
2
3 4

3
3. Connect to Power
2. Insert the MicroSD Card
3
3
4

4
Please read all of the installation instructions carefully before installing
the product. Improper installation will void manufacturer’s warranty. The
installation instructions do not apply to all types of vehicles, and are
written as guidelines to assist in installing the system.
Consult an experienced technician if you are not comfortable installing
the product. You can also contact YADA at 1.866.294.9244 to speak
to one of our installation specialists if you have any specific questions
regarding the 1080P Mirror Roadcam.
BEFORE using the 1080P Mirror Roadcam, please read the
safety information provided in this user manual. ALWAYS use
the product as outlined in this user manual.
Please make sure to read and understand all local laws and regulations
regarding Roadcams and their use in a vehicle. Laws vary by state.
INTRODUCTION

TF Card
8 GB
5
PACKAGE CONTENTS
21
3 4
1. 1 x 1080P Mirror Roadcam
2. 1 x Mounting Kit
3. 1 x 12V/24V Power Adapter
4. 1 x 8GB MicroSD Card

6
PRODUCT SPECIFICATIONS
Display: 4.3 inch display
Lens: 128 degrees diagonal
Video Resolution: FHD (1920x1080), HD (1280x720)
or VGA (640x480)
Circular Video: Seamless loop recording
Memory Card: MicroSD (maximum support 32GB)
Microphone: Supported
Built-in Audio: Supported
Operating Temperature: 14°F~140°F (-10°C~60°C)
Operating Voltage: Cigarette Charger - DC 12/24V / DC 5V (Mini-USB)
Battery: Built-in 150 mAh li-ion battery
PRODUCT DIMENSIONS
11.92” / 303mm 1.22” / 31mm
3.26” /
83mm

7
PRODUCT OVERVIEW
1. Power / Screen Saver Button
2. Menu Button
3. Mode / Back Button
4. Up Navigation Button
5. Down Navigation Button
6. OK / Record Button
7. Video Display
8. Speaker
9. MicroSD Card Slot
10. Mini-USB Power Port
11. Power Reset Hole
12. Night Vision LED
13. Directional Lens
3.26” /
83mm
10
11
13
12
8
9
13
2456
7

8
1.
2.
INSTALLATION
Place the Roadcam in front of your existing rear view
mirror and attach the rubber mounting straps to the
top anchors of the Roadcam.
Reattach the rubber mounting straps to the lower
anchors to secure the Roadcam in place. Adjust the
angle of the directional lens to get the best front view.

9
3.
4.
INSTALLATION
Plug the power cable into the Mini-USB
Power port of the Roadcam.
Route and hide the power cable in the headliner and
pillars in your vehicle. Plug the cigarette lighter adapter
into your vehicle’s 12/24V DC outlet.

10
CONFIGURATION & MENU SETTINGS
Initial Setup
Set the date & time before installing and using the Roadcam. This date &
time is the time stamp for all recorded media files and digital clock.
Switching Modes
Press the button to cycle through the following modes: video mode >
camera mode > playback mode. The Roadcam cannot switch between
modes while it is recording. Press the button to stop recording and then
press the button to switch between modes.
Video Mode
• This is the default recording setting. The Roadcam will start recording
automatically once it is turned on.
• Files are looped or recorded over by the default of 1 minute.
The MicroSD card will hold 1 minute segments and record over them as
space is needed.
• Stop loop video: press the button once to start or stop recording.
• Lock video: press the button during recording to lock that recorded file.
• Press and hold the button during recording to turn the microphone
on or off.
Note: The Roadcam will record automatically when you switch back
to video mode from other shooting modes.
G-Sensor Setting The Roadcam’s integrated G-Sensor will
automatically save and lock the recorded file if activated by an impact
event or accident. Select to adjust the G-Sensor sensitivity level, or to turn
it on or off. The default setting is low.

11
Camera Mode
• Press the button each time you want to take a picture.
Playback Mode
• Press the and button to cycle through all the media files.
• Press the button to play video files and press it again to pause.
• Press the button to select file managing options:
Delete: Select to erase current file or all files.
Protect: Select to lock/unlock current file or all files.
General Settings
Recording must be paused manually to access the general settings page. Press
the button on video mode or camera mode to open the general settings page.
Press the and button to cycle through all the settings and press the
button to change your selections.
Video Resolution FHD (1920x1080), HD (1280x720) or VGA
(640x480).
Loop Record 1minute, 3 minutes, or 5 minutes.
Camera Resolution 12M (4032x3024), 10M (3648x2736), 8M
(3264x2448) or 5M (2592x1944).
Date/Time Set the date and time.
G-Sensor High, Medium, Low or OFF.
Parking Monitor High, Medium, Low or OFF.
Language Supports English Only.

12
Motion Detection ON or OFF.
License Plate Stamp Enter your vehicle license plate number here.
Date Stamp ON or OFF.
Flash ON or OFF.
Record Audio ON or OFF.
Beep Sound ON or OFF.
Screen Save 1 minute, 3 minutes, 5 minutes or OFF.
(Screen will dim to a digital clock interface after the
specified time you select.)
Digital Clock ON or OFF.
Frequency 50Hz or 60Hz.
(Adjust this setting to prevent the flickering of lights by
selecting the frequency according to your local regulations.)
Format Select to erase all data on your MicroSD card.
Default Setting Reset to default settings.
Version Firmware version.
Regulatory Info Regulation related information.

13
Automatic ON / OFF
When the Roadcam is connected to the vehicle’s power, it will power on
and start recording when the vehicle engine starts. When the engine is
off, the Roadcam will stop recording and turn off automatically.
Gravity Induction Recording Protection System
In a vehicle collision, the Roadcam will lock the video of the accident and
save it as a special image. At the same time, the icon of a lock will be
displayed on the top left corner of the screen. The locked image will not
be overwritten by looped recordings.
Note: The G-Sensor supports sensitivity adjustment and it can be done
in the general settings page according to actual needs.
Park & Record Mode
The Park & Record mode allows the Roadcam to record videos when
an impact is detected while the vehicle’s engine is off. The Roadcam
will turn on automatically and record a 20 second video clip and then
shutdown; when it detects another impact, it will record another 20
second video clip and then shutdown until memory card capacity is
reached or the camera is running out of battery.
Note: The Roadcam will switch to Park & Record mode when the
vehicle’s engine is turned off.
Battery Indications:
Please refer to the diagram below for battery indication.
Fully charged 80% charged 40% charged
Battery low Charging
ADDITIONAL FEATURES

14
1) Problem: The Roadcam is unable to take pictures and record videos.
Solution: Check if the MicroSD card has enough space and lock it.
2) Problem: The Roadcam stopsautomatically when it is recording a
video.
Solution: Because HD video data takes a lot of space, please use a
high-speed MicroSD card compatible with SDHC, high-speed
MicroSD cards will have a C10 logo.
3) Problem: During the playback of pictures and videos, a “file error”
message prompts.
Solution: When a MicroSD card storage error or incomplete file
occurred, please use the camera’s “format” function to
reformat the MicroSD card.
4) Problem: The image looks foggy.
Solution: Please check whether there is dirt or fingerprintson the lens.
Clean the lens using lens cleaner or lens wiper before using.
Help / FAQs
Note: The Roadcam is designed to be powered on while the vehicle is
running. The built-in battery is only designed for storing documents when
the vehicle’s engine is off. The battery capacity of the built-in battery is
limited. Please connect the Roadcam to the vehicle’s on-board power
supply for daily use.

15
IMPORTANT SAFETY INSTRUCTIONS
1. SAVE THESE INSTRUCTIONS– This manual contains important
safety and operating instructions of 12V/24V cigarette lighter adapter
for Model BT532981.
2. Before using the product, read all instructions and cautionary markings.
3. Do not expose cigarette lighter adapter to rain, moisture, or snow.
4. Use of an attachment not recommended or sold by the product
manufacturer may result in a risk of fire, electric shock, or injury to
persons.
5. To reduce risk of damage to cigarette lighter connector and cord,
pull by cigarette lighter connector rather than cord when disconnecting
cigarette lighter adapter.
6. Make sure cord is carefully secured so that it will not be stepped on,
tripped over, or otherwise subjected to damage or stress.
7. Do not operate cigarette lighter adapter with damaged cord or
cigarette lighter connector – replace it immediately.
8. Do not operate cigarette lighter adapter if it has received a sharp
blow, been dropped, or otherwise damaged in any way; take it to a
qualified serviceperson.
9. Do not disassemble cigarette lighter adapter; take it to a qualified
serviceperson when service or repair is required. Incorrect reassembly
may result in a risk of electric shock or fire.
10. To reduce risk of electric shock, unplug cigarette lighter adapter
before attempting any maintenance or cleaning. Turning off controls
will not reduce this risk.
SAFETY INFORMATION

16
WARNING: A failure to read and follow these warnings and instructions
may result in a serious accident, including damaged property or a serious
injury, including loss of life.
• The 1080P Mirror Roadcam is designed as an aid to the driver in
detecting large stationary objects to help avoid damaging the vehicle.
However, you, the driver, must use it safely and properly. Use of the
1080P Mirror Roadcam is not a substitute for safe, proper and legal
driving.
• Always check behind and all around the vehicle visually with mirrors
before proceeding.
• Be sure to check the Roadcam’s position and mounting angle before each use.
• Do not strike the 1080P Mirror Roadcam. It is a precision instrument.
Otherwise, it may malfunction or cause damage resulting in a fire or an
electric shock.
• This product will only provide images of items that are within the field of
view of the 1080P Mirror Roadcam. Thus, it is imperative that the 1080P
Mirror Roadcam should be kept clean and unobstructed.
• Adhere to all applicable traffic laws and motor vehicle regulations
applicable to the device.
• Consult local laws and regulations for any restrictions on installation or use.
• Never allow children to play with the device. Small parts may be a
choking hazard.
• There is a plastic cover over the 1080P Mirror Roadcam. Do not scratch
the cover when cleaning dirt or snow from the cover.
• If the temperature changes rapidly, the system may not operate normally.
• When strong light directly enters a Roadcam, objects may not be
displayed clearly.
• The screen may flicker under fluorescent light.

17
Safety Around and Behind Other Vehicles
Using a 1080P Mirror Roadcam is not enough to completely overcome a
vehicle’s blind spot. Many preventable injuries and deaths occur in driveways
or parking lots when drivers do not see children, pets, or others near their
vehicles. Here are a few safety tips that will help you to avoid a back-over
accident:
• Walk completely around your vehicle before getting in. Check for kids,
toys, and pets before entering the vehicle and starting the engine.
• Know where children are. Have children stand in a place where they are
in full view.
• The colors of objects on the 1080P Mirror Roadcam may differ from those
of the actual object.
• Do not use alcohol or thinner to clean the Roadcam. This will cause
discoloration. To clean the Roadcam, wipe with a clean cloth dampened
with mild cleaner diluted with water and then wipe with a dry cloth.

18
MAINTENANCE & WARRANTY
Cleaning
• If dirt, rain or snow attaches to the Roadcam, the Monitor may not clearly
display objects. If water droplets, snow or mud adhere to the Roadcam
lens, rinse with water and wipe with a dry cloth.
• Do not use alcohol or thinner to clean the Roadcam. This will cause
discoloration. To clean the Roadcam, wipe with a clean cloth dampened
with mild cleaner diluted with water and then wipe with a dry cloth.
Warranty
YADA LIMITED WARRANTY
YADA warrants, to the original purchaser, that its products are free from
defects in material and workmanship for 1 year from the date of original
purchase. Where permitted by law, YADA’s liability shall be limited to that set
forth in this limited express warranty. This limited express warranty shall be
the exclusive remedy of the purchaser and YADA makes no other warranty
of any kind aside from the limited express warranty stated above.
Note: Warranty only applies for North American customers of purchases
made in North America.
• Be aware of young children. Young children are small and hard to see.
• Parents, caregivers and all adults need to be vigilant in supervising
children, especially when children are in the yard, driveway or parking lot
playing near parked cars.
• Roll down your window so you will be able to hear what is happening
outside your vehicle.
• Owners of SUVs, trucks, and vans need to take extra care to avoid hitting
or running over a child.
• Teach children to move away from a vehicle whenever it is started.

19
CONDITIONS OF WARRANTY
If during the 1 year warranty period your new product is found to be
defective, YADA will repair such defect, or replace the product, without
charge for parts or labor subject to the following conditions:
1. All repairs must be performed by YADA.
2. All warranty claims must be accompanied by a copy of the sales
receipt or bill of sale.
3. The equipment must not have been altered or damaged through
negligence, accident, improper operation, or failure to follow the
product instructions for installation, use, or care.
4. The replacement of parts is excluded from the warranty when
replacement is necessary due to normal wear and tear.
5. Repair or replacement parts supplied by YADA under this warranty are
protected only for the unexpired portion of the original warranty.
6. This is a “repair or replace” warranty only, and does not cover the costs
incurred for the installation, removal or reinstallation of the product, or
damage to any mobile phone device or vehicle.
OWNER’S RESPONSIBILITIES:
YADA will make every effort to provide warranty service within a reasonable
period of time. SHOULD YOU HAVE ANY QUESTIONS ABOUT SERVICE
RECEIVED OR IF YOU WOULD LIKE ASSISTANCE IN OBTAINING SERVICE,
PLEASE CALL TOLL FREE 1.866.294.9244 DURING REGULAR BUSINESS
HOURS MONDAY THROUGH FRIDAY 8:00 AM TO 5:00PM.
Note: Toll Free # is for North America Customers ONLY. See Customer
service section for customer contact numbers for other regions/offices.
For customer service and technical support, please call us at
1.866.294.9244. If at that time it is determined that a replacement unit is

20
needed, the support representative will issue a Return Authorization and
instruct on how to get a new unit.
YADA makes no other warranty of any kind aside from the limited express
warranty stated herein.
DISCLAIMER OF WARRANTIES, INCLUDING WARRANTY OF
MERCHANTABILITY AND WARRANTY OF FITNESS FOR PARTICULAR
PURPOSE: EXCEPT AS SPECIFICALLY SET FORTH HEREIN, NO
WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIES, IS MADE
AS TO THE 1080P MIRROR ROADCAM. EXCEPT AS EXPRESSLY
SET FORTH HEREIN, YADA AND/OR ITS AFFILIATES EXPRESSLY
DISCLAIMS, WITHOUT LIMITATION, ANY STATUTORY WARRANTIES
AND ALL IMPLIED WARRANTIES, INCLUDING ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE.
YADA and/or its affiliates do not guarantee or promise that the user of
1080P Mirror Roadcam will not be in an accident or otherwise not collide
with an object and/or person. Our 1080P Mirror Roadcam is not intended
in any way to be a substitute for careful and cautious driving or for the
consistent adherence to all applicable traffic laws and motor vehicle safety
regulations.
YADA and/or its affiliates are not responsible for a user’s intended or
actual use of the 1080P Mirror Roadcam. In no event shall YADA and/or
its affiliates have any liability for any losses (whether direct or indirect, in
contract, tort or otherwise) incurred in connection with the 1080P Mirror
Roadcam, including but not limited to damaged property, personal injury
and/or loss of life. Neither shall YADA and/or its affiliates have any liability
for any decision, action or inaction taken by any person in reliance on the
