Yaesu FT-270R Manual

1FT-270R/E Technical Supplement
©2010 VERTEX STANDARD CO., LTD. EH022N91B
Technical Supplement
Specifications ....................................................................................................................................................................2
Exploded View & Miscellaneous Parts .......................................................................................................................3
Block Diagram .................................................................................................................................................................. 5
Circuit Description ..........................................................................................................................................................7
Alignment ..........................................................................................................................................................................9
Board Units (Schematics, Layouts & Parts)
Main Unit................................................................................................................................................................... 13
FTD-7 DTMF Paging Unit (Option) ....................................................................................................................... 29
Introduction
This manual provides the technical information necessary for servicing the FT-
270R/E VHF FM Transceiver.
Servicing this equipment requires expertise in handing surface-mount chip compo-
nents. Attempts by non-qualified persons to service this equipment may result in
permanent damage not covered by the warranty, and may be illegal in some coun-
tries.
Two PCB layout diagrams are provided for each double-sided board in this trans-
ceiver. Each side of the board is referred to by the type of the majority of compo-
nents installed on that side (“Side A” or “Side B”). In most cases one side has only
chip components (surface-mount devices), and the other has either a mixture of
both chip and leaded components (trimmers, coils, electrolytic capacitors, ICs, etc.),
or leaded components only.
While we believe the information in this manual to be correct, VERTEX STANDARD
assumes no liability for damage that may occur as a result of typographical or other
errors that may be present. Your cooperation in pointing out any inconsistencies in
the technical information would be appreciated.
Contents
FT-270R/E
VERTEX STANDARD CO., LTD.
4-8-8 Nakameguro, Meguro-Ku, Tokyo 153-8644, Japan
VERTEXSTANDARD
US Headquarters
10900 Walker Street, Cypress, CA 90630, U.S.A.
YAESU UK LTD.
Unit 12, Sun Valley Business Park, Winnall Close
Winchester, Hampshire, SO23 0LB, U.K.
VERTEX STANDARD HK LTD.
Unit 5, 20/F., Seaview Centre, 139-141 Hoi Bun Road,
Kwun Tong, Kowloon, Hong Kong
VERTEX STANDARD (AUSTRALIA)PTY., LTD.
Normanby Business Park, Unit 14/45 Normanby Road
Notting Hill 3168, Victoria, Australia
Important Note
The transceiver was assembled using Pb (lead) free solder, based on the RoHS
specification.
Only lead-free solder (Alloy Composition: Sn-3.0Ag-0.5Cu) should be used
for repairs performed on this apparatus. The solder stated above utilizes the
alloy composition required for compliance with the lead-free specification,
and any solder with the above alloy composition may be used.
CAUTION
Risk of explosion if battery is replaced by an incorrect type. Dispose of used
batteries according to the instructions.

2FT-270R/E Technical Supplement
Specifications
General
Frequency Ranges: RX 137 (136) - 174 MHz
TX 144 - 146 (148) MHz
Channel Steps: 5/10/12.5/15/20/25/50/100 kHz
Frequency Stability: ±5 ppm @ –14° to +140° F (–10° to +60° C)
Repeater Shift: ±600 kHz
Emission Type: F2D , F3E
Antenna Impedance: 50-ohm
Rating: Battery Operation: 7.2 V DC 1.5 A
Battery Charging: 12 V DC 1.5 A (EXT DC jack: PA-44C/U)
Supply Voltage: Battery Operation: 7.2 V DC (FNB-83)
Battery Charging: 12 V DC (EXT DC jack: PA-44C/U)
Current Consumption: 165 mA (Receive, 200 mW output)
(Approx. @7.2 V) 45 mA (Standby, Saver Off)
20.5 mA (Standby, Saver On)
8 mA (Auto Power Off)
1.5 A (5 W TX 7.2 V DC)
Operating Temperature: –4 °F to +140 °F (–20 °C to +60 °C)
Case Size: 2.36" (W) x 4.72" (H) x 1.26" (D) mm (60 x 120 x 32 mm)
(W/O knob, antenna, & belt clip)
Weight: 13.8 Oz (390 g) with FNB-83, antenna, and belt clip
Transmitter
RF Power Output: 5.0 W (High) / 2.0 W (Middle) / 0.5 W (Low) (@7.2 V)
Modulation Type: Variable Reactance F2D, F3E
Maximum Deviation: ±5.0 kHz (F2D, F3E)
Spurious Emission: At least 60 dB below
Microphone Impedance: 2 k-ohm
Receiver
Circuit Type: Double-Conversion Superheterodyne
Intermediate Frequencies: 1st: 21.7 MHz
2nd: 450 kHz
Sensitivity: 0.2 μV for 12 dB SINAD (137-140 MHz)
0.16 μV for 12 dB SINAD (140-150 MHz)
0.2 μV TYP for 12 dB SINAD (150-174 MHz)
Selectivity: 12 kHz/35 kHz (–6 dB /–60 dB)
AF Output: 800 mW @ 16-ohm for 10 % THD (Internal Speaker)
(@ 7.2 V) 450 mW @ 8-ohm for 10 % THD (EXT SP Jack)
Specifications are subject to change without notice, and are guaranteed within the 144 MHz amateur band only.
Frequency ranges and fanctions will vary according to transceiver version; check with your dealer.

3FT-270R/E Technical Supplement
Exploded View & Miscellaneous Parts






G6090166
LCD
M3290045
MIC. ELEMENT
RA113680A
LIGHT GUIDE
RA0580700
INTER CONNECTOR
RA0578200
MIC HOLDER RUBBER
CP8221004
PANEL ASSY
CP8220001
REAR CASE ASSY
RA0577600
EXT CAP
RA0304300
WASHER
RA1113400
KNOB
RA1113300
KNOB
RA008890A
O RING
RA108700B
KNOB SCREW
RA046760A
O RING
RA061740B
RUBBER PACKING
RA057800A
RUBBER PACKING
RA055770C
LATCH NAIL
RA0337300
SHEET
RA070930A
MASKSHEET
RA1113600
RUBBER KNOB
RA0580500
REFLECTOR SHEET
RA0578300
WASHER
RA057840A
RING NUT
RA057730B (x2 pcs)
SPACER
RA0577400 (x2 pcs)
TERMINAL









RA1113500
WINDOW
RA057710A
HOLDER
RA057700A
RUBBER KNOB
RA111430A
DOUBLE FACE
RA0434100
SHEET
M4090185A
SPEAKER
RA0607200
SHEET PORON
MAIN-Unit
RA1084700
O RING
RA057720B
LIGHT GUIDE
RA1113200
PANEL
RA0557900
SP NET
RA0748900
O RING
RA1063700
SPACER
Ref.





VXSTD P/N
U9900068
U9900181
U24110002
U9900035
U07240202
Description
TAPTITESCREW M2X4NI#3
TAPTITESCREW 2X3.5(CAP)
TAPTITESCREW M2X10NI
TAPTITE SCREW M2X3 #1
PAN HEAD SCREW M2X4NI#2
Qty.
11
1
2
2
2
Non-designated parts are available
only as part of a designated assembly.
RA1127500
NAME PLATE (YAESU)
RA008920C
ORING
RA0087900
SPECIALNUT

4FT-270R/E Technical Supplement
Exploded View & Miscellaneous Parts
Note

5
Block Diagram
FT-270R/E Technical Supplement

6
Block Diagram
FT-270R/E Technical Supplement
Note

7FT-270R/E Technical Supplement
Circuit Description
Receive Signal Path
Incoming RF signal is from the antenna jack is delivered
to the Main Unit and passed through the low-pass filter
network, antenna switching diode D1003 and D1004 (both
RLS135), and low-pass filter network to the RF amplifier
Q1022 (3SK296ZQ). The amplified RF signal is passed
through band-pass filtered again by varactor-tuned band-
pass filter consisting of coils L1024, L1025, and L1026, and
diodes D1017, D1018, and D1019 (all HVC350B), then ap-
plied to the 1st mixer Q1023 (3SK296ZQ) along with the
first local signal from the PLL circuit.
The first local signal is generated between 115.3 MHz and
152.3 MHz by the VCO, which consists of Q1014
(2SC5005)and varactor diodes D1009, D1010 (both
HVC365) and D1011 (HSC277) according to the receiv-
ing frequency.
IF and Audio Circuits
The 21.7 MHz first IF signal is applied to the monolithic
crystal filters XF1001 and XF1002 which strip away un-
wanted mixer products, and the IF signal is applied to the
first IF amplifier Q1024 (2SC4915). The amplified first IF
signal is then delivered to the FM IF subsystem IC Q1004
(NJM2591V), which contains the second mixer, limiter am-
plifier, noise amplifier, and FM detector.
The second local signal is generated by 21.25 MHz crystal
X1002, produces the 450 kHz second IF signal when mixed
with first IF signal within Q1004 (NJM2591V).
The 450 kHz second IF signal is applied to the ceramic
filter CF1001 or CF1002 which strip away unwanted mix-
er products to the ceramic discriminator CD1001 which
removes any amplitude variations in the 450 kHz IF sig-
nal before detection of speech.
The detected audio from the Q1004 (NJM2591V) is ap-
plied to a band-pass filter consisting of Q1081 and Q1082
(both 2SC4617), then passes through the audio mute gate
Q1052 (2SC4617) and Q1045 (DTC144EE).
The audio signal is passed through the audio VR which
adjusts the audio sensitivity to compensate for audio lev-
el variations, then delivered to the audio amplifier Q1008
(TDA2822D).
Squelch Control
When no carrier received, noise at the output of the de-
tector stage in Q1004 (NJM2591V) is applied to pin 49 of
main CPU Q1001 (HD64F2266TF13), which compares the
squelch threshold level to that which set by the SQL knob.
While no carrier is received, pin 71 of Q1001
(HD64F2266TF13) remains “low,” to disable audio out-
put from the speaker.
Transmit Signal Path
The speech signal from the microphone is amplified by
Q1074 (LM2902PWR). The amplified speech signal is sub-
jected to the low-pass filter network Q1074 (LM2902PWR)
and deviation controller Q1075 (DTC144EE).
VHF Transmit Signal Path
The adjusted speech signal from Q1075 (DTC144EE) is
delivered to VCO Q1014 (2SC5005) which frequency
modulates the transmitting VCO made up of D1010
(HVC365).
The modulated transmit signal passes through buffer
amplifier Q1013 and Q1012 (both 2SC5005).
The transmit signal applied to the Pre-Drive amplifier
Q1011 (2SC5005) and Drive amplifier Q1010 (2SK3074),
then finally amplified by Power amplifier Q1009
(2SK3476) up to 5 Watts. This two stages (Q1010 and
Q1009) power amplifier’s gain is controlled by the APC
circuit.
The 5 Watts RF signal passes through low-pass filter net-
work, antenna switch D1003 (RLS135), and another low-
pass filter network, and then deliver to the ANT jack.
Tx APC Circuit
A portion of the Power amplifier output is rectified by
D1002 (1SS321), then delivered to APC Q1019
(LM2904PWR), Q1020 and Q1021 (both DTC144EE), as a
DC voltage which is proportional to the output level of
the power amplifier.
The APC Q1019 (LM2904PWR) is compared the rectified
DC voltage from the power amplifier and the reference
voltage from the main CPU Q1001 (HD64F2266TF13), to
produce a control voltage, which regulates supply volt-
age to the Drive amplifier Q1010 (2SK3074) and Power
amplifier Q1009 (2SK3476), so as to maintain stable out-
put power under varying antenna loading condition.
PLL
A portion of the output from the VCO Q1014 (2SC5005),
passes through the buffer amplifier Q1017 (2SC5005), then
delivered to the programmable divider section of the PLL
IC Q1003 (MB15A01PFV1), which divided according to the
frequency dividing data that is associated with the setting
frequency input from the main CPU Q1001
(HD64F2266TF13). It is then sent to the phase comparator.
The 21.25 MHz frequency of the reference oscillator cir-
cuit made up of X1002 is divided by the reference frequen-
cy divider section of Q1003 (MB15A01PFV1) into 4250 or
3400 parts to become 5 kHz or 6.25 kHz comparative ref-
erence frequencies, which are utilized by the phase com-
parator.

8FT-270R/E Technical Supplement
Circuit Description
The phase comparator section of Q1003 (MB15A01PFV1)
compares the phase between the frequency-divided os-
cillation frequency of the VCO circuit and comparative
frequency and its output is a pulse corresponding to the
phase difference. This pulse is integrated by the charge
pump and loop filter of D1012 (DA221) and Q1016
(DTC144EE) into a control voltage (VCV) to control the
oscillation frequency of the VCO.

9FT-270R/E Technical Supplement
Alignment
Introduction
The FT-270R/E is carefully aligned at the factory for the
specified performance across the amateur band. Realign-
ment should therefore not be necessary except in the event
of a component failure. Only an authorized Vertex Stan-
dard representative should perform all component re-
placement and service, or the warranty policy may be
void.
The following procedures cover the adjustments that are
not normally required once the transceiver has left the fac-
tory. However, if damage occurs and some parts subse-
quently are replaced, realignment may be required. If a
sudden problem occurs during normal operation, it is like-
ly due to component failure; realignment should not be
done until after the faulty component has been replaced.
We recommend that servicing be performed only by au-
thorized Vertex Standard service technicians who are ex-
perienced with the circuitry and fully equipped for repair
and alignment. If a fault is suspected, contact the dealer
from whom the transceiver was purchased for instructions
regarding repair. Authorized Vertex Standard service tech-
nicians realign all circuits and make complete performance
checks to ensure compliance with factory specifications
after replacing any faulty components.
Those who do undertake any of the following alignments
are cautioned to proceed at their own risk. Problems
caused by unauthorized attempts at realignment are not
covered by the warranty policy. Also, Vertex Standard
reserves the right to change circuits and alignment proce-
dures in the interest of improved performance, without
notifying owners.
Under no circumstances should any alignment be attempt-
ed unless the normal function and operation of the trans-
ceiver are clearly understood, the cause of the malfunc-
tion has been clearly pinpointed and any faulty compo-
nents replaced, and realignment determined to be abso-
lutely necessary.
Required Test Equipment
The following test equipment (and familiarity with its
use) is necessary for complete realignment. Correction of
problems caused by misalignment resulting from use of
improper test equipment is not covered under the war-
ranty policy. While most steps do not require all of the
equipment listed, the interactions of some adjustments
may require that more complex adjustments be per-
formed afterwards.
Do not attempt to perform only a single step unless it is
clearly isolated electrically from all other steps. Have all
test equipment ready before beginning and, follow all of
the steps in a section in the order presented.
RF Signal Generator with calibrated output level at 200
MHz
Deviation Meter (linear detector)
In-line Wattmeter with 5% accuracy at 200 MHz
50-Ohm 10-W RF Dummy Load
8-Ohm AF Dummy Load
Regulated DC Power Supply adjustable from 6 to 15
VDC, 2A
Frequency Counter: 0.2-ppm accuracy at 200 MHz
AF Signal Generator
AC Voltmeter
DC Voltmeter: high impedance
VHF Sampling Coupler
SINAD Meter
Alignment Preparation & Precautions
A 50-Ohm RF load and in-line wattmeter must be con-
nected to the main antenna jack in all procedures that call
for transmission; alignment is not possible with an anten-
na. After completing one step, read the next step to see if
the same test equipment is required. If not, remove the
test equipment (except dummy load and wattmeter, if
connected) before proceeding.
Correct alignment requires that the ambient temperature
be the same as that of the transceiver and test equipment,
and that this temperature be held constant between 68 ~
86° F (20° ~ 30° C). When the transceiver is brought into
the shop from hot or cold air, it should be allowed some
time to come to room temperature before alignment.
Whenever possible, alignments should be made with os-
cillator shields and circuit boards firmly affixed in place.
Also, the test equipment must be thoroughly warmed up
before beginning.
Note: Signal levels in dB referred to in the alignment pro-
cedure are based on 0dBμ= 0.5μV.

10 FT-270R/E Technical Supplement
Alignment
Test Setup
Set up the test equipment as shown below for transceiver
alignment.
Entering the Alignment Mode
Alignment of the FT-270R/E is performed using a front
panel software-based procedure. To perform alignment
of the transceiver, it must first be placed in the “Align-
ment Mode,” in which the adjustments will be made and
then stored into memory.
To enter the Alignment mode:
1. Rotate the [VOL/PWR] knob (inner knob) out of the
click-stop to turn on the radio.
2. Rotate the DIAL knob to select the frequency to 145.050
MHz.
3. Turn the power off by rotating the [VOL/PWR] knob
fully counter clockwise.
4. Press and hold in the [VFO(PRI)] key turning the ra-
dio on. Once the radio is on, release the key.
5. Turn the power off by rotating the [VOL/PWR] knob
fully counter clockwise.
6. Press and hold in the PTT and MONI switches turning
the radio on. Once the radio is on, release these two
switches.
7. Press the keypad in the following sequence:
[(MHz)] [0(SET)] [2(CODE)] 
[2(CODE)] [MR/MW(SKIP)]
8. Press the [F]key to cause “A0 REF.xxxA0 REF.xxx
A0 REF.xxxA0 REF.xxx
A0 REF.xxx” to appear on
the display for five seconds, this signifies that the trans-
ceiver is now in the “Alignment Mode.”
PLL Reference Frequency
1. Rotate the DIAL knob to select the display to “B0106.”
Press the [F]key, then press the [MR/MW(SKIP)] key
to set the alignment, then set the transmit power level
to “LOW.”
2. Press the [F]key, then press the [MR/MW(SKIP)] key
to set the alignment parameter to “A0 REF.xxxA0 REF.xxx
A0 REF.xxxA0 REF.xxx
A0 REF.xxx,” if
needed.
3. With in five second of appearing the “A0 REF.xxxA0 REF.xxx
A0 REF.xxxA0 REF.xxx
A0 REF.xxx” on
the display, press the PTT switch to activate the trans-
mitter, adjust the DIAL knob so that the counter fre-
quency reading is 145.050 MHz (±100 Hz).
“TX SECTION” ALIGNMENT SETUP
“RX SECTION” ALIGNMENT SETUP
Inline
Wattmeter RF Sampling
Coupler AF Signal
Generator
9.9 V DC
Regulated Power Supply
50
Dummy Load

Frequency
Counter
Frequency
Counter
MIC GND
7.5 V DC
Regulated Power Supply
SINAD
Meter
RF Signal
Generator
8
Dummy Load

SP GND

11FT-270R/E Technical Supplement
RF Front-end Tuning
1. Connect the DC voltmeter to TP1031 on the MAIN unit,
then inject a 145.050 MHz signal at a level of +10 dBμ
(with 1 kHz modulation @±3.5 kHz deviation) from
the RF signal generator.
2. Rotate the DIAL knob to select the display to “B0106.”
3. Press the [F/W]key, then press the [MR/MW(SKIP)]
key to set the alignment parameter to “A1 TUN.xxxA1 TUN.xxx
A1 TUN.xxxA1 TUN.xxx
A1 TUN.xxx.”
4. With in five second of appearing the “A1 TUN.xxxA1 TUN.xxx
A1 TUN.xxxA1 TUN.xxx
A1 TUN.xxx” on
the display, adjust the DIAL knob so that the DC volt-
meter reaches maximum deflection. The FT-270R RF
Front-end has a broad bandwidth. Therefore, prior to
adjustment you must adjust the DIAL knob to set the
frequency to the middle of the band, in step 2, so you
can set peak in the DC voltmeter’s deflection in the
center of the RF passband.
TX Power Output
1. Rotate the DIAL knob to select the display to “B0206,”
then set the transmit power level to “LOW.”
2. Press the [F/W]key, then press the [MR/MW(SKIP)]
key to set the alignment parameter to “A2 PWR.xxxA2 PWR.xxx
A2 PWR.xxxA2 PWR.xxx
A2 PWR.xxx.”
3. With in five second of appearing the “A2 PWR.xxxA2 PWR.xxx
A2 PWR.xxxA2 PWR.xxx
A2 PWR.xxx”
on the display, press the PTT switch to activate the
transmitter, adjust the DIAL knob so that the watt-
meter reading is 0.5 Watts (±0.05 Watt).
4. Increase the Transmit power level to “MID.”
5. Press the [F/W]key to recall the alignment parameter
“A2 PWR.xxxA2 PWR.xxx
A2 PWR.xxxA2 PWR.xxx
A2 PWR.xxx.”
6. With in five second of appearing the “A2 PWR.xxxA2 PWR.xxx
A2 PWR.xxxA2 PWR.xxx
A2 PWR.xxx”
on the display, press the PTT switch to activate the
transmitter, adjust the DIAL knob so that the watt-
meter reading is 2.0 Watts (±0.1 Watt).
7. Increase the Transmit power level to “HIGH.”
8. Press the [F/W]key to recall the alignment parameter
“A2 PWR.xxxA2 PWR.xxx
A2 PWR.xxxA2 PWR.xxx
A2 PWR.xxx."
9. With in five second of appearing the “A2 PWR.xxxA2 PWR.xxx
A2 PWR.xxxA2 PWR.xxx
A2 PWR.xxx”
on the display, press the PTT switch to activate the
transmitter, adjust the DIAL knob so that the watt-
meter reading is 5.0 Watts (±0.1 Watt).
TX Deviation
1. Rotate the DIAL knob to select the display to “B0206,”
then set the transmit power level to “LOW.”
2. Press the [F/W]key, then press the [MR/MW(SKIP)]
key to set the alignment parameter to “A3 DEV.xxxA3 DEV.xxx
A3 DEV.xxxA3 DEV.xxx
A3 DEV.xxx.”
3. With in five second of appearing the “A3 DEV.xxxA3 DEV.xxx
A3 DEV.xxxA3 DEV.xxx
A3 DEV.xxx” on
the display, press the PTT switch to activate the trans-
mitter, adjust the DIAL knob so that the deviation
meter reading is 4.2 kHz (±0.2 kHz) (EXP version: 4.5
kHz ± 0.2 kHz).
DCS TX Deviation
1. Rotate the DIAL knob to select the display to “B0206,”
then activate the DCS, and set the transmit power level
to “LOW.”
2. Press the [F/W]key, then press the [MR/MW(SKIP)]
key to set the alignment parameter to “A4 DCS.xxxA4 DCS.xxx
A4 DCS.xxxA4 DCS.xxx
A4 DCS.xxx.”
3. With in five second of appearing the “A4 DCS.xxxA4 DCS.xxx
A4 DCS.xxxA4 DCS.xxx
A4 DCS.xxx” on
the display, press the PTT switch to activate the trans-
mitter (with no microphone input), adjust the DIAL
knob so that the deviation meter reading is 0.7 kHz
(±0.05 kHz).
Alignment
TP1031

12 FT-270R/E Technical Supplement
Alignment
CTCSS TX Deviation
1. Rotate the DIAL knob to select the display to “B0206,”
then activate the CTCSS encoder with a “100 Hz” tone,
and set the transmit power level to “LOW.”
2. Press the [F/W]key, then press the [MR/MW(SKIP)]
key to set the alignment parameter to “A5 CTC.xxxA5 CTC.xxx
A5 CTC.xxxA5 CTC.xxx
A5 CTC.xxx.”
3. With in five second of appearing the “A5 CTC.xxxA5 CTC.xxx
A5 CTC.xxxA5 CTC.xxx
A5 CTC.xxx” on
the display, press the PTT switch to activate the trans-
mitter (with no microphone input), adjust the DIAL
knob so that the deviation meter reading is 0.7 kHz
(±0.05 kHz).
S-meter Sensitivity
1. Rotate the DIAL knob to select the display to “B0206.”
2. Inject a 146.050 MHz signal at a level of –5 dBμV (with
1 kHz modulation @±3.5 kHz deviation) from the RF
signal generator.
3. Press the [F/W]key, then press the [MR/MW(SKIP)]
key to set the alignment parameter to “A6 SM UA6 SM U
A6 SM UA6 SM U
A6 SM U/DD
DD
D.”
4. With in five second of appearing the “A6 SM UA6 SM U
A6 SM UA6 SM U
A6 SM U/DD
DD
D” on
the display, press the [(MHz)] key.
5. Increase the RF signal generator output level to +23
dBμV.
6. Press the [F/W]key to recall the alignment parameter
to “A6 SM UA6 SM U
A6 SM UA6 SM U
A6 SM U/DD
DD
D.”
7. With in five second of appearing the “A6 SM UA6 SM U
A6 SM UA6 SM U
A6 SM U/DD
DD
D” on
the display, press the [(MHz)] key.
Squelch Sensitivity
1. Rotate the DIAL knob to select the display to “B0206.”
2. Inject a 146.050 MHz signal at a level of –12 dBμV (with
1 kHz modulation @±3.5 kHz deviation) from the RF
signal generator.
3. Press the [F/W]key, then press the [MR/MW(SKIP)]
key to set the alignment parameter to “A7 SQL UA7 SQL U
A7 SQL UA7 SQL U
A7 SQL U/DD
DD
D.”
4. With in five second of appearing the “A7 SQL UA7 SQL U
A7 SQL UA7 SQL U
A7 SQL U/DD
DD
D” on
the display, press the [(MHz)] key.
5. Increase the RF signal generator output level to –3
dBμV.
6. Press the [F/W]key to recall the alignment parameter
to “A7 SQL UA7 SQL U
A7 SQL UA7 SQL U
A7 SQL U/DD
DD
D.”
7. With in five second of appearing the “A7 SQL UA7 SQL U
A7 SQL UA7 SQL U
A7 SQL U/DD
DD
D” on
the display, press the [(MHz)] key.
DC Voltmeter
1. Set the power supply voltage to 9.9 V.
2. Press the [F/W]key, then press the [MR/MW(SKIP)]
key to set the alignment parameter to “A8 BAT RVA8 BAT RV
A8 BAT RVA8 BAT RV
A8 BAT RV.”
3. With in five second of appearing the “A8 BAT RVA8 BAT RV
A8 BAT RVA8 BAT RV
A8 BAT RV” on
the display, press the [REV(HOME)] key.
To close the alignment mode
1. Turn the power off by rotating the [VOL/PWR] knob
fully counter clockwise.
2. The next time the transceiver is turned on, press and
hold in the [VFO(PRI)] key turning the radio on. Once
the radio is on, release the key.
normal operation may resume.

13
MAIN Unit
FT-270R/E Technical Supplement
Circuit Diagram
1.78 V
1.13 V
1.29 V
1.83 V
2.15 V
3.18 V
3.18 V
5.12 V
8.13 V
8.05 V
1.91 V
1.29 V
8.00 V
3.75 V
3.72 V
RX: 1.93 V
TX: 1.89 V
2.45 V
3.12 V
0.42 V
4.43 V
5.08 V
3.30 V
2.08 V @ Low Freq.
Wide: 5.05 V
Narrow: 0 V
RX: 4.41 V
TX: 5.05 V
RX: 5.02 V
TX: 0 V RX: 0 V
TX: 4.96 V
Wide: 0 V
Narrow: 5.07 V
Wide: 4.49 V
Narrow: 0 V
RX: 5.07 V
TX: 0 V
0.65 V
4.32 V
RX: 0.40 V
TX: 5.09 V
RX: 4.56 V
TX: 5.00 V
RX: 5.05 V
TX: 0.60 V
RX: 0.64 V
TX: 0 V
RX: 4.86 V
TX: 0 V
2.61 V
2.33 V
2.88 V 5.11 V
4.64 V
2.35 V
0.28 V
0.88 V
5.13 V
2.07 V
2.07 V
9.14 V 3.30 V
3.30 V
5.13 V
3.36 V
2.77 V
3.32 V
1.95 V
1.95 V
1.95 V
1.95 V
5.13 V
1.48 V @CHG (PWR "OFF")
0.91 V @CHG (PWR "OFF")
1.53 V @CHG
13.1 V @CHG
13.8 V
13.5 V
4.90 V
4.86 V
0.99 V
+16.0 dBμ
4.21 V
2.24 V
0.69 V
4.84 V
1.80 V
0.26 V 0.81 V
TX: 1.88 V
TX: 3.93 V
TX "H": 2.33 V
TX "M": 2.09 V
TX "L": 1.85 V
TX "H": 8.10 V
TX "M": 8.14 V
TX "L": 8.17 V
TX "H": 3.04 V
TX "M": 1.64 V
TX "L": 0.59 V
TX "H": 2.23 V
TX "M": 1.25 V
TX "L": 0.50 V
TX: 1.72 V
4.96 V 4.66 V
2.77 V
0.66 V
0.14 V
2.10 V
2.10 V
2.10 V 2.10 V
5.13 V
2.10 V
2.10 V
1.95 V
2.26 V
PTT: 1.65 V
MONI: 2.05 V
3.30 V
3.30 V
1.90 V
2.98 V
TX: 2.96 V
3.25 V
TX: 3.25 V
3.28 V
3.19 V
3.26 V
2.14 V1.06 V
RX: 2.00 V
TX: 0 V
5.57 V 3.95 V
2.73 V
1.97 V
2.62 V
TX: 2.62 V
10.9 V
3.30 V
9.37 V @CHG (PWR "OFF")
TX: 10.5 V
TX: +18.3 dBm @146.00 MHz
TX: +6.3 dBm
RX: –0.9 dBm
TX: +2.5 dBm
+11.2 dBm @124.30 MHz
+12.7 dBμ@21.7 MHz
+18.3 dBμ
+13.0 dBμ@ 146.00 MHz,
SINAD 12 dB
1.43 V @146.00 MHz

14
MAIN Unit
FT-270R/E Technical Supplement
Note

15
MAIN Unit
FT-270R/E Technical Supplement
Parts Layout (Side A)
BADCFEG
1
3
2
4
BD4845FVE
(Q1006)
HD64F2266
(Q1001)
DA221 (K)
(D1025)
1SS321 (F9)
(D1002)
DAN222 (N)
(D1024)
2SA1774 (FR)
(Q1030, 1031, 1032,
1034, 1040, 1059)
2SC4617 (BR)
(Q1034, 1038, 1039,
1042, 1061, 1062,
1064, 1065, 1069,
1076, 1077, 1079)
2SC4915 (QY)
(Q1024)
FMMTL718TA
(Q1041)
2SB1132 (BA)
(Q1063, 1078)
DTA144EE (16)
(Q1033, 1043, 1058,
1071)
DTC144EE (26)
(Q1020, 1021, 1029,
1044, 1045, 1057,
1068)
H
2SB1201S
(Q1037)
2SD1664 (DA)
(Q1067)
2SK3476
(Q1009)
BR24L64F
(Q1002)
LM2904PWR
(Q1019)
TDA28822
(Q1008)

16
MAIN Unit
FT-270R/E Technical Supplement
Parts Layout (Side B)
badcfeg
1
3
2
4
2SA1774 (FR)
(Q1018, 1036)
2SC4617 (BR)
(Q1028, 1052, 1055,
1060, 1066, 1072,
1073, 1081, 1082)
2SC5005 (73)
(Q1011, 1012, 1013,
1014, 1017)
DTC144EE (26)
(Q1015, 1016, 1025,
1026, 1047, 1048,
1049, 1051, 1070,
1075)
MB15A01PFV1
(Q1003)
NJM2591V
(Q1004)
DA221 (K)
(D1012, 1030)
DAN222 (N)
(D1021, 1022, 1029)
2SJ364 (4M)
(Q1056)
2SK3074 (WA)
(Q1010)
DTA144EE (16)
(Q1027, 1054, 1084)
LM2904PWR
(Q1050, 1083)
LM2902PWR
(Q1046, 1074)
NJU7231F30
(Q1007)
XC6202P
(Q1080)
BU2090FS
(Q1005)
h
3SK296ZQ (ZQ)
(Q1022, 1023)

17
Parts List
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
MAIN Unit
FT-270R/E Technical Supplement
PCB with Components CB3164015 VX-270R USA A2
CB3164016 VX-270R EXP A1
CB3164017 VX-270R EXP A2
CB3164018 VX-270R EXP A3
CB3164019 VX-270E EXPB1
CB3164020 VX-270E EXPB2
CB3164021 VX-270R EXPB3
Printed Circuit Board FR013350C 1-
C 1002 CHIPCAP. 15pF 50V CH GRM1552C1H150JZ01D K22178216 1- B a1
C 1003 CHIPCAP. 5pF 50V CH GRM1552C1H5R0BZ01D K22178292 1- B a1
C 1004 CHIPCAP. 33pF 50V CH GRM1552C1H330JZ01D K22178224 1- B a1
C 1005 CHIPCAP. 3pF 50V CJ GRM1553C1H3R0BZ01D K22178290 1- B b1
C 1006 CHIPCAP. 2pF 50V CK GRM1554C1H2R0BZ01D K22178289 9- B b1
C 1007 CHIPCAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B b1
C 1008 CHIPCAP. 27pF 50V CH GRM1552C1H270JZ01D K22178222 1- B a1
C 1009 CHIPCAP. 27pF 50V CH GRM1552C1H270JZ01D K22178222 1- B b1
C 1010 CHIPCAP. 10pF 50V CH GRM1552C1H100BZ01D K22178297 1- A G1
C 1011 CHIPCAP. 0.5pF 50V CK GRM1554C1HR50BZ01D K22178285 1- A G1
C 1012 CHIPCAP. 3pF 50V CJ GRM1553C1H3R0BZ01D K22178290 1- A G1
C 1013 CHIPCAP. 0.5pF 50V CK GRM1554C1HR50BZ01D K22178285 1- A G1
C 1014 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A G1
C 1016 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A G1
C 1017 CHIPCAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B b1
C 1018 CHIPCAP. 15pF 50V CH GRM1552C1H150JZ01D K22178216 1- B b1
C 1019 CHIPCAP. 10pF 50V CH GRM1552C1H100BZ01D K22178297 1- B b1
C 1020 CHIPCAP. 12pF 50V CH GRM1552C1H120JZ01D K22178214 1- B b1
C 1021 CHIPCAP. 18pF 50V CH GRM1552C1H180JZ01D K22178218 1- B b1
C 1022 CHIPCAP. 43pF 50V CH GRM1552C1H430JD01D K22178227 1- B c1
C 1023 CHIPCAP. 47pF 50V CH GRM1552C1H470JZ01D K22178228 1- B c1
C 1025 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b2
C 1026 CHIPCAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 1- A G2
C 1027 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b1
C 1028 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A G1
C 1029 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A G1
C 1030 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A G1
C 1031 CHIPCAP. 0.047uF 10V B GRM155B11A473KA01D K22108801 1- A G1
C 1032 CHIPCAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A G1
C 1033 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A G1
C 1034 CHIPTA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- A F1
C 1035 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F1
C 1037 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b1
C 1038 CHIPCAP. 47pF 50V CH GRM1552C1H470JZ01D K22178228 1- B c1
C 1039 CHIPCAP. 43pF 50V CH GRM1552C1H430JD01D K22178227 1- B c1
C 1040 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B d1
C 1041 CHIPCAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d1
C 1041 CHIPCAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 28- B d1
C 1042 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B d1
C 1043 CHIPCAP. 33pF 50V CH GRM1552C1H330JZ01D K22178224 1- B d1
C 1044 CHIPCAP. 27pF 50V CH GRM1552C1H270JZ01D K22178222 1- B d1
C 1045 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B d1
C 1046 CHIPCAP. 10pF 50V CH GRM1552C1H100BZ01D K22178297 1- B e1
C 1047 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B e1
C 1048 CHIPCAP. 5pF 50V CH GRM1552C1H5R0BZ01D K22178292 1- B f1
C 1049 CHIPCAP. 5pF 50V CH GRM1552C1H5R0BZ01D K22178292 1- B f1
C 1050 CHIPCAP. 1.5pF 50V CK GRM1554C1H1R5BZ01D K22178288 1- B f1
C 1051 CHIPCAP. 18pF 50V CH GRM1552C1H180JZ01D K22178218 1- B f1
C 1052 CHIPCAP. 18pF 50V CH GRM1552C1H180JZ01D K22178218 1- B f1
C 1053 CHIPCAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B f1
C 1054 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B f1
C 1055 CHIPCAP. 33pF 50V CH GRM1552C1H330JZ01D K22178224 1- B f1
C 1056 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B f1
C 1057 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B f1
C 1058 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B f2
C 1059 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B f1
C 1060 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B f1
C 1061 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B f2
C 1062 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B f1
C 1063 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B f2
C 1064 CHIPTA.CAP. 0.1uF 20V SKF-1D104M-RP K78130049 1- B f1
C 1065 CHIPTA.CAP. 0.1uF 20V SKF-1D104M-RP K78130049 1- B f1
C 1066 CHIPTA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- B g1
C 1067 CHIPTA.CAP. 0.1uF 20V SKF-1D104M-RP K78130049 1- B g1
C 1068 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B f1

18
Parts List
MAIN Unit
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
FT-270R/E Technical Supplement
C 1069 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B g1
C 1070 CHIPCAP. 0.047uF 10V B GRM155B11A473KA01D K22108801 1- B g2
C 1071 CHIPCAP. 47pF 50V CH GRM1552C1H470JZ01D K22178228 1- B g1
C 1072 CHIPTA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B g2
C 1073 CHIPCAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B g1
C 1074 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B g1
C 1075 CHIPCAP. 1uF 10V F GRM188F11A105ZA01D K22105001 1- B g2
C 1076 CHIPCAP. 33pF 50V CH GRM1552C1H330JZ01D K22178224 1- B g2
C 1077 CHIPCAP. 33pF 50V CH GRM1552C1H330JZ01D K22178224 1- B g2
C 1078 CHIPCAP. 33pF 50V CH GRM1552C1H330JZ01D K22178224 1- B g2
C 1079 CHIPCAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- B g1
C 1080 CHIPCAP. 10pF 50V CH GRM1552C1H100BZ01D K22178297 1- B g1
C 1080 CHIPCAP. 9pF 50V CH GRM1552C1H9R0BZ01D K22178296 53- B g1
C 1081 CHIPCAP. 22pF 50V CH GRM1552C1H220JZ01D K22178220 1- B g1
C 1082 CHIPCAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B h2
C 1083 CHIPCAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B h2
C 1084 CHIPCAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A D2
C 1086 CHIPCAP. 10pF 50V CH GRM1552C1H100BZ01D K22178297 1- B g1
C 1087 CHIPCAP. 22pF 50V CH GRM1552C1H220JZ01D K22178220 1- B h1
C 1088 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B h1
C 1089 CHIPCAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- B g2
C 1090 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B h1
C 1092 CHIPCAP. 27pF 50V CH GRM1552C1H270JZ01D K22178222 1- B a2
C 1093 CHIPCAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- B b2
C 1097 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c1
C 1098 CHIPCAP. 8pF 50V CH GRM1552C1H8R0BZ01D K22178295 1- B b2
C 1099 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b2
C 1100 CHIPCAP. 2pF 50V CK GRM1554C1H2R0BZ01D K22178289 1- B c2
C 1101 CHIPCAP. 7pF 50V CH GRM1552C1H7R0BZ01D K22178294 1- B c2
C 1102 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c2
C 1103 CHIPCAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c2
C 1103 CHIPCAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 28- B c2
C 1104 CHIPCAP. 8pF 50V CH GRM1552C1H8R0BZ01D K22178295 1- B c2
C 1106 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c2
C 1107 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c2
C 1108 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c2
C 1109 CHIPCAP. 1pF 50V CK GRM1554C1H1R0BZ01D K22178287 1- B c2
C 1110 CHIPCAP. 1pF 50V CK GRM1554C1H1R0BZ01D K22178287 1- B c2
C 1111 CHIPCAP. 0.5pF 50V CK GRM1554C1HR50BZ01D K22178285 1- B c1
C 1112 CHIPCAP. 0.75pF 50V CK GRM1554C1HR75BZ01D K22178286 1- B c1
C 1113 CHIPCAP. 10pF 50V CH GRM1552C1H100BZ01D K22178297 1- B c1
C 1114 CHIPCAP. 47pF 50V CH GRM1552C1H470JZ01D K22178228 1- B c1
C 1115 CHIPCAP. 47pF 50V CH GRM1552C1H470JZ01D K22178228 1- B c1
C 1116 CHIPCAP. 0.5pF 50V CK GRM1554C1HR50BZ01D K22178285 1- B c2
C 1117 CHIPCAP. 0.75pF 50V CK GRM1554C1HR75BZ01D K22178286 1- B d1
C 1118 CHIPCAP. 4pF 50V CH GRM1552C1H4R0BZ01D K22178291 1- B c1
C 1119 CHIPCAP. 47pF 50V CH GRM1552C1H470JZ01D K22178228 1- B c1
C 1120 CHIPCAP. 0.5pF 50V CK GRM1554C1HR50BZ01D K22178285 1- B d1
C 1121 CHIPCAP. 8pF 50V CH GRM1552C1H8R0BZ01D K22178295 1- B d1
C 1122 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B d1
C 1123 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B d1
C 1124 CHIPCAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d1
C 1124 CHIPCAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 28- B d1
C 1125 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B d1
C 1126 CHIPCAP. 56pF 50V CH GRM1552C1H560JD01D K22178230 1- B d1
C 1128 CHIPCAP. 6pF 50V CH GRM1552C1H6R0BZ01D K22178293 1- B e1
C 1129 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B d1
C 1130 CHIPCAP. 22pF 50V CH GRM1552C1H220JZ01D K22178220 1- B d1
C 1131 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A C1
C 1132 CHIPCAP. 43pF 50V CH GRM1552C1H430JD01D K22178227 1- A C1
C 1133 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B e2
C 1134 CHIPTA.CAP. 22uF 6.3V TEESVA0J226M8R K78080047 1- B g2
C 1134 CHIPCAP. 10uF 6.3V B JMK316BJ106KL-T K22081802 6- B g2
C 1135 CHIPCAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B g3
C 1135 CHIPCAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 28- B g3
C 1136 CHIPCAP. 39pF 50V CH GRM1552C1H390JZ01D K22178226 1- B g3
C 1137 CHIPCAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B g3
C 1138 CHIPCAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B g3
C 1139 CHIPCAP. 56pF 50V CH GRM1552C1H560JD01D K22178230 1- B g2
C 1139 CHIPCAP. 56pF 50V CH GRM1552C1H560JD01D K22178230 17- B g2
C 1140 CHIPCAP. 68pF 50V CH GRM1552C1H680JZ01D K22178232 1- B g2
C 1140 CHIPCAP. 68pF 50V CH GRM1552C1H680JZ01D K22178232 17- B g2
C 1141 CHIPCAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B f2

19
Parts List
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
MAIN Unit
FT-270R/E Technical Supplement
C 1142 CHIPCAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B g3
C 1142 CHIPCAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 28- B g3
C 1143 CHIPCAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B g3
C 1143 CHIPCAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 28- B g3
C 1144 CHIPCAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B g3
C 1145 CHIPCAP. 470pF 50V B GRM155B11H471KA01D K22178805 1- B g2
C 1146 CHIPCAP. 470pF 50V B GRM155B11H471KA01D K22178805 1- B g2
C 1147 CHIPCAP. 220pF 50V B GRM155B11H221KA01D K22178801 1- B f2
C 1148 CHIPCAP. 680pF 50V B GRM155B11H681KA01D K22178807 1- B f2
C 1149 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B g2
C 1150 CHIPCAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B g2
C 1150 CHIPCAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 28- B g2
C 1151 CHIPCAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B h3
C 1151 CHIPCAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 28- B h3
C 1152 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A C2
C 1153 CHIPTA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- A C2
C 1154 CHIPTA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- A C2
C 1155 CHIPCAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- A F2
C 1156 CHIPCAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 1- A F2
C 1157 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F3
C 1158 CHIPTA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- A G3
C 1158 CHIPTA.CAP. 4.7uF 16V TEESVA21C475M8R K78120080 26- A G3
C 1159 CHIPTA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- A F2
C 1159 CHIPTA.CAP. 4.7uF 16V TEESVA21C475M8R K78120080 26- A F2
C 1160 CHIPCAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B f2
C 1161 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A G2
C 1162 AL.ELECTRO.CAP. 100uF 16V EEE1CA101WP K48120012 1- B a3
C 1162 AL.ELECTRO.CAP. 100uF 16V UWX1C101MCL1GB K48120032 39- B a3
C 1163 CHIPTA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- A G3
C 1163 CHIPTA.CAP. 10uF 10V TEESVA21A106M8R K78100076 26- A G3
C 1164 CHIPCAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A G3
C 1165 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A G3
C 1166 CHIPCAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A G2
C 1167 AL.ELECTRO.CAP. 100uF 10V RVZ-10V101MF55U-R2 K48100008 1- B b2
C 1167 AL.ELECTRO.CAP. UWX1C101MCL1GB S8101395 36- B b2
C 1167 AL.ELECTRO.CAP. 100uF 16V UWX1C101MCL1GB K48120032 44- B b2
C 1168 CHIPCAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A G2
C 1169 AL.ELECTRO.CAP. 100uF 10V RVZ-10V101MF55U-R2 K48100008 1- B a3
C 1169 AL.ELECTRO.CAP. UWX1C101MCL1GB S8101395 36- B a3
C 1169 AL.ELECTRO.CAP. 100uF 16V UWX1C101MCL1GB K48120032 44- B a3
C 1170 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F2
C 1171 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F2
C 1172 CHIPCAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- A G2
C 1173 CHIPCAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- A G2
C 1174 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a2
C 1175 CHIPCAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- A H3
C 1175 CHIPCAP. 0.0047uF 50V B GRM155B11H472KA01D K22178838 28- A H3
C 1176 CHIPCAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- A H3
C 1176 CHIPCAP. 0.0047uF 50V B GRM155B11H472KA01D K22178838 28- A H3
C 1177 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b1
C 1178 CHIPCAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B f4
C 1179 CHIPCAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B f4
C 1180 CHIPCAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d3
C 1180 CHIPCAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 28- B d3
C 1181 CHIPCAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d3
C 1181 CHIPCAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 28- B d3
C 1182 CHIPCAP. 0.0022uF 50V B GRM155B11H222KA01D K22178813 1- B d3
C 1183 CHIPCAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d3
C 1183 CHIPCAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 28- B d3
C 1184 CHIPCAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B d3
C 1185 CHIPCAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B d3
C 1186 CHIPTA.CAP. 22uF 6.3V TEESVA0J226M8R K78080047 1- B d3
C 1187 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B g4
C 1188 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B g4
C 1189 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B g3
C 1190 CHIPCAP. 0.0068uF 25V B GRM155B11E682KA01D K22148803 1- B g3
C 1191 CHIPCAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B g3
C 1192 CHIPCAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B g3
C 1193 CHIPCAP. 0.047uF 10V B GRM155B11A473KA01D K22108801 1- B g3
C 1194 CHIPCAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A G3
C 1194 CHIPCAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 28- A G3
C 1195 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E1
C 1196 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A D1

20
Parts List
MAIN Unit
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
FT-270R/E Technical Supplement
C 1197 CHIPCAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A D1
C 1198 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A D1
C 1199 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b4
C 1200 AL.ELECTRO.CAP. 47uF 16V RV4-16V470MF46-RR2 K48120019 1- B b3
C 1200 AL.ELECTRO.CAP. 47uF 16V UZS1C470MCL1GB K48120031 30- B b3
C 1201 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b4
C 1202 CHIPTA.CAP. 150uF 4V TEESVC0G157M12R K78060034 1- B a4
C 1203 CHIPCAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 1- A G3
C 1204 CHIPCAP. 0.22uF 10V B GRM188B11A224KA01D K22104801 1- A H3
C 1205 CHIPTA.CAP. 22uF 6.3V TEESVA0J226M8R K78080047 1- A G2
C 1205 CHIPTA.CAP. 22uF 6.3V TEESVA20J226M8R K78080088 26- A G2
C 1206 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A G2
C 1207 CHIPCAP. 0.022uF 16V B GRM155B11C223KA01D K22128806 1- B d2
C 1208 CHIPCAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- B d2
C 1209 CHIPCAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d2
C 1209 CHIPCAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 28- B d2
C 1210 CHIPCAP. 330pF 50V B GRM155B11H331KA01D K22178803 1- B c2
C 1211 CHIPTA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- B c2
C 1212 CHIPCAP. 0.022uF 16V B GRM155B11C223KA01D K22128806 1- B c2
C 1213 CHIPCAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c2
C 1213 CHIPCAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 28- B c2
C 1214 CHIPCAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- B c2
C 1214 CHIPCAP. 0.0047uF 50V B GRM155B11H472KA01D K22178838 28- B c2
C 1215 CHIPCAP. 680pF 50V B GRM155B11H681KA01D K22178807 1- B c2
C 1216 CHIPCAP. 470pF 50V B GRM155B11H471KA01D K22178805 1- B c2
C 1217 CHIPCAP. 0.022uF 16V B GRM155B11C223KA01D K22128806 1- B c3
C 1218 CHIPCAP. 0.0068uF 25V B GRM155B11E682KA01D K22148803 1- B c3
C 1219 CHIPCAP. 330pF 50V B GRM155B11H331KA01D K22178803 1- B c3
C 1220 CHIPCAP. 680pF 50V B GRM155B11H681KA01D K22178807 1- B c3
C 1221 CHIPCAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- B c3
C 1221 CHIPCAP. 0.0047uF 50V B GRM155B11H472KA01D K22178838 28- B c3
C 1222 CHIPCAP. 0.22uF 10V B GRM188B11A224KA01D K22104801 1- B c3
C 1223 CHIPCAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- B d2
C 1224 CHIPCAP. 0.0068uF 25V B GRM155B11E682KA01D K22148803 1- B c2
C 1225 CHIPCAP. 0.0068uF 25V B GRM155B11E682KA01D K22148803 1- B d2
C 1226 CHIPCAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- B d2
C 1227 CHIPCAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B d3
C 1228 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c1
C 1229 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E3
C 1230 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c4
C 1231 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c4
C 1232 CHIPTA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- A F3
C 1233 CHIPCAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c4
C 1233 CHIPCAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 28- B c4
C 1234 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c4
C 1235 CHIPCAP. 0.022uF 16V B GRM155B11C223KA01D K22128806 1- B c3
C 1236 CHIPCAP. 0.022uF 16V B GRM155B11C223KA01D K22128806 1- B c3
C 1237 CHIPCAP. 470pF 50V B GRM155B11H471KA01D K22178805 1- B c3
C 1238 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F3
C 1239 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F1
C 1240 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b4
C 1241 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A A4
C 1242 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c3
C 1243 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B d3
C 1244 CHIPCAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c3
C 1245 CHIPCAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- B b3
C 1245 CHIPCAP. 0.0047uF 50V B GRM155B11H472KA01D K22178838 28- B b3
C 1246 CHIPCAP. 5pF 50V CH GRM1552C1H5R0BZ01D K22178292 1- B b3
C 1247 CHIPTA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B b2
C 1248 CHIPCAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B b3
C 1248 CHIPCAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 28- B b3
C 1249 CHIPCAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c3
C 1250 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c3
C 1251 CHIPCAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c3
C 1252 CHIPCAP. 27pF 50V CH GRM1552C1H270JZ01D K22178222 1- B c3
C 1253 CHIPCAP. 470pF 50V B GRM155B11H471KA01D K22178805 1- B c3
C 1255 CHIPCAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- B c3
C 1256 CHIPCAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A E2
C 1257 CHIPCAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- A F2
C 1257 CHIPCAP. 0.0047uF 50V B GRM155B11H472KA01D K22178838 28- A F2
C 1258 CHIPCAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A D2
C 1258 CHIPCAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 28- A D2
C 1259 CHIPCAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- A D3
