Yaesu FTM-400DR/DE Manual

Specications
Exploded View & Miscellaneous Parts
Block Diagram
Alignment
Board Unit (Schematics, Layouts & Parts)
MAIN Unit
PANEL Unit
DSP Unit
144/430 MHz 50 W Dual-Band Transceiver
FTM-400DR/DE
TECHNICAL SUPPLEMENT
©2014 YAESU MUSEN CO., LTD. EH034M90B
YAESU MUSEN CO., LTD.
Tennozu Parkside Building
2-5-8 Higashi-Shinagawa, Shinagawa-ku, Tokyo 140-0002 Japan
YAESU USA
6125 Phyllis Drive, Cypress, CA 90630, U.S.A.
YAESU UK
Unit 12, Sun Valley Business Park, Winnall Close
Winchester, Hampshire, SO23 0LB, U.K.
Introduction
This manual provides the technical information necessary for
servicing the FTM-400DR/DE 144/430 MHz 50 W Dual Band
Transceiver.
Servicing this equipment requires expertise in handing surface-
mount chip components. Attempts by non-qualified persons
to service this equipment may result in permanent damage not
covered by the warranty, and may be illegal in some countries.
Two PCB layout diagrams provided for each double-sided
board in this transceiver. Each side of the board is referred to
by the type of the majority of components installed on that side
("Side A" or "Side B"). In most cases one side has only chip
components, and the other has either a mixture of both chip and
leaded components (trimmers, coils, electrolytic capacitors,
ICs, etc.), or leaded components only.
While we believe the information in this manual to be correct,
YAESU assumes no liability for damage that may occur as a
result of typographical or other errors that may be present. Your
cooperation in pointing out any inconsistencies in the technical
information would be appreciated.
Important Note
1) This transceiver was assembled using Pb (lead) free solder, based on the RoHS specication.
Only lead-free solder (Alloy Composition: Sn-3.0Ag-0.5Cu) should be used for repairs performed on this apparatus. The solder stat-
ed above utilizes the alloy composition required for compliance with the lead-free specication, and any solder with the above alloy
composition may be used.
2) Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions.
Contents

FTM-400DR/DE Technical Supplement
Specications
SPECIFICATIONS-1
General
Frequency Range:
TX 144 - 146 MHz or 144 - 148 MHz
430 - 440 MHz or 430 - 450 MHz
RX 108 - 137 MHz (Air Band)
137 - 174 MHz (144 MHz HAM)
174 - 400 MHz (GEN1)
400 - 480 MHz (430 MHz HAM)
480 - 999.99 MHz (GEN2)
Channel Steps: 5, 6.25, 8.33, 9, 10, 12.5, 15, 20, 25, 50, 100 kHz
(8.33 kHz: only for Air Band, 9 kHz: only for AM Radio)
Frequency Stability: ±2.5 ppm (–4 °F to +140 °F [–20 °C to +60 °C])
Emission Type: F1D, F2D, F3E, F7W
Supply Voltage: Norminal 13.8 V DC, negative ground
Current Consumption: 0.5 A (receive)
11 A (50 W TX, 144 MHz)
12 A (50 W TX, 430 MHz)
Operating Temperature: –4 °F to +140 °F (–20 °C to +60 °C)
Case Size (W x H x D): Radio unit: 5.5” (W) × 1.6” (H) × 4.9” (D) (140 × 40 × 125 mm) w/o fan
Controller: 5.5” (W) × 2.8” (H) × 0.8” (D) (140 × 72 × 20 mm)
Weight (approx.): 2.64 lbs (1.2 kg) with radio unit, controller, control cable
Transmier
RF Power Output: 50 / 20 / 5 W
Modulation Type: F1D, F2D, F3E : Variable Reactance modulation
F7W: 4 FSK (C4FM)
Spurious Emission: At least 60 dB below

FTM-400DR/DE Technical Supplement
Specications
SPECIFICATIONS-2
Receiver
Circuit Type: Double-Conversion Super heterodyne
Intermodiate Frequencies: A Band: 1 st: 47.25 MHz, 2 nd: 450 kHz
B Band: 1 st: 44.85 MHz, 2 nd: 450 kHz
Sensitivity: 108 - 137 MHz (AM) 0.8μV typ for 10 dB SN
137 - 140 MHz (FM) 0.2μV for 12 dB SINAD
140 - 150MHz (FM) 0.2μV for 12 dB SINAD
150 - 174 MHz (FM) 0.25μV for 12 dB SINAD
174 - 222 MHz (FM) 0.3μV typ for 12 dB SINAD
222 - 300 MHz (FM) 0.25μV typ for 12 dB SINAD
300 - 336 MHz (AM) 0.8μV typ for 10 dB SINAD
336 - 420 MHz (FM) 0.25μV for 12 dB SINAD
420 - 470 MHz (FM) 0.2μV typ for 12 dB SINAD
470 - 520 MHz (FM) 0.2μV for 12 dB SINAD
800 - 900 MHz (FM) 0.4μV typ for 12 dB SINAD
900 - 999.99 MHz (FM) 0.8μV typ for 12 dB SINAD
Cellular blocked (USA only)
Digital mode
140 - 150 MHz (Digital) 0.19μV typ for BER 1%
420 - 470 MHz (Digital) 0.19μV typ for BER 1%
Squelch sensitivity: 0.16μV (144/430 MHz)
Selectivity: AM, FM 12 kHz/35 kHz (−6 dB/−60 dB)
AF Output: 3 W (8 Ω, THD10%, 13.8 V) internal speaker
8 W (4 Ω, THD10%, 13.8 V) Optional MLS-200-M10
AF output impedance: 4 - 16 Ω
Strength of secondary radio waves: 4 nW and below
Performance specications are nominal, unless otherwise indicated, and are subject to change without no-
tice. Measured in accordance with TIA/EIA-603.

EXPLODED VIEW-1 FTM-400DR/DE Technical Supplement
Exploded View & Miscellaneous Parts
RA140640A
FRONT COVER
RA1568800
SHEET(MIC)
RA0924400
SPONGE RUBBER(BT)
PANEL-UNIT
Q7000649
REF. YAESU P/N Description Qty.
①U20205007 BINDING HEAD SCREW M2.6X5B 2
②U31208007 OVAL HEAD SCREW M2.6X8B 8
③U20318007 BINDING HEAD SCREW M3X18B 4
④U70003007 PLAIN WASHER FW3B 4
⑤U20308002 BINDING HEAD SCREW M3X8NI 2
⑥U44308001 PAN HEAD TAPTITE-B M3X8 15
⑦U03310002 SEMS SCREW ASM3X10NI 4
⑧U24212007 BIND HEAD TAPTITE-B M2.6X12B 4
⑨U07240202 PAN HEAD SCREW M2X4NI#2 4
⑩U24206002 BIND HEAD TAPTITE-B M2.6X6NI 4
⑪U31206007 OVAL HEAD SCREW M2.6X6B 4
⑫U20208007 BINDING HEAD SCREW M2.6X8B 1
⑬U9900171 PLAIN WASHER FW2.6X7.5X0.5B 1
⑭U04510007 PAN HEAD(SEMS) SCREW HSM5X10B 1
Non-designated parts are available only as part of a designated assembly.
①
⑬
⑫
①
②
③
⑦
⑦
⑦⑦
⑥⑥⑥
⑥
⑥
⑥
⑥
⑥
⑥
⑥
⑥
⑥
⑥
⑥
⑨
⑨
⑨
⑨
⑧
⑧
⑧
⑧
⑪
⑪
⑪
⑪
⑩
⑩
⑩⑩
④
④
④
④
⑤
RA140630A
RUBBER KNOB(PWR)
RA1434600
DOUBLE FACE(HOLDER)
RA1434500
HOLDER PLATE(H034)
RA133910A
ENCODER KNOB(ASSY)
RA1339400
VOLUME KNOB (ASSY)
RA134050A
REAR PANEL
RA140620A
RUBBER KNOB(D)
RA1340000
LCD SPACER (A)
RA1340100
LCD SPACER (B)
RA0446200
LEAF SPRING
RA026680C
CHASSIS
S5000288
FAN GUARD K-G04D02-4HA
M2090053
FAN
P1091158
CONNECTOR
RA1406600
GROUND PLATE(FET)
RA1406500
SHIELD CASE COVER
RA1457300
ELEC. COND TAPE
RA0924400
SPONGE RUBBER(BT)
RA1317000 (CE Version)
COVER(C-MJ4)
RA1316900 (CE Version)
SHEET(SP-JACK)
RA123300A (CE Version)
COVERSP-JACK
RA1563700 (CE Version)
SHEET(40X25)
RA1550600
SP HOLDER(H034M)
RA1560700
SHEET(SP66)
RA131710A
SPONGE RUBBER(SP-CE)
RA1550700
SP NET(66)
M4090229
SPEAKER 66S-A3627
RA1406700
SPONGE RUBBER(VU)
RA02132A0
HIMERON TAPE
②
②
②
②
②
②
②
RA15505000
CASE(H034M)
RA1260500 (CE Version)
COVER(C-MJ6)
RA1563800 (CE Version)
SHEET(21.5X18.5)
③
③
③
⑤
RA0438700
RUBBER
RA1316600
PLATE(FET)
RA1058400
GASKET(6612)
⑥
RA135370B
FRONT PANEL (PRINT)
RA1339900
BRACKET (GPS)
Q7000642
GPS MODULE GPS-76A
CQ0189003 (USA)
CQ0189004 (EXP)
CQ0189005 (EU)
CQ0189006 (AUS)
PANEL ASSY
CS2204101
CASE ASSY
RA1339700 (CE Version)
COVER (JACK)
⑭

BLOCK DIAGRAM-1 FTM-400DR/DE Technical Supplement
Block Diagram

FTM-400DR/DE Technical Supplement
Alignment
ALIGNMENT-1
Introduction and Precautions
The FTM-400DR/FTM-400DE has been carefully
aligned at the factory for performance across the
specified amateur bands. Realignment should
therefore not be necessary except in the event of a
component failure. All component replacement and
service should be performed only by an authorized
YAESU representative, or the warranty policy may
be voided.
The following procedures cover the sometimes crit-
ical and tedious adjustments that are not normally
required once the transceiver has left the factory.
However, if damage occurs and some parts are re-
placed, realignment may be required. If a sudden
problem occurs during normal operation, it is like-
ly due to component failure; realignment should
not be done until after the faulty component has
been replaced.
We recommend that servicing be performed only
by authorized YAESU service technicians, who are
experienced with the circuitry and fully equipped
for repair and alignment. Therefore, if a fault is
suspected, contact the dealer from whom the trans-
ceiver was purchased for instructions regarding re-
pair. Authorized YAESU service technicians realign
all circuits and make complete performance checks
to ensure compliance with factory specifications
aer replacing any faulty components.
Those who do undertake any of the following
alignments are cautioned to proceed at their own
risk. Problems caused by unauthorized aempts at
realignment are not covered by the warranty pol-
icy. Also, YAESU must reserve the right to change
circuits and alignment procedures in the interest of
improved performance, without notifying owners.
Under no circumstances should any alignment be
attempted unless the normal function and opera-
tion of the transceiver are clearly understood, the
cause of the malfunction has been clearly pinpoint-
ed and any faulty components replaced, and the
need for realignment determined to be absolutely
necessary.
Required Test Equipment
RF Signal Generator with calibrated output level
at 1 GHz
Deviation Meter (linear detector)
 In-line Wameter with 5% accuracy at 1 GHz
 50-ohm, 100-W RF Dummy Load
 8-ohm AF Dummy Load
Regulated DC Power Supply adjustable from
11.5 to 16 V DC, 15 A
Frequency Counter: 0.2-ppm accuracy at
1 GHz
AF Signal Generator
AC Voltmeter
DC Voltmeter: high impedance
VHF/UHF Sampling Coupler
SINAD Meter
Important Notice
Do not adjust the alignment menus that are
not mentioned in this manual.

FTM-400DR/DE Technical Supplement
Alignment
ALIGNMENT-2
Alignment Preparation & Precautions
A 100-W RF dummy load and in-line wattmeter
must be connected to the main antenna jack in all
procedures that call for transmission; alignment
is not possible with an antenna. After complet-
ing one step, read the next step to see if the same
test equipment is required. If not, remove the test
equipment (except dummy load and wattmeter,
if connected) before proceeding. Correct align-
ment requires the transceiver and test equipment
be maintained at a constant ambient temperature
between 68 ~ 86 °F (20 ~ 30 °C). When the trans-
ceiver is brought into the shop from hot or cold air,
it should be allowed some time to come to room
temperature before alignment. Whenever possible,
alignments should be made with oscillator shields
and circuit boards rmly axed in place. Also, the
test equipment must be thoroughly warmed up be-
fore beginning.
Note: Signal levels in dB referred to in the alignment
procedure are based on 0 dBμ=0.5 μV (closed circuit).
Test Setup
Set up the test equipment as shown below for
transceiver alignment. Maintain the supply voltage
at13.8V DC for all steps.
Internal System Alignment Routine
This uses a programmed routine in the transceiver
which simplies many previously complex discrete
component seings and adjustments with digital-
ly-controlled seings via Microphone buons.
To enter the Alignment mode:
1. Press and hold in the [F(MW)]and [GM)]keys
while turning the transceiver on.
2. Press the [POWER(LOCK)]key.
"LOCK" will appear in the display.
3. Press the keys of the Microphone in the follow-
ing sequence.
[0]à[3]à[4]à[0]à[3]à[4]
4. Press the [POWER(LOCK)]key.
"UNLOCK" will appear in the display.
5. The transceiver is now in the "Alignment
mode".
MIC Jack
50-ohm
Dummy Load
Freq. Counter
Deviation
Meter
AC Voltmeter
AF Generator
AC Voltmeter
Inline
Wattmeter
Sampling
Coupler
Regulated
13.8V PSU

FTM-400DR/DE Technical Supplement
Alignment
ALIGNMENT-3
VCO VCV Adjustment
Connect the DC voltmeter to TP1503 (MAIN) and
TP1502 (SUB). Referring to the table below, turn
the transceiver to each frequency listed. Conrm
that the correct voltage is present, or adjust the list-
ed seing for the required voltage.
MAIN
Tune to: TX/RX for
440.05 MHz RX 2.6 ± 0.25 V
440.05 MHz TX 2.1 ± 0.25 V
146.05 MHz RX 1.4 - 0.25 V/+0.30 V
146.05 MHz TX 2.2 ± 0.25 V
130.00 MHz RX 0.35 ~ 0.70 V
174.00 MHz RX 0.40 ~ 0.70 V
299.99 MHz RX 5.0 ~ 6.1 V
549.95 MHz RX 3.5 ~ 5.3 V
550.00 MHz RX 0.15 ~ 0.35 V
SUB
Tune to: TX/RX for
440.05 MHz RX 2.6 ± 0.30 V
146.05 MHz RX 1.2 - 0.25 V/+0.30 V
130.00 MHz RX 0.55 V
174.00 MHz RX 0.5 ~ 0.90 V
299.99 MHz RX 5.0 ~ 6.2 V
549.95 MHz RX 3.5 ~ 5.2 V
550.00 MHz RX 0.15 ~ 0.35 V
DC Voltmeter
1. Set the power supply voltage to 13.8 V.
2. Press the [P1]key of the Microphone to set the
alignment menu Item to "Adj 10 BAT".
3. Press the [P3]key of the Microphone, to save
the new seing.
TP1502
TP1503

FTM-400DR/DE Technical Supplement
Alignment
ALIGNMENT-4
TX Power Adjustment
1. Press the [P1]key of the Microphone to set the
alignment menu Item to "Adj 02 PWR".
2. Set the transceiver frequency to 440.050 MHz.
3. Press the [F(MW)]key, then press the [Tx PWR]
to select "LO".
4. Press the [F(MW)]key.
5. Press the PTT switch to activate the transmier,
adjust the DIAL knob (Band B) so that RF Power
Meter reading is 5.3 W (± 0.5 W).
6. Press the [P2]key of the Microphone to set the
alignment menu Item to "Adj 02 DRV".
7. Adjust the DIAL knob (Band B) to set the DRV
to "9AH".
8. Press the [P2]key of the Microphone to set the
alignment menu Item to "Adj 02 PWR".
9. Press the [F(MW)]key, then press the [Tx PWR]
to select "MD".
10.Press the [F(MW)]key.
11.Press the PTT switch to activate the transmier,
adjust the DIAL knob (Band B) so that RF Power
Meter reading is 20 W (± 0.5 W).
12.Press the [P2]key of the Microphone to set the
alignment menu Item to "Adj 02 DRV".
13.Adjust the DIAL knob (Band B) to set the DRV
to "B0H".
14.Press the [P2]key of the Microphone to set the
alignment menu Item to "Adj 02 PWR".
15.Press the [F(MW)]key, then press the [Tx PWR]
to select "HI".
16.Press the [F(MW)]key.
17.Press the PTT switch to activate the transmier,
adjust the DIAL knob (Band B) so that RF Power
Meter reading is 50 W (± 0.5 W).
18.Press the [P2]key of the Microphone to set the
alignment menu Item to "Adj 02 DRV".
19.Adjust the DIAL knob (Band B) to set the DRV
to "D0H".
20.Press the [P2]key of the Microphone to set the
alignment menu Item to "Adj 02 PWR".
21.Set the transceiver frequency to 146.050 MHz.
22.Press the [F(MW)]key, then press the [Tx PWR]
to select "LO".
23.Press the [F(MW)]key.
24.Press the PTT switch to activate the transmier,
adjust the DIAL knob (Band B) so that RF Power
Meter reading is 5 W (± 0.5 W).
25.Press the [P2]key of the Microphone to set the
alignment menu Item to "Adj 02 DRV".
26.Adjust the DIAL knob (Band B) to set the DRV
to "CFH".
27.Press the [P2]key of the Microphone to set the
alignment menu Item to "Adj 02 PWR".
28.Press the [F(MW)]key, then press the [Tx PWR]
to select "MD".
29.Press the [F(MW)]key.
30.Press the PTT switch to activate the transmier,
adjust the DIAL knob (Band B) so that RF Power
Meter reading is 20 W (± 0.5 W).
31.Press the [P2]key of the Microphone to set the
alignment menu Item to "Adj 02 DRV".
32.Adjust the DIAL knob (Band B) to set the DRV
to "DAH".
33.Press the [P2]key of the Microphone to set the
alignment menu Item to "Adj 02 PWR".
34.Press the [F(MW)]key, then press the [Tx PWR]
to select "HI".
35.Press the [F(MW)]key.
36.Press the PTT switch to activate the transmier,
adjust the DIAL knob (Band B) so that RF Power
Meter reading is 50 W (± 0.5 W).
37.Press the [P2]key of the Microphone to set the
alignment menu Item to "Adj 02 DRV".
38.Adjust the DIAL knob (Band B) to set the DRV
to "EFH".
39.Press the [P2]key of the Microphone to set the
alignment menu Item to "Adj 02 PWR".

FTM-400DR/DE Technical Supplement
Alignment
ALIGNMENT-5
PLL Reference Frequency Adjustmen t
1. Press the [P1]key of the Microphone to set the
alignment menu Item to "Adj 00 REF/A".
2. Set the transceiver frequency to 435.050 MHz.
3. Press the [F(MW)]key, then press the [Tx PWR]
to select "LO".
4. Press the [F(MW)]key.
5. Press the PTT switch to activate the transmit-
ter, adjust the DIAL knob (Band B), if necessary,
so the counter frequency is within 100 Hz of
435.050MHz.
6. Press the [P2]key of the Microphone to set the
alignment menu Item to "Adj 00 REF/B".
7. Connect the frequency counter fed through
the0.001μF capactor to the TP1501.
8. Adjust adjust the DIAL knob (Band B), as need-
ed, so that thecounter frequency reading is
390.200 MHz (±100Hz).
RF Front-end Tuning
1. Connect the DC voltmeter to TP1001 (BAND
A) and TP1002 (BAND B) on the MAIN unit,
then inject a 439.050 MHz signal at a level of +10
dBμV (with 1kHz modulation ± 3.5 kHz devia-
tion) from the RF signal generator.
2. Set the transceiver frequency to 439.050 MHz.
3. Press the [P1]key of the Microphone to set the
alignment menu Item to "Adj 01 TUN/A".
4. Adjust the DIAL knob (Band B) for maximum
deflection on the DC Voltmeter and then turn
the dialin the opposite direction until the meter
deection drops slightly lower than maximum.
5. Set the transceiver and RF signal generator fre-
quency to 145.050 MHz.
6. Adjust the DIAL knob (Band B) for maximum
deflection on the DC Voltmeter and then turn
the dialin the opposite direction until the meter
deection drops slightly lower than maximum.
7. Set the RF signal generator frequency to
439.050MHz.
8. Set the transceiver frequency to 439.050 MHz of
the Band B.
9. Press the [P2]key of the Microphone to set the
alignment menu Item to "Adj 01 TUN/B".
10.Adjust the DIAL knob (Band B) for maximum
deflection on the DC Voltmeter and then turn
the dialin the opposite direction until the meter
deection drops slightly lower than maximum.
11.Set the transceiver and RF signal generator fre-
quency to 145.050 MHz.
12.Adjust the DIAL knob (Band B) for maximum
deflection on the DC Voltmeter and then turn
the dialin the opposite direction until the meter
deection drops slightly lower than maximum.
TP1501TP1001 TP1002

FTM-400DR/DE Technical Supplement
Alignment
ALIGNMENT-6
Squelch Threshold Level
1. Set the RF signal generator to 440.050 MHz. Set
the generator for ±3.5 kHz deviation of a 1 kHz
modulation tone, and set the RF output level
from the signal generator to -12 dBμV.
2. Set the transceiver frequency to 440.050 MHz.
3. Press the [D(X)]key to select "FM".
4. Press the [P1]key of the Microphone to set the
alignment menu Item to "Adj 09 SQL/A".
5. Press the [P3]key to save the new seing.
6. Increase the output level of the signal genera-
torup to -4 dBμV.
7. Press the [P4]key to save the new seing.
8. Set the transceiver and RF signal generator fre-
quency to 146.050 MHz.
9. Increase the output level of the signal genera-
torup to -12 dBμV.
10.Press the [P3]key to save the new seing.
11.Increase the output level of the signal genera-
torup to -4 dBμV.
12.Press the [P4]key to save the new seing.
13.Press the [P2]key of the Microphone to set the
alignment menu Item to "Adj 09 SQL/B".
14.Set the RF signal generator to 440.050 MHz. Set
the generator for ±3.5 kHz deviation of a 1 kHz
modulation tone, and set the RF output level
from the signal generator to -12 dBμV.
15.Set the transceiver frequency to 440.050 MHz.
16.Press the [D(X)]key to select "FM".
17.Press the [P3]key to save the new seing.
18.Increase the output level of the signal genera-
torup to -4 dBμV.
19.Press the [P4]key to save the new seing.
20.Set the transceiver and RF signal generator fre-
quency to 146.050 MHz.
21.Increase the output level of the signal genera-
torup to -12 dBμV.
22.Press the [P3]key to save the new seing.
23.Increase the output level of the signal genera-
torup to -4 dBμV.
24.Press the [P4]key to save the new seing.
S-Meter Calibration
1. Set the RF signal generator to 440.050 MHz. Set
the generator for ±3.5 kHz deviation of a 1 kHz
modulation tone, and set the RF output level
from the signal generator to -5 dBμV.
2. Set the transceiver frequency to 440.050 MHz.
3. Press the [D(X)]key to select "FM".
4. Press the [P1]key of the Microphone to set the
alignment menu Item to "Adj 08 SM/A".
5. Press the [P3]key to save the new seing.
6. Increase the output level of the signal genera-
torup to +23 dBμV.
7. Press the [P4]key to save the new seing.
8. Set the transceiver and RF signal generator fre-
quency to 146.050 MHz.
9. Increase the output level of the signal genera-
torup to -5 dBμV.
10.Press the [P3]key to save the new seing.
11.Increase the output level of the signal genera-
torup to +23 dBμV.
12.Press the [P4]key to save the new seing.
13.Press the [P2]key of the Microphone to set the
alignment menu Item to "Adj 09 SM/B".
14.Set the RF signal generator to 440.050 MHz. Set
the generator for ±3.5 kHz deviation of a 1 kHz
modulation tone, and set the RF output level
from the signal generator to -5 dBμV.
15.Set the transceiver frequency to 440.050 MHz.
16.Press the [D(X)]key to select "FM".
17.Press the [P3]key to save the new seing.
18.Increase the output level of the signal genera-
torup to +23 dBμV.
19.Press the [P4]key to save the new seing.
20.Set the transceiver and RF signal generator fre-
quency to 146.050 MHz.
21.Increase the output level of the signal genera-
torup to -5 dBμV.
22.Press the [P3]key to save the new seing.
23.Increase the output level of the signal genera-
torup to +23 dBμV.
24.Press the [P4]key to save the new seing.

FTM-400DR/DE Technical Supplement
Alignment
ALIGNMENT-7
TX Deviation
1. Inject a 1 kHz, 80 mV signal from the Audio
Generator.
2. Set the transceiver frequency to 440.050 MHz.
3. Press the [F(MW)]key, then press the [Tx PWR]
to select "LO".
4. Press the [F(MW)]key.
5. Press the [P1]key of the Microphone to set the
alignment menu Item to "Adj 03 DEV".
6. Press the PTT switch to activate the transmier,
adjust the DIAL knob (Band B) so that the Devi-
ation Meter reading is 4.5 kHz (±0.2 kHz) (USA
Version: 4.2 kHz (±0.2 kHz).
7. Set the transceiver frequency to 146.050 MHz.
8. Press the [F(MW)]key, then press the [Tx PWR]
to select "LO".
9. Press the PTT switch to activate the transmier,
adjust the DIAL knob (Band B) so that the Devi-
ationMeter reading is 4.5 kHz (±0.2 kHz) (USA
Version: 4.2 kHz (±0.2 kHz).
Digital TX Deviation
1. Inject a 1 kHz, 80 mV signal from the Audio
Generator.
2. Set the transceiver frequency to 440.050 MHz.
3. Press the [F(MW)]key, then press the [Tx PWR]
to select "LO".
4. Press the [F(MW)]key.
5. Press the [P1]key of the Microphone to set the
alignment menu Item to "Adj 04 MOD".
6. Press the [P2]key of the Microphone to set the
alignment menu Item to "Adj 04 MIX".
7. Press the PTT switch to activate the transmier,
adjust the DIAL knob (Band B) so that the Devi-
ation Meter reading is 4.5 kHz (±0.2 kHz).
8. Set the transceiver frequency to 146.050 MHz.
9. Press the [F(MW)]key, then press the [Tx PWR]
to select "LO".
10.Press the [F(MW)]key.
11.Press the PTT switch to activate the transmier,
adjust the DIAL knob (Band B) so that the Devi-
ationMeter reading is 4.5 kHz (±0.2 kHz) (USA
Version: 4.2 kHz (±0.2 kHz).
DCS TX Deviation
1. Set the transceiver frequency to 440.050 MHz.
2. Press the [F(MW)]key, then press the [Tx PWR]
to select "LO".
3. Press the [SQL]to select "D-TRX".
4. Press the [F(MW)]key.
5. Press the [P1]key of the Microphone to set the
alignment menu Item to "Adj 05 DCS".
6. Press the PTT switch to activate the transmier,
adjust the DIAL knob (Band B) so that the Devi-
ation Meter reading is 0.60 kHz ~ 0.80 kHz.
7. Set the transceiver frequency to 146.050 MHz.
8. Press the [F(MW)]key, then press the [Tx PWR]
to select "LO".
9. Press the [F(MW)]key.
10.Press the PTT switch to activate the transmier,
adjust the DIAL knob (Band B) so that the Devi-
ation Meter reading is 0.60 kHz ~ 0.80 kHz.
CTCSS TX Deviation
1. Set the transceiver frequency to 440.050 MHz.
2. Press the [F(MW)]key, then press the [Tx PWR]
to select "LO".
3. Press the [SQL]to select "T-TRX".
4. Press the [F(MW)]key.
5. Press the [P1]key of the Microphone to set the
alignment menu Item to "Adj 06 CTC".
6. Press the PTT switch to activate the transmier,
adjust the DIAL knob (Band B) so that the Devi-
ation Meter reading is 0.65 kHz ~ 0.75 kHz.
7. Set the transceiver frequency to 146.050 MHz.
8. Press the [F(MW)]key, then press the [Tx PWR]
to select "LO".
9. Press the [F(MW)]key.
10.Press the PTT switch to activate the transmier,
adjust the DIAL knob (Band B) so that the Devi-
ation Meter reading is 0.65 kHz ~ 0.75 kHz.

FTM-400DR/DE Technical Supplement
Alignment
ALIGNMENT-8
Center Meter Calibration
1. Set the RF signal generator to 440.050 MHz. Set
the generator for ±3.5 kHz deviation of a 1 kHz
modulation tone, and set the RF output level
from the signal generator to +10 dBμV.
2. Set the transceiver frequency to 440.050 MHz.
3. Press the [D(X)]key to select "FM".
4. Press the [P1]key of the Microphone to set the
alignment menu Item to "Adj 07 CTR/A".
5. Press the [P3]key to save the new seing.
6. Set the transceiver frequency to 440.050 MHz of
the Band B.
7. Press the [D(X)]key to select "FM".
8. Press the [P2]key of the Microphone to set the
alignment menu Item to "Adj 07 CTR/B".
9. Press the [P3]key to save the new seing.
To close the alignment mode, just turn the power
off bypressing and holding the [POWER(LOCK)]
switch for two seconds. The next time the trans-
ceiver is turned on, normaloperation will resume.

FTM-400DR/DE Technical Supplement
MAIN-1
MAIN Unit
Circuit Diagram

FTM-400DR/DE Technical Supplement
MAIN-2
MAIN Unit
Parts Layout
Side A
AB D FC E
1
2
3
5
4
6
G

FTM-400DR/DE Technical Supplement
MAIN-3
MAIN Unit
Side B
ab d fc e
1
2
3
5
4
6
g

MAIN-4
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG YAESU P/N VERS. LOT SIDE LAY ADR
MAIN Unit
Parts List
FTM-400DR/DE Technical Supplement
PCB with Components CS2201703 USA: A2U
CS2201704 EXP: A1
CS2201705 EXP: A2
CS2201706 EXP: A3
CS2201707 EU: B1
CS2201708 EU: B2
CS2201709 EXP: B3
CS2201710 EU: C1
CS2201711 EU: C2
CS2201712 EXP: C3
CS2201713 EU: D1
CS2201714 EU: D2
CS2201715 AUS: H1
CS2201716 AUS: H2
BT1501 LI-ION BATTERY ML614R-TT31 Q9000895 1- A A6
C 1001 CHIP CAP. 12pF 50V CH GRM1552C1H120GA01D K22179723 1- B a2
C 1002 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a3
C 1004 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a3
C 1007 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a3
C 1008 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b4
C 1009 CHIP CAP. 68pF 50V CH GRM1552C1H680JA01D K22178232 1- B b4
C 1010 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b4
C 1011 CHIP CAP. 27pF 50V CH GRM1552C1H270GA01D K22179726 1- B b4
C 1012 CHIP CAP. 0.5pF 50V CK GRM1554C1HR50BA01D K22178285 1- B b4
C 1013 CHIP CAP. 0.5pF 50V CK GRM1554C1HR50BA01D K22178285 1- B b4
C 1014 CHIP CAP. 27pF 50V CH GRM1552C1H270GA01D K22179726 1- B b4
C 1015 CHIP CAP. 1pF 50V CK GRM1554C1H1R0BA01D K22178287 1- B b4
C 1016 CHIP CAP. 0.75pF 50V CK GRM1554C1HR75BA01D K22178286 1- B b4
C 1017 CHIP CAP. 0.5pF 50V CK GRM1554C1HR50BA01D K22178285 1- B b4
C 1018 CHIP CAP. 1pF 50V CK GRM1554C1H1R0BA01D K22178287 1- B b4
C 1019 CHIP CAP. 1pF 50V CK GRM1554C1H1R0BA01D K22178287 1- B b4
C 1020 CHIP CAP. 27pF 50V CH GRM1552C1H270GA01D K22179726 1- B b4
C 1021 CHIP CAP. 18pF 50V CH GRM1552C1H180JA01D K22178218 1- B b4
C 1022 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c4
C 1023 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B c4
C 1024 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b4
C 1025 CHIP CAP. 7pF 50V CH GRM1552C1H7R0BA01D K22178294 1- B b4
C 1026 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BA01D K22178289 1- B b4
C 1027 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b3
C 1028 CHIP CAP. 6pF 50V CH GRM1552C1H6R0BA01D K22178293 1- B b4
C 1029 CHIP CAP. 22pF 50V CH GRM1552C1H220GA01D K22179707 1- B b4
C 1030 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c4
C 1031 CHIP CAP. 0.5pF 50V CK GRM1554C1HR50BA01D K22178285 1- B c4
C 1032 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b4
C 1033 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E4
C 1034 CHIP CAP. 6pF 50V CH GRM1552C1H6R0BA01D K22178293 1- B c4
C 1035 CHIP CAP. 1.5pF 50V CK GRM1554C1H1R5BA01D K22178288 1- B c4
C 1036 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a2
C 1037 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a3
C 1038 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a3
C 1040 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a3
C 1041 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a4
C 1042 CHIP CAP. 68pF 50V CH GRM1552C1H680JA01D K22178232 1- B a4
C 1043 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A G5
C 1044 CHIP CAP. 27pF 50V CH GRM1552C1H270GA01D K22179726 1- B a4
C 1045 CHIP CAP. 0.5pF 50V CK GRM1554C1HR50BA01D K22178285 1- B a4
C 1046 CHIP CAP. 0.5pF 50V CK GRM1554C1HR50BA01D K22178285 1- B a4
C 1047 CHIP CAP. 27pF 50V CH GRM1552C1H270GA01D K22179726 1- B a4
C 1048 CHIP CAP. 0.75pF 50V CK GRM1554C1HR75BA01D K22178286 1- B a4
C 1049 CHIP CAP. 1pF 50V CK GRM1554C1H1R0BA01D K22178287 1- B a4
C 1050 CHIP CAP. 0.5pF 50V CK GRM1554C1HR50BA01D K22178285 1- B a4
C 1051 CHIP CAP. 1pF 50V CK GRM1554C1H1R0BA01D K22178287 1- B a4
C 1053 CHIP CAP. 27pF 50V CH GRM1552C1H270GA01D K22179726 1- B a4
C 1054 CHIP CAP. 15pF 50V CH GRM1552C1H150GA01D K22178300 1- B a4
C 1055 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A G5
C 1056 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B a5
C 1057 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a4
C 1058 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a4
C 1059 CHIP CAP. 7pF 50V CH GRM1552C1H7R0BA01D K22178294 1- B a4
C 1060 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BA01D K22178289 1- B a4
C 1061 CHIP CAP. 22pF 50V CH GRM1552C1H220GA01D K22179707 1- B a5
C 1062 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a4
C 1063 CHIP CAP. 6pF 50V CH GRM1552C1H6R0BA01D K22178293 1- B a4

MAIN-5
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG YAESU P/N VERS. LOT SIDE LAY ADR
MAIN Unit
Parts List
FTM-400DR/DE Technical Supplement
C 1064 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a5
C 1065 CHIP CAP. 0.5pF 50V CK GRM1554C1HR50BA01D K22178285 1- B a5
C 1066 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A G5
C 1067 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A G5
C 1068 CHIP CAP. 3pF 50V CJ GRM1553C1H3R0BA01D K22178290 1- A G5
C 1069 CHIP CAP. 6pF 50V CH GRM1552C1H6R0BA01D K22178293 1- B a5
C 1070 CHIP CAP. 12pF 50V CH GRM1552C1H120JA01D K22178214 1- B a3
C 1071 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a4
C 1072 CHIP CAP. 6pF 50V CH GRM1552C1H6R0BA01D K22178293 1- B a4
C 1073 CHIP CAP. 10pF 50V CH GRM1552C1H100BA01D K22178297 1- B a3
C 1074 CHIP CAP. 8pF 50V CH GRM1552C1H8R0BA01D K22178295 1- B a4
C 1075 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a4
C 1076 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B a4
C 1077 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b4
C 1078 CHIP CAP. 0.5pF 50V CK GRM1554C1HR50BA01D K22178285 1- B b4
C 1079 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b4
C 1080 CHIP CAP. 8pF 50V CH GRM1552C1H8R0BA01D K22178295 1- B b4
C 1081 CHIP CAP. 1.5pF 50V CK GRM1554C1H1R5BA01D K22178288 1- B b4
C 1082 CHIP CAP. 47pF 50V CH GRM1552C1H470GA01D K22179709 1- B b4
C 1083 CHIP CAP. 0.75pF 50V CK GRM1554C1HR75BA01D K22178286 1- B b4
C 1084 CHIP CAP. 18pF 50V CH GRM1552C1H180GA01D K22179701 1- B b4
C 1085 CHIP CAP. 1.5pF 50V CK GRM1554C1H1R5BA01D K22178288 1- B b4
C 1086 CHIP CAP. 0.5pF 50V CK GRM1554C1HR50BA01D K22178285 1- B b4
C 1087 CHIP CAP. 47pF 50V CH GRM1552C1H470GA01D K22179709 1- B b4
C 1088 CHIP CAP. 8pF 50V CH GRM1552C1H8R0BA01D K22178295 1- B b4
C 1089 CHIP CAP. 0.5pF 50V CK GRM1554C1HR50BA01D K22178285 1- B b4
C 1090 CHIP CAP. 1pF 50V CK GRM1554C1H1R0BA01D K22178287 1- B b4
C 1091 CHIP CAP. 47pF 50V CH GRM1552C1H470GA01D K22179709 1- B b4
C 1092 CHIP CAP. 15pF 50V CH GRM1552C1H150GA01D K22178300 1- B b4
C 1093 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c4
C 1094 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B c4
C 1095 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E4
C 1096 CHIP CAP. 7pF 50V CH GRM1552C1H7R0BA01D K22178294 1- A E4
C 1097 CHIP CAP. 5pF 50V CH GRM1552C1H5R0BA01D K22178292 1- B a3
C 1098 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a4
C 1099 CHIP CAP. 8pF 50V CH GRM1552C1H8R0BA01D K22178295 1- B a4
C 1100 CHIP CAP. 0.75pF 50V CK GRM1554C1HR75BA01D K22178286 1- B a4
C 1101 CHIP CAP. 3pF 50V CJ GRM1553C1H3R0BA01D K22178290 1- B a4
C 1102 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b4
C 1103 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a4
C 1104 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B a4
C 1105 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a4
C 1106 CHIP CAP. 0.5pF 50V CK GRM1554C1HR50BA01D K22178285 1- B a4
C 1107 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F4
C 1108 CHIP CAP. 1.5pF 50V CK GRM1554C1H1R5BA01D K22178288 1- B a4
C 1109 CHIP CAP. 0.75pF 50V CK GRM1554C1HR75BA01D K22178286 1- B a4
C 1110 CHIP CAP. 47pF 50V CH GRM1552C1H470GA01D K22179709 1- B a4
C 1111 CHIP CAP. 18pF 50V CH GRM1552C1H180GA01D K22179701 1- B a4
C 1112 CHIP CAP. 0.5pF 50V CK GRM1554C1HR50BA01D K22178285 1- B a4
C 1113 CHIP CAP. 0.5pF 50V CK GRM1554C1HR50BA01D K22178285 1- B a4
C 1114 CHIP CAP. 15pF 50V CH GRM1552C1H150GA01D K22178300 1- B a4
C 1115 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a5
C 1116 CHIP CAP. 1.5pF 50V CK GRM1554C1H1R5BA01D K22178288 1- B a4
C 1117 CHIP CAP. 0.5pF 50V CK GRM1554C1HR50BA01D K22178285 1- B a4
C 1118 CHIP CAP. 47pF 50V CH GRM1552C1H470GA01D K22179709 1- B a4
C 1119 CHIP CAP. 8pF 50V CH GRM1552C1H8R0BA01D K22178295 1- B a4
C 1120 CHIP CAP. 47pF 50V CH GRM1552C1H470GA01D K22179709 1- B a4
C 1121 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B a5
C 1122 CHIP CAP. 8pF 50V CH GRM1552C1H8R0BA01D K22178295 1- A F5
C 1123 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F4
C 1124 CHIP CAP. 12pF 50V CH GRM1552C1H120GA01D K22179723 1- B a3
C 1125 CHIP CAP. 7pF 50V CH GRM1552C1H7R0BA01D K22178294 1- A F3
C 1126 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F4
C 1128 CHIP CAP. 22pF 50V CH GRM1552C1H220GA01D K22179707 1- A F4
C 1130 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F4
C 1131 CHIP CAP. 47pF 50V CH GRM1552C1H470GA01D K22179709 1- A E4
C 1132 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F4
C 1133 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E4
C 1135 CHIP CAP. 3pF 50V CJ GRM1553C1H3R0BA01D K22178290 1- A E4
C 1136 CHIP CAP. 3pF 50V CJ GRM1553C1H3R0BA01D K22178290 1- A E4
C 1137 CHIP CAP. 27pF 50V CH GRM1552C1H270GA01D K22179726 1- A E4
C 1138 CHIP CAP. 1pF 50V CK GRM1554C1H1R0BA01D K22178287 1- A E4
C 1139 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E4

MAIN-6
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG YAESU P/N VERS. LOT SIDE LAY ADR
MAIN Unit
Parts List
FTM-400DR/DE Technical Supplement
C 1140 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F4
C 1141 CHIP CAP. 8pF 50V CH GRM1552C1H8R0BA01D K22178295 1- A E4
C 1142 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F4
C 1143 CHIP CAP. 0.5pF 50V CK GRM1554C1HR50BA01D K22178285 1- A F4
C 1144 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F4
C 1145 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F4
C 1146 CHIP CAP. 47pF 50V CH GRM1552C1H470GA01D K22179709 1- A F4
C 1147 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BA01D K22178289 1- A F4
C 1148 CHIP CAP. 3pF 50V CJ GRM1553C1H3R0BA01D K22178290 1- A F4
C 1149 CHIP CAP. 3pF 50V CJ GRM1553C1H3R0BA01D K22178290 1- A F4
C 1150 CHIP CAP. 22pF 50V CH GRM1552C1H220GA01D K22179707 1- A F4
C 1151 CHIP CAP. 1pF 50V CK GRM1554C1H1R0BA01D K22178287 1- A F4
C 1152 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F5
C 1153 CHIP CAP. 10pF 50V CH GRM1552C1H100BA01D K22178297 1- A F4
C 1154 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BA01D K22178289 1- A F2
C 1155 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a2
C 1156 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 1- B a2
C 1157 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BA01D K22178289 1- B a2
C 1158 CHIP CAP. 6pF 50V CH GRM1552C1H6R0BA01D K22178293 1- B a2
C 1159 CHIP CAP. 2pF 200V CK GRM1884C2D2R0CV01D K22234204 1- A F2
C 1160 CHIP CAP. 1pF 50V CK GRM1554C1H1R0BA01D K22178287 1- B a2
C 1161 CHIP CAP. 3pF 50V CJ GRM1553C1H3R0BA01D K22178290 1- B a2
C 1162 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a2
C 1163 CHIP CAP. 1.5pF 50V CK GRM1554C1H1R5BA01D K22178288 1- B a3
C 1164 CHIP CAP. 1.5pF 50V CK GRM1554C1H1R5BA01D K22178288 1- B a3
C 1165 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F3
C 1166 CHIP CAP. 8pF 50V CH GRM1552C1H8R0BA01D K22178295 1- B a3
C 1167 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E4
C 1168 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E4
C 1169 CHIP CAP. 27pF 50V CH GRM1552C1H270GA01D K22179726 1- A E4
C 1170 CHIP CAP. 1pF 50V CK GRM1554C1H1R0BA01D K22178287 1- A E4
C 1171 CHIP CAP. 10pF 50V CH GRM1552C1H100BA01D K22178297 1- A E4
C 1173 CHIP CAP. 22pF 50V CH GRM1552C1H220GA01D K22179707 1- A E4
C 1174 CHIP CAP. 15pF 50V CH GRM1552C1H150GA01D K22178300 1- A E4
C 1175 CHIP CAP. 0.75pF 50V CK GRM1554C1HR75BA01D K22178286 1- A E4
C 1176 CHIP CAP. 10pF 50V CH GRM1552C1H100BA01D K22178297 1- A E4
C 1177 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BA01D K22178289 1- A E4
C 1178 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BA01D K22178289 1- A E4
C 1179 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E4
C 1180 CHIP CAP. 1.5pF 50V CK GRM1554C1H1R5BA01D K22178288 1- B a3
C 1181 CHIP CAP. 8pF 50V CH GRM1552C1H8R0BA01D K22178295 1- A G3
C 1182 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F4
C 1184 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A G4
C 1185 CHIP CAP. 27pF 50V CH GRM1552C1H270GA01D K22179726 1- A G4
C 1186 CHIP CAP. 1pF 50V CK GRM1554C1H1R0BA01D K22178287 1- A G4
C 1187 CHIP CAP. 22pF 50V CH GRM1552C1H220GA01D K22179707 1- A F4
C 1188 CHIP CAP. 10pF 50V CH GRM1552C1H100BA01D K22178297 1- A G4
C 1189 CHIP CAP. 15pF 50V CH GRM1552C1H150GA01D K22178300 1- A F5
C 1190 CHIP CAP. 0.75pF 50V CK GRM1554C1HR75BA01D K22178286 1- A G4
C 1191 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BA01D K22178289 1- A G5
C 1192 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BA01D K22178289 1- A G5
C 1193 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A G4
C 1194 CHIP CAP. 10pF 50V CH GRM1552C1H100BA01D K22178297 1- A F4
C 1195 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E4
C 1196 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b4
C 1197 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F4
C 1198 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A C6
C 1199 CHIP TA.CAP. 10uF 10V TAJA106M010Y K78100072 1- A E6
C 1204 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A C6
C 1205 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A C6
C 1206 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E5
C 1207 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E4
C 1208 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A A4
C 1209 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A A4
C 1210 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B g4
C 1211 CHIP CAP. 7pF 50V CH GRM1552C1H7R0BA01D K22178294 1- B c4
C 1212 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c4
C 1213 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c4
C 1214 CHIP CAP. 7pF 50V CH GRM1552C1H7R0BA01D K22178294 1- A D4
C 1215 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c4
C 1216 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- A D4
C 1217 CHIP CAP. 22pF 50V CH GRM1552C1H220GA01D K22179707 1- B d4
C 1218 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B d4

MAIN-7
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG YAESU P/N VERS. LOT SIDE LAY ADR
MAIN Unit
Parts List
FTM-400DR/DE Technical Supplement
C 1219 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B d4
C 1220 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A C4
C 1221 CHIP CAP. 0.47uF 6.3V B GRM155B30J474KE18D K22088802 1- A C4
C 1222 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BA01D K22178289 1- B c5
C 1223 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B d5
C 1224 CHIP CAP. 22pF 50V CH GRM1552C1H220GA01D K22179707 1- B d5
C 1225 CHIP CAP. 100pF 50V CH GRM1552C1H101JA01D K22178236 1- B d5
C 1226 CHIP TA.CAP. 22uF 6.3V TEESVA0J226M8R K78080047 1- B d4
C 1227 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B d5
C 1228 CHIP TA.CAP. 10uF 10V TAJA106M010Y K78100072 1- B d5
C 1229 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 1- A C5
C 1230 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 1- A C5
C 1231 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B d5
C 1232 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- A C5
C 1233 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A C5
C 1234 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 1- A C5
C 1235 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B d5
C 1236 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B d5
C 1237 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 1- B d5
C 1238 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B d5
C 1239 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A C5
C 1240 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B d5
C 1241 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B d5
C 1242 CHIP CAP. 100pF 50V CH GRM1552C1H101JA01D K22178236 1- B d5
C 1243 CHIP CAP. 22pF 50V CH GRM1552C1H220GA01D K22179707 1- A C5
C 1244 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A C5
C 1245 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A C5
C 1246 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A D6
C 1247 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B d5
C 1248 CHIP CAP. 7pF 50V CH GRM1552C1H7R0DA01D K22178209 1- B b5
C 1249 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b5
C 1250 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B b5
C 1251 CHIP CAP. 7pF 50V CH GRM1552C1H7R0BA01D K22178294 1- A F5
C 1252 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B b6
C 1253 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- A E4
C 1254 CHIP CAP. 22pF 50V CH GRM1552C1H220GA01D K22179707 1- B b5
C 1255 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B b5
C 1256 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b5
C 1257 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b4
C 1258 CHIP CAP. 0.47uF 6.3V B GRM155B30J474KE18D K22088802 1- B b5
C 1259 CHIP CAP. 1pF 50V CK GRM1554C1H1R0BA01D K22178287 1- B a6
C 1260 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B b6
C 1261 CHIP CAP. 27pF 50V CH GRM1552C1H270JA01D K22178222 1- B b6
C 1262 CHIP CAP. 100pF 50V CH GRM1552C1H101JA01D K22178236 1- B b5
C 1263 CHIP TA.CAP. 22uF 6.3V TEESVA0J226M8R K78080047 1- B b5
C 1264 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B b5
C 1265 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 1- B b5
C 1266 CHIP TA.CAP. 10uF 10V TAJA106M010Y K78100072 1- B b6
C 1267 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 1- B b6
C 1268 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 1- B b6
C 1269 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B b6
C 1270 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B b6
C 1271 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- B b6
C 1272 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b6
C 1273 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B b5
C 1274 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 1- B b5
C 1275 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- A E5
C 1276 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B b6
C 1277 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- A E5
C 1278 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B b6
C 1279 CHIP CAP. 100pF 50V CH GRM1552C1H101JA01D K22178236 1- B b6
C 1280 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 1- B b5
C 1281 CHIP CAP. 22pF 50V CH GRM1552C1H220GA01D K22179707 1- A F6
C 1282 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A F6
C 1283 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b5
C 1284 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b5
C 1285 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c4
C 1286 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c4
C 1287 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c5
C 1288 CHIP CAP. 0.0056uF 25V B GRM155B11E562KA01D K22148802 1- A C5
C 1289 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A C5
C 1290 CHIP CAP. 1uF 6.3V B GRM155B30J105KE18D K22088803 1- A D6
C 1291 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A C5
