Yakima HoldUp Plus2 User manual

HoldUp Plus2
SAFETY CLIP (1X)
BASE (1X)
WRENCH (1X)
REAR WHEEL TRAY
ASSEMBLY (1X)
FRONT WHEEL TRAY
ASSEMBLY (1X)
BOLT (1X)
LOCK WASHER (1X)
BOLT (8X)
LOCK WASHER (8X)
WASHER (8X)
INsTAll ThIs
PROducT ON 2"
hITch veRsION Of
The hOlduP
PIN (1X)
PLUG (1X)
KEY (2X)
Safety Kit included:
See additional
instructions for
installation.

1034431D-2/21
ReMOve eNd cAP
fROM hOlduP.
Using a flathead screwdriver, remove
the end cap from the HoldUp.
INseRT Plus2 BAse INTO hOlduP.
Insert the Plus2
base into the
HoldUp tube,
aligning holes.
Align
INsTAll MAIN BOlT.
Insert bolt,
and lock-
washer in
order shown.
Tighten with
adjustable
wrench.
ROTATe TO uPRIGhT POsITION.
Pull spring pin to
release base.
Lift frame.
Release spring pin. Pin
should snap into place.
75 ft-lbs.
ReMOve fAsTeNeRs.
The fasteners are installed in the trays for shipping
purposes. Remove them to prepare for assembly.

1034431D-3/21
ATTAch fIRsT TRAY TO BAse.
LOWER TRAY:
IMPORTANT: Wheel strap is
to your right, and pivot arm is
to your left.
wheel strap
•Alignholesintraytobecenteredinslotsonbase.
•Installbolt,lock-washer,andwasher,inordershown.
•Fingertightenallfourbolts.
•Tightenwithsuppliedwrench.
pivot arm
17 ft-lbs.
ATTAch secONd TRAY TO BAse.
UPPER TRAY:
IMPORTANT:
Wheel strap is
to your left, and
pivot arm is to
your right.
pivot arm
wheel strap
17 ft-lbs.
•Alignholesintraytobecenteredinslotsonbase.
•Installbolt,lock-washer,andwasher,inordershown.
•Fingertightenallfourbolts.
•Tightenwithsuppliedwrench.

Tuck strap into slot at
rear of whelltray.
Release wheelstrap by pressing
the lever on the buckle.
PRePARe fOR lOAdING.
CAUTION: If any part
of your bike comes in
contact with the red
trigger, do not use this
carrier with that bike.
Note: HoldUp can fold
down past horizontal to
aid in loading your bikes.
lOAd heAvIesT BIKe fIRsT.
Do not install your bike
if tire may go flat or has
a slow leak. Lost tire
pressure after install may
result in an insecure load.
If a fender prevents proper placement
of the wheel hook, remove the fender
for proper and safe loading.
Be sure to return the HoldUp to the locked
horizontal position after loading.
fOld hOlduP dOWN.
Pull spring Pin.
Fold down holdup
Spring pin should
snap into place.
INseRT sTABIlIzeR PIN.
ALWAYS USE
STABALIZER PIN.
Completely insert pin
into hole. Pin will lock
into place.
Use pin when HoldUp
Plus2 is in down
position, or up position.
fOld PIvOT
ARM dOWN.
INsTAll sTABIlIzeR PIN.
Thread plug
through loop
on lanyard.
Firmly press
plug into
hole on base.
Do not push
arm beyond
horizontal.
1034431D-4/21

4X
>
1034431D-5/21
If you have bike to bike interference
when loading two or more bikes,
adjust trays as necessary to eliminate
interference between bikes.
Loosen the 4
tray bolts (do not
remove bolts).
Slide the tray
left or right.
Retighten the 4
tray bolts.
Each tray can be
adjusted.
Rotate the pivot arm up until the
hook rests on the bike tire 1” or
less from the brakes or the fork.
sWING PIvOT ARM INTO PlAce. secuRe The hOOK.
Compress the
hook against
the wheel by
applying firm
pressure.
Refer to steps 11 through 17 to load additional bikes..
Alternate bike direction with each additional bike
lOAd AddITIONAl BIKes.
Failure to place
wheel hook
in the correct
position can cause
your bicycle to
eject, and cause
personal injury,
property damage,
or death.
Feed the strap through the spokes of wheel.
Rotate the wheel
slightly, if necessary.
 
strap end
through
the top of
the ratchet
buckle.
 
pad rests on
the rim.
secuRe ReAR Wheel sTRAP. TIGhTeN ReAR Wheel sTRAP.
Move the ratchet tab up and
down to tighten the strap.

1034431D-6/21
Access locking cables at
the end of each pivot arm.
Wrap locking cable
around bike frame.
Insert the pin from the
pivot arm into hole at the
end of the locking cable.
Lock with key.
 

 
 
checK The
INsTAllATION
BefORe
dRIvING AWAY.
ReAd All WARNINGs ON NeXT PAGe BefORe dRIvING AWAY.
AlWAYs use INTeGRATed lOcKING cABle WheN TRANsPORTING BIKes.
Slide the hook
against the rear
wheel cradle.
Fold up HoldUp.
secuRe PIvOT ARMs WheN NOT IN use.
WheN NOT cARRYING BIKes AlWAYs fOld hOlduP uP.
Tilt wheeltray
inboard.
Rotate pivot
arm down.
Fold wheeltray
inboard.
