Yale SDA16 User manual

SDA16
Stand-Alone Alarm Device
Installation Instructions
An ASSA ABLOY Group brand
80-9470-0330-000 (01-13)
EMERGENCY EXIT - ALARM WILL SOUND

An ASSA ABLOY Group brand
80-9470-0330-000 (01-13)
1. Frame and Door Preparation
Frame
Edge
Horizontal
Reference
Line
L
C
Out-swinging Door In-swinging Door
DOOR
DOOR
Frame
Frame
1. For installation on an In-swinging Door, mark a
Vertical Reference Line 1-15/16"(50mm) off of the
Frame Edge, also decide the vertical placement and
mark a Horizontal Reference Line. Align template
as shown with Vertical and Horizontal Reference Lines.
2. Use a center punch to mark door for
(2) .144"(3.7mm) Dia. (#27 Drill) mounting holes
for the Device Mounting Base (Shown Below).
3. Use a center punch to mark frame for (2) .099"(2.5mm) Dia.
(#39 Drill) holes for the Magnet (Shown Below).
4. If outside Cylinder Control Option is to be used,
bore a 1-1/4"(32mm) Dia. Hole thru door. Fig. 2 ‘B’ Hole
5. For Hardwire option requiring door preparation, mark and
bore a 1"(25mm) Dia. Hole to required depth. Fig. 2 ‘C’ Hole
6. Install Magnet to door frame with (2) #4 screws supplied.
1. For installation on an Out-swinging Door,
mark a Vertical Reference Line 2-3/16"(56mm)
off of the Frame Stop, also decide the vertical
placement on the door and mark a Horizontal
Reference Line. Fold template as shown and
align with Vertical and Horizontal Reference Lines.
2. Use a center punch to mark door for
(2) .144"(3.7mm) Dia. (#27 Drill) mounting holes
for the Device Mounting Base (Shown Below).
3. Use a center punch to mark frame for
(2) .099"(2.5mm) Dia. (#39 Drill) holes for the Magnet
(Shown Below).
4. If outside Cylinder Control Option is to be used,
bore a 1-1/4"(32mm) Dia. Hole thru door. Fig. 1 ‘B’ Hole
5. For Hardwire option requiring door preparation, mark and
bore a 1"(25mm) Dia. Hole to required depth. Fig. 1 ‘C’
Hole
6. Install Magnet to door frame with (2) #4 screws supplied.
Vertical
Reference
Line
Vertical
Reference
Line
Horizontal
Reference
Line
Figure 2
Figure 1
C
B
C
B
Arrows on the magnet face toward the
alarm housing and away from the door.
!
Arrows on the magnet face toward the
alarm housing and away from the door.
!
2

An ASSA ABLOY Group brand
80-9470-0330-000 (01-13)
TYPICAL MORTISE CYLINDER
Use standard 1-1/8" mortise cylinder with cam.
Cylinder Collar is not required.
Cylinders
3. Device Handing Change2. Installing Cylinder
1. Insert mortise cylinder through hole in the Housing.
2. Orient keyway to the 6 o’clock position, adjust as needed.
3. Assemble cylinder actuator onto the cylinder from inside
as shown below. The split tabs should be oriented towards
the controller board (12 o’clock position), trapping the
toggle switch on the printed circuit board. Fig. 4
Caution: Carefully install Actuator without damaging the
Toggle Switch.
4. Attach cylinder nut to cylinder, rotate clockwise until secure.
NOTE: Actuator should be free to rotate, by installing in
position shown.
Orient
Arrow
towards
Door Edge
1. Remove (2) screws retaining the magnet sensor
and set components aside.
2. Remove (2) screws retaining the Tamper Switch and
exchange locations of both components (See Figure 5).
3. Reattach components with the screws.
NOTE: a.The arrow on the magnet sensor should face outward,
towards the edge of the door (See Figure 5).
b. Replace wires behind ribs in cover to protect them
from moving parts.
4. Remove and relocate tamper switch contact from mounting
base to opposite location as shown below (See Figure 6).
5. Reattach with (2) screws.
Tamper Switch
Contact
Figure 6
3/4
(19)
J1
J2 J4
ON
J3
123456
(+)
(—)
Figure 5
Tamper
Switch
Magnet
Sensor
±1/16
Rib
(Note Position)
Cylinder Nut
Cylinder
Actuator
Mortise
Cylinder
Alarm
Housing
Figure 3
Toggle
Switch
Cylinder
Actuator
Figure 4
!!
!!
!!
3

An ASSA ABLOY Group brand
80-9470-0330-000 (01-13)
4. Standard Installation
6. Standard Device x Outside Cylinder Control Installation
3. Attach mounting base to door, wall or Gang Box following
previous instructions from Step 4 or 5.
4. With mounting base securely attached to door,
insert cylinder and ring through prep on opposite
side of door, fasten securely with (2) cylinder screws
inserted through slotted holes in the mounting base
(See Figure 10).
NOTE: Cylinder Screws and Collar are supplied with
the cylinder, when required.
5. Hardwire Installation
Note: Hardwire options require wire harness within the door or
wall and may require door position switches (DPS) or other means
of activation. This unit is equipped to accept the Electrolynx™ quick
connect system. See catalog for wiring harness and power supply
details.
1a. Door Mounted. After preparing the door, remove Knockout Plug
and attach the Mounting Base to the door through holes “A” &
“D”, using (2) #10 screws provided.
NOTE: Knockout Plug will accept standard 1/2" electrical nipple
to protect wires.
1b. Wall Mounting. This unit may be mounted between two doors,
to monitor both doors (TIP: Attach unit to a wall stud).
1c. Wall Mounting to a single “Gang Box”. Attach the Mounting
Base through holes “A” and “X”, using standard gang box
screws as shown in Figure 8 (Gang Box screws not provided).
Attach Alarm Housing per section 4.2 & 4.3 (Standard Installation).
Hole “D”
Hole “D”
Hole “X”
(*Gang Box Only)
Hole “A”
1. After preparing the door, attach the Mounting Base
to door through holes “A” & “D”, using (2) #10 screws
provided, as shown below.
2. Attach Alarm Housing over hook at the upper end
of mounting base. Pull downward and press towards
the door, until housing is flush with surface of door.
3. Engage housing key into the bottom cylinder, underneath
lower edge of housing. Rotate clockwise until positive
latch is made.
NOTE: Check that Device is secure to the Door.
Knockout
Plug
(Remove for
Wire Routing)
Catch Hook
Clip Retainer
Hole “A”
1. If not pre-assembled insert Cam Bushing Assembly
through mounting base from the back side
(See Figure 9) and install retainer clip onto exposed
groove on bushing.
2. Orient cam bushing assembly so that the long end of the
pin is vertical (UP) in the 12 o’clock position.
Rim Cylinder
Cylinder Collar
(when required)
(2) Cylinder
Mounting Screws
Figure 8
Figure 10
Cam Bushing
Assembly
Figure 9
Figure 7
Refer to Page 5 for Alarm Function Adjustments
Before proceeding with Step 4
!! !!
4

An ASSA ABLOY Group brand
80-9470-0330-000 (01-13)
ALARM FUNCTION AS SHIPPED
1) Upon arming, LED will flash AMBER and the device will allow egress without triggering alarm for 7 seconds.
2) After 7 seconds, alarm will chirp one time and the device will be ARMED.
The LED will flash RED every 30 seconds, indicating the device is ARMED.
3) Once the device is ARMED, egress will result in an alarm sound that will stop only when the device is RESET
by key or remote.
4) Low Battery Indicator - Alarm will chirp every 10 seconds, indicating battery needs to be replaced.
• Alarm PC Board has Dip Switches DS-1, 2, 3, 4, and 5 factory preset per Tables 1, 2, and 3 shown below.
• Dip Switch DS-6 is for “hard wire”configurations and setting does not affect stand-alone battery operation.
REX and Passage Time Delay TABLE 1
DS-1 DS-2 Timer Delay
*Off *Off 7 Seconds
Off On 10 Seconds
On Off 15 Seconds
On On 20 Seconds
Automatic Alarm Reset TABLE 2
DS-3 DS-4 Reset Time
Off Off 2 Minutes
Off On 5 Minutes
On Off 10 Minutes
*On *On No Auto Reset
every 30 seconds instead of RED to indicate a violation
has occurred.
Armed and Violation LED Color Selection TABLE 3
Device is shipped standard, per Table 3, so that RED LED
flashes every 30 seconds when device is ARMED, and
flashes GREEN every 30 seconds under auto reset, when
door has been violated.
When the device is initially ARMED by key, the LED
will flash AMBER and allow egress for a time defined
in Table 1.
PassageDS-5 Armed
LED Color
Armed Violation
LED Color
Off
On
Red
Green
Amber
Factory Preset
Amber
Green
Red
NOTES:
J1
J2
J4
ON
J3
1 2 3 4 5 6
ON
123456
Dip Switch Settings
Enlarged View
Black
Battery plugs in place with polarity
connected as shown
(+)
(—)
Battery
Bracket
* The unit is shipped with power disconnected, attach battery connector as shown below.
The alarm can be set so that it will reset itself after a
violation has occurred per Table 2. If the device
automatically resets, the indicator light will flash GREEN
When the unit is hard wired, DS-6 must be in the “On” position for remote monitoring thru connector J3.
5

An ASSA ABLOY Group brand
80-9470-0330-000 (01-13)
6
•
•
•
•
•
•
•
•
•
•
Alarm will not sound
Alarm sounds when keyswitch
is activated.
Alarm chirps every 10 seconds.
ARMED indicator LED, wrong
color.
Problem
TROUBLESHOOTING
•
•
Battery is not connected.
Battery needs replacing.
Alarm is not ARMED. Turn key clockwise.
Magnet Sensor is not installed correctly. Verify
that the proper handing applies (See Step 3, Figure 5).
Tamper Switch is not closing when Alarm Housing
is installed. Make sure Switch Contact is located in the
correct position (See Step 3, Figure 6). Verify that the
Alarm Housing is installed correctly.
J2 connector not installed, or loose.
Low battery indicator, replace battery.
Change position of DS-5 Dip Switch.
“OFF” for RED ARMED indicator.
“ON” for GREEN ARMED indicator.
Solution
Yale® is a registered trademark of Yale Security Inc., an ASSA ABLOY Group company. Other products' brand names may be trademarks or registered trademarks of their
respective owners and are mentioned for reference purposes only. These materials are protected under U.S. copyright laws. All contents current at time of publication.
Yale Security Inc. reserves the right to change availability of any item in this catalog, its design, construction, and/or its materials.
Copyright © Yale Security Inc., an ASSA ABLOY Group company.
All rights reserved. Reproduction in whole or in part without the express written permission of Yale Security Inc. is prohibited.
2005, 2013
Product Support Tel 800. • www.yalelocks.com810.WIRE (9473)
Yale Locks & Hardware is a division of Yale Security Inc., an ASSA ABLOY Group company.

An ASSA ABLOY Group brand
80-9470-0330-000 (01-13)
7
Frame Edge
(Do Not Fold)
Vertical
Reference
Line
Frame Edge
(Do Not Fold)
L
CDevice Template
(In-Swinging Door)
3/8"
(10)
1-15/16"
(50)
13/16"
(21)
13/16"
(21)
1-9/16"
(40)
3-3/4"
(95)
1-21/32"
(42)
3/8"
(10)
1-15/16"
(50)
13/16"
(21)
1-21/32"
(42)
1-1/4"
(32)
1"
(25)
Dia. #27 Drill
Dia.
.144
(4)
Dia. Thru
Dia. #27 Drill
.144
(4)
.099
(3)
Dia.
#39 Drill 2x .099
(3)
Dia.
#39 Drill
1/2"
(13)
(Ref)
2x
1-15/16"
(50)
Magnet and
Cylinder located
on same centerline
(Arrow on Magnet
oriented towards
Alarm Housing
Assembly).
L
C
DOOR
Locate off
of edge to
clear swing
of door
L
C*
CAUTION: Office copiers and facsimile mach-
ines may change the size of a drawing and make
the template inaccurate to use as a door marker.
If this is not the original template packed with the
trim, use only the holes on the door (do not use
template as a door marker).
Standard Install
Hardwire Option
Std. Install x
Outside Cylinder
FUNCTION
A, D, E
A, C, D, E
A, B, D, E
* Hardwire Option Only
“D”
“C”
“B”
“A”
“E”
“E”“E”
“E”
Horizontal
Reference
Line
!!

8
Frame Edge
(Fold Line)
Frame Edge
(Fold Line)
L
CDevice Template
(Out-Swinging Door)
CAUTION: Office copiers and facsimile mach-
ines may change the size of a drawing and make
the template inaccurate to use as a door marker.
If this is not the original template packed with the
trim, use only the holes on the door (do not use
template as a door marker).
Standard Install
Hardwire Option
Std. Install x
Outside Cylinder
FUNCTION
A, D, E
A, C, D, E
A, B, D, E
Dia. #27 Drill
.144
(4)
1-9/16"
(40)
3-3/4"
(95)
3/8"
(10)
2x .099
(3)
Dia.
#39 Drill
13/16"
(21)
1-21/32"
(42)
2-3/16"
(56)
2-3/16"
(56)
1"
(25) Dia.
1-1/4"
(32) Dia. Thru
13/16"
(21)
Dia. #27 Drill
.144
(4)
13/16"
(21)
3/8"
(10)
.099
(3)
Dia.
#39 Drill
2x
1-21/32"
(42)
2-3/16"
(56)
3/16"
(5) (Ref.)
1/16"
(2)
Magnet and
Cylinder located
on same centerline
(Arrow on Magnet
oriented away
from Door).
L
C
DOOR
L
C
*
* Hardwire Option Only
“D”
“C”
“B”
“A”
“E”
“E”
“E”
“E”
Horizontal
Reference
Line
!!
Vertical
Reference
Line
An ASSA ABLOY Group brand
80-9470-0330-000 (01-13)
