Yamato Fish Analyzer PRO DFA110 User manual

Fish Analyzer
Fish Analyzer TM PRO [DFA110]
Operation Manual
Yamato Scale Co., Ltd.
Introduction
Thank you for purchasing the Fish Conditioner “Fish Analyzer TM” or “Fish Analyzer TM PRO”. Please
read this manual carefully and use it for branding and quality control of fish.

2
Yamato Scale Co., Ltd.
Message from supervisors
Traditionally, the quality of marine products at the distribution stage has been subjectively evaluated by the
experience of distribution specialists and has not been quantified on a certain basis. In order to digitize, it
requires specialized knowledge and special equipment, and we have to rely on time-consuming chemical
methods. Therefore, with the aim of developing a compact device that can measure the content of fat, which is
one of the deliciousness indexes as quality information of marine products, simply and nondestructively,
Nagasaki University Fisheries Department, Nagasaki Prefectural Fisheries Research Institute, Chiba Prefectural
Fisheries Research Center, Yamato Scale Co., Ltd., Fisheries Research Institute (currently National Research
Development Corporation Fisheries Research and Education Organization) jointly developed the technology
conference on agriculture and forestry and fisheries technology 2010 “New Practical Technology Development
Project to Promote Agriculture, Forestry and Fisheries Policy” and "Development of quality measurement
equipment aiming at improvement of fish prices and provision of high quality marine products and fish
processing products", we developed Fish Analyzer TM Pro and have been sold. Fish AnalyzerTM Pro can measure
the fat content of horse mackerel, yellowtail, tuna, sea bream, bonito, and sardines nondestructively and quickly
at fishery sites.
In addition, it is also possible to distinguish fresh fish from frozen / thawed fish. Quality information that can be
measured with this device is branding of tasty superior aquatic products, grasping of raw material characteristics
at the time of manufacturing processed products, quality control of farmed fish, etc. We hope that it contributes
to the sustainable supply of high quality products to consumers.
Nagasaki University Fisheries Department Doctor of Health Katuyasu Tachibana
Japan Association for Techno-innovation in Agriculture,
Forestry and Fisheries
Doctor of Agricultural Science Masakazu Murata
―――――――――― Table of contents ――――――――――
Chapter 1 Read before use 3
1-1. For safety use 3
1-2. Preparation 5
1-3. Available functions 6
1-4. Product package 7
1-5. Name of parts 7
1-6. To keep the device effectively 8
Chapter 2 Preparation before use 9
2-1. How to set the accessories 9
2-2. Display and keys 10
2-3. Fish species and measuring points 11
2-4. Selection of the day of catching or the next day of catching 13
Chapter 3 How to measure 14
3-1. Posture to measure properly 14
3-2. Measurement 14

3
3-3. Measurement results in the past 15
3-4. Status of fish 16
Chapter 4 User parameters 17
4-1. Choosing a fish species 17
4-2. Setting for saving energy 18
4-3. Display of average value 19
4-4. Limiting function of fat percentage display 19
Chapter 5 Evaluation by actual measuring result 20
5-1. Evaluation by impedance mode 20
5-2. Evaluation of “Status of fish” by actual measurement value 20
5-3. Measuring in impedance mode 20
5-4. How to make an original algorithm (Impedance mode) 21
Chapter 6 Others 22
6-1. Error messages 22
6-2. Frequent Q&A 22
6-3. Specifications 24

4
Chapter 1 Read before use
1-1. For safety use
Read "For your safely use" before using this product for protecting yourself or your property.
After you read it, keep it with care so as to be available whenever you need it.
●Marks used in this manual and the meanings
Danger:
Indicates operations without complying with the instruction may result in fatal
or serious injury.
Warning:
Indicates operations without complying with the instruction may result in bodily
injury or damage of properties
Caution:
Indicates operations without complying with the instruction or correcting your
practice may result in damage of the entire product.
Indicates things to be prohibited
Indicates things to be enforced
●Before use please read “Danger”, “Warning” and “Caution” carefully to comply with accordingly.
Danger
For preventing from electric shock accident
Do not remove any screw on the back of the housing.
For preventing from explosion or fire accident
This device does not have non-explosion feature.
Do not use the device where flammable gas or hazardous substances exist.
For preventing from fire and/or electric shock accident
Using it in such an abnormal situation where there is smoke or unusual smell may result in
fire and/or electric shock.
Remove batteries and confirm that no smoke comes out before asking the vendor for
its repair.
Do not try to repair by yourself as it is dangerous.

Chapter 4 User parameters
5
Warning
For preventing from injury or damage
1 When the housing or electrodes are damaged by being dropped, do not use it
because it may damage fish or injure you by the damaged portion of the device.
2 When the display liquid comes out by being dropped, as the liquid is toxic, be
careful not to accidentally put it in the mouth.
Caution:
Not to damage the device
1 Use the designated batteries. Otherwise, rupture or leakage of batteries may
cause fire, injury or damage.
2 Do not put a battery in fire or water, or heat it. It may burst
3 Do not mix alkaline and manganese batteries. It may cause liquid leakage or explosion
4 Set batteries correctly as shown by the polarity marks (+ and -). Incorrect installation
may cause liquid leakage or explosion.
5 Remove batteries when the equipment is left unused for a long time (about 1 month or
longer). Otherwise, they may leak and cause the inside of the equipment to be corroded.
6 Do not separate or modify the device.
7 Do not drop the device. It may cause damage on the device.
8 Do not sink the device in water or shore it under humid environment. It may damage
the device.

Chapter 5 Evaluation by actual measuring result
6
1-2. Preparation
●Cause of trouble
1 Do not separate or modify the device.
2 Do not hit a display and keyboard with a nail tip or a sharp tool.
3 Hold the main body when you carry it.
4 Do not drop the device or do not give excessive shock or vibration.
5 Do not apply thinner, benzine, etc.
●Cause of inaccuracy
1 Do not operate near the place of fire, steam, direct sunlight or wind from air conditioner.
2 Do not operate near the device like a microwave, which generate excessive shock, vibration or
electro-magnetic discharge.
3 Operate under the designated environment 10 40 30 RH 85 RH
Measuring error may happen even under the conditions if dew condensation generates:
1 Being operated or stored for long time under humid environment.
2 When temperature changes rapidly even under low humidity (giving cold water on the device)
3 Being operated in the circumstances where the device is exposed with cold air from a
refrigerator or steam.
Storage and Disposal
●Storage
(1) Do not store the equipment in the place with high temperature/humidity or receiving
direct sunlight for a long period of time. It should also be noted that substantial
changes in the ambient temperature may cause condensation inside the
equipment, resulting in a failure of the operation
(2) This is an electronic precision equipment. Do not store it in the place where vibration
and/or shock can be expected.
●Disposal
(1) When the device is disposed of, it must be disposed of as an industrial waste
(nonflammable waste). Make sure to observe the local regulations when
disposing.
(2) When used batteries are disposed, put scotch tapes on electrodes and dispose
according to the local regulations.

Chapter 4 User parameters
7
1-3. Available functions
1 Nondestructive measurement method that does not damage fish.
This device uses the "bioelectrical impedance method" to send a weak electricity
into the fish using four electrodes and estimate the fat percentage from the
impedance. Therefore, the fat rate is displayed in only 4 seconds without
damaging the fish.
2 The multi-frequency measurement method is adopted.
When electricity flows in the low frequency band, electricity flows mainly outside
the cell, and when it flows in the high frequency band, electricity also flows in the
cell. This device has adopted a multi-frequency measurement method in which
electricity flows at multiple frequencies for achieving high accuracy.
3 Measuring the fat percentage of 20 species of fish. (P.11)
This device can measure horse mackerel 1, mackerel 1, Mackerel 2, sardine,
saury, Bluefin tuna (back, belly, tail), Sea bream, Alfonsino, Bonito 1, Salmon,
Rainbow trout, Spanish mackerel, Butterfish, Sea bass, Sailfin sandfish, Grouper,
Bonito 2, Sea eel, Horse mackerel 2.
4 You can also estimate the fat ratio of unregistered fish. (P.20)
It is equipped with "calibration curve mode" to measure unregistered fish. In
impedance mode, the impedance value at 100 kHz is displayed instead of the fat
percentage. From this number, you can know the approximate fat ratio, and you
can also use Fish A, Fish B, and Fish C to create the original formula.
5 Detecting defrosted products
After freezing and thawing the fish, the cell membrane will be destroyed, so the
difference in the flow of electricity will not be seen. Using this feature, fish with
frozen history will be displayed as "defrosted". However, please note that the fat
percentage of the thawed product is not displayed.
6 Displaying the average value of the measurement results. (P. 19)
In order to determine the fat percentage from multiple measurement results, and
also to weigh several fish in a container, and to present it as the average value of
the container, the "average value calculation function" is equipped. The average
value is displayed at the bottom of the screen until you press or turn off the
power.
7 Displaying the fish status (freshness index) in 5 levels (P. 16)
Fish Analyzer TM PRO allows you to determine the condition of fish at the same
time as the fat percentage. The status of the fish is a function to see changes in
in-cells and out-cells, and changes to A ', A, B, C, D according to the deterioration
of cells and the decrease in water holding capacity. It can be used for cooking
guidelines and quality control.
8 Strict quality control can be performed. (P.20)
Fish AnalyzerTM PRO is equipped with "Fish status mode". In the fish status
mode, impedance at 5kHz is displayed along with the 5-step judgment. As the
impedance decreases along with the decrease in freshness, stricter quality control
can be performed by following this process.

Chapter 5 Evaluation by actual measuring result
8
1-4. Product package
Main body Accessories
Attachment
Dry batteries
(C size x 2)
Manual
1-5. Name of parts

Chapter 4 User parameters
9
1-6. To keep the device effectively
●If the electrode and attachment are left with salt water or fish slime, the stainless steel part may rust. After
use, wash out salt water and slime of on the stainless steel part with fresh water, then wipe off moisture
and dirt with a towel.
●To prevent falling, pass your straps through the strap holes and fix the straps to your body.
●After replacing the batteries, securely tighten the case. At this time, do not open or close the battery cover
in places with lots of sand, dust or dirt. If foreign matter adheres to the packing, waterproofness may be
impaired.
●If the battery cover is not closed firmly, water may get inside. The following shows how to slide the battery
cover and how to clean the inside of the battery box. Clean the inside of the battery box regularly, and
after cleaning, close the battery cover firmly.
Wipe off dirt and dust with a dry tissue etc. mainly on the
contacts for batteries. If water drops are found, wipe them
out. In addition, if the packing (transparent color) embedded
around the battery cover is lifted, promptly contact the store
where you purchased it.
At setting the battery cover, push the
battery cover firmly from the bottom so
that there is no gap. There are lines on
the main unit and the battery cover, so
please match the lines.
●If the attachment is set to the main body while dirt like seawater or dirt is adhering on the attachment, the dirt will also be
adhering to the connection terminal of the attachment, then the accurate measurement cannot be performed (the display
will not change from . Clean without fail always after use.
Be sure to wipe off any dirt
adhering to the electrodes with
water or alcohol before
mounting the attachment.
If dirt is adhering to the connection terminal of the
attachment, moisten the tip of the swab with water
or alcohol, and then slide the swab toward the
inside of the connection terminal to wipe off dirt.
Be careful. If you press the outside
of the connection terminal
downward, the connection
terminal will bend outward.
Chapter 2 Preparation before use
2-1. How to set the accessories
●Dry batteries

Chapter 5 Evaluation by actual measuring result
10
Step Step Step
Slide the battery lid down to
remove it.
Insert the dry cells, paying attention
not to mistake the polarity.
Insert the top hook of the battery lid into the
battery lid hook and push the battery lid
upward from the bottom.
●Attachment
Step Step Step
Align the convex to the front and fit
it straight up toward the body.
Installation is completed when the
side hooks catch the body.
For removing, put your finger in the space
on the side hook and pull it down slightly.
The attachment will come off.
1 For measuring horse mackerel, sardine, saury, grouper and sea eel, be sure to use the attachment.
2 For measuring in impedance mode or fish status mode, use an attachment if the thickness of fish is 3 cm or less.
2-2. Display and keys
Display
Fish Analyzer TM Ver.3.00 Fish Analyzer TM PRO Ver.1.00

Chapter 4 User parameters
11
●Special symbol
Battery level It displays the battery level in 3 levels. Replace batteries when only one is
displayed.
Attachment It means that the attachment is needed for measurement.
Next day It means the measurement mode for the next day of catching.
If you want to measure on the day of catching, please select the mode without
this symbol.
Not in contact It means that the contact of the electrode to the fish is insufficient.
Keys
Measurement Press to start measurement under the normal screen.
Press to return to the previous display under setting or measurement mode.
ON/OFF Press to turn on the power when the power is off.
Press to return to the normal screen when setting or measurement mode.
Hold down the key awhile to turn off.
Set Press to display the past measurement result under the normal screen.
Hold down the key awhile to display the setting screen under the normal screen.
Press to finalize the setting during the setting mode.
Fish species Press to display a fish species under the normal screen.
Press to advance to the next display during setting or confirming the measurement
result.

Chapter 5 Evaluation by actual measuring result
12
2-3. Fish species and measuring points
No.1 Horse mackerel 1 Attachment No.2 Mackerel 1
Centering the electrode between the first and second fins,
apply the electrode a little above the side line.
Centering the electrode on the back of the dorsal fin, place
the electrode a little above the side line.
No.3 Mackerel 2 No.4 Sardine Attachment
Centering the electrode on the back of the dorsal fin, place
the electrode a little above the side line.
Centering the electrode on the center of the dorsal fin,
place the electrode a little above the side line.
No.5 Saury Attachment No.6 Yellowtail
Centering the electrodes on the center of the belly
fin, place the electrodes a little above the side line.
Centering the electrode between the first and second fins,
apply the electrode a little above the side line.
No.7-1 Bluefin tuna (back) No.7-2 Bluefin tuna (belly)
Aligning the tip of the electrode to the back end of the
chest fin, place the electrodes a little above the side line.
Aligning the tip of the electrode to the back end of the chest
fin, place the electrodes between the base of the belly fin
and the side line.
No.7-3 Bluefin tuna (tail) No.8 Sea bream
Aligning the tip of the electrode to the back of the anal
position, place the electrode slightly below the side line.
Centering the electrode on the back of the dorsal fin, place
the electrode a little above the side line.
No.9 Alfonsino No.10 Bonito 1

Chapter 4 User parameters
13
Centering the electrode on the center of the dorsal fin,
place the electrode a little above the side line.
Centering the electrode between the first and second fins,
apply the electrode a little above the side line.
No.11 Salmon No.12 Rainbow trout
Centering the electrode on the center of the dorsal fin,
place the electrode a little above the side line.
Centering the electrode on the center of the dorsal fin,
place the electrode a little above the side line.
No.13 Spanish mackerel No.14 Butterfish
Aligning the back of the electrode to the tip of the second fin,
place the electrode a little above the side line.
Centering the electrode on the tip of the dorsal fin, place
the electrode a little above the side line.
No.15 Sea bass No.16 Sailfin sandfish Attachment
Align the back of the electrode to the back end of the 1st
fin, place the electrode a little above the side line.
Centering the electrode on the tip of the dorsal fin, place
the electrode a little above the side line.
No.17 Grouper No.18 Bonito 2
Centering the electrode on the tip of the dorsal fin, place
the electrode a little above the side line.
Centering the electrode between the first and second fins,
apply the electrode a little above the side line.
No.19 Sea eel Attachment No.20 Horse mackerel 2
Straightening the fish, aligning the tip of the electrode to
the anal position, place the electrode slightly above the
lateral line.
Centering the electrode between the first and second fins,
apply the electrode a little above the side line.

Chapter 5 Evaluation by actual measuring result
14
2-4. Selection of the day of catching or the next day of catching
This device measures the percentage of fat from the information inside and
outside the cells, but as the cell condition is different on the day and the next day
of catching (the day of lethality), it has two modes for accurate measuring.
Therefore, make sure that you should choose a mode (the day or the next day)
as well as a fish species.
As for Saury, Bonito, Sea bream, Sailfin sandfish, Sea ell, Horse mackerel, there is no mode for
measuring on the next day, so measurement should be performed on the day of catching. For measuring
correctly in both modes, fish should be kept in an ice storage.
●The day of catching means measurement at the production area.
In the case of production areas, fish may still be alive. If you take measurements immediately after
lethality, you may get a lower fat percentage. First, store it in an ice storage and wait at least one hour
before making measurements. Also, if several days have passed since the death in the production area,
please make measurements on the next day after catching.
In Fish AnalyzerTM PRO, the status of the fish is displayed in 5 levels next to the fat percentage. when
several days have passed since the lethality, if the device shows "A '" or "A", choose the day of catching
and if it shows "B" or "C", choose the next day of catching.
●The next day of catching means measurement at the distribution site.
Fish AnalyzerTM is affected by changes in freshness, so make measurements as soon as possible after
procurement. In addition, Fish AnalyzerTM PRO displays the status of fish along with the fat percentage in 5
levels. If the status of the fish is displayed as "D", please think that it is difficult to obtain an accurate fat
percentage.

Chapter 4 User parameters
15
Chapter 3 How to measure
3-1. Posture to measure properly
Although this device is a non-destructive device that does not break fish, it is also a contact-type that directly
touches the fish, so if the subcutaneous fat is crushed, the values may change. To make an accurate
measurement, please read the following points and get familiar with the device.
1Grasping properly 2Fixing not to move
Press ON key and
choose a fish species
with the fish species
key.
Place your thumb on
the measurement
button and the
remaining fingers grip
the body.
If touching fish is ok, support a fish with
your fingertips and place the device.
If you cannot touch the fish, fix your
arm to the measuring stand and place
the device.
3Touch the fish with the electrode 4Confirm not only the screen but also the electrode
position
Lightly touch the four
electrodes in place, make sure
that they are firmly in contact,
and then press the
measurement key. Apply the
electrode with 45 degree like
an image that raises the body
a little
At measuring, first
make sure that the “*”
mark is displayed, then
move your eyes to the
electrode position to
confirm the electrode
position is not
changed.
3-2. Measurement
ex Measuring a yellowtail
Operation Screen
1
Press key to turn on.
2
Press key to call “Yellowtail”.
Choose ”Yellowtail ”.
3
Afer returning to normal screen, place the electrode then press key.
During measurement “ ” mark moves.
Operation Screen
When the measurement is over, the fat percentage is displayed. When the
average value display function is enabled, the average value is displayed at the
bottom center of the screen (displayed to one decimal place).
Fish Analyzer TM PRO displays also the status of the fish in 5 levels.

Chapter 5 Evaluation by actual measuring result
16
4
Hold down key awhile to turn off after you get the result.
3-3. Measurement results in the past
●How to find the measurement results in the past
Operation Screen
1
Press key under normal screen.
2
Each time pressing key displays a measurement result in the past.
The past measurement results are stored up to 50 times before.
The number of measurements is displayed up to 9999 times on the lower right of
the screen, and returns to 0 times after 9999 times.
3
Press key to return to normal screen.
●Clearing the measuring result
Operation Screen
1
Hold down key awhile under the result being displayed.
2
Holding down the key “Result clear” is displayed.
Choosing <Yes> with a cursor by moving it with key, then press key.
3Clearing results is started, and when “clear complete” is displayed, deletion of the
past measurement results is completed. Press key to return to the normal
screen.
Remarks: Please note that clearing results will erase all past measurement results and the number of measurements.
3-4. Status of fish
There is a K value as the freshness index of fish based on the result of biochemical analysis, but the "Status of fish"
displayed on Fish AnalyzerTM PRO is a freshness index based on "the electrical feature of cells", which is different from the
K value.
This device uses a multi-frequency measurement method and basically the cell membrane has high electrical capacity and
insulation at low frequency bands. As electricity flows outside the cell without flowing inside the cell, the impedance (electrical

Chapter 4 User parameters
17
resistance) is high. Conversely, at the high frequency band, the cell membrane is electrically shorted, and electricity flows
inside the cell, resulting in low impedance.
This is the electrical feature of the cell, while the status of the fish after death changes with time, and the electrical feature
of the cell also changes in the way that reflects it. After death, the impedance rises first in proportion to the tightness of the
fish. This tightness level is "A" or "A '". After that, the fish starts to soften and the impedance starts to decrease but the cell's
electrical characteristics are still maintained. This status is "B". If the fish being measured immediately after death, the device
may display “B” as the condition is similar to the one before the fish starts to tighten, and if blood remains, it may display "C".
When freshness starts to fall rapidly, the impedance at the lower frequency band in particular drops significantly. This is
because the cell's structure changes and the cell's electrical characteristics deteriorates. Moreover, the water holding
capacity of cells decreases, and the intracellular fluid flows out of cells, which lowers the impedance at the lower frequency
band. Since the ability to retain water in cells is undoubtedly an important factor in fish freshness, the electrical feature of the
cells changes, and the status of poor water holding capacity is “C” or “D”. Of course, the status of fish is not irrelevant to the
K value, and the condition of the fish corresponding to the K value of 1% to 20% is "A", "A '" or "B", and the K value is 20% or
more is equivalent to "C" or "D".
Note that “E” is displayed when a measurement error occurs, and “F” is displayed in the case of a thawed product in the
impedance mode and the fish status mode in which “thawed product” is not displayed.
Remarks: It is not possible to decide whether the fish can be eaten raw only by the freshness evaluation as well as the K value.
Basically, fish such as salmon and mackerel, which are not eaten raw, should be cooked before eating even if the status
of fish is good

Chapter 5 Evaluation by actual measuring result
18
Chapter 4 User parameters
4-1. Choosing a fish species
Normally, a fish species to be measured is selected with key each time, but it is possible to select in
advance only the fish species to be measured and not to display fish species not to be measured.
ex in case of choosing “mackerel “
Operation Screen
1
Press key to turn on. Under the normal screen hold down key until
Menu is displayed.
2
Match cursor (→ to “Fish species select” and press key to change
screen.
3Move the cursor (→ by pressing key to a fish species (in this case,
mackerel) and press key.
The species with check mark (レ) are only displayed.
4After setting, press key to return to Menu screen.
Press key again to return to normal screen then setting is completed.
Then onlt the selected species are displayed with key.
List of all fish species
Impedance mode Bluefin tuna (back) Salmon Bonito 2
Horse mackerel 1 Bluefin tuna (back) Salmon Bonito 2
Horse mackerel 1 Bluefin tuna (belly) Rainbow trout Sea eel
Mackerel 1 Bluefin tuna (belly) Rainbow trout Horse mackerel 2
Mackerel 1 Bluefin tuna (tail) Spanish mackerel Fish
Mackerel 2 Bluefin tuna (tail) Spanish mackerel Fish B
Mackerel 2 Sea bream Butterfish Fish C
Sardine Sea bream Sea bass Status of fish
Sardine Alfonsino Sea bass
Saury Alfonsino Sailfin sandfish
Yellowtail Bonito 1 Grouper
Yellowtail Grouper
4-2. Setting for saving energy
Settings for saving energy
1.Auto off 1 When the set time has passed, the power is automatically turned off.
2.Auto off 2
The screen turns off automatically when the set time has passed. After turning off, press
any key to display the screen displayed last time (The power is turned off when the
setting time of auto off 1 has elapsed).
3.Brightness Choose the level from “Saving energy”, “Normal” or “Bright”.

Chapter 4 User parameters
19
(ex Setting 10 seconds for Auto off 2
Operation Screen
1
Press key to turn on. Under normal screen hold down key until Menu is
displayed.
2
Match a cursor → to Operation setting and then press key.
3
When operation setting are displayed, move the cursor → to 2. Auto off 2 by
pressing key twice and then press key.
4
Set 10 seconds by pressing for decreasing or pressing for
increasing and then press key.
5
Press key under operation setting screen to return to normal screen.
Then the setting is completed.
●Cancelling Auto off 1 or Auto off 2
Operation Screen
1
Choose OFF to cancel Auto off 1 or Auto off 2 with or key.
4-3. Display of average value
By enabling the operation setting "4. Average value", the average value of the measurement results so far is displayed at
the bottom of the screen. It can be used to determine the fat percentage from multiple measurement results, or to weigh
several fish in a container and present them as the average value in the container.
Operation Screen
Press key to turn on. Under normal screen hold down key until Menu is
displayed. Match a cursor → to Operation setting and then press key.
When operation setting are displayed, move the cursor → to 4. Average value

Chapter 5 Evaluation by actual measuring result
20
by pressing key and then press key.
4
Choose ON by pressing key and then press key.
Press key under operation setting screen to return to normal screen.
5
The setting is completed. With this setting, the average value is displayed at the
bottom of the screen until you press key or the power is turned off.
4-4. Limiting function of fat percentage display
As this device is affected by the change in freshness, it becomes difficult to obtain an accurate fat percentage if the
freshness falls. Fish status is displayed but when the status of fish is "D", it has a function not to display the fat percentage,
and it is possible to display only the fat percentage with high reliability.
Operation Screen
Press key to turn on. Under normal screen hold down key until Menu is
displayed. Match a cursor → to Operation setting and then press key.
When operation setting are displayed, move the cursor → to 5. Fat % display
by pressing key and then press key.
4
Choose Limited by pressing key and then press key.
Press key under operation setting screen to return to normal screen.
5
The setting is completed.
Any fat % would not be displayed when the status of fish is "D".
