YOKOGAWA WT5000 Specification sheet

IM WT5000-01EN
1st Edition
Precision Power Analyzer
WT5000
Features Guide

i
IM WT5000-01EN
List of Manuals
Thank you for purchasing the WT5000 Precision Power Analyzer. This manual contains useful
information about the features of this instrument. To ensure correct use, please read this manual
thoroughly before operation.
Keep this manual in a safe place for quick reference in the event a question arises. The following
manuals, including this one, are provided as manuals for this instrument. Please read all manuals.
Manual Title Manual No. Description
WT5000
Precision Power Analyzer
Features Guide
IM WT5000-01EN This manual. The supplied CD contains the
PDF file of this manual. This manual explains
all the instrument’s features other than the
communication interface features.
WT5000
Precision Power Analyzer
User’s Manual
IM WT5000-02EN The supplied CD contains the PDF file of this
manual. The manual explains how to operate
this instrument.
WT5000
Precision Power Analyzer
Getting Started Guide
IM WT5000-03EN This guide explains the handling precautions,
basic operations, and specifications of this
instrument.
WT5000
Precision Power Analyzer
Communication Interface User’s Manual
IM WT5000-17EN The supplied CD contains the PDF file
of this manual. The manual explains the
instrument’s communication interface
features and instructions on how to use
them.
WT5000
Precision Power Analyzer
IM WT5000-92Z1 Document for China
The “EN” and “Z1” in the manual numbers are the language codes.
Contact information of Yokogawa offices worldwide is provided on the following sheet.
Document No. Description
PIM 113-01Z2 List of worldwide contacts
Notes
• The contents of this manual are subject to change without prior notice as a result of continuing
improvements to the instrument’s performance and functions. The figures given in this manual
may differ from those that actually appear on your screen.
• Every effort has been made in the preparation of this manual to ensure the accuracy of its
contents. However, should you have any questions or find any errors, please contact your
nearest YOKOGAWA dealer.
• Copying or reproducing all or any part of the contents of this manual without the permission of
YOKOGAWA is strictly prohibited.
• The TCP/IP software of this product and the documents concerning it have been developed/
created by YOKOGAWA based on the BSD Networking Software, Release 1 that has been
licensed from the Regents of the University of California.
1st Edition: September 2018 (YMI)
All Rights Reserved, Copyright © 2018 Yokogawa Test & Measurement Corporation

ii IM WT5000-01EN
Trademarks
• Microsoft, Internet Explorer, MS-DOS, Windows, Windows 7, Windows 8.1, and Windows 10 are
registered trademarks or trademarks of Microsoft Corporation in the United States and/or other
countries.
• Adobe and Acrobat are either registered trademarks or trademarks of Adobe Systems
Incorporated.
• In this manual, the ® and TM symbols do not accompany their respective registered trademark
or trademark names.
• Other company and product names are trademarks or registered trademarks of their respective
holders.
Revisions
• 1st Edition:September 2018

iii
IM WT5000-01EN
Contents
1 Items That This Instrument Can Measure
Measurement Functions Used in Normal Measurement............................................................... 1-1
Harmonic Measurement Functions............................................................................................... 1-3
Delta Computation Functions........................................................................................................ 1-5
Motor Evaluation Functions (Option) ............................................................................................ 1-5
Auxiliary Input Measurement Functions (Option).......................................................................... 1-5
What Is a Measurement Function?............................................................................................... 1-7
Measurement Period..................................................................................................................... 1-7
2 Setup Menu
Navigation..................................................................................................................................... 2-1
Setup Menu (Setup, MENU(SETUP))........................................................................................... 2-1
Measurement Mode (Measurement Mode)................................................................................... 2-1
Initialize Settings (Initialize Settings)............................................................................................. 2-1
File List (File List).......................................................................................................................... 2-1
Saving Setup Data (Save Setup, SAVE(SETUP)) ........................................................................ 2-3
Loading Setup Data (Load Setup, LOAD(SETUP)) ...................................................................... 2-4
3 Input Settings (Basic Measurement Conditions)
Input Settings (Basic Measurement Conditions, Input (Basic))..................................................... 3-1
Wiring System (Wiring) ................................................................................................................. 3-1
Selecting the Element for Setting the Measurement Range (Element1 to 7, 1 to 7 (ELEMENTS)) ....... 3-3
Voltage Range (Voltage, VOLTAGE RANGE)............................................................................... 3-4
Auto Voltage Range (Auto (Voltage), AUTO (VOLTAGE RANGE)) .............................................. 3-5
Current Range (Current, CURRENT RANGE).............................................................................. 3-6
Auto Current Range (Auto (Current), AUTO (CURRENT RANGE)) ............................................. 3-6
External Current Sensor On/O󰀨 (Ext Sensor)............................................................................... 3-7
Power Range ................................................................................................................................ 3-9
Scaling (Scaling)......................................................................................................................... 3-10
Line Filter (Line Filter)................................................................................................................. 3-12
Frequency Filter (Freq Filter) ...................................................................................................... 3-13
Measurement Period (Sync Source)........................................................................................... 3-14
4 Input Settings (Advanced/Options)
Input Settings (Advanced/Options, Input (Advanced/Options)) .................................................... 4-1
Measurement Range (Range) ...................................................................................................... 4-1
Crest Factor (Crest Factor)........................................................................................................... 4-2
Range Σ link (Range Σ Link)......................................................................................................... 4-3
Display Format of External Current Sensor Range (Ext Sensor Range Display Format)............. 4-4
Valid Measurement Range (Valid Measurement Range).............................................................. 4-5
Line Filter (Line Filter)................................................................................................................... 4-6
Frequency Filter, Rectier, Level (Freq Filter/Rectier/Level) ....................................................... 4-8
Null Feature (Null Settings)..........................................................................................................4-11
Enabling and Disabling the Null Feature (Null, NULL)................................................................ 4-12

iv IM WT5000-01EN
Contents
5 Motor Evaluation and Auxiliary Input (Option)
Motor Evaluation/Auxiliary Inputs (Motor/Aux).............................................................................. 5-1
MTR Conguration (MTR Conguration) ...................................................................................... 5-2
Motor/Aux Settings (Ch Settings).................................................................................................. 5-4
Input Signal Name (Aux Name) .................................................................................................... 5-4
Scaling Factor (Scaling)................................................................................................................ 5-5
Unit (Unit)...................................................................................................................................... 5-5
Input Signal Type (Sense Type).................................................................................................... 5-6
Analog Input Range ...................................................................................................................... 5-7
Linear Scaling of Analog Input ...................................................................................................... 5-8
Line Filter (Line Filter(Butterworth)) ............................................................................................ 5-10
Pulse Noise Filter (Pulse Noise Filter) ........................................................................................ 5-10
Sync Source (Sync Source)........................................................................................................ 5-10
Upper and Lower Limits of Pulse Input Range (Pulse Range Upper, Pulse Range Lower) ........5-11
Torque Signal Pulse Rating..........................................................................................................5-11
Revolution Signal Pulses per Revolution (Pulse N).................................................................... 5-13
Sync Speed(Sync Speed)........................................................................................................... 5-14
Electrical Angle Measurement (Electrical Angle Measurement) ................................................. 5-15
Computing the Motor E󰀩ciency and Total E󰀩ciency .................................................................. 5-16
6 Computation and Output Conguration
Computation and Output (Computation/Output) ........................................................................... 6-1
E󰀩ciency Equation (E󰀩ciency)..................................................................................................... 6-2
Delta Computation (Δ Measure).................................................................................................... 6-3
Data Update Interval (Update rate)............................................................................................... 6-6
Averaging (Averaging) .................................................................................................................6-11
D/A Output (D/A Output, option).................................................................................................. 6-13
7 Harmonic Measurement Conditions
Harmonic Measurement Conditions (Harmonics)......................................................................... 7-1
Input Element Group (Elements) .................................................................................................. 7-1
PLL Source (PLL Source) ............................................................................................................. 7-1
Measured Harmonic Orders (Min Order/Max Order) .................................................................... 7-2
Distortion Factor Equation (Thd Formula)..................................................................................... 7-3
Number of FFT Points (FFT Points).............................................................................................. 7-3
Anti-Aliasing Filter......................................................................................................................... 7-3
8 Computation
Computation (Measure) ................................................................................................................ 8-1
User-Dened Functions (User Dened Functions) ....................................................................... 8-1
Measuring the Average Active Power ........................................................................................... 8-5
MAX Hold (Max Hold) ................................................................................................................... 8-5
User-Dened Events (User Dened Event) .................................................................................. 8-6
Equation for Apparent Power (S Formula) .................................................................................... 8-8
Apparent Power and Reactive Power Computation Types (S,Q Formula) ................................... 8-9
Equation for Corrected Power (Pc Formula)............................................................................... 8-10
Phase Di󰀨erence Display Format (Phase)...................................................................................8-11
Master/Slave Synchronous Measurement (Sync Measure)........................................................ 8-12

v
IM WT5000-01EN
Contents
9 Display
Display (Display)........................................................................................................................... 9-1
Single Screen Display (Full Screen Display) ................................................................................ 9-1
Split Display .................................................................................................................................. 9-1
Display Settings ............................................................................................................................ 9-1
10 Numeric Data Display
Numeric Data Display (NUMERIC)............................................................................................. 10-1
Switching the Displayed Page (Page Scroll)............................................................................... 10-3
Number of Displayed Digits (Display Resolution) ....................................................................... 10-3
Display Items (Items, Numeric)................................................................................................... 10-4
All display (All Items)................................................................................................................... 10-6
4-, 8-, and 16-Value Displays (4 Items/8 Items/16 Items)........................................................... 10-7
Matrix display (Matrix)................................................................................................................. 10-8
Harmonics List Single/Dual (Hrm List Single/Dual)..................................................................... 10-9
11 Graph Display
Graph Display (GRAPH)..............................................................................................................11-1
Waveform display (Wave) ............................................................................................................11-1
Display Group (Group).................................................................................................................11-2
Display Items (Items, Wave) ........................................................................................................11-2
Display Format (Form, Wave)......................................................................................................11-4
Number of Windows (Format)......................................................................................................11-4
Time Axis (Time/div).....................................................................................................................11-4
Vertical Axis (Amplitude) ..............................................................................................................11-6
Advanced Waveform Display Settings (Advanced) .....................................................................11-7
Cursor Measurement (Cursors) ...................................................................................................11-7
Trend Display (Trend) ..................................................................................................................11-8
Display Group (Group).................................................................................................................11-8
Display Items (Items, Trend) ........................................................................................................11-9
Display Format (Form, Trend)....................................................................................................11-10
Cursor Measurement (Cursors) .................................................................................................11-11
Measurement Display (Value)....................................................................................................11-11
Bar Graph Display (Bar).............................................................................................................11-12
Display Group (Group)...............................................................................................................11-12
Display Items (Items, Bar)..........................................................................................................11-12
Display Format (Form, Bar) .......................................................................................................11-13
Cursor Measurement (Cursors) .................................................................................................11-13
Vector Display (Vector) ..............................................................................................................11-14
Display Group (Group)...............................................................................................................11-14
Display Items (Items, Vector) .....................................................................................................11-15
Display Format (Form, Vector)...................................................................................................11-15
12 Custom Display
Custom Display (CUSTOM)........................................................................................................ 12-1
13 Holding Measured Values, Performing Single Measurements, and
Zero-Level Compensation
Holding Measured Values (Hold, HOLD) .................................................................................... 13-1
Single Measurement (Single Execute, SINGLE) ........................................................................ 13-1
Zero-Level Compensation (Cal Execute, CAL)........................................................................... 13-1

vi IM WT5000-01EN
Contents
14 Integrated Power (Watt Hours/Ampere Hours)
Integrated Power (Integration, MENU (INTEGRATION))............................................................ 14-1
Integration-Related Display......................................................................................................... 14-1
Number of Displayed Digits (Display Resolution) ....................................................................... 14-3
Integration Mode (Integration Mode)........................................................................................... 14-5
Integration Timer (Integration Timer)........................................................................................... 14-8
Scheduled Times for Real-Time Integration (Start Time/End Time)............................................ 14-9
Enabling or Disabling Independent Integration (Independent Control)..................................... 14-10
Integration Source Elements (Element Objects)....................................................................... 14-10
Integration Auto Calibration On/O󰀨 (Auto Cal)...........................................................................14-11
Watt Hour Integration Method for Each Polarity (WP ± Type)....................................................14-11
Current Mode for Current Integration (q Mode) .........................................................................14-11
Integration resume action at power failure recovery (Resume Action) ..................................... 14-12
Starting, Stopping, and Resetting Integration ........................................................................... 14-13
15 Cursor Measurement
Cursor Measurement (Cursors) .................................................................................................. 15-1
Turning Cursor Measurement On and O󰀨 (Cursors)................................................................... 15-1
Waveform Measured by Cursor 1 (+) (C1+ Trace) ..................................................................... 15-1
Position of Cursor 1 (+) (C1+ Position)....................................................................................... 15-2
Position of Cursor 1 (+) (C1+ Order)........................................................................................... 15-2
Waveform Measured by Cursor 2 (x) (C2x Trace) ...................................................................... 15-2
Position of Cursor 2 (x) (C2x Position)........................................................................................ 15-2
Position of Cursor 2 (x) (C2x Order) ........................................................................................... 15-2
Cursor Path (Cursor Path) .......................................................................................................... 15-2
Linking Cursor Movement (Linkage)........................................................................................... 15-2
Measured Items .......................................................................................................................... 15-3
Cursor Movement ....................................................................................................................... 15-4
16 Data Storage
Data Storage (Store, MENU (STORE)) ...................................................................................... 16-1
Storage Conditions ..................................................................................................................... 16-1
Storage Control........................................................................................................................... 16-2
Stored Items................................................................................................................................ 16-5
File Save Conditions................................................................................................................... 16-7
Starting, Pausing, and Ending Storage Recording ..................................................................... 16-9
Storage Operations in Each Storage Mode ...............................................................................16-11
17 Saving Numeric Data, Waveform Data, and Screen Images
Saving Data (Data Save, MENU (DATA SAVE))......................................................................... 17-1
Storage Device ........................................................................................................................... 17-2
Saved Items (Saved Objects) ..................................................................................................... 17-3
Conditions for Saving Numeric Data........................................................................................... 17-4
Conditions for Saving Screen Images......................................................................................... 17-5
File Save Conditions................................................................................................................... 17-6
Saving (Save Exec, EXEC)......................................................................................................... 17-6

vii
IM WT5000-01EN
Contents
18 Ethernet Communication
Ethernet Communication (Network)............................................................................................ 18-1
TCP/IP(TCP/IP) .......................................................................................................................... 18-2
FTP Server (FTP Server)............................................................................................................ 18-3
Network Drive (Net Drive)........................................................................................................... 18-4
SNTP(SNTP) .............................................................................................................................. 18-5
19 Utility
Utility (Utility, UTILITY)................................................................................................................ 19-1
Instrument Information (System Overview)................................................................................. 19-2
System Conguration (System Conguration)............................................................................ 19-3
Remote Control (Remote Control) .............................................................................................. 19-7
Releasing Remote Mode (UTILITY)............................................................................................ 19-8
Key Lock (KEY LOCK)................................................................................................................ 19-9
Touch Lock (TOUCH LOCK)....................................................................................................... 19-9
Self-test (Selftest) ....................................................................................................................... 19-9
Index

1-1
IM WT5000-01EN
1 Items That This Instrument Can Measure
The items that you can measure with this instrument are listed below. For details about how the values of the
measurement functions are determined, see appendix 1 in the Getting Started Guide, IM WT5000-03EN. For
explanations of the terms measurement function, input element, and wiring unit, see “What Is a Measurement
Function?”
Click here.
The input elements and wiring units referred to in each measurement function table are listed below. However,
the input elements and wiring units that you can measure vary depending on how many input elements are
installed in this instrument.
• Input elements: Element1 to Element7
• Wiring units: ΣA, ΣB, ΣC
• Motor numbers: Motor1 to Motor4
Measurement Functions Used in Normal Measurement
Voltage
Function Description Input Element Wiring Unit
Urms True rms voltage Yes Yes
Umn Rectified mean voltage calibrated to
the rms value
Yes Yes
Udc Simple voltage average Yes Yes
Urmn Rectified mean voltage Yes Yes
Uac AC voltage component Yes Yes
Ufnd Fundamental voltage component Yes Yes
U+pk Maximum voltage Yes No
U−pk Minimum voltage Yes No
CfU Voltage crest factor Yes No
Current
Function Description Input Element Wiring Unit
Irms True rms current Yes Yes
Imn Rectified mean current calibrated to the
rms value
Yes Yes
Idc Simple current average Yes Yes
Irmn Rectified mean current Yes Yes
Iac AC current component Yes Yes
Ifnd Fundamental current component Yes Yes
I+pk Maximum current Yes No
I−pk Minimum current Yes No
CfI Current crest factor Yes No
Power
Function Description Input Element Wiring Unit
P Active power Yes Yes
S Apparent power Yes Yes
Q Reactive power Yes Yes
λPower factor Yes Yes
ΦPhase difference Yes Ye s
Pfnd Fundamental active power Yes Yes
Sfnd Fundamental apparent power Yes Yes
Qfnd Fundamental reactive power Yes Yes
λfnd Fundamental power factor Yes Yes
Φfnd Fundamental phase difference Yes No
Pc Corrected Power Yes Yes
P+pk Maximum power Yes No
P−pk Minimum power Yes No

1-2 IM WT5000-01EN
Frequency
Function Description Input Element Wiring Unit
fU Voltage frequency Yes No
fI Current frequency Yes No
f2U Voltage frequency Yes No
f2I Current frequency Yes No
fPLL1 Frequency of PLL1 No No
fPLL2 Frequency of PLL2 No No
Integrated Power (Watt hours)
Function Description Input Element Wiring Unit
ITime Integration time Yes No
WP Sum of positive and negative watt
hours
Yes Yes
WP+ Sum of positive P values Yes Yes
WP− Sum of negative P values Yes Ye s
q Sum of positive and negative ampere
hours
Yes Yes
q+ Sum of positive I values Yes Yes
q− Sum of negative I values Yes Yes
WS Volt-ampere hours Yes Yes
WQ Var hours Yes Yes
Efficiency
Function Description
η1 to η4 Efficiency
User-Defined Functions
Function Description
F1 to F20 User-defined functions
User-Defined Events
Function Description
Ev1 to Ev8 User-defined events
1 Items That This Instrument Can Measure

1-3
IM WT5000-01EN
Harmonic Measurement Functions
Function Description Input Element Wiring Unit
U(k) Rms voltage of harmonic order k Yes Yes
I(k) Rms current of harmonic order k Yes Yes
P(k) Active power of harmonic order k Yes Yes
S(k) Apparent power of harmonic order k Yes Yes
Q(k) Reactive power of harmonic order k Yes Yes
λ(k) Power factor of harmonic order k Yes Yes
Φ(k) Phase difference between the voltage
and current of harmonic order k
Yes No
ΦU(k) Phase difference between the
fundamental signal, U(1), and
harmonic voltage U(k)
Yes No
ΦI(k) Phase difference between the
fundamental signal, I(1), and harmonic
current I(k)
Yes No
Z(k) Impedance of the load circuit Yes No
Rs(k) Series resistance of the load circuit Yes No
Xs(k) Series reactance of the load circuit Yes No
Rp(k) Parallel resistance of the load circuit Yes No
Xp(k) Parallel reactance of the load circuit Ye s No
Uhdf(k) Harmonic voltage distortion factor Yes No
Ihdf(k) Harmonic current distortion factor Yes No
Phdf(k) Harmonic active power distortion factor Yes No
Uthd Total harmonic voltage distortion Yes No
Ithd Total harmonic current distortion Yes No
Pthd Total harmonic active power distortion Yes No
Uthf Telephone harmonic factor of the
voltage
Yes No
Ithf Telephone harmonic factor of the
current
Yes No
Utif Telephone influence factor of the
voltage
Yes No
Itif Telephone influence factor of the
current
Yes No
hvf Harmonic voltage factor Yes No
hcf Harmonic current factor Yes No
K−factor K factor Yes No
ΦUi−Uj1Phase difference between the
fundamental voltage of element i,
Ui(1), and the fundamental voltage of
element j, Uj(1)
No Yes
ΦUi−Uk1Phase difference between Ui(1) and
the fundamental voltage of element k,
Uk(1)
No Yes
ΦUi−Ii1Phase difference between Ui(1) and
the fundamental current of element i,
Ii(1)
Yes2Yes
ΦUj−Ij1Phase difference between Uj(1) and
the fundamental current of element j,
Ij(1)
No Yes
ΦUk−Ik1Phase difference between Uk(1) and
the fundamental current of element k,
Ik(1)
No Yes
1 i, j, and k are input element numbers. For example, when the number of input elements in wiring unit ΣA is
six and the wiring system of elements 1, 2, and 3 is three phase, four wire, i is 1, j is 2, and k is 3. ΦUi – Uj
represents ΦU1 – U2, the difference between the fundamental voltage signal of element 1, U1(1), and the
fundamental voltage signal of element 2, U2(1). In the same way ΦUi – Uk, ΦUi – Ii, ΦUj – Ij, and ΦUk−Ik
represent to ΦU1 – U3, ΦU1 – I1, ΦU2 – I2, and ΦU3 – I3, respectively.
2 Setting i to an input element, is the same as setting k to 1 in Φ(k).
1 Items That This Instrument Can Measure

1-4 IM WT5000-01EN
Harmonic Measurement Function Orders
The harmonic orders that you can specify are indicated below.
Input Element Harmonic Measurement Functions
Measurement
Function
Characters or Numbers in Parentheses
Total Value 0(DC) 1 k
U( ) Yes Yes Yes 2 to 500
I( ) Yes Ye s Yes 2 to 500
P( ) Yes Yes Ye s 2 to 500
S( ) Yes Yes Ye s 2 to 100
Q( ) Ye s Always zero Yes 2 to 100
λ( ) Ye s Yes Yes 2 to 100
Φ( ) Yes No Ye s 2 to 500
ΦU( ) No No No 2 to 500
ΦI( ) No No No 2 to 500
Z( ) No Yes Yes 2 to 100
Rs( ) No Yes Yes 2 to 100
Xs( ) No Yes Yes 2 to 100
Rp( ) No Yes Yes 2 to 100
Xp( ) No Yes Yes 2 to 100
Uhdf( ) No Yes Yes 2 to 500
Ihdf( ) No Yes Yes 2 to 500
Phdf( ) No Yes Yes 2 to 500
Uthd Yes No No No
Ithd Yes No No No
Pthd Yes No No No
Uthf Yes No No No
Ithf Yes No No No
Utif Yes No No No
Itif Yes No No No
hvf Yes No No No
hcf Yes No No No
K-factor Yes No No No
Functions with parentheses will produce different values depending on which of the following is contained in their
parentheses.
• Total: Total value (The total value of all harmonic components from the minimum order to N.* For information
about how the value is determined, see appendix 12 in the Getting Started Guide, IM WT5000-03EN.)
• 0(DC): DC value
• 1: Fundamental harmonic value
• k: The value of any order from 2 to N.*
* N is the maximum measurable order. he maximum measurable harmonic order is the smallest of the three
orders listed below.
• The specified maximum measurable harmonic order
• The value determined automatically according to the PLL source frequency (see section 6.7 in the Getting
Started Guide, IM WT5000-03EN)
• When the data update interval is 50 ms or Auto, the maximum measurable harmonic order is 100.
1 Items That This Instrument Can Measure

1-5
IM WT5000-01EN
Wiring Unit Harmonic Measurement Functions (Σ functions)
Measurement
Function
Characters or Numbers
in Parentheses
Total Value 1
UΣ( ) Yes Yes
IΣ( ) Yes Yes
PΣ( ) Yes Yes
SΣ( ) Yes Yes
QΣ( ) Ye s Yes
λΣ( ) Yes Yes
Functions with parentheses will produce different values depending on which of the following is contained in their
parentheses.
• Total: Total value
• 1: Fundamental harmonic value
Delta Computation Functions
Function Description
ΔU1 The values returned by the delta computation
functions vary depending on the specified delta
computation type.
ΔU2
ΔU3
ΔUΣ
ΔI
ΔP1
ΔP2
ΔP3
ΔPΣ
For details about delta computation functions, see “Delta Computation (Δ Measure).”
Click here.
Motor Evaluation Functions (Option)
Function Description Motor Number Input Element
Speed Motor rotating speed Yes No
Torque Motor torque Yes No
SyncSp Synchronous speed Yes No
Slip Slip (%) Yes No
Pm Mechanical output of the motor
(mechanical power)
Yes No
EaM1U,
EaM1I
Electrical angles: Phase angles of the
fundamental waves of U1 to I7 with
the rising edge of the signal received
through the Motor1 (MTR1) Z terminal
of the motor evaluation function as the
reference (specify an input element).
No Yes
EaM3U,
EaM3I
Electrical angles: Phase angles of the
fundamental waves of U1 to I7 with
the rising edge of the signal received
through the Motor3 (MTR2) Z terminal
of the motor evaluation function as the
reference (specify an input element).
No Yes
Auxiliary Input Measurement Functions (Option)
Function Description
Aux1 to 8 Auxiliary inputs 1 to 8
1 Items That This Instrument Can Measure

1-6 IM WT5000-01EN
Measurement Range
Function Description Input Element Motor Number
RngU Voltage measurement range Yes No
RngI Current measurement range Yes No
RngSpd Speed measurement range No Yes
RngTrq Torque measurement range No Yes
RngAux1 to 8 Aux measurement range No No
For measurement range functions, data can be acquired using the following methods.
• By setting a user-defined function
• By storing or by saving numeric data
• By outputting through communication
1 Items That This Instrument Can Measure

1-7
IM WT5000-01EN
What Is a Measurement Function?
Measurement Function
The physical values (such as rms voltage, average current, power, and phase difference) that this instrument
measures and displays and measurement range and other measurement information are called measurement
functions. Each measurement function is displayed using symbols that correspond to its physical value. For
example, “Urms” corresponds to the true rms voltage.
Element
Element refers to a set of input terminals that can receive a single phase of voltage and current to be measured.
This instrument can contain up to seven elements, numbered from 1 to 7. An element number is appended to
the measurement function symbol for the measured data that this instrument displays, so that you can tell which
data belongs to which element. For example, “Urms1” corresponds to the true rms voltage of element 1.
Wiring System
You can specify five wiring systems on this instrument to measure the power of various single-phase and
threephase power transmission systems: single-phase, two-wire; single-phase, three-wire; three-phase, three-
wire; three-phase, four-wire; and three-phase, three-wire with three-voltage, three-current method.
Wiring Unit
The wiring unit is a set of two or three input elements of the same wiring system that are grouped to measure
three-phase power. There can be up to three wiring units: ΣA, ΣB, and ΣC.
Click here.
Σ Functions
The measurement function of a wiring unit is called a Σ function.
For example, “UrmsΣA” corresponds to the average of the voltages of the input elements that are assigned to
the wiring unit ΣA. The average value represents the true rms value.
Click here.
Three-phase
three-wire
Σ A
1
Element number
Wiring system
Wiring unit
Voltage input
Current input
234 5 6 7
Three-phase
three-wire
Σ B
Three-phase
four-wire
Σ C
Measurement Period
For information about the measurement period for computing measurement functions, see “Measurement Period
(SYNC SOURCE).”
Click here.
1 Items That This Instrument Can Measure

2-1
IM WT5000-01EN
2 Setup Menu
This section explains the following settings:
• Navigation
• Setup Menu (Setup, SETUP)
Navigation
When you start the instrument, the navigation window appears.
Select whether to display the setup menu to configure the instrument or not display the setup menu and change
to the measurement screen.
Setup Menu (Setup, MENU(SETUP))
Configure or execute the following items according to how the instrument is to be used.
• Measurement Mode (Measurement Mode)
• Input Settings (Basic Measurement Conditions, Input (Basic))
• Input Settings (Advanced/Options, Input (Advanced/Options))
• Computation/Output (Computation/Output)
• Utility (Utility)
• Initialize Settings (Initialize Settings)
• File List (File List)
• Save Setup (Save Setup)
• Load Setup (Load Setup)
Measurement Mode (Measurement Mode)
The measurement mode is fixed to normal measurement (Normal).
Initialize Settings (Initialize Settings)
You can reset the instrument settings to their factory default values. This feature is useful when you want to
cancel all the settings that you have entered or when you want to redo measurement from scratch.
For information about how initialize the settings, see section 3.7 in the Getting Started Guide, IM WT5000-03EN.
File List (File List)
You can perform file operations such as creating folders on the storage device, deleting and copying files, and
changing file names.
Storage Device Displayed in the File List
Click here.

2-2 IM WT5000-01EN
Up to 512 files and folders can be displayed in the file list. If there are more than a total of 512 files and
folders in a given folder, the file list for that folder will display only 512 files and folders. There is no way to set
which files and folders are displayed.
Display Format
Select whether to display the file list in a one-column list, two-column list, or using thumbnails.
Sorting the File List
You can sort the file list by file name, size, or date and time.
Selecting Files
Select the files or folders you want to manipulate. Selecting multiple files is useful when you want to copy or
delete multiple files at the same time.
Selecting Files Collectively
• Selecting All Files
When the cursor is on a device or folder in the file list, select ALL Set to select all of the files and folders within
the device or folder that the cursor is on.
• Deselecting All Files
All of the selected files and folders are deselected.
Making Folders (New folder)
You can make folders. You can use the same characters in folder names that you can in file names.
Copying (Copy)
You can copy selected files and folders to other storage devices or folders. You can copy multiple files at the
same time.
Moving (Move)
You can move selected files and folders to other storage devices or folders. You can move multiple files at the
same time.
Renaming (Rename)
You can rename a selected file or folder.
Protecting (Protect)
You can set or release the protection of selected files.
Deleting (Delete)
You can delete selected files and folders.
2 Setup Menu

2-3
IM WT5000-01EN
Saving Setup Data (Save Setup, SAVE(SETUP))
You can save the setup data of this instrument to the specified storage device. The date, time, and
communication setup parameters are not saved.
The extension is .SET.
File List (File List)
On the file list, specify the save destination. You can perform file operations such as creating folders on the
storage device, deleting and copying files, and changing file names.
Click here.
Auto Naming (Auto Naming)
OFF
The auto naming feature is disabled. The name that you specify using the File Name setting is used. If there is a
file with the same name in the save destination folder, you cannot save the data.
Auto Numbering (Numbering)
This instrument automatically adds a four-digit number from 0000 to 0999 after the common name specified
using the File Name setting and saves files.
Date (Date)
The date and time when the file is saved are used as its name. The file name specified for the File Name setting
is ignored.
Year
Month
Day
Hour
Minute
Second
20180130_121530_0 (2018/01/30 12:15:30)
Sequence number (0 to 9 then A to Z) for when multiple files
are saved at the same time (second)
A sequence number is appended to the date and time when multiple files are saved at the same time (second).
The number starts at 0 and is incremented by one each time a file is added. The number 9 is followed by letters
of the alphabet.
Save Destination Folder for Storage Caused by User-Defined Events
Click here.
File Name (File Name)
You can set the common file name that is used when the auto naming feature is turned off or when the auto
naming feature is set to Numbering. The maximum number of characters that you can use for file names and
folder names is 32 characters. The following restrictions apply.
• Of those characters on the keyboard that appears on the screen, the characters that can be used are 0-9,
A-Z, a-z, _, –, =, (, ), {, }, [, ], #, $, %, &, ~, !, `, and @. @ cannot be entered consecutively.
• The following exact strings cannot be used due to MS-DOS limitations:
AUX, CON, PRN, NUL, CLOCK, LPT1, LPT2, LPT3, LPT4, LPT5, LPT6, LPT7, LPT8, LPT9, COM1, COM2,
COM3, COM4, COM5, COM6, COM7, COM8, COM9
• Keep the full path name (absolute path from the root folder) within 255 characters. If this is exceeded, an
error will occur when you perform file operations (save, copy, rename, create folder, etc.). When an operation
is being performed on a folder, the full path is up to the name of the folder. When an operation is being
performed on a file, the full path is up to the name of the file.
The following additional restrictions apply when you use the file name auto naming feature.
• If you set auto naming to Numbering, a file name will consist of the characters that you entered for the file
name and a four-character sequence number.
• If you set auto naming to Date, the characters that you entered for the file name will not be used. File names
will only consist of the date information.
2 Setup Menu

2-4 IM WT5000-01EN
Comment (Comment)
You can add a comment that consists of up to 30 characters when you save a file. You do not have to enter a
comment. You can use all characters and spaces that are displayed on the keyboard.
Settings That Are Shared with Those of Other Menus
The following settings are shared by the menus for saving setup data, storing data, saving data.
• File list display and save destination settings (File List)
• Automatic file naming settings (Auto Naming)
• File name (File Name)
The comment settings (Comment) are shared by the menus for saving setup data and storing data.
Saving (Save Exec)
Saves the data to the specified save destination with the specified file name.
Loading Setup Data (Load Setup, LOAD(SETUP))
On the file list, specify a file to load setup data from. The extension is .SET. For information about how to
configure the file list display and how to operate files and folders, see “File List (File List).”
Click here.
Loading (Execute Load)
Loads the data of the specified file.
• If you change the extension of the saved data file, by using a PC or some other device, the instrument will
no longer be able to load it.
• When setup data is loaded from a file, the setup data for each key is changed to match the loaded settings,
and it cannot be changed back. We recommend that you save the current settings before loading different
setup data.
• The date, time, and communication setup parameters are not saved. So even if you load setup data from a
file, the date, time, and communication settings will not change.
• This instrument cannot load setup data that has been saved by a product with an incompatible firmware
version.
• This instrument cannot load setup data that was saved by an instrument with a different element
configuration, different options, etc.
2 Setup Menu

3-1
IM WT5000-01EN
3 Input Settings (Basic Measurement Conditions)
Input Settings (Basic Measurement Conditions, Input (Basic))
You can specify the following items.
• Wiring system (Wiring)
• Selecting the element for setting the measurement range (Element1 to 7, 1 to 7 (ELEMENTS))
• Voltage range (Voltage, VOLTAGE RANGE)
• Auto voltage range (Auto (Voltage), AUTO)
• Current range (Current, CURRENT RANGE)
• Auto current range (Auto (Current), AUTO)
• External current sensor on/off (Ext Sensor)
• External current sensor conversion ratio (Sensor Ratio)
• Scaling (Scaling)
• Line filter (Line Filter)
• Frequency filter (Freq Filter)
• Measurement Period (Sync Source)
Wiring System (Wiring)
The following five wiring systems are available on the instrument. The selectable wiring systems vary depending
on the number of installed input elements.
• 1P2W: Single-phase two-wire system
• 1P3W: Single-phase three-wire system
• 3P3W: Three-phase three-wire system
• 3P4W: Three-phase four-wire system
• 3P3W(3V3A): Three-voltage three-current method
Wiring Unit
Wiring units are sets of two or three input elements of the same wiring system that are grouped together. You
can define up to three wiring units: ΣA, ΣB, and ΣC.
• When there is one wiring unit, that unit is ΣA. You cannot make ΣB or ΣC the first wiring unit.
• When there are two wiring units, those units are ΣA and ΣB. You cannot make ΣC one of the first two wiring
units.
• When there are three wiring units, those units are ΣA, ΣB, and ΣC.
• When there are multiple wiring units, element numbers are assigned to them in ascending order. The element
numbers are assigned to ΣA, ΣB, and then ΣC.
• Wiring units are composed of input elements that are next to each other. Wiring units cannot consist of input
elements that are not next to each other.
• Wiring units cannot consist of input elements that are different types.
Σ Functions
The measurement function of a wiring unit is called a Σ function.
For example, “UrmsΣA” corresponds to the average of the voltages of the input elements that are assigned to
the wiring unit ΣA. The average value represents the true rms value.
