York MCC-MCH 09 User manual

035T80012-000
Installation Manual
MINISPLIT
FLOOR/CEILING
AIR CONDITIONER
MODELS
MCC-MCH/MOC-MOH09
MCC-MCH/MOC-MOH 12
MCC-MCH/MOC-MOH 18
MCC-MCH/MOC-MOH 25
MCC-MCH/MOC-MOH 35
MCC-MCH/MOC-MOH 45
MCC-MCH/MOC-MOH 55
01_install.p65 19/4/02, 14:411

YORK MINISPLIT FLOOR/CEILING Code 035T80012-000
2 FLOOR/CEILING
Please read this installation manual
carefully before starting the installation.
It will tell you necessary information.
Quality POLICY
We will continuously strive to satisfy
our customers with consistent reliability
in product, service and support.
CONTENTS
Safety Precautions ......................................4
Cautions for Installation ...........................................4
Part List.........................................................5
Indoor Unit............................................................ 5-6
Preparation Before Installation ..................7
Selection of the Location .........................................7
Drilling Measurement ...............................................8
Remote Control Receiving Type Setting............ 9-10
Installation in the Following Places
May Result in Trouble ............................................11
Installation Diagram ..................................12
Installation Procedure ...............................13
Indoor Unit........................................................ 13-14
Outdoor Unit ..................................................... 15-17
Test Operation............................................18
Check This Item Before Start Operation................18
System Test Diagnostics........................................18
Trouble Shooting Guide ............................19
Diagnostic Information Function ............................20
Technical Specification .............................21
Indoor Unit..............................................................21
Condensing Unit............................................... 22-23
02_install.p65 19/4/02, 14:452

YORK MINISPLIT FLOOR/CEILING Code 035T80012-000
FLOOR/CEILING 3
REQUIRED TOOLS
1. Screw Driver
2. Hexagonal Wrench
3. Torque Wrench
4. Spanner
5. Reamer
6. Hole Core Drill
7. Tape Measure
8. Thermometer
9. Manifold Guage
10. Gas Leak Detector
11. Vacuum Pump
12. Pipe Clamp
13. Pipe Cutter
14. Flare Tool Set
15. Electrical Circuit Tester
EXTENDED PARTS
1. Refrigerant Pipe
Models
MCC-MCH/MOC-MOH
9 12 18,25,35 45,55
Liquid size 1/4" 1/4" 3/8" 3/8"
Gas size 3/8" 1/2" 5/8" 3/4"
2. Pipe Insulation Material (Polyethylene foam
9 mm thick)
3. Vinyl Tape
4. Putty
02_install.p65 19/4/02, 14:453

YORK MINISPLIT FLOOR/CEILING Code 035T80012-000
4 FLOOR/CEILING
SAFETY PRECAUTIONS
•Please read this installation manual carefully before starting installation of the unit.
•This air conditioning system contains refrigerant under pressure, rotating parts and
electrical connection which may be dangerous and can cause injury. Installation
andmaintenanceofthisairconditioningsystem should onlybecarried outbytrained
and qualified personnel.
•After unpacking, please check the unit carefully for possible damage.
•Before undertaking any work on the unit, make sure that the power supply has
been disconnected.
CAUTIONS FOR INSTALLATION
Do not install in a place where flammable gas may
leak.
It may cause fire.
Do not store or unpack the unit in a wet area or expose
to rain or water.
It may cause the unit to short circuit and may result electric
shocks or fire.
Do not conduct installation in wet area or in the rain.
It is a high risk to cause the electrical shocks.
This system is designed for domestic or residential
use only.
If used in certain envionments, such as a manufacturing
workplace, the equipment may not function efficiently.
02_install.p65 19/4/02, 14:454

YORK MINISPLIT FLOOR/CEILING Code 035T80012-000
FLOOR/CEILING 5
Description Q'ty USE
Drain Hose
1
Insulation (Drain hose)
1
Adhesive type
VT Wire 1For drain hose
(280 mm)
Remote Control
1
Installation and
2
Owner’s manual
INSTALLATION ACCESSORIES
Description Q'ty USE
Cover Plate
2
Tapping Screw (∅4x10) 2
Tapping Screw (∅4x20) 6For indoor side pipe
joint (small pipe)
Wall Bracket
2
Bracket for wall
installation
Coupler Heat Insulator
2
For indoor side pipe
joint
Nylon Fastener 1For drain hose
PART LIST
INDOOR UNIT
■MCC-MCH09-25
Installation Manual
Owner's Manual
SLEEP ON/OFF
TEMP
(continued)
02_install.p65 19/4/02, 14:455

YORK MINISPLIT FLOOR/CEILING Code 035T80012-000
6 FLOOR/CEILING
Description Q'ty
Remote Control
1
Installation and Owner’s manual
2
■MCC-MCH35-55
INSTALLATION ACCESSORIES
Description Q'ty
Bracket
2
Rubber, Screw and Bolt
16
N12 N12 N12
SLEEP ON/OFF
TEMP
Installation Manual
Owner's Manual
Part list (continued)
02_install.p65 19/4/02, 14:456

YORK MINISPLIT FLOOR/CEILING Code 035T80012-000
FLOOR/CEILING 7
PREPARATION BEFORE INSTALLATION
•Before doing any work, check the interior power supply cord and the main breaker capacity are sufficient and the
installation area is sufficient and complies with the requirements.
•Check that the power supply available agrees with nameplate voltage.
•Electrical work, wiring and cables must be performed in compliance with national and local wiring codes and
standard.
•Do not use the extension cables.In the case extended cables are needed, use the terminal block.
SELECTION OF THE LOCATION
■Select a place which provides the space around the units as shown in the
diagram below.
Indoor Unit Outdoor Unit
(continued)
Dimension MCC-MCH
(cm) 09 12 18 25 35 45 55
A 50505050505050
B 80808080808080
C 5555555
D 20202020202020
Dimension MOC-MOH
(cm) 09 12 18 25 35 45 55
A 40404040404040
B 20202020202020
C 20202020202020
D 60606060606060
02_install.p65 19/4/02, 14:457

YORK MINISPLIT FLOOR/CEILING Code 035T80012-000
8 FLOOR/CEILING
DRILLING MEASUREMENT
D
E
F
Preparation Before Installation (continued)
■Indoor Unit
Drill the hole to fixing unit follow the diagram
below
Ceiling Installation Drilling
Floor Installation Drilling
Model MCC-MCH09, 12, 18, 25
Drain hose drilling measurment floor case.
Model MCC-MCH35, 45, 55
Drain hose drilling measurment floor case.
■Outdoor Unit
A
BC
Dimensions MCC-MCH
(mm) 35 45 55
A 1,402 1,402 1,692
B 201 201 201
C 145 145 145
D 215 215 215
E 115 115 115
F888888
MO 25
95mm
511mm 125mm
245mm 990mm 245mm
95mm
42mm
A
6
31
15
15
130
25
77.5
86
G 177
175 325
110
MO 09-12
MO 18
MO 35-55
517
144 144
296
260 316
429
150 550 150
100100
64
64
234
315
287 2424 335
60100
160
30
740160
1010 375
30
395
Dimensions MCC-MCH
(mm) 35 45 55
G 1,122 1,122 1,442
497133.5 133.5
248
230 268
02_install.p65 19/4/02, 14:458

YORK MINISPLIT FLOOR/CEILING Code 035T80012-000
FLOOR/CEILING 9
REMOTE CONTROL RECEIVING TYPE SETTING
The Indoor Unit can set its remote control receiver into type-A and type-B.
1 Open front grille.
2 Adjust dip switch 1 No. 8 to desire receiver type.
(continued)
02_install.p65 19/4/02, 14:459

YORK MINISPLIT FLOOR/CEILING Code 035T80012-000
10 FLOOR/CEILING
Notes
1. Default remote control receiving type setting is type-A.
2. Default remote control transmission type setting is type-A.
3. Remote control receiving type must be correct to Remote control transmission type.
4. Setting Remote control Transmission type see the Owner’s manual.
Switch No. Setting Remote Control receive
SW1 8 HA
LB
Preparation Before Installation (continued)
02_install.p65 19/4/02, 14:4510
