Y9USC/E 09 / 12 / 18 B5R
SERVICE MANUAL
Y9USC-09 B5R; Y9USE-09 B5R
Y9USC-12 B5R; Y9USE-12 B5R
Y9USC-18 B5R; Y9USE-18 B5R
SM-Y9USC-E-09-18GB 03-07

Service manual
1. Precaution ........................................................................................................................................................................................... 2
1.1 safety Precaution............................................................................................................................................................................... 2
1.2 WARNING ......................................................................................................................................................................................... 2
1.3 CAUTION .......................................................................................................................................................................................... 2
1.4 FEATURES ....................................................................................................................................................................................... 3
1.5 DIAGRAM PANEL............................................................................................................................................................................. 3
1.6 OUTSIDE DIMENSIONS .................................................................................................................................................................. 3
1.7 SPECIFICATION............................................................................................................................................................................... 4
2 INSTALLATION .................................................................................................................................................................................. 10
2.1 SELECT THE BEST LOCATION .................................................................................................................................................... 10
2.2 CHECK OFF INSTALLATION......................................................................................................................................................... 10
2.3 HOW TO DRAIN ............................................................................................................................................................................. 11
2.4. HOW TO INSTALL ......................................................................................................................................................................... 11
3 REFRIGERANT CYCLE DIAGRAM .................................................................................................................................................. 13
4 OPERATION LIMITS.......................................................................................................................................................................... 14
4.1 COOLING OPERATION ................................................................................................................................................................. 14
4.2HEATING OPERATION ................................................................................................................................................................... 14
5. TROUBLESHOOTING ................................................................................................................................................................... 17

Service manual
1. PRECAUTION
1.1 SAFETY PRECAUTION
To prevent injury to the user or other people and property damage, the following instructions must be followed.
Incorrect operation due to ignoring instruction will cause harm or damage.
BEFORE SERVICE UNIT, BE SURE TO READ THIS SERVICE MANUAL AT FIRST.
1.2 WARNING
1.2.1 DO NOT USE DAMAGED POWER CORDS, PLUGS, OR A LOOSE SOCKET.
1.2.2 ALWAYS USE THE POWER PLUG AND SOCKET WITH THE GROUND TERMINAL
1.2.3 DO NOT MODIFY OR EXTEND THE POWER CORD
1.2.4 DO NOT TURN THE AIR-CONDITIONER ON OR OFF BY PLUGGING OR UNPLUGGING THE POWER PLUG
1.2.5 USE A DEDICATED POWER OUTLET FOR THIS APPLIANCE
1.2.6 GRASP THE PLUG TO REMOVE THE CORD FROM THE OUTLET. DO NOT TOUCH IT WITH WET HANDS.
1.2.7 DO NOT PLACE A HEATER OR OTHER APPLIANCE NEAR THE POWER CABLE
1.2.8 DO NOT ALLOW WATER TO RUN INTO ELECTRICAL PARTS
1.2.9 DO NOT STORE OR USE FLAMMABLE GAS OR COMBUSTIBLES NEAR THE AIR CONDITIONER
1.2.10 UNPLUGGING THE UNIT IF STRANGE SOUNDS, ODORS, OR SMOKE COMES FROM IT
1.2.11 BE CAUTION THAT WATER COULD NOT ENTER THE PRODUCT
1.3 CAUTION
1.3.1 USE A SOFT CLOTH TO CLEAN. DO NOT USE HARSH DETERGENTS, SOLVENTS, ETC
1.3.2 DO NOT TOUCH THE METAL PARTS OF THE PRODUCT WHEN REMOVING THE AIR FILTER. THEY ARE VERY SHARP
1.3.3 DO NOT STEP ON OR PUT ANYTHING ON THE PRODUCT
1.3.1 DO NOT INSERT HANDS OR OTHER OBJECTS THROUGH THE AIR INLET OR OUTLET WHILE THE AIR CONDITIONER IS
PLUGGED IN

Service manual
3
1.4 FEATURES
Designed for HEAT PUMP..
Powerful cooling & heating..
Slide-in and slide-out chassis for the simple installation and service.
Side air-intake, side cooled-air discharge.
WASHABLE ONE-TOUCH FILTER AND EASY REMOVED PANEL.
Super compact design.
Reliable and efficient rotary compressor is equipped.
Unique Quiet Design.
Fresh air switch
1.5 DIAGRAM PANEL
Auto louver
When the switch is on ,the louver motor will operate and begin auto louver function. When the switch is off, the louver motor will stop.
Thermostat
Set the temperature desired
Selector
Selector operation function on COOL, HEAT or FAN ONLY with HIGH, MID or LOW fan speed.
Test run
Turn the knob to this position to operate the unit in FORCED COOLING. Under this mode, the unit will operate in cooling immediately.
Wait three minutes before restarting
To protect the compressor, please do NOT restart the unit in COOLING or HEATING mode in three minutes.
1.6 OUTSIDE DIMENSIONS
Model
A (mm)
B (mm)
C (mm)
Y9USC-09 B5R
Y9USE-09 B5R
346
450
535
Y9USC-12 B5R
Y9USE-12 B5R
400
560
650
Y9USC-18 B5R
Y9USE-18 B5R
434
660
650

Service manual
4
1.7 SPECIFICATION
Model
Y9USC-09 B5R
Y9USE-09 B5R
Factory Model
CE-KC26/E1N2
CE-KCR26/E1N2
Power supply
Ph-V-Hz
1Ph , 220-240V~, 50Hz
1Ph , 220-240V~, 50Hz
Capacity
Btu/h
9000
9000
Input
W
1050
1110
Rated current
A
4.7
4.7
Cooling
EER
Btu/w.h W/W
8.6,2.51
8.6,2.51
Capacity
Btu/h
9000
Input
W
980
Rated current
A
4.4
Heating
COP
W/W
2.7
Moisture Removal
L/h
0.9
0.9
Max. input consumption
W
1400
1450
Max. current
A
7.3
7.5
Starting current
A
24
24
Plug type
Thermostat type
Mechanical control
Mechanical control
Model
PG180X1C-4DZ3
PG180X1C-4DZ3
Type
ROTARY
ROTARY
Brand
TOSHIBA
TOSHIBA
Capacity
Btu/h
10650
10650
Input
W
995
995
Rated current(RLA)
A
4.6
4.6
Locked rotor Amp(LRA)
A
24
24
Thermal protector
UP3QE0591-T61
UP3QE0591-T61
Capacitor
uF
30
30
Compressor
Refrigerant oil
ml
400
400
Refrigerant type
R407C/510g
R407C/550g
Design pressure
MPa
2.6
2.6
Model
YSK60-4C
YSK60-4C
Brand
Welling,Broad
Welling,Broad
Input
W
112/98/86
112/98/86
Capacitor
uF
2.5
2.5
Fan motor
Speed(hi/mi/lo)
r/min
1270/1170/1050
1270/1170/1050
a.Number of rows
3
3
b.Tube pitch(a)x row pitch(b)
mm
21X13.37
21X13.37
c.Fin spacing
mm
1.2
1.2
d.Fin type (code)
Hydrophilic aluminium
Hydrophilic aluminium
e.Tube outside dia.and type
mm
7x0.25, innergroove tube
7x0.25, innergroove tube
f.Coil length x height x width
mm
248X294X40.11
248X294X40.11
Evaporator
g.Number of circuits
2
2
Indoor air flow (Hi/Mi/Lo)
m3/h
420/380/330
420/380/330
Indoor noise level (Hi/Mi/Lo)
dB(A)
51/48/45
51/48/45

Service manual
5
a.Number of rows
3
3
b.Tube pitch(a)x row pitch(b)
mm
21X13.37
21X13.37
c.Fin spacing
mm
1.3
1.3
d.Fin type (code)
Hydrophilic aluminium
Hydrophilic aluminium
e.Tube outside dia.and type
mm
7x0.25, innergroove tube
7x0.25, innergroove tube
f.Coil length x height x width
mm
370X315X40.11
370X315X40.11
Condenser
g.Number of circuits
2
2
Outdoor air flow (Hi/Mi/Lo) m3/h
m3/h
700/620/540
700/620/540
Outdoor noise level (Hi/Mi/Lo) dB(A)
dB(A)
58/55/52
58/55/52
Dimension (W*H*D)
mm
450×350×540
450×350×540
Packing (W*H*D)
mm
495×435×580
495×435×580
Net/Gross weight
Kg
35/39
37/41
Operation temp
℃
16 31
16 31
Ambient temp
℃
17 ~ 43
-10 ~ 43
Application area
m2
14-20
14-20
Qty’per 20’& 40’HQ Fcl
Pieces
220/572
220/572

Service manual
6
Model
Y9USC-12 B5R
Y9USE-12 B5R
Factory Model
CE-KC35/E1N2
CE-KCR35/E1N2
Power supply
Ph-V-Hz
1Ph , 220-240V~, 50Hz
1Ph , 220-240V~, 50Hz
Capacity
Btu/h
12000
12000
Input
W
1420
1400
Rated current
A
6.3
6.2
Cooling
EER
Btu/w.h W/W
8.5,2.48
8.6,2.51
Capacity
Btu/h
12000
Input
W
1210
Rated current
A
5.4
Heating
COP
W/W
2.9
Moisture Removal
L/h
1.1
1.1
Max. input consumption
W
1760
1680
Max. current
A
9.1
8.5
Starting current
A
Plug type
Thermostat type
Mechanical control
Mechanical control
Model
PG225X2C-4FT
PG225X2C-4FT
Type
ROTARY
ROTARY
Brand
TOSHIBA
TOSHIBA
Capacity
Btu/h
13540
13540
Input
W
1290
1290
Rated current(RLA)
A
6
6
Locked rotor Amp(LRA)
A
Not Fixed
Not Fixed
Thermal protector
INTERNAL
INTERNAL
Capacitor
uF
35
35
Compressor
Refrigerant oil
ml
480
480
Refrigerant type
R407C/870g
R407C/900g
Design pressure
MPa
2.6
2.6
Model
YSK70-6C
YSK70-6C
Brand
Welling,Broad
Welling,Broad
Input
W
113/104/100
113/104/100
Capacitor
uF
2.5
2.5
Fan motor
Speed(hi/mi/lo)
r/min
900/800/700
900/800/700
a.Number of rows
3
3
b.Tube pitch(a)x row pitch(b)
mm
25.4X22
25.4X22
c.Fin spacing
mm
1.7
1.7
d.Fin type (code)
Hydrophilic aluminium
Hydrophilic aluminium
e.Tube outside dia.and type
mm
9.53x0.27, innergroove tube
9.53x0.27, innergroove tube
f.Coil length x height x width
mm
317X355.6X66
317X355.6X66
Evaporator
g.Number of circuits
2
2
Indoor air flow (Hi/Mi/Lo)
m3/h
550/500/450
550/500/450
Indoor noise level (Hi/Mi/Lo)
dB(A)
50/47/44
50/47/44

Service manual
7
a.Number of rows
3
3
b.Tube pitch(a)x row pitch(b)
mm
25.4X22
25.4X22
c.Fin spacing
mm
1.7
1.7
d.Fin type (code)
Hydrophilic aluminium
Hydrophilic aluminium
e.Tube outside dia.and type
mm
9.53x0.27, innergroove tube
9.53x0.27, innergroove tube
f.Coil length x height x width
mm
475X381X66
475X381X66
Condenser
g.Number of circuits
2
2
Outdoor air flow (Hi/Mi/Lo) m3/h
m3/h
850/780/700
850/780/700
Outdoor noise level (Hi/Mi/Lo) dB(A)
dB(A)
58/55/52
58/55/52
Dimension (W*H*D)
mm
560×400×650
560×400×650
Packing (W*H*D)
mm
620×445×770
620×445×770
Net/Gross weight
Kg
48/53
54/59
Operation temp
℃
16 31
16 31
Ambient temp
℃
17 ~43
-10 ~43
Application area
m2
18-26
18-26
Qty’per 20’& 40’HQ Fcl
Pieces
133/340
133/340

Service manual
8
Model
Y9USC-18 B5R
Y9USE-18 B5R
Factory Model
CE-KC46/E1N2
CE-KCR46/E1N2
Power supply
Ph-V-Hz
1Ph , 220-240V~, 50Hz
1Ph , 220-240V~, 50Hz
Capacity
Btu/h
18000
18000
Input
W
2100
2100
Rated current
A
9.3
9.3
Cooling
EER
Btu/w.h W/W
8.6,2.5
8.6,2.5
Capacity
Btu/h
18000
Input
W
2000
Rated current
A
9.6
Heating
COP
W/W
2.7
Moisture Removal
L/h
2.0
2.0
Max. input consumption
W
3020
3020
Max. current
A
15.8
15.8
Starting current
A
Plug type
Thermostat type
Mechanical control
Mechanical control
Model
PG290X2C-4FT1
PG290X2C-4FT1
Type
ROTARY
ROTARY
Brand
TOSHIBA
TOSHIBA
Capacity
Btu/h
17700
17700
Input
W
1700
1700
Rated current(RLA)
A
8.2
8.2
Locked rotor Amp(LRA)
A
Not Fixed
Not Fixed
Thermal protector
UP3QE0391-T39
UP3QE0391-T39
Capacitor
uF
35
35
Compressor
Refrigerant oil
ml
520
520
Refrigerant type
R407C/870g
R407C/1150g
Design pressure
MPa
2.6
2.6
Model
YSK93-6C
YSK93-6C
Brand
Welling,Broad
Welling,Broad
Input
W
143/130/120
143/130/120
Capacitor
uF
4
4
Fan motor
Speed(hi/mi/lo)
r/min
900/800/700
900/800/700
a.Number of rows
2
2
b.Tube pitch(a)x row pitch(b)
mm
25.4*22
25.4x22
c.Fin spacing
mm
1.3
1.5
d.Fin type (code)
Hydrophilic aluminium
Hydrophilic aluminium
e.Tube outside dia.and type
mm
Ф9.53x0.27, innergroove tube
Ф9.53x0.27, innergroove tube
f.Coil length x height x width
mm
365x381x44
365x381x44
Evaporator
g.Number of circuits
2
2
Indoor air flow (Hi/Mi/Lo)
m3/h
660/610/560
660/610/560
Indoor noise level (Hi/Mi/Lo)
dB(A)
52/49/46
52/49/46

Service manual
9
a.Number of rows
2
3
b.Tube pitch(a)x row pitch(b)
mm
25.4x22
25.4x22
c.Fin spacing
mm
1.4
1.7
d.Fin type (code)
Hydrophilic aluminium
Hydrophilic aluminium
e.Tube outside dia.and type
mm
Ф9.53x0.27, innergroove tube
Ф9.53x0.27, innergroove tube
f.Coil length x height x width
mm
560x406x44
560x406x66
Condenser
g.Number of circuits
2
2
Outdoor air flow (Hi/Mi/Lo) m3/h
m3/h
1200/1100/1000
1200/1100/1000
Outdoor noise level (Hi/Mi/Lo) dB(A)
dB(A)
60/57/54
60/57/54
Dimension (W*H*D)
mm
660×435×640
660×435×640
Packing (W*H*D)
mm
750×520×740
750×520×740
Net/Gross weight
Kg
55/60
59/64
Operation temp
℃
16 31
16 31
Ambient temp
℃
17 ~ 43
-10 ~ 45
Application area
m2
30-40
30-40
Qty’per 20’& 40’HQ Fcl
Pieces
94/240
94/240
Note:
The noise date is base on hemi-anechoic chamber, during actual operation; these values are normally somewhat different as a result of
ambient condition.
The above design and specifications are subject to change without prior notice for product improvement.

Service manual
10
2 INSTALLATION
2.1 SELECT THE BEST LOCATION
1. To avoid vibration and noise, make sure the unit is installed securely and firml.
2. Install the unit where the sunlight does not shine directly on the unit. If the unit receives
direct sunlight, build an awning to shade the cabinet.
3. There should be no obstacle, such as a fence or wall, within 50cm from the back of the
ambient because it will prevent heat radiation of the condenser.
4. Restriction of outside air will greatly reduce the cooling and heating efficiency of the air
conditioner.
5. Install the unit on a slight angle so that an condensate formed will not enter the room
(about 10mm or 1/4 bubble with level).
6. Install the unit with its bottom portion 75~150cm above the floor level.
7. The power cord must be connected to an independent circuit. The yellow/green wire must
be grounded.
2.2 CHECK OFF INSTALLATION
The setting conditions must be checked prior to initial starting. The under mentioned items are especially important checking points when the installation
is finished.
Grounding wire (yellow/Green) is provided in the power cord. The wire must be grounded.
Ensure that the unit is connected to a suitably rated and dedicated circuit.
To avoid vibration or noise, make sure the air conditioner is installed securely.
Avoid placing furniture of draperies in front of the air inlet and outlet.

Service manual
11
2.3 HOW TO DRAIN
The base pan ma overflow due to high humidity. To drain the excess water, remove the drain cap from the bottom of the unit (if fitted) and attach a drain
hose (not supplied).
1. Take the drain pan which is packed with the unit.
2. Remove the rubber plug from the bottom of the base pan (if fitted).
3. Install the drain pan over the area of the cabinet where you removed the plug, and secure with 2 screws provided.
4. Connect the drain hose to the outlet located at the bottom of the drain pan. You can purchase the drain hose or tubing locally to satisfy our particular
needs (Drain hose is not supplied).
2.4. HOW TO INSTALL
2.4.1 INSTALLATION OF THE HOUSING
Step1
Remove the air conditioner from it's packaging, remove fixing screws and slide the air conditioner out of it's housing (refer to installation steps)
Step2
Prepare the hole in the wall so that the bottom of the housing is well supported, the top has minimum clearance and the air inlet louvers have clearance
as shown below in options a and b. Holes from the outside through to the cavity should be sealed. The housing should slope down towards the rear b
about 5mm to allow water formed during operation to drain.
Step3
Install the housing into the wall and secure. Ensure the foam seals are not damaged. Flash, seal or fill gaps around the inside and outside to provide
satisfactory appearance and protection against the weather, insects and rodents.

Service manual
12
2.4.2 INSTALLATION OF THE UNIT INTO THE HOUSING
Slide the unit into the housing until it is firmly against the rear of the housing. Care is required to ensure the foam sealing strips on the housing remain in
position.
Connect the air conditioner to the power and position excess cord length
beneath the air conditioner base.
Engage the chassis fixing brackets into the bottom housing rail and
secure to the base with the screw provided.
Remove the front panel from it's carton and plastic bag and fit as per the
installation instruction.
Switch unit on. Check for operation of the unit and check for vibration in
the installation.
Fit the drain pan to the housing and run a drain line to a suitable location
if required.
2.4.3 INSTALLATION OF THE UNIT INTO THE WALL
2.4.4 INSTALLATION STEPS
Step 1. Remove the front panel and the air filter
Hold the slot under the front panel, then uplift it outwards, and remove the front panel (See Fig.1).
Pinch the handle under the air filter and make the air filter arched, remove it from the slot from
underside to upside (See Fig.2).
Step 2. Remove the frame.
Remove the two fixing screws from the frame (See Fig.3).
Grasp the left corner of the frame's underside, then loosen the frame (See Fig.4).
Step 3. Installation.
Remove the two fixing screws on the chassis fixing brackets, then remove the chassis fixing brackets
(See Fig.5).
Grasp the handle on the chassis and carefully slide the air conditioner out of the cabinet (See Fig.6).
Remove shipping pad from around compressor before operation and make sure the discharge points
to the drain pan are aligned before the chassis is pushed into the cabinet (See Fig.7).
Push the unit chassis into the cabinet (See Fig.8).
Install the two chassis fixing brackets using the two fixing screws (See Fig.5).
Step 4. Install the frame.
Install the frame making sure not to interfere with the temperature sensor cable (See Fig.9).
Fix the screws on the frame (See Fig.3).
Step 5. Install the air filter and front panel.
Install the air filter into the frame's slot from upside to underside (See Fig.2).
Hang the front panel on the frame's buckle, then press the front panel into the frame's slot until you hear a click (See Fig10).

Service manual
13
3 REFRIGERANT CYCLE DIAGRAM
The figure below is a brief description of the important components and their function in what is called the refrigeration system.
This will help to understand the refrigeration cycle and the flow of the refrigerant in the cooling cycle.

Service manual
14
4 OPERATION LIMITS
4.1 COOLING OPERATION
Outdoor unit air temp.ºC DB
Indoor air temp. ºC DB
Note: The chart is the result from the continuous operation under constant air temperature conditions. However, excludes the initial pull-down stage.
4.2 HEATING OPERATION
Indoor air temp. ºC DB
Outdoor unit air temp.ºC DB
Note: The chart is the result from the continuous operation under constant air temperature conditions. However, excludes the initial pull-down stage.

Service manual
15
5 SCHEMATIC DIAGRAM AND WIRING DIAGRAM
Y9USC-09 B5R:
Y9USE-09 B5R:

Service manual
16
Y9USC-12 B5R Y9USC-18 B5R:
Y9USE-12 B5R Y9USE-18 B5R:

Service manual
17
6. TROUBLESHOOTING
In general, possible trouble is classified in three kinds. One is called Starting Failure which is caused from an electrical defect, another is ineffective Air
Conditioning caused b a defect in the refrigeration circuit and improper application, and the other is called the Structure Damage.
ROOM AIRCONDITIONER
VOLTAGE LIMITS:
PROBLEM
POSSIBLE CAUSE
REMED
No power
Check voltage at electrical outlet. Correct if none.
Power supply cord
Check voltage at the power cord terminal. Replace the power cord if none.
Wire disconnected or connection
loose
Connect wire. Refer to wiring diagram for terminal identification. Repair or replace
loose terminal.
Main switch failure
Check and replace the main switch if failure.
Capacitor (Discharge capacitor
before testing)
Test capacitor.
Replace if not within +/-10% of manufacture's rating. Replace if shorted, open or
damaged.
Fan motor will not run.
Will not rotate
Fan blade hitting shroud or blower hitting scroll. Realign assembly.
Check fan motor bearings. Replace the motor if motor shaft do not rotate.
Check voltage. Call an electrician if not within limits.
Test capacitor.
Replace if not within +/-10% of manufacture's rating.
Check bearings. Replace the motor if the fan blade cannot rotate freely.
Fan motor runs
intermittently
Cycles on overload.
Pay attention to any change from high speed to low speed. Replace the motor if the
speed does not change.
Fan
Replace the fan if cracked, out of balance, or partially missing.
Blower
Replace the blower if cracked, out of balance, or partially missing.
Loose screws
Tighten them.
Fan motor noise.
Worn bearings
Replace the motor if knocking sounds continue when running or loose, or the motor
hums or noise appears to be internal while running.
NAMEPLATE RATING
MINIMUM
MAXIMUM
220~240V
196V
253V

Service manual
18
The compressor not to
stop even the room
temp. has got to the
setting temperature.
Thermostat
Check and replace if the thermostat is damaged.
Air filter
Clean or replace if restricted.
Vent. door
Close if open.
Unit undersized
Determine if the unit is properly sized for the area to be cooled or heated.
Condenser and Evaporator
Clean or replace if restricted.
Fan motor
Check the fan capacitor and replace if not within +/-10% of manufactures rating.
Room structure
Take proper measures to make the door and windows sealed well if gap is found.
Air flow
Clean or remove if any barrier is found to block the inlet/outlet wind flow of the unit.
Sunlight
Add a awning if the condenser is exposed to the sunlight.
Less refrigerant
Check the tubes for reasons of leakage. Recycle the refrigerant, correct the leakage
points and recharge.
Capillary tube
Regulate the flow if capillary tube and make the evaporating temperature
appropriate if the evaporator is frosted. Replace if blocked. Repair joint if leaking.
Compressor
The inlet and outlet valve of the compressor is damaged, making the low pressure
connected with the high pressure. The refrigerating system can not produce high
pressure and low pressure. Replace the compressor after checking for the reason.
Heat sources
Reduce if too many.
reverse valve
The seal in valve is damaged, making the low pressure connected with the high
pressure. The refrigerating system can not produce high pressure and low pressure.
Replace the reverse valve after checking for the reason.
Insufficient cooling or
heating.
Drainage
The drainage is blocked. It will increase the efficiency in cooling mode, but will cause
the condenser to frost in heating mode.
Refrigerant
The amount of the refrigerant is too much, making the compressor load too big.
Recycle and recharge the refrigerant after checking for the reason.
Stop instantly after
startup.
Compressor
The compressor is seized. Replace after checking for the reason.
No power
Check the voltage. Call an electrician if no within the limit.
Wiring
Check the terminals. Repair and correct if loose.
Temperature setting
Check and adjust the thermostat.
Main switch setting
Check and adjust the main switch setting.
Reverse valve wire
Check the resistance of reverse valve wire. Replace the wire if short, open or
damaged.
No cooling or heating.
Reverse valve
If the reverse valve is blocked, the heating mode will not perform. Replace the
reverse valve after checking the reason.

Service manual
19
Voltage
Check voltage. Call Supply Authority if not within limits.
Wiring
Check the wire connections, if loose, repair or replace the terminal. If wires are off,
refer to wiring diagram for identification, and replace. Check wire locations. If not per
wiring diagram, correct.
Main switch failure
Check and replace the main switch if failure.
Capacitor (Discharge capacitor
before testing)
Check the capacitor.
Replace if not within +/-10% of manufacturers rating. Replace if shorted, open, or
damaged.
Thermostat
Check the thermostat setting if not at the coolest (in cooling mode) or the warmest
(in heating mode). Set it if not.
Compressor will not run
while fan motor runs.
Compressor
Check the compressor for open circuit or ground. If open or grounded, replace the
compressor.
Excessive noise.
Copper tubing
Remove the cabinet and carefully rearrange tubing not to contact cabinet,
compressor, shroud and barrier.
Power supply
The input power supply voltage is too low. Call an electrician if not within limits.
The unit starts and stops
frequently.
Outdoor temperature
When the outdoor temperature is too high, the compressor will protect.
