Elite LED Rechargeable
Slimline Torch
York Survey Supply Centre
Follow us!
@York_Survey
@York_Survey
Code: 53221

©York Survey Supply Centre 2021Ref:.. \operat98\instructions 21\53221.qxp 04-01-21
Elite LED Rechargeable
Slimline Torch
This versatile pocket inspection torch utilises the
latest technology in portable lighting, allowing an
extremely bright light to be encased in a
lightweight and slimline compact unit.
The powerful 200 lumen C B LED features
three light settings:
• White light - solid dimmable
• ®ed light - solid
• Red light - solid
A strong magnet in the base enables the torch to
be fixed to metalwork. The cleverly designed
pocket clip allows for the torch to be attached to
clothing or a belt. A recess on the rear enables
fixing to a substrate via a screw.
An ideal companion for use in all trades and
around the home or car. The compact design
makes it an ideal leisure torch offering minimal
storage space and weight.
Specifications
Battery Recharging
The torch must be fully charged for a minimum
of 2 hours before being used for the first time,
this will ensure that the battery gives its best
performance now and on future recharging
cycles.
The charging cable is for recharging the battery
only. It cannot be used to directly power the light.
Failure to recharge the light every 3 months may
permanently damage or reduce the performance
of the light.
The battery charge does not have to be fully
depleted before recharging.
Using the Charging Lead
Plug the USB charger lead into the micro USB
charging socket on the side of the torch. Plug the
other end of the lead into any USB charging
outlet
While on charge the small charging indicator
lamp will glow red and will turn blue when the
battery is fully charged (approximately 2 hours).
Please note the following
1) For the best performance Li-Ion batteries
should not be stored for prolonged periods
without being charged at regular intervals.
2) Manufacturers recommend keeping the
battery in a state-of-charge of 40 - 50% when
placing in storage. If in doubt, keep the light in a
higher charged state in a cool place.
3) Self-discharge rate is approximately 10%
per month.
Operating Instructions
The inspection light output functions are
controlled by a sequential switch on the front of
the light.
Press and release the button to turn on the
white light.
Press and release the button again to turn on
the red light.
Press and release button again to change to
flashing red light.
Alternatively, press and hold the button for two
seconds to turn on red light, skipping the white
light stage.
The white light has a dimmable function:
With the white light turned on, press and hold
the button down to increase or decrease
brightness. The light will flash to indicate when
it has reached the highest or lowest level.
Release the button when the desired light
output is reached.
Under optimum conditions, with a full charge, the
light can normally be used for 1.5 hours.
To achieve the best performance from your
LED Mini Slimline Torch, always switch the light
off when the battery power begins to run low, and
recharge immediately.
Cleaning
Clean the light using a soft cloth, dampened with
a soap and water solution.
Do not immerse or submerge the light in water
or any other fluid.
Maintenance
There are no serviceable parts inside this
light. pening or visible attempts to repair the
light will void any guarantee.
LED bulbs should not wear out under normal
conditions and do not need to be replaced.
Never attempt to open a battery, as
liquid may be e ected, if accidental
contact occurs flush the affected area
with water. If the liquid comes into
contact with the eyes flush with water
and seek medical help. Liquid e ected
from batteries may cause irritation or
burns.
Li-ion batteries are formulated from
environmentally sensitive materials and
must be disposed of properly.
Please return these batteries to your local
recycling centre where they will be
•
•
•
•
•
recycled or disposed of properly.
Never attempt to incinerate batteries as
they may leak or explode.
One-Year Home Use Limited Guarantee
Lighthouse guarantees this product to the
original purchaser for a period of NE YEAR
against any defects in material or workmanship
but shall not cover damage caused by misuse,
abuse, alteration or accident. This product is
intended for home use only and the guarantee
will not cover products used for commercial
purposes.
Brightness 200 lumens
Beam distance 30 metres
Run time 1.5 hours
Light source C B LED
Battery 3.7V Polymer Li-ion
500mAh
Charge time approx 2 hours
Impact resistant 1 metre
Water resistant IP64
Weight 37g
Dimensions 123 x 25 x 12mm
Supplied with USB Charging Lead
