NOTE: The M8 Bolt Cover (LL), M6 Bolt Cover (MM), M8 PLASTIC Cap (NN),
M6 PLASTIC Cap (OO) in step 1 to 8 are only for reference. Please attach
them to bolts in step 9.
Vendor stock No.: GCS00283D
TUSCANY 2PERSON PATIO SWING

PART
NO. PICTURE DESCPRITION QTY
AA M8x105 Bolt 6
BB M8x70 Bolt 4
CC M8x20 Bolt 2
DD M6x50 Bolt 2
EE M6x40 Bolt 8
FF M6x30 Bolt 2
GG M6x20 Bolt 6
HH M8 Nut 6
II M6 Nut 2
JJ M8 Washer 18
KK M6 Washer 18
LL M8 Bolt Cover 6
MM M6 Bolt Cover 2
NN M8 Plastic Cap 12
OO M6 Plastic Cap 16
PP Hook 2
QQ Allen Wrench 1
RR Wrench 1
NOTE: The M8 Bolt Cover (LL), M6 Bolt Cover (MM), M8 PLASTIC Cap (NN),
M6 PLASTIC Cap (OO) in step 1 to 8 are only for reference. Please attach
them to bolts in step 9.
Vendor stock No.: GCS00283D
TUSCANY 2PERSON PATIO SWING

5
NOTE: The M8 Bolt Cover (LL), M6 Bolt Cover (MM), M8 PLASTIC Cap (NN),
M6 PLASTIC Cap (OO) in step 1 to 8 are only for reference. Please attach
them to bolts in step 9.
PART
NO. PICTURE DESCPRITION QTY
A Top Bar 1
B Leg 4
C Short Connector 2
D Leg Connector 2
E Seat 1
F Back 1
G Right Arm 1
H Left Arm 1
I 2
J 2
K Top Straight Bar 1
L Top Curved Bar 2
M Canopy 1
N Knob 2
Vendor stock No.: GCS00283D
TUSCANY 2PERSON PATIO SWING
Short Hanging Bar
Long Hanging Bar

6
NOTE: The M8 Bolt Cover (LL), M6 Bolt Cover (MM), M8 PLASTIC Cap (NN),
M6 PLASTIC Cap (OO) in step 1 to 8 are only for reference. Please attach
them to bolts in step 9.
Vendor stock No.: GCS00283D
TUSCANY 2PERSON PATIO SWING
Step 1:
- Attach the Top Bar (A) to the Leg (B).
- Connect with M8 x 105 Bolt (AA), the M8 Washer (JJ) and
the M8 Nut (HH) as shown in the picture.
- Loosely tighten by hand.
Step 2:
- Attach the Short Connector (C) to the Top Bar (A).
- Connect with M8 x 70 Bolt (BB), the M8 Washer (JJ) as shown
in the picture.
- Loosely tighten by hand.
- Attach the Short Connector (C) to the Leg (B).
- Connect with M8 x 105 Bolt (AA), the M8 Washer (JJ) and
the M8 Nut (HH) as shown in the picture.
- Loosely tighten by hand.

7
NOTE: The M8 Bolt Cover (LL), M6 Bolt Cover (MM), M8 PLASTIC Cap (NN),
M6 PLASTIC Cap (OO) in step 1 to 8 are only for reference. Please attach
them to bolts in step 9.
Vendor stock No.: GCS00283D
TUSCANY 2PERSON PATIO SWING
Step 3:
- Attach the Leg Connector (D) to the Leg (B).
- Connect with M6 x 40 Bolt (EE), the M6 Washer (KK)
as shown in the picture.
- Tighten all the bolts from step 1 to step 3 with
Allen Wrench(QQ) and Wrench (RR).
Step 4:
- Attach the Seat (F) and Back (E) at right angle as shown
in the picture.
- Connect with M6 x 50 Bolt (DD),
the M6 Washer (KK) as shown in the picture.

8
NOTE: The M8 Bolt Cover (LL), M6 Bolt Cover (MM), M8 PLASTIC Cap (NN),
M6 PLASTIC Cap (OO) in step 1 to 8 are only for reference. Please attach
them to bolts in step 9.
Vendor stock No.: GCS00283D
TUSCANY 2PERSON PATIO SWING
Step 6:
- Attach the Short Hanging Bar (I) & Long Hanging
Bar (J) to Right Arm (G) and Left Arm (H)
With M6 x 20 Bolt (GG) and M6 Washer (KK)
as shown in the picture.
- Bring the holes in the free ends of
Short Hanging Bar (I) & Long Hanging Bar (J)
together and thread them onto the Hook (PP).
- Tighten all the bolts with Allen Wrench (QQ)
and Wrench (RR).
Step 5:
- Attach the Right Arm (G) and Left Arm (H)
to the Back (F).
- Connect with M6 x 20 Bolt (GG),
the M6 Washer (KK) as shown in the picture.
- Tighten all the bolts from step 4 to step 5
with Allen Wrench (QQ) and Wrench (RR).

9
NOTE: The M8 Bolt Cover (LL), M6 Bolt Cover (MM), M8 PLASTIC Cap (NN),
M6 PLASTIC Cap (OO) in step 1 to 8 are only for reference. Please attach
them to bolts in step 9.
Vendor stock No.: GCS00283D
TUSCANY 2PERSON PATIO SWING
Step 7:
- Hang the Hook (PP) in the holes on the Short Connector (C).
Step 8:
- Attach the Top Straight Bar (K) to the Top Curved Bars (L)
with M6 x 30 Bolt (FF) and M6 Washer (KK) and
the M6 Nut (II) as shown in the picture.
- Loosely tighten by hand first, then completely tighten
with Allen Wrench (QQ).
- Place the Canopy (M) to the assembled top frame and
tie the Canopy (M) to the Top Curved Bar (L) by affixing
the velcro.

10
NOTE: The M8 Bolt Cover (LL), M6 Bolt Cover (MM), M8 PLASTIC Cap (NN),
M6 PLASTIC Cap (OO) in step 1 to 8 are only for reference. Please attach
them to bolts in step 9.
Vendor stock No.: GCS00283D
TUSCANY 2PERSON PATIO SWING
Step 9:
- Attach the assembled canopy on both sides to the Top Bar (A).
- Insert the Knob (N), turning the Knob (N) clockwise tightly.
- Ensure all connections are secure before use.
- Attach the M8 Bolt Cover (LL), M6 Bolt Cover (MM), M8 Plastic Cap (NN) and
M6 Plastic Cap (OO) to all the bolts as shown in previous steps.
