YOTRIO Target Latigo GCS09061E User manual

Latigo
Hanging Egg Chair
style # GCS09061E
dpci # 009000255
>>assembly instructions TM

Congratulations on your latest Target purchase.
Now what? Don't start sweating over this box of parts. This will be easy. We did the hard work for you.
All you need to do is follow our simple instructions and you'll be on your way to transforming your patio in no time.
Good luck – though we're confident you won't need it.
ATTENTION:
This Chair is not intended for use during any kind of inclement weather and the manufacturer is not,
and can not beheld responsible for any damages caused as a result of such weather. Weather-related
damage, or damage as a result of the Chair not being stored properly when not in use, is not the
responsibility of the manufacturer.
During extended periods of non-usage, off season, or in inclement weather (wind, rain, snow, hail,
sleet), freezing conditions and extreme heat, the Chair needs to be stored in a dry, sheltered place to
prolong the life and to avoid damage to the Chair.
2
IMPORTANT WARNING:
Unpack the box on a clean, soft, level surface and make sure all parts have been included.
To replace missing or damaged parts please call 855-MYTGTHOME (855-698-4846) during 7am - 7pm CST M-F, and 8am - 5pm CST Saturday.
WEIGHT LIMIT 250 LBS MAXIMUM.
Chair is intended to be used by one person at a time.
Chair and stand must be used with all provided parts. Ensure that all parts are
installed according to instructions and inspected for damage before use.
Ensure that all bolts and hardware are securely tightened and installed before use.
Always inspect your chair, hardware, and stand for damage before use.
Never place infants or pets in the chair.
Never allow young children to use chair without adult supervision.
Do not jump, stand, or twist in chair.
Chair and stand are designed for minimal swing motion. Use care when getting in and
out of chair. If using stand, ensure that chair is facing forward and do not cause chair
to swing outside base area of stand.
Stand must be used with attached safety rope, included with product.
Do not climb on support pole.
Use on even-flat surfaces only.
This hanging egg chair is not a toy.
.
WARNING-TO AVOID RISK OF FALLING

WARRANTY:
This Chair comes with a one year limited warranty against original manufacture defects. If you experience
trouble with your chair, please call the customer service number below.
3
Target Corporation
Toll Free at: 855-MYTGTHOME (855-698-4846) during 7am - 7pm CST M-F, and 8am - 5pm CST Saturday.
Code: Yotrio 2020
before you begin
1. Check for damage or missing parts. Call to order missing supplies.
2. Use the carton as a working surface to prevent product damage during assembly.
3. Gather all tools prior to assembly.
855-MYTGTHOME (855-698-4846)

table of contents
intruction
hardware
parts list
assembly
2-3
5
6
7-11
QUESTIONS?
4Please call 855-MYTGTHOME (855-698-4846) parts and service. For faster service, have th e style number and DPCI number ready when calling.

hardware
5
(Part G)×4
M6 *50 bolt with washer
(Part O)×1
wrench
(Part N)×1
allen wrench
(Part H)×2
M8 *55 bolt with washer
(Part I)×1
M8 *60 bolt with washer
(Part F)×1
hook
(Part K)×4
M6 nut
(Part J)×4
M6 washer
(Part L)×3
M8 washer
(Part M)×3
M8 nut
(Part P)×2
plastic muffler
(Part Q)×1
plastic connection ring

ITEM DESCRIPTION QUANTITY
1
A
6
base
B upper hanging bar 1
1
Clower hanging bar
1
Dback frame
1
Eseat frame
1
Fhook
2
Pplastic mulffer
B
C
D
A
F
Q
P
P
E

7
step 01:
ATTENTION: To avoid damage to your new patio furniture, please
use either the carton or another soft surface such as carpet as a
working surface to prevent product damage during assembly.
1. Put plastic connection ring (Q) on lower hanging bar (C), and Insert lower hanging bar (C)
into the base(A).Secure with M8*60 bolt with washer (I) M8 washer (L), M8 nut (M).
2.
2. B
C
A
I
L
L
M
I
1.
(Part H)×2
M8 *55 bolt with washer
(Part L)×3
M8 washer
(Part M)×3
M8 nut
(Part O)×1
wrench
(Part N)×1
allen wrench
Insert upper hanging bar (B) into the lower hanging bar (C).Secure
allen wrench (N) and wrench (O).
with M8*55 bolt with washer (H) M8 washer (L), M8 nut (M).tighten using
Do not completely tighten screws until all screws are started.
Q
C
H
M

8
step 02:
1. Attach the back frame (D) to the seat frame (E) by lining up screw holes
on the back frame (D) with corresponding screw holes on the seat frame (E).
2. Secure with M6*50 bolt with washer (G), M6 washer (J) and M6 nut (K).
tighten using allen wrench (N) and wrench (O).
(Part G)×4
M6 *50 bolt with washer
(Part J)×4
M6 washer
(Part K)×4
M6 nut
(Part N)×1
allen wrench 4X
G
J
K
D
E
Do not completely tighten screws until all screws are started.

step 03:
1. Put plastic muffler (P) on the bar loop on upper hanging bar (B) and back frame (B).
(Part P)×2
plastic muffler
B
P
PP
P
9
1. 2.
3. 4.
Do not completely tighten screws until all screws are started.
D
E

10
step 04:
2. Hang the back frame (D) and seat frame (E) on the hook (F).fully tighten the hook
(F) as shown on the diagram in circle 3 at the top.
1. Follow the diagram in circle1 at the top to open the hook (F),hang the hook(F)
on the upper hanging bar (B).
(Part F)×1
hook
F
B
F
D
E
2.
1.
3.

step 05:
C
1. 2.
3. 4.
1. Open the hook of safety rope on the seat frame (E), pass through the iron loop on
the lower hanging bar (C). Then tighten the hook of safety rope.
11

step 06:
12
1. T ighten all the bolts.
2. Put the cushion on the chair.
You are now ready to enjoy your new chair.
