Your Finder Small Track User manual


Small Track
Life Safety Device
User Manual



Find us also on Google Play and Apple Store.
Search "your-finder ".

Accessories
Small Track device.
USB cable.
Wall Charger.
User Manual.
Small Track device and its enclosed accessories arrived to you after severe
laboratory examination and found working. For any clarification, question,
problem, error or comment, don't hesitate to contact us at:
Customer Service: [phone]
Email: [e-mail]
Website: http://www.your-finder.co.il
The device has CE and RoHs certifications
2


your-finder | All Rights Reserved ©
Do not distribute this manual or copy it with any electronic or mechanical way
1. Product Overview
1.1 Overall description
Congratulations! You are now holding Small Track device. A round shaped device
that can be used as a necklace, keychain or in your personal belonging.
Small Track is a smart tracking device that includes the basic functions of calling,
GPS tracking, monitoring, and Emergency supervision. It can also send the location
information to mobiles and computers quickly from your-finder Application.
Small Track lets you stay close to your relatives that are not capable of using regular
mobile phone, and also track them in case of need.
Small Track is intended to Kids, Adults,Alzheimer disease patients, blind people and
travelers around the world.
All of the controlling options in the device are handled by sending SMS from a
regular mobile phone or from "your-finder " application.
1.2 Small Track Features
Incoming and outgoing phone calls.
GPS tracking.
Online platform for tracking
(GPRS).
Fall Down detection alarm using the
accelerometer sensor.
Monitor for surrounding
supervision.
SOS emergency button.
Motion and movement alarm.
Doze mode and Deep sleep mode.
Low battery alarm by SMS.
No need for special installation.
2. Technical Specification
Name Parameters
Product name Small Track version 1.0
3


Charging voltage 5V-DC
Weight (include battery) 35g
Operating Temperature -20C ~ +70C
Working frequency Sensitivity GSM 850/900/1800/1900 MHz, 2G
Battery capacity 900mAh
GPS device Ublox-7
3. First Time Instructions
Before first use, please read the following instructions:
Charge the device at least 4 hours first charge.
Small Track is NOT waterproof (unless you bought waterproof version), and
you shall not use it in water.
Do not use any detergent to clean the device or the charger. Use only dry rag.
Do not try to replace the internal battery, contact customer support.
Do not expose the device to high temperature, fire, dust, sand or humidity.
Use Small Track only with the power supply we supplied for you.
Do not try to fix the device or the power supply by yourself. Any damage to the
power supply's wires could cause electrocution.
In any case of failure please contact our support team.
Before using Small Track, you must purchase SIM card from your favorite
mobile carrier that supports 2 GSM network and buy talk and text plan. If you
would like to be able to track the device position using the GPRS online
platform, you should also purchase Data plan.
Keep your SIM card mobile phone number that you received from the carrier.
You should use micro SIM card.
Make sure your SIM card is not password protected and there is no PIN code.
Make sure the Caller ID feature is not blocked.
With Small Track you can set up to three owners / admin phone numbers.
Only those numbers can control the device's features.
4


4. Introduction
4.1 Key Description
4.2 Button and LED information
GSM LED – Green LED
The device is connected to GSM networkFast flashing and stop for three seconds The device is connected to online trackingTwo Fast flashing and stop for three seconds The device is not connected to GSM networkSlow Flashing and stop for three seconds No SIM cardSolid LED The device is in deep sleep modeLED is off
GPS LED – Blue LED
The device is connected to GPS satellitesFast flashing and stop for three seconds The device is not connected to GSP satellitesSlow flashing and stop for three seconds The device is in deep sleep or doze modeLED is off
Power / Motion Led – Red LED
The device is chargingSolid LED Motion sensor detects movementFlashing LED There is no movementLED is off Low battery (15%) – you must charge the deviceFast flashing The device is in deep sleep modeFlashing every five seconds
Buttons
Press three seconds to turn off or onPower button Press four seconds to send SOS alertSOS Button
5


Press four seconds to initiate a phone callCall Button

5. Instructions – Step by Step.
Download our unique application "your-finder " in order to control the device. You
can also control the device with the instructions below:
5.1 SIM card installation
Please insert the Micro SIM card to the slot. The metal side of the SIM card should
be up and the sliced side should be pointed right as the picture below.
Afterwards, press the power button (three seconds) to turn on the device.
5.2 Set Admin numbers for SOS button
Pressing the SOS button will send SMS alert to the pre-set numbers.
Pressing the call button dials the first number you set.
In order to set the three dialing numbers, send SMS to the device with the following
syntax:
3Number,2Number,1Number,1
5.3 Getting GPS position link
The Small Track device has a built in GPS chip that can track anywhere.
Sending SMS to the device will reply address, map, street view and navigation
instructions. It might take up to 3 minutes to get the SMS back from the device.
6


SMS syntax: LOC (if you receive a reply "no GPS info", there is no GPS signal)
5.4 Incoming Call
When one of the admin numbers calls the device, it will ring and answer the call
automatically. You can speak with the person that has the device.
5.5 Monitor
Monitor enables you to listen to the device, incoming call from one of the admin
numbers will activate "monitor" feature. It will not have any ring and you will be able
to listen to the surrounding.
SMS syntax: L1 to cancel the monitor: L0
5.6 Doze Mode
Doze mode is activated automatically as default. In this mode, after three minutes
without movement, the device will turn off the GPS, and keep the GSM on – cellular
on. In doze mode you can call the device normally. The GPS will turn back on if the
device is moving or SMS has been sent or phone call received.
In this mode, the battery can last approximately 7 days.
SMS syntax: PS1 to cancel the doze mode: PS0
5.7 Deep Sleep Mode
In Deep Sleep mode, after three minutes without movement, the device will turn off
both GPS and GSM. In this mode, you can not call the device, send SMS or contact
with it in any way.
The device will turn GPS and GSM back on only with movement of the device.
In this mode, the battery can last approximately 30 days.
SMS syntax: DS1 to cancel deep sleep: DS0
7


** Comment: if you turn on both deep sleep and doze mode, the device will work according to deep
sleep mode.
5.8 Fall Detection
Fall detection alert will notify when the device falls to the ground, and send SOS
alert to the admin numbers.
Moreover, the device will make a phone call to the first admin number. In order for
this alert to work, the device must be dropped on the floor.
SMS syntax: FL1 to cancel fall detection: FL0
5.9 GPS Lost Alarm
GPS lost alarm will remember last known GPS coordinates, and if the device loses
the GPS signal (for at least 10 minutes), it will send SMS alert to the admin numbers
with last known location.
SMS syntax: GR1 to cancel GPS lost alarm: GR0
5.10 Movement Alert
Small Track device has motion sensor inside. With any motion to the device, it will
alert the admin numbers by SMS.
Moreover, the device will call the first admin number.
SMS syntax: V1,60S to cancel movement alert: V0
5.11 Shutdown LED
For any reason you may want, you can turn off all three LED of the device.
SMS syntax: LED1 turn LED back on: LED0
8


6. Safety instruction to use Small Track
Safety to use charger
Avoid any liquid or moisture.
Avoid extreme temperature – radiator, hot oven or the sun.
Keep away from candles, cigarettes and flames.
Avoid any nearby acid.
Plug the charger only to the voltage stated on the charger.
Never try to fix or replace the charger yourself in case of damage. Contact support.
The Charger is for internal use only.
Safety to use lithium battery
Keep the battery away from heat, sun, light and extreme temperature.
Do not try to replace the battery yourself in case of damage. Wrong exchange can
cause explosion.
Do not throw the battery to the garbage can. Put it in the recycle litter bin.
9


7.Warranty
Dear customer,
We want to thank you for choosing our product, and hope you will produce the best
of it. Product name: Small Track. Company name: your-finder.
Small Track warranty is valid for 1 year from the day you bought it. Including
the battery and the charger

Warranty Terms
1) During the warranty time, your-finder undertakes to fix any fault or error that will
be found on the device. Free of charge.
2) your-finder undertakes to use only real and genuine replacement parts.
3) your-finder undertakes to fix the device within 10 days from receiving the device.
Saturdays and holidays will not be counted.
4) After returning the device from the reparation, the device warranty will be covered
for the rest of the warranty time and will not be extended due to repairing time.
5) In case of need to replace the entire device, the broken device will be the property
of the manufacturer.
6) In case of need to replace the entire device, the customer knows that all the
information inside the device will be deleted and set to factory default.
7) your-finder undertakes to give the customer full detail of the fixing process and
replacement parts being used.
8) Fixing and repairing the device will be in your-finder 's offices. The expenses of
the delivery will be paid by the customer.
10


9) your-finder can refuse to provide a warranty in case of deliberate harm to the
device or if found any of the following cases:
- Depravation caused by using the device for any use it was not meant to be.
- Damage caused by fragile, accident, hit, stroke, fall down, pressure on the device,
destruction, negligence, carelessness, sand, dusk or fluid penetration.
- Force Majeure or any similar event caused after the device arrived to the
customer.
-Any attempt to fix the device by a non-certified on our behalf.
-Any water or fluid penetration. The device is not water resistant.
-Any occasion of lack of GPS or cellular coverage or by any wireless disruption.
Dear Customer, in order to improve the service provided to you please keep
this manual safe. This warranty is valid only with the original invoice.
11


12
Small Track
Life Safety Device




















More products from your-finder:
GPS watch –your-finder watch
Tracking device for home care
Tracking device for hikers
Tracking device for cars
Tracking device for motorbikes
http://www.your-finder.co.il
© All rights reserved • Headquarters: czheala tel aviv, Israel
• Office phone[phone] •
Email: support@your‐finder.co.il • Website: http://www.your‐finder.co.il
