Zimmer HRC-07 Series User manual

INSTALLATION AND
OPERATING
INSTRUCTIONS
3-jaw concentric gripper, electric
HRC-07 series
DDOC01015
THE KNOW-HOW FACTORY
www.zimmer-group.com

2
Parameter explanation (glossary)
Parameter Explanation
ActualPosition Value of the current position of the product [1/100mm]
BasePosition BasePosition is the outer jaw position. Depending on the gripper prole, this can also be a work
position.
ControlWord Activation of the product
Only one bit is permitted to be active in the word. The value "0" is also permitted.
DeviceMode Used to select gripping proles as well as the additional help modes in the product.
Diagnosis If an error occurs, outputs a diagnostic code that can be compared with the error list.
DIR Direction/24V cable connection - Depending on the product, this signal is used to move the
product.
Error Fault
GND Abbreviation for ground connection
GripForce Setting the gripping force
Offset Correction value
PositionTolerance Tolerance range for TeachPosition, BasePosition and WorkPosition
The value of the parameter acts in both directions.
ShiftPosition ShiftPosition is a switching position between pre-positioning and gripper movement.
StatusWord In its bits, returns the most important information about the status of the product to the control
system.
Teach/Adjust Programming/Adjusting
With this signal, depending on the gripper type, the current position of the gripper jaws can be
taught in as the new workpiece position.
Adjust is used to dene the reachable end positions of the gripper jaws.
TeachPosition Actual workpiece position
Traversing routine Dened procedure for movement of the gripper jaws
Travel path Path on which the gripper jaws travel.
WorkpieceNo Selection of the workpiece recipes stored in the product
WorkPosition Inner jaw position on the product
Depending on the application, this can also be the standby position.
INSTALLATION AND OPERATING INSTRUCTIONS: HRC-07
DDOC01015 / a EN / 2022-07-20
Zimmer GmbH • Im Salmenkopf 5 •  77866 Rheinau, Germany •  [phone] • www.zimmer-group.com

1 Supporting documents ............................................................................................................................................................... 5
1.1 Notices and graphics in the installation and operating instructions ...............................................................................................................................5
2 Safety notices............................................................................................................................................................................... 6
3 Proper use .................................................................................................................................................................................... 7
4 Personnel qualication................................................................................................................................................................ 7
5 Product description ..................................................................................................................................................................... 8
5.1 Possible applications...........................................................................................................................................................................................................8
5.2 Forces and torques..............................................................................................................................................................................................................8
5.3 Type plate .............................................................................................................................................................................................................................9
5.4 Use in applications ..............................................................................................................................................................................................................9
6 Functional description ............................................................................................................................................................... 10
6.1 LED status display .............................................................................................................................................................................................................11
6.2 Control ................................................................................................................................................................................................................................12
6.3 Veried conguration examples .......................................................................................................................................................................................12
6.4 Self-locking mechanism ....................................................................................................................................................................................................12
7 Technical data ............................................................................................................................................................................ 12
8 Accessories/scope of delivery ................................................................................................................................................. 13
9 Transportation/storage/preservation....................................................................................................................................... 13
10 Installation .................................................................................................................................................................................. 14
10.1 Installing the product.........................................................................................................................................................................................................15
10.2 Safe shutoff for products with IO-Link..............................................................................................................................................................................16
10.3 Installing the energy supply ..............................................................................................................................................................................................17
10.3.1 Mounting the pin assignment.............................................................................................................................................................................17
10.4 Static charge ......................................................................................................................................................................................................................18
10.5 Heat dissipation .................................................................................................................................................................................................................18
10.6 Installing accessories ........................................................................................................................................................................................................18
11 Commissioning ..........................................................................................................................................................................19
11.1 Process data .....................................................................................................................................................................................................................19
11.2 IODD Import .......................................................................................................................................................................................................................20
11.3 Handshake Data Transfer Method....................................................................................................................................................................................20
11.4 Parameters .........................................................................................................................................................................................................................21
11.4.1 ControlWord.........................................................................................................................................................................................................21
11.4.2 DeviceMode .........................................................................................................................................................................................................22
11.4.3 WorkpieceNo .......................................................................................................................................................................................................26
11.4.4 PositionTolerance ................................................................................................................................................................................................26
11.4.5 GripForce .............................................................................................................................................................................................................27
11.4.6 DriveVelocity ........................................................................................................................................................................................................27
11.4.7 BasePosition ........................................................................................................................................................................................................28
11.4.8 TeachPosition.......................................................................................................................................................................................................28
11.4.9 WorkPosition........................................................................................................................................................................................................28
11.4.10 StatusWord...........................................................................................................................................................................................................29
11.4.11 Diagnosis..............................................................................................................................................................................................................31
11.4.12 ActualPosition ......................................................................................................................................................................................................31
11.5 Minimum travel path..........................................................................................................................................................................................................32
11.6 Minimum startup path .......................................................................................................................................................................................................32
11.7 Easy Startup .......................................................................................................................................................................................................................32
11.8 Quickstart Basic Parameters ............................................................................................................................................................................................33
11.9 Starting the gripping movement.......................................................................................................................................................................................34
11.10 Repeated movements in the same direction...................................................................................................................................................................34
INSTALLATION AND OPERATING INSTRUCTIONS: HRC-07
DDOC01015 / a EN / 2022-07-20
Zimmer GmbH • Im Salmenkopf 5 •  77866 Rheinau, Germany •  [phone] • www.zimmer-group.com
Content
3

11.11 Recipe examples ...............................................................................................................................................................................................................35
11.11.1 Save recipe...........................................................................................................................................................................................................35
11.11.2 Loading a recipe..................................................................................................................................................................................................36
12 Operation....................................................................................................................................................................................37
12.1 Adjustable gripping force..................................................................................................................................................................................................37
12.2 Emergency release ............................................................................................................................................................................................................37
13 Gripping force charts................................................................................................................................................................. 37
14 Error diagnosis...........................................................................................................................................................................38
15 Status in LED display................................................................................................................................................................. 40
16 Table with acyclic data (ISDU) .................................................................................................................................................. 41
17 Maintenance............................................................................................................................................................................... 43
18 Decommissioning/disposal ...................................................................................................................................................... 43
19 RoHS declaration....................................................................................................................................................................... 44
20 REACH declaration.................................................................................................................................................................... 44
21 Declaration of Incorporation ..................................................................................................................................................... 45
22 Declaration of Conformity ......................................................................................................................................................... 46
INSTALLATION AND OPERATING INSTRUCTIONS: HRC-07
DDOC01015 / a EN / 2022-07-20
Zimmer GmbH • Im Salmenkopf 5 •  77866 Rheinau, Germany •  [phone] • www.zimmer-group.com
4

5
1 Supporting documents
NOTICE
Read through the installation and operating instructions before installing or working with the product.
The installation and operating instructions contain important notes for your personal safety. They must be read
and understood by all persons who work with or handle the product during any phase of the product lifetime.
The documents listed below are available for download on our website www.zimmer-group.com.
• Installation and operating instructions
• Catalogs, drawings, CAD data, performance data
• Information on accessories
• Technical data sheets
• General Terms and Conditions, including warranty information.
ÖOnly those documents currently available on the website are valid.
In these installation and operating instructions, "product" refers to the product designation on the title page!
1.1 Notices and graphics in the installation and operating instructions
DANGER
This notice warns of an imminent danger to the life and health of people. Ignoring these notices can lead to
serious injury or even death.
►You absolutely must comply with the described measures for avoiding these dangers!
ÖThe warning symbols are assigned according to the type of danger.
WARNING
This notice warns of a situation that is potentially hazardous to personal health. Ignoring these notices can cause
serious injury or damage to health.
►You absolutely must comply with the described measures for avoiding these dangers!
ÖThe warning symbols are assigned according to the type of danger.
CAUTION
This notice warns of a situation that is potentially hazardous for people or that may result in material or environ-
mental damage. Ignoring these notices may result in slight, temporary injuries or damage to the product or to the
environment.
►You absolutely must comply with the described measures for avoiding these dangers!
ÖThe warning symbols are assigned according to the type of danger.
NOTICE
General notices contain usage tips and valuable information, but no warnings of dangers to health.
INFORMATION
This category contains useful tips for handling the product e󹱺ciently. Failure to observe these tips will not result
in damage to the product. This information does not include any information relevant to health or workplace
safety.
INSTALLATION AND OPERATING INSTRUCTIONS: HRC-07
DDOC01015 / a EN / 2022-07-20
Zimmer GmbH • Im Salmenkopf 5 •  77866 Rheinau, Germany •  [phone] • www.zimmer-group.com

6
2 Safety notices
CAUTION
Risk of injury and material damage in case of non-compliance
Installation, commissioning, maintenance and repairs may only be performed by qualied specialists in
accordance with these installation and operating instructions.
The product is state-of-the-art.
It is tted to industrial machines and is used to hold, transport and store workpieces.
The following are examples of situations in which the product may cause a hazard:
• The product is not properly installed, used or maintained.
• The product is not used for its designated purpose.
• The locally applicable regulations, laws, directives or guidelines are not observed.
►The product may only be used in accordance with these installation and operating instructions and the
product's technical data. Any changes or additions to the intended use of the product, as well as modications
to the product, such as those in the following examples, require the written permission of the manufacturer:
• Use of the product under extreme conditions, such as aggressive uids or abrasive dusts
• Additional drilled holes or threads
ÖZimmer GmbH shall accept no liability for any damage caused by improper use. The operator bears sole
responsibility.
►Make sure that the power supply is disconnected before you mount, adjust, modify, maintain or repair the
product.
►Whenever work is carried out on the product, make sure that the product cannot be actuated by mistake.
►Perform maintenance tasks, renovation work or attachment work outside of the machine's danger zone when
possible.
►Do not reach into the operational range of the product.
►Observe the specied maintenance intervals and specications regarding the quality of the operating material.
►When using the product under extreme conditions, adjust the maintenance interval according to the degree of
contamination.
INSTALLATION AND OPERATING INSTRUCTIONS: HRC-07
DDOC01015 / a EN / 2022-07-20
Zimmer GmbH • Im Salmenkopf 5 •  77866 Rheinau, Germany •  [phone] • www.zimmer-group.com

7
CAUTION
Notes and handling regulations for electrostatically sensitive components
Electrostatically sensitive components are individual components, integrated circuits or assemblies that can be
damaged by electrostatic elds or electrostatic discharge.
►When handling electrostatic components, make sure that persons, the work area and packaging are all fully
grounded.
►Touch electronic components only in appropriately identied areas with conductive ooring and only if:
• You are grounded by means of special bracelets.
• You wear shoes that are suitable and approved for the discharge of electrostatic charges.
►Do not bring electronic assemblies into contact with plastics and parts of clothing that have plastic content.
►Store electronic assemblies on conductive underlays only.
►Do not install electronic assemblies in the vicinity of data back-up devices or monitors (monitor distance >
100 mm).
►Perform measurements on electronic assemblies only if:
• The measuring instrument is grounded (e.g. via a ground conductor).
• The measuring head is momentarily discharged before measuring with a oating measuring instrument.
3 Proper use
NOTICE
The product is only to be used in its original state with its original accessories, with no unauthorized changes and
within the stipulated parameter limits and operating conditions.
Any other or secondary use is deemed improper.
►Operate the product only in compliance with the associated installation and operating instructions.
►Operate the product only when it is in a technical condition that corresponds to the guaranteed parameters
and operating conditions.
ÖZimmer GmbH shall accept no liability for any damage caused by improper use. The operator bears sole
responsibility.
The product is designed exclusively for electric operation using a 24V DC power supply.
The product is intended for industrial use.
The product is used as dened under "Proper use" in enclosed rooms for temporarily gripping, handling and holding
workpieces in human-robot collaboration.
The pre-assembled gripper ngers are designed for outside gripping as the closed and rounded surfaces faces inward. For
inside gripping of the product, the gripper ngers must be mounted backwards to ensure safe operation and so that the
rounded surfaces face outward.
The product is not suitable for clamping workpieces during a machining process.
Direct contact with perishable goods/food is not permitted.
4 Personnel qualication
Installation, commissioning and maintenance may only be performed by trained specialists. These persons must have read
and understood the installation and operating instructions in full.
INSTALLATION AND OPERATING INSTRUCTIONS: HRC-07
DDOC01015 / a EN / 2022-07-20
Zimmer GmbH • Im Salmenkopf 5 •  77866 Rheinau, Germany •  [phone] • www.zimmer-group.com

8
5 Product description
CAUTION
Reduction of the gripping force can cause personal injury and material damage
When exible components are gripped, the gripping force of the product is reduced.
Reduced gripping force can lead to personal injury or material damage, because the components that are being
gripped can no longer be securely gripped and transported.
NOTICE
►Make sure that the setting of the gripping force and the selection of the gripper nger length are correct to
prevent incorrect bracing of the gripper jaws.
ÖAn incorrect conguration or selection can lead to malfunction
The product is a safe gripper in accordance with DINISO13849-1.
The basic and proven safety principles from DIN EN 13849-1 can be complied with only if original parts from Zimmer GmbH
are used.
This ensures that a gripping force of 60N cannot be exceeded.
5.1 Possible applications
Outside gripping Inside gripping
The product can be used for outside gripping. The product can be used for inside gripping.
MoveToWork command MoveToBase command
5.2 Forces and torques
INFORMATION
►You can nd the information in the technical data sheet on our website.
►Please contact Zimmer Customer Service if you have any questions.
INSTALLATION AND OPERATING INSTRUCTIONS: HRC-07
DDOC01015 / a EN / 2022-07-20
Zimmer GmbH • Im Salmenkopf 5 •  77866 Rheinau, Germany •  [phone] • www.zimmer-group.com

9
5.3 Type plate
A type plate is attached to the housing of the product.
XXX
XX-XXXXXX
am
an
The article number and conrmation number are shown on the type
plate.
am Article number
an Conrmation number
5.4 Use in applications
The criteria listed below justify the suitability of
the product for use in collaborative
applications:
• The product has been designed in
accordance with the specications of ISO/
TS 15066.
• As stipulated by ISO/TS 15066, the
maximum permissible gripping force of the
product is <140 N. Compliance with this
value has been checked using a suitable
measuring device. The product did not
exceed a gripping force of 60 N.
• The maximum torque of the motor, in
combination with the transmission design
and pre-assembled gripper jaws, ensures
that this force value is not exceeded.
• The gripping forces generated when
gripping soft objects are signicantly
reduced, since the amount of dynamic force
is lowered.
Automation cell Coexistence
Separated workspaces Detection of presence
Cooperation Collaboration
Zones of action Shared workspaces
INSTALLATION AND OPERATING INSTRUCTIONS: HRC-07
DDOC01015 / a EN / 2022-07-20
Zimmer GmbH • Im Salmenkopf 5 •  77866 Rheinau, Germany •  [phone] • www.zimmer-group.com

10
6 Functional description
The gripper jaws of the product are arranged on three guide rails offset to each other at an angle of 120° and can be moved
toward each other.
The force of the motor is transmitted by a worm drive. A pinion and a rack generate the movement of the gripper jaws and
synchronize these movements.
Despite its small installation space, the product is suited for gripping a wide range of form-t and frictional t parts.
You can optionally adjust the gripping force to the workpiece by using the control system via IO-Link.
1Signal transmission
2LED display
3Gripper nger
1
2
3
INSTALLATION AND OPERATING INSTRUCTIONS: HRC-07
DDOC01015 / a EN / 2022-07-20
Zimmer GmbH • Im Salmenkopf 5 •  77866 Rheinau, Germany •  [phone] • www.zimmer-group.com

11
6.1 LED status display
4Power/communication
5Error
4
5
INSTALLATION AND OPERATING INSTRUCTIONS: HRC-07
DDOC01015 / a EN / 2022-07-20
Zimmer GmbH • Im Salmenkopf 5 •  77866 Rheinau, Germany •  [phone] • www.zimmer-group.com

12
6.2 Control
INFORMATION
►You can nd the information in the technical data sheet on our website.
►Please contact Zimmer Customer Service if you have any questions.
6.3 Veried conguration examples
INFORMATION
►You can nd the information in the technical data sheet on our website.
►Please contact Zimmer Customer Service if you have any questions.
6.4 Self-locking mechanism
INFORMATION
The product has a mechanical self-locking mechanism to ensure that the workpiece remains held by the product
in the event of power supply loss or failure (e.g. an emergency stop).
►Please contact Zimmer Customer Service if you have any questions.
7 Technical data
INFORMATION
►You can nd the information in the technical data sheet on our website.
This data varies within the series, depending on the specic design.
►Please contact Zimmer Customer Service if you have any questions.
INSTALLATION AND OPERATING INSTRUCTIONS: HRC-07
DDOC01015 / a EN / 2022-07-20
Zimmer GmbH • Im Salmenkopf 5 •  77866 Rheinau, Germany •  [phone] • www.zimmer-group.com

13
8 Accessories/scope of delivery
INFORMATION
If any accessories not sold or authorized by Zimmer GmbH are used, the function of the product cannot be
guaranteed. Zimmer GmbH accessories are specically tailored to the individual products.
►For optional accessories and those included in the scope of delivery, refer to our website.
9 Transportation/storage/preservation
►Transport and storage of the product must be done only with the original packaging.
►If the product has already been installed on the superordinate machine unit, care must be taken during transport to
ensure that no unexpected movements can occur.
►Before commissioning the product and after transport, check all power and communication connections as well as
all mechanical connections.
►If the product is stored for an extended period, the following points are to be observed:
►Keep the storage location as dust-free and dry as possible.
►Avoid temperature uctuations/observe and adhere to the temperature range.
►Avoid wind/drafts/water condensation formation.
►Cover the product with a weatherproof, tear-resistant foil to prevent dust.
►Pack the product and do not expose it to direct sunlight during storage.
►Clean all components. There must be no soiling left on the components.
►Visually inspect all components.
►Remove all foreign substances.
►Properly remove potential corrosion spots.
►Close electrical connections using suitable covers.
INSTALLATION AND OPERATING INSTRUCTIONS: HRC-07
DDOC01015 / a EN / 2022-07-20
Zimmer GmbH • Im Salmenkopf 5 •  77866 Rheinau, Germany •  [phone] • www.zimmer-group.com

14
10 Installation
WARNING
Risk of injury due to uncontrolled movements
Risk of injury in case of unexpected movement of the machine or system into which the product is to be installed.
►Switch off the energy supply of the machine before any work.
►Secure the power supply against being switched on unintentionally.
►Check the machine for any residual energy that may be present.
CAUTION
Risk of injury due to uncontrolled movements
Risk of injury in the event of uncontrolled movement of the product when the power supply is connected.
►Switch off the power supply to the machine before carrying out any work.
►Secure the power supply against being switched on unintentionally.
►Check the machine for any residual energy that may be present.
NOTICE
►Installation may only be carried out by qualied personnel in accordance with these installation and operating
instructions.
►Switch off the power supply before any assembly, installation or maintenance work.
►Install the product on an appropriate mounting surface in accordance with the atness specications.
INFORMATION
Requirements for the mounting surface:
• Permissible unevenness: 0.03 mm
• Cleanliness of the mounting surfaces of the product and mounting piece (product grounding)
Further installation information:
• The mounting screws are not included in the scope of delivery.
• Strength class of the mounting screws is at least 8.8 (DIN EN ISO 4762)
►Make sure that the mounting piece is su󹱺ciently rigid.
►Observe the tightening torque of the mounting screws.
►Verify the permitted load capacity of the required screw connections in accordance with VDI 2230.
INSTALLATION AND OPERATING INSTRUCTIONS: HRC-07
DDOC01015 / a EN / 2022-07-20
Zimmer GmbH • Im Salmenkopf 5 •  77866 Rheinau, Germany •  [phone] • www.zimmer-group.com

15
10.1 Installing the product
The product and the robot are connected to
each other via an adapter ange.
6
7
8
9
►Position the product on the robot ange
using the pin, drilled holes and bolt.
►Mount the product on the robot ange using
the mounting screws.
7
9
6Mounting screw
7Robot ange
8Pin
9Pin for positioning
INSTALLATION AND OPERATING INSTRUCTIONS: HRC-07
DDOC01015 / a EN / 2022-07-20
Zimmer GmbH • Im Salmenkopf 5 •  77866 Rheinau, Germany •  [phone] • www.zimmer-group.com

16
10.2 Safe shutoff for products with IO-Link
INFORMATION
For safe shutoff for IO-Link products, two contactors are switched in series with one auxiliary contact each. Here,
the auxiliary contacts monitor the status of the contactors. If one contactor does not switch, the second contactor
ensures safety. The malfunction can still be detected using the contacts.
The following example corresponds to control category3 and the PLd can be reached in any case. PLe in control
category4 can be reached only if S24V is also shut off with two channels and with error monitoring, similar to the example
above. The product cannot carry out a hazardous movement.
.
PE
..
1
..
2
..
3
..
4
.
PE
-W3
1
2
3
4
PE
Up
GND Up
Us
GND Us
PE
Up
GND Up
Us
GND Us
Up
GND Up
Us
GND Us
br
-W4
M12 5pol 5m
ws
bl
sw
gr
1
2
3
4
5
1
Power
OUT
WH/OR WH/GN GN OR WH/OR WH/GN GN OR
TX+
RX+
RX-
TX- TX+
RX+
RX-
TX-
PE
Up
GND Up
Us
GND Us
1
2
3
4
5
1
2
3
4
5
1
2
3
4
1
2
3
4
2
3
4
5
-Q10
12
3
4
5
6
12
3
4
5
6
-Q11
12
3
4
5
6
12
3
4
5
6
Rk_1
Rk_2
-KXX2
24V IN 24V OUT
L/A IN L/A OUT
X01
GND_Up
1
GND_Us
2
PE
3
Us
4
Up
5
GND_Up
1
GND_Us
2
PE
3
Us
4
Up
5
Tx+
1
Rx+
2
Rx-
3
Tx-
4
Tx+
1
Rx+
2
Rx-
3
Tx-
4
L+
1
P24
2
L-
3
C/Q
4
N24
5
2122 21222122 2122
Power
IN
-K1
S24V
1
P24V
2
SGND
3
C/Q
4
PGND
5
cable
Ensure galvanic
isolation.
feedback circle
of Q10 & Q11
Fieldbus
bus module head
L/A IN
Fieldbus module
bus module head
L/A OUT
IO-Link master
Zimmer IO-Link gripper
without STO cable
Two contactors in series,
each with an auxiliary
contact
Connection to other
field devices
Connection to other
fieldbus nodes
NOTICE
Without an externally fed power supply,the motor of the product cannot carry out an active movement and thus
cannot carry out a hazardous movement.
There is no galvanic isolation between the two voltage supplies (signal and power). There is a low-voltage
connection via ground (GND).
Because of the self-locking mechanism, the product remains in the last approached position, even if no power is
supplied.
INSTALLATION AND OPERATING INSTRUCTIONS: HRC-07
DDOC01015 / a EN / 2022-07-20
Zimmer GmbH • Im Salmenkopf 5 •  77866 Rheinau, Germany •  [phone] • www.zimmer-group.com

17
10.3 Installing the energy supply
The integrated pin assignment supplies the
product and control system with power.
1
1Signal transmission
10.3.1 Mounting the pin assignment
pin Function Explanation
8|H 2|B
1|A7|G
1|A - -
2|B - -
3|C + 24 V DC actuator Actuator supply voltage
4|D C/Q IO-Link communication
5|E FE Functional ground
6|F - -
7|G GND
8|H + 24 V DC sensor Supply voltage of sensor
INSTALLATION AND OPERATING INSTRUCTIONS: HRC-07
DDOC01015 / a EN / 2022-07-20
Zimmer GmbH • Im Salmenkopf 5 •  77866 Rheinau, Germany •  [phone] • www.zimmer-group.com

18
10.4 Static charge
CAUTION
Non-compliance may result in material damage.
Grounding the product is recommended if ESD sensitive parts come into contact with the product.
Grounding is also recommended in applications that require high EMC shielding.
The movement of the gripper jaws creates low voltages as a result of static charging. These charges cannot be dissipated if
the product is mounted on an insulating surface and if discharge is also not possible through the workpiece.
10.5 Heat dissipation
In the event of high ambient temperatures, the product must be installed on heat-dissipating materials.
If the product is operated under very high ambient temperatures and with fast clock cycles on an ongoing basis, this might
reduce its service life.
INFORMATION
ÖThe cycle time must therefore be reduced as the temperature increases.
10.6 Installing accessories
NOTICE
Before installing an accessory, make sure it is suitable for use with the selected variant.
►You can nd information on our website.
►Please contact Zimmer Customer Service if you have any questions.
INSTALLATION AND OPERATING INSTRUCTIONS: HRC-07
DDOC01015 / a EN / 2022-07-20
Zimmer GmbH • Im Salmenkopf 5 •  77866 Rheinau, Germany •  [phone] • www.zimmer-group.com

19
11 Commissioning
11.1 Process data
There is an option to control the product only with the process data that is transmitted in each cycle.
Outputs: Process data from the IO-Link master to the product!
Name Data type
ControlWord UINT16
DeviceMode UINT8
WorkpieceNo UINT8
Reserve UINT8
PositionTolerance UINT8
GripForce UINT8
DriveVelocity UINT8
BasePosition UINT16
Reserve UINT16
TeachPosition UINT16
WorkPosition UINT16
Control system Gripper
Input
Output
Name Data type
StatusWord UINT16
Diagnosis UINT16
ActualPosition UINT16
INSTALLATION AND OPERATING INSTRUCTIONS: HRC-07
DDOC01015 / a EN / 2022-07-20
Zimmer GmbH • Im Salmenkopf 5 •  77866 Rheinau, Germany •  [phone] • www.zimmer-group.com

20
11.2 IODD Import
►Import the IODD (device description) into the control system.
►Go to our website.
►Select the desired product.
►Download the corresponding .zip le via the Download IODD link.
ÖYou will need the .zip le for import into the control system.
ÖAs soon as the hardware conguration is complete and the IO-Link connection to the product is established, data will be
displayed in the process input data.
ÖSome control systems demand a byte swap to bring this process data into a logical sequence.
►Look at bit 6 (GripperPLCActive) in the StatusWord to determine whether a byte swap is necessary.
►Determine whether bit 6 is active in the rst or second byte of the StatusWord.
ÖBit 6 is active in the rst byte: The bytes already have the correct sequence.
►Continue with the commissioning.
ÖBit 6 is active in the second byte.
►Apply a byte swap, refer to the "StatusWord" section.
INFORMATION
The product is controlled via IO-Link by means of the cyclical process data as well as the acyclic service data with
a cycle time of 5ms.
►It is mandatory to verify the process data!
11.3 Handshake Data Transfer Method
The handshake method makes it possible to transfer the process data about the product. All process data described in the
following sections must be transferred with the handshake.
►Send the ControlWord = 0x0001 to the product.
ÖThe data transfer was started.
►Check the response of the product by using Statusbit 12 = TRUE (data transfer OK).
►Send the ControlWord = 0x0000 to stop the data transfer.
ÖThe data transmission is complete when the product sends back Statusbit 12 = DataTransferOK = FALSE.
INFORMATION
►For examples, refer to the "Quickstart Basic Parameters" section.
INSTALLATION AND OPERATING INSTRUCTIONS: HRC-07
DDOC01015 / a EN / 2022-07-20
Zimmer GmbH • Im Salmenkopf 5 •  77866 Rheinau, Germany •  [phone] • www.zimmer-group.com
