ZION DELUXE User manual

COLOR
White and Brown
VOLTAGE
220 V
NW/GW
55 kg / 65 kg
MEAS
117 x 75 x 106 cm
SHOULDER AIRBAG
FOOT AIRBAG WHEEL
POWER BOX
PARTS DESCRIPTION
1
LEG AIRBAG
HIP VIBRATION
HIP AIRBAG
ARM AIRBAG WAIST
MASSAGE
ARM REST
BLUETOOTH SPEAKER
HEAD PILLOW
MONITOR

SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should always be followed,
including the following: Read all instructions before using.
DANGER - To reduce the risk of electric shock:
Always unplug this appliance from the electrical outlet immediately after
using and before cleaning.
Never use pins or other metallic fasteners with this appliance.
Carefully examine the covering before each use. Discard the appliance if the
covering shows any sign of deterioration, such as checking, blistering, or
cracking.
WARNING - To reduce the risks of burns, fire, electric shock or injury to persons:
An appliance should never be left unattended when plugged in. Unplug from
outlet when not in use, and before putting on or taking off parts
Close supervision is necessary when this appliance is used by, on, or near
children, or disabled persons
Use this appliance only for its intended use as described in this manual. Do not
use attachments that have not been recommended by the manufacturer.
Never operate this appliance if it has a damaged cord or plug, if it is not
working properly, if it has been dropped or damaged, or dropped into water.
Return the appliance to a service center for examination and repair.
Do not carry this appliance by the supply cord or use the cord as a handle.
Keep the cord away from heated surfaces
Never operate the appliance with the air openings blocked. Keep the air
openings free of lint, hair, and the like
Never drop or insert any object into any opening.
Do not use outdoors.
Do not operate where aerosol (spray) products are being used or where
oxygen is being administered.
To disconnect, turn all controls to the off position, then remove plug from
outlet.
Keep children away from the extended foot support
Connect this appliance to a properly grounded outlet only. See Grounding
Instructions.
Use heated surfaces carefully. May cause serious burns. Do not use over
insensitive skin areas or in the presence of poor circulation. The unsupervised
use of heat by children or disabled persons may be dangerous
Do not operate under a blanket or pillow. Excessive heating can occur and
cause fire, electric shock, or injury to persons.
2

GROUNDING INSTRUCTIONS
This product must be grounded. If it should malfunction or break
down, grounding provides a path of least resistance for the electric
current to reduce the risk of electric shock.
This product is equipped with a cord with an equipment-grounding
conductor and a grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
Danger-Improper connection of the equipment-grounding
conductor can result in a risk of electric shock.
Check with a qualified electrician or serviceman if you are in doubt
as to whether the product is properly grounded. Do not modify the
plug provided with the product - if it will not fit the outlet, have a
proper outlet installed by a qualified electrician.
Grounding Pin
SAFETY INSTRUCTIONS
Grounded
Outlet Box
Grounded
Outlet
3

OPERATING SURROUNDINGS
Do not use or store the massage chair in a damp environment: i.e. bathroom,
sauna, spa to avoid any mold, electric shock, fire or mechanical failure.
Do not use the massage chair outdoors.
Do not use the massage chair under dusty, smeary, or anoxic conditions.
Do not place the massage chair near a heater, stove, or near sunlight radiation
to avoid inner components overheating and causing fire.
Make sure to place the massage chair on a flat level ground.
The bracket part should be placed on the plain ground.
To avoid electric shock, please make sure to connect an earth wire and have it
grounded.
Don't use the machine while smoking.
SAFETY INSTRUCTIONS
FOLLOWING CONDITIONS SHOULD CONSULT DOCTORS BEFORE USE
Suffered from malignant tumor
Serious heart disease
Serious skin disease
Serious boned hyperplasia
During pregnancy, be on the rest cure under the doctor's supervision
If there is a bend in the back caused by an accident or disease
Needing peaceful surroundings
Arthritis Disease
Implanted pacemaker for medical purpose
Suffered from bowels disease (i.e. gastritis, entritis, diarrhea, hepatitis)
Serious blood circulation trouble
Consciousness trouble
In hyperpyretic
Children under the age of 18 or people with disabilities
(physical and mental) are not allowed to operate the
massage chair without a doctors consent to prevent cases
of electric shock, injuries, or mechanism malfunctions.
4

Non-professional technicians are not allowed to dismantle or
repair the chair to avoid fire, electrical shock or serious harm.
Do not spray or directly pour liquids to the switch when cleaning to
avoid insolation fault, electrical shock or short-circuiting.
When moving the chair in the process of storing or maintenance,
be sure to disconnect the power plug from socket. Do not detach
the plug with wet hands
Make sure to shut off and detach the power plug when cleaning or
storing product. During cleaning or moving the machine, make
sure to detach power cord to avoid fire or electrical shock .
Do not place the machine onto an unstable surface to avoid
roasting, insulation failure, electrical shock or turnover. When
storing the machine, make sure to disconnect power plug to avoid
fire caused by electricity leaking. Unexpected earthquake or
external force may also cause damage or injury.
Clean power plug periodically to avoid fire due to dust.
Do not use it in any unsafe places or for other purposes. It is the
main reason of product damage or accident.
Keep supply cord unobstructed at all time, i.e. not twisted, knotted,
over flexed or pulled and do not place anything heavy on it.
The appliance has a heated surface. Persons insensitive to heat
must be careful when using the appliance.
SAFETY INSTRUCTIONS
For safety reasons and in order to clearly indicate potential dangers
should the product be used improperly, instructions have been
marked in the following manners and should be strictly noted.
CAUTIONS
5

CAUTIONS
SAFETY INSTRUCTIONS
6
Do not store it near a fire or flammable substances. It is one of the
reasons of causing product manipulation, deviation, or damage .
Should any abnormality occur(i.e. scorching smell), stop using
immediately and detach power plug from socket. Operating under
an abnormal situation will cause fire or electrical shock, please
contact your local seller or authorized service agent for
maintenance.
Only rated voltage must be used (220 V).
Be sure to keep children away during operating to avoid any
hazard.
If the supply cord is damaged, it must be replaced by the
manufacturer or its authorized persons for repair or maintenance
to avoid any hazard.

SAFETY INSTRUCTIONS
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure
requirement. The device can be used in portable exposure
condition without RF striction. Changes or modifications not
approved by the party responsible for compliance could void
the users authority to operate the equipment. This equipment
has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
- Consult the dealer or an experienced radio/ TV technician
for help.
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. In order to avoid the
possibility of exceeding the FCC radio frequency exposure limits,
Human proximity to the antenna shall not be less than 20cm (8
inches) during normal operation.
7

MOVING THE MASSAGE CHAIR
When moving the chair, one person should tilt the back
and the other lift up the footrest to 45 degrees. Then
push the chair forward via casters.
The back should not be reclined too low in case of the
chair falling down and causing damage and harm to
property or persons.
Please grasp the bottom of the side plate (not the base)
with your hands and lift it up.
Due to the heavy weight, the chair must be carried by two
or more people. Also please be careful when handling to
avoid back strain.
8

ATTENTION
MOVING THE MASSAGE CHAIR
Do not drag or push the chair when it is not installed.
Do not hold the plastic parts of the foot cover and power box for moving.
Otherwise, it is easy to cause machine failure or personal injury.
Do not move the chair when someone is seated. Otherwise, it may cause
malfunction or personal injury
Before moving the machine, please turn off the chair (backrest & footrest
will go back to original position) and unplug the power cord. Otherwise, it
may cause malfunction or personal injury.
It is recommended to lay a cushion on the floor in case of scratching by
casters when
CHAIR PLACEMENT
When placing your massage chair, be sure to leave 6 in. of space
between the chair back and wall to allow it to recline safely.
When using the massage chair, ensure there are no people, pets, or
objects within 20 in. of the chair to allow the footrest to extend safely.
9
12 INCHES
12 INCHES

ATTENTION
CHAIR PLACEMENT
Do not use in places with high humidity such as bathrooms or saunas.
Please use on a flat and non-slippery ground.
Do not use in a place with a lot of debris or dust, or a place with high
surrounding temperature (above 40°C).
Do not place the unit under direct sunlight or near high-temperature
places such as heating appliances.
Do not let flames such as cigarettes near the massage chair.
Connecting the Power Cord
Insert the power cord into the chair's power socket, then plug the cord
into a grounded wall outlet.
Turn the power switch to the ON () position.
10

When the shutdown or timing time arrives, the massage chair enters the
reset state, and the LCD display reset sign, all keys are invalid at this time.
CONTROLLER PANEL
TOUCH KEY TOUCH KEY
SCREEN
POWER BUTTON
NOTE
11
The Bluetooth speaker will be automatically on when the massage chair
is turned on.
Search and connect your mobile phone bluetooth device into the
massage chair bluetooth device named " AMY 888 ". The user can see
that the new Bluetooth device is successfully connected to the massage
chair bluetooth speaker.
Bluetooth & Music Function

HOW TO USE
A Warning: Do not insert or pull out the power plug with
wet hands, otherwise an electric shock would happen.
Automatic massage programs including the following massages. Each
program massage different locations: foot, various movement of rollers
in the back part of the body, beating, and airbag pressure.
12
2. Starting your Massage
Sit in the chair, then press the power button [ ]of controller panel to enter
the full-automatic massage working state. The massage chair will be
automatically check your body shape. The default timing is 15 minutes, and
then press the power button [ ] to turn off the whole machine.
1. Turning On the Massage Chair
First, be sure that the Power Switch is in the off "O” position. Then insert the
power cable into the port of socket. Once firmly plugged in, proceed to plug
the power cord into the outlet. Then flip the switch to the on " I " position,
and the power switch should light up.

KEY
FUNCTION
Power
Power On / Power Off and Time Adjustment
Shoulder & Arm Pinch
Turn On/ Turn Off the shoulder arm pinch massage.
Pinch of Head and
Buttocks
Turn On/ Turn Off the head and hip airbag pinching
massage.
Leg Airbag Pinch
Turn On / Turn Off the leg airbag pinching massage.
Air Pressure +
Increases air pressure
Air Pressure -
Decreases air pressure
Airbag Automatic
Turn On/ Turn Off all airbags
Kneading Mode
Turn On / Turn Off the neck kneading massage function
Massage Mode
Turn On / Turn Off the waist and back massage function
Mode Selection
Toggle the massage function of kneading forward or
reverse.
Speed +
Increases the kneading massage.
HOW TO USE
13

KEY
FUNCTION
Speed -
Decreases the kneading massage.
Automatic Back
Turn On / Turn Off the back massage.
Rebound
Rise up the angle of massage chair
Declination
Lay down the angle of massage chair
Kneading the Sole
Knead the sole of the foot
Hip Massage
Turn On or Turn Off the hip vibration
Constant Temperature Hot
Compress
Turn on / Turn Off the constant temperature hot
compress
Zero G
Recline and to reset the massage chair
Fully Automatic
Set five modes, and select Relaxing, Fatigue, Sleep,
Recovery, Leisure
HOW TO USE
14
3. Adjust your Massage Time
When the massage chair is working, simply press the power button on the
controller panel. The massage chair enters timed mode. You can now adjust
your massage time from 15 minutes to 30 minutes with an interval of 5
minutes.

HOW TO USE
* Please wait the leg rest to return to its original position before standing up
to avoid damaging the foot parts due to the whole body's weight. After
using the massage chair, please turn off the power switch, and pull the
power cord plug out from the power socket.
4) Repeat the same process to enter F3 mode. F3 mode refers to the sleep
massage program. It is meticulously designed to provide a restful night's
sleep. This program relaxes your body and mind to achieve a good night's
sleep by giving you a soft and relaxing massage.
5) F4 mode refers to the massage program for soreness. Thoughtfully
designed to improve athletic recovery and performance, reduce stress,
anxiety and muscle tension, treat chronic back pain and break up scar
tissue. This type of massage applies heavy pressure onto muscles and deep
tissues to relieve built-up knots and tension.
6) Lastly the F5 mode. F5 mode refers to the elderly massage program.
Indulged with light, gentle massage and passive stretching to ease muscle
tension without excessive friction on the skin. It helps the elderly to improve
posture and alleviate arthritis pain and stiffness.
1) In control panel press Fully Automatic Button. You can choose between
from F1 to F5.
2)After pressing it, you will be entered into F1 mode in the automatic
massage function. F1 mode is a massage program that is perfect for relaxing.
Relaxing is specifically designed for people who want to relieve stress. It also
helps your body by increasing endorphin levels, which helps you reduce
body pain and tension.
3)Repeat the same process to enter F2 mode. F2 mode refers to the fatigue
massage program. It is thoroughly designed for fatigued muscles to
decrease their overall health, as this can lead to muscle weakness and
injury. It will work on your upper back and neck, increasing oxygen, reducing
muscle fatigue and maintaining healthy muscles.
Fully Automatic Massage Function
15

DAILY CARE AND MAINTENANCE
After using the massage chair, please turn off the power switch,
and pull the power cord plug out from the power socket
WARNING
Supervision and guidance is mandatory for those disabled montally and physically. Please
advise with your doctor before using the chair if you have ANY medical conditions. Children
under 18 should not use the chair and consult with a doctor for approval if attempted. Do not
operate the chair if there are any children or pets near by. Serious injuries may occur if those
instructions are not followed.
SAFETY INSTRUCTIONS
1. Should any abnormality occur, shut off and detach power plug from socket.
2. When the power cord is damaged, it must be changed from a special
power cord available from the manufacturer or the service department. A
Warning: Do not dismantle, modify, or change components by
unauthorized person to avoid electric shock or fire.
DAILY CARE & MAINTENANCE
STORAGE GU ID E
Do not dismantle back of the chair. Electrical shock may happen when in
touch with the inner elements of chair
An unauthorized person must not dismantle the chair to avoid electric
shock or fire.
Make sure to shut off and detach the power plug when cleaning to avoid
electric shock or hazard.
Keep the massage chair clean and free of dust. Do not place the massage
chair in a damp environment. © If not in use for a long period, please cover
it with a cloth to free dust. © Do not place the massage chair under
sunlight. 16

SAFETY INSTRUCTIONS
MAINTENANC E
Use neutral detergents only
Use neutral detergents to clean the back cushion, head cushion, and leg
cushion. Let it dry.
Use detergent and cloth to clean the plastic, pipe and leather material of
massage chair.
Make sure not to use organic solvents as gasoline, amyl acetate, benzene
for cleaning to avoid fading of the color, aging, or breakage.
Do not spray pesticide to avoid electric shock or fire. © Please clean with
dry cloth to avoid mechanical failure.
ABNORMALITY SITUATION
SOLUTION GUIDE
Failure to start and
indicator light is off
Check that the plug is well connected
Check if the switch on the chair is turned to "I"
position
Sound in operation
Sound for kneading or knocking
Sound changes after speed adjustment
Sound from the box in massage
Vibration sound for backrest in massage
Sound for air input and output
Sound for leg adjustment
Sound for motor when the massage chair is loaded
The sound is normal in following situation:
TROUBLESHOOTING
Checking is necessary in frequent usage.
Make sure the machine work properly before usage, after not in use for long time.
17
