Zodiac Medline 9 2022 User manual

Page 1 / 63
Issue 2
E
N
G
L
I
S
H
VOLUME 2
DESCRIPTION - BUOYANCY CHAMBER
PROPULSION SYSTEM
INSTALLATION AND CIRCUITS
CONTENTS
I DESCRIPTION............................................................................................................................... 3
I-1 TECHNICAL SPECIFICATIONS.................................................................................................... 3
I-2 INVENTORY AND LOCATION.................................................................................................... 6
I-3 LOCATION OF ACCESSORIES.................................................................................................. 10
I-4 HANDLING ............................................................................................................................. 11
I-4-1 Transport........................................................................................................................... 11
I-4-2 Storage .............................................................................................................................. 12
I-4-3 Lifting................................................................................................................................. 14
II BUOYANCY CHAMBER............................................................................................................... 15
II-1 BUOYANCY CHAMBER MAINTENANCE ................................................................................. 15
II-2 INSTALLING THE BUOYANCY CHAMBER ON THE HULL ......................................................... 15
II-3 FIXING THE PROTECTIVE FLAP............................................................................................... 16
II-4 INFLATING THE BUOYANCY CHAMBER ................................................................................. 17
II-5 PRESS-STUD........................................................................................................................... 19
III PROPULSION SYSTEM................................................................................................................ 21
IV HOW TO DRIVE YOUR BOAT...................................................................................................... 22
V INSTALLATION AND CIRCUITS ................................................................................................... 23
V-1 FUEL....................................................................................................................................... 23
V-1-1 Location ofitems............................................................................................................ 23
V-1-2 Tank ............................................................................................................................... 24
V-1-3 Water/fuel separator filter............................................................................................ 25
V-1-4 Using the fuel circuit cut-off valves............................................................................... 26
V-1-5 Recommendations......................................................................................................... 27
V-2 ELECTRICAL............................................................................................................................ 28
V-2-1 Cable routing ................................................................................................................. 28
V-2-2 General wiring diagram................................................................................................. 29
V-2-1 “COMFORT” Fuse box.................................................................................................... 32
V-2-1 “EQUIP NAV” fuse box................................................................................................... 33

Page 2 / 63
Issue 4
V-2-2 Location of items........................................................................................................... 34
V-2-3 Circuit-breaker............................................................................................................... 34
V-2-4 Coupler operation ......................................................................................................... 35
V-2-5 Battery (not supplied) ................................................................................................... 39
V-2-6 Navigation lights............................................................................................................ 40
V-2-7 Wiring an accessory....................................................................................................... 40
V-2-8 Wiring options............................................................................................................... 41
V-3 WATER................................................................................................................................... 44
V-3-1 Location of items........................................................................................................... 44
V-3-1 Using the hand shower and bolster tap ........................................................................ 44
V-4 TOILET.................................................................................................................................... 45
V-4-1 Location of items........................................................................................................... 45
V-4-2 Using the Toilet.............................................................................................................. 45
V-4-3 Draining black water...................................................................................................... 46
V-5 DRAINING SYSTEMS............................................................................................................... 47
V-5-1 DESCRIPTION OF FUNCTIONAL COMPONENTS............................................................. 47
V-5-2 Bilge pump..................................................................................................................... 48
V-5-3 Hull scupper................................................................................................................... 49
V-6 STEERING............................................................................................................................... 50
V-7 FIRE........................................................................................................................................ 51
V-8 ANCHORING/MOORING........................................................................................................ 52
V-9 BOARDING............................................................................................................................. 53
VI LABELLING ................................................................................................................................. 54
VI-1 POSITION OF LABELS ............................................................................................................. 54
VI-2 DESCRIPTION OF LABELS ....................................................................................................... 55
VII INSTALLATION ........................................................................................................................... 56
VII-1 Installing elements that come non-mounted........................................................................ 56
VII-1-1 WINGS ........................................................................................................................... 56
VII-1-2 Aft platforms ................................................................................................................. 57
VII-2 Installing optional elements.................................................................................................. 59
VII-2-1 POLYESTER ROLL BAR .................................................................................................... 59
VIII USE............................................................................................................................................. 60
VIII-1 Aft sun lounger.................................................................................................................. 60

Page 3 / 63
Issue 2
E
N
G
L
I
S
H
DESCRIPTION - Technical characteristics
IDESCRIPTION
I-1 TECHNICAL SPECIFICATIONS
Dimensions
Dimension tolerance +/- 3%
m
8.74
Buoyancy chamber
diameter
m
0.6
ft
28‘ 8“
ft
1‘12“
m
8.22
Without the
buoyancy chamber
a
m
8.36
ft
26‘ 97“
ft
27‘5“
m
3.06
b
m
2.27
ft
10‘ 04“
ft
7‘ 45’’
m
2.03
c
m
2.19
ft
6‘ 66“
ft
7‘ 19’’
HA
(mm)
1767
Max. air draught
T (mm)
677
Max. draught
°
18
Angle of the transom
mm
820
Height of the transom
Design category
(Directive 2013/53/EU)
B / C
Capacity
Weight tolerance +/- 5%
(ISO)
B
C
8*
20
Maximum
ISO 14946
Kg
1490
2400
Maximum load i.a.w. ISO 14946 (1+2+3+4)
data figuring on the ICNN certificate.
Maximum load i.a.w. ISO 14945 (1+2+3+5)
data figuring on the manufacturer plate.
1. Weight of people
2. Personal property
3. List of all options proposed
4. Content of consumable liquid tanks
(fuel, drinking water...)
5. Weight of the engine or engines
lb.
3285
5291
Maximum
ISO 14945
Kg
1130
2040
lb.
2492
4498
Kg
1850
The weights indicated do not include any
accessories
lb.
4079
Number of compartments
7
a

Page 4 / 63
Issue 4
DESCRIPTION - Technical characteristics
* WARNING
THE NUMBER OF PEOPLE FOR CATEGORY B DEPENDS ON THE NUMBER OF
SEATED PLACES ON THE BACK (HALF OF THE BOAT).
PASSENGERS SHOULD ALSO BE ABLE TO HOLD ON WITH BOTH HANDS.
WARNING!!!
DO NOT EXCEED THE MAXIMUM NUMBER OF PEOPLE RECOMMENDED.
NO MATTER HOW MANY PEOPLE ARE ON BOARD, THE TOTAL WEIGHT OF
PASSENGERS AND EQUIPMENT MUST NEVER EXCEED THE MAXIMUM
RECOMMENDED LOAD.
ALWAYS USE THE DESIGNATED SEATS OR SEATING AREAS.
MEDLINE 9.0 Engine
Shaft length
SINGLE ENGINE
TWIN-ENGINE
XXL
XL
MINIMUM
recommended
power
HP
250
2 x 175
The recommended power
corresponds to optimal use of
the boat's capacities for an
average load.
KW
187
2 x 131
MAXIMUM
recommended
power
HP
300
2 x 250
KW
224
2 x 186
MAXIMUM
allowed power
HP
450
2 x 350
KW
335
2 x 261
Maximum
MAXIMUM engine
weight
Kg
453
2 x 330
Lbs
998
2 x 727
Seat with handholds

Page 5 / 63
Issue 2
E
N
G
L
I
S
H
DESCRIPTION - Technical characteristics
NOTE: The maximum authorized power, when greater than the maximum recommended power, must
be used with extreme caution. It is intended for experienced users, using their boat under very specific
conditions (transport of heavy loads, etc.). See the "Sailing advice" chapter in Volume 1 of the manual.
WARNING!!!
WHEN LOADING THE BOAT, NEVER EXCEED THE MAXIMUM RECOMMENDED
LOAD. ALWAYS LOAD THE BOAT CAREFULLY AND SPREAD OUT THE LOAD
APPROPRIATELY, TO MAINTAIN THE THEORETICAL TRIM (APPROXIMATELY
HORIZONTAL). AVOID PLACING HEAVY LOADS HIGH UP.
WARNING!!!
THE MAXIMUM LOAD ON THE MANUFACTURER'S PLATE SHOULD NOT BE
EXCEEDED.
WE RECOMMEND, WHEN THE BOAT IS AT MAXIMUM CAPACITY:
-TO SAIL CAREFULLY
-TO SPREAD THE LOAD
-MAINTAIN APPROPRIATE TRIM.
WARNING!!!
DO NOT STORE FLAMMABLE PRODUCTS IN THE REAR COMPARTMENT.
IT IS STRICTLY FORBIDDEN TO STORE A SPARE FUEL TANK.

Page 6 / 63
Issue 4
DESCRIPTION - INVENTORY and location
I-2 INVENTORY AND LOCATION
1
2
3
4
5
6
7
8
10
9
11
11
12
12
12
12
13
14
15
16
16
17
17
18
18
19
20
21
21
21
23
24
24
25
26
27
28
28
31
29
29
30
30
32
34
33
22
35

Page 7 / 63
Issue 2
E
N
G
L
I
S
H
DESCRIPTION - INVENTORY and location
Ref.
DESCRIPTION
Polyester hull with counter-moulded deck
1
Aft platform
2
White navigation light
3
Bolster assembly
4
Console assembly
5
Bow roller assembly
6
Boarding ladder
7
Electric bilge pump
8
Battery (box) Inside the aft locker
9
Water/fuel separator filter
10
Battery switch
11
Aft lockers
12
Cup holder
13
Picnic table
14
Fuel tank assembly
15
Cabin under console
16
Bow lockers
17
Forward anchoring cleats
18
Red / green navigation lights
19
Anchor locker
20
Handhold
21
Deck drain
22
Inflation/deflation valves (X7)
23
Water tank fill port
24
Aft anchoring cleats
25
Bilge pump outlet
26
Tank vent
27
Hydraulic steering system and engine wiring harness cable deck seal
28
Engine recess drain
29
High flow rate self-bailer
30
Towing chain plates
31
Hull scupper
32
Bow chain plate
33
Anchor locker drain
34
Rubbing strip
35
Stainless steel bow windlass
Removable buoyancy chamber with wide rubbing strip, grab lines and long cones.
STANDARD EQUIPMENT
2 telescopic paddles, 1 foot inflator, 1 repair kit, 1 owner's manual (2 volumes), 1
pressure gauge.

Page 8 / 63
Issue 4
DESCRIPTION - INVENTORY and location
13
20
21
7
19
15
18
4
4
16
5
2
2
7
6
6
8
10
11
21
22
5
12
14
17
23
24
25

Page 9 / 63
Issue 2
E
N
G
L
I
S
H
DESCRIPTION - INVENTORY and location
REF.
DESCRIPTION
1
Cabin handrail
2
Semi-circular handrail
3
Console seat and bow sitting area
4
Bolster seat handrail
5
12V plug and USB plug
6
Cup holder
7
Ventilation
8
Foot braces
9
Stainless steel closing pin
10
Steering wheel, hydraulic steering
11
Bilge pump/navigation light switch
12
Console cabin access hatch
13
Sink
14
Bolster access hatch
15
Work surface
16
Fuel vent
17
Fuel valve access hatch
18
Fuel filling
19
Bolster aft locker
20
Bolster seats with fold-up system
21
Glove compartment
22
Cup holder
23
Water circuit access hatch
24
Toilet
25
Cabin locker

Page 10 / 63
Issue 4
DESCRIPTION - INVENTORY and location
I-3 LOCATION OF ACCESSORIES
An installation manual is supplied with each accessory.
REF.
DESCRIPTION
1
Forward sun lounger extension
2
Forward pulpit
3
Gas griddle
4
Refrigerator
5
Polyester frame
6
Bimini with frame
Bimini without frame
7
Aft sun lounger
8
Ski mast
9
Cabin berth
Synthetic teak deck
Fusion audio system, radio, mp3, aerial, 2 speakers
Other options available. See your ZODIAC dealer
5
6
8
2
7
1
3
4
9

Page 11 / 63
Issue 2
E
N
G
L
I
S
H
DESCRIPTION - Handling
I-4 HANDLING
I-4-1Transport
Trailer installation recommendations are specified in VOLUME I of the owner's manual.
Use a trailer adapted to your boat.
The boat is compatible with standard road gauge. It is designed to be transported inflated.
The weight in transport conditions for a trailer includes:
Unladen weight of the boat:
1855 kg
Tolerance +/- 5 %
Weight of the engine(s):
734 kg
Weight of the engine + battery
Consumable quantity:
402 kg
Fuel tank and freshwater tank
Options:
457 kg
Model including all options
Safety equipment:
59 kg
Equipment + anchoring
:
3507 kg
STOWING ON A TRAILER OR CRADLE:
USE THE BOW RING AND THE REAR CHAIN PLATES ON THE OUTSIDE OF THE
TRANSOM.
RECOMMENDATION: IF TRANSPORTED WITH BUOYANCY CHAMBER
DEFLATED!
TO AVOID DAMAGING THE CONE ENDS, WE RECOMMEND YOU USE THE
TRANSPORT STRAP KIT (OPTIONAL EQUIPMENT).

Page 12 / 63
Issue 4
DESCRIPTION - Handling
I-4-2Storage
WARNING!!!
THE BOAT MUST REST ON THE BOW LINE.
SEE DIAGRAM BELOW.

Page 13 / 63
Issue 2
E
N
G
L
I
S
H
DESCRIPTION - Handling

Page 14 / 63
Issue 4
DESCRIPTION - Handling
I-4-3Lifting
WARNING
THE BOAT HAS NO LIFTING FITTINGS. HOISTING REQUIRES PASSING
SUITABLE LIFTING STRAPS UNDER THE HULL.
* Estimate of the centre of gravity with the heaviest engine, options excluded.
Single engine (approx. 2400kg)
A = 3.20m
Twin engine (approx. 2650kg)
A = 2.95m
WARNING
LIFTING MUST BE CARRIED OUT BY PROFESSIONALS.
DANGER!!!
NO PASSENGERS ON BOARD WHILE LIFTING.
WARNING!!!
ALL EQUIPMENT MUST BE UNLOADED FROM THE BOAT FOR LIFTING
OR DAVIT HANDLING.
BEFORE LAUNCHING THE BOAT, OPEN THE AFT DRAIN HOLE TO DRAIN
ANY RAINWATER FROM THE BOTTOM OF THE BILGE (CLOSE THE
DRAIN HOLE AGAIN BEFORE LAUNCHING).
A mm

Page 15 / 63
Issue 2
E
N
G
L
I
S
H
BUOYANCY CHAMBER –Installing the buoyancy chamber on the hull
II BUOYANCY CHAMBER
II-1 BUOYANCY CHAMBER MAINTENANCE
Your boat's buoyancy chamber is made of NEOPRENE CSM-CR 1670 decitex, 1500 gr/m².
The maintenance recommendations are specified in VOLUME I of the owner's manual.
II-2 INSTALLING THE BUOYANCY CHAMBER ON THE HULL
IF THE BUOYANCY CHAMBER WAS STORED AT A TEMPERATURE BELOW 0°C /
32°F, LEAVE IT AT 20°C / 68°F FOR 12 HOURS BEFORE UNFOLDING.
YOU CAN INFLATE THE NON-FITTED BUOYANCY CHAMBER (pressure 240mb)
AND LET IT STABILIZE FOR AROUND ONE HOUR. THEN DEFLATE IT.
NOTE: the buoyancy chamber is fitted to the hull with the buoyancy chamber deflated
1
In order to facilitate the fitting of the buoyancy chamber, apply liquid soap to the hull’s rails (A).
2
Place the buoyancy chamber bolt rope (a) in the hull rail (b) starting with the front of the hull. Pull
the buoyancy chamber to bring it to the water guard near the transom.
3
Repeat for the other side of the buoyancy chamber.
The two protective flaps (sealing and exterior) should pass over the hull’s nose.

Page 16 / 63
Issue 4
BUOYANCY CHAMBER - INFLATING THE BUOYANCY CHAMBER
II-3 FIXING THE PROTECTIVE FLAP
Fastening with inserts:
4
Place the buoyancy chamber and make fast the outer flap (buoyancy chamber deflated) using the
stainless steel bars and the screws supplied in the buoyancy chamber kit. To ensure the
mechanical hold of the fitting, use medium threadlock on the screws.
Fastening with bolts:
4
After inflating the buoyancy chamber (see the chapters below), fit the outer flap using the
stainless steel bars and screws provided in the buoyancy chamber kit. Apply sealing compound on
all the screws and in the hull holes to achieve watertightness.

Page 17 / 63
Issue 2
E
N
G
L
I
S
H
BUOYANCY CHAMBER - INFLATING THE BUOYANCY CHAMBER
II-4 INFLATING THE BUOYANCY CHAMBER
INFLATOR
a. tube end
b. adaptor
c. tube base
d. inflation valve
NOTE: An electrical (12 V) high output inflation pump is available as an option (contact your dealer).
"EASY - PUSH" VALVES
To change position
In inflating position
In deflating position
Push
The membrane is closed, the
plunger is up
The membrane is open, the
plunger is down
a
b
c
d

Page 18 / 63
Issue 4
BUOYANCY CHAMBER - INFLATING THE BUOYANCY CHAMBER
THE PRESSURE GAUGE
WARNING!!!
DO NOT USE A COMPRESSOR OR COMPRESSED AIR CYLINDER.
INFLATION
1º/Place all valves in inflation position.
2º/ Fit the adaptor that matches the diameter of the "easy-
push" valve to the inflation tube tip.
3º/ Attach the hose connector to the inflation pump inflation
valve.
To inflate your buoyancy chamber properly, the inflation pump
should be correctly placed on the ground.
The chamber inflates rapidly if the inflation pump is used
smoothly and without haste.
4º/ Inflate the buoyancy chamber, starting with the first compartment (a) at the bow, to 200 mb
pressure.
5º/ Then inflate the midship chambers (b), to 220 mb pressure, read on the pressure gauge on the
first compartment.
6º/ Then inflate the stern compartments (c) to 240 mb, with the pressure gauge still on the first
compartment. The partitions (1) enable the pressure between each chamber to balance out.
7º/ Inflation is completed: screw on the inflation valve plugs.

Page 19 / 63
Issue 2
E
N
G
L
I
S
H
BUOYANCY CHAMBER - PRESSURE
NOTE: A slight loss of air is normal before the cap is screwed on.
Only the plugs provide final airtightness.
II-5 PRESS-STUD
The buoyancy chamber has 5compartments. Each must be inflated to a pressure of 240 mb / 3.4 PSI.
It is the buoyancy chamber's correct pressure.
The ambient temperature of the air or the
water proportionally influences the internal
pressure of the buoyancy chamber.
Ambient temperature
Pressure inside the
buoyancy chamber
+1°C
+4 mb / 0.06 PSI
-1°C
-4 mb / 0.06 PSI
It is therefore important to anticipate.
Check and adjust the pressure of inflatable compartments (by inflating or deflating) depending on
the temperature (particularly when temperature variations are high between the morning and
evening in particularly hot regions) and check that the pressure does not exceed the recommended
pressure zone (from 220 to 270 mb).
RISK OF PRESSURE LOSS
Example:
Your boat is exposed to direct sunlight on the beach (temperature=50°C) at the recommended
pressure (240 mb/3.4 PSI). When you launch the boat (temperature = 20°C), the temperature and
pressure in the inflatable compartments will both drop (up to 120 mb) and YOU MUST THEN RE-
INFLATE THEM until the millibars lost due to the difference between air and water temperature are
regained.
It is normal to observe a drop in pressure at the end of the day when the outdoor temperature drops.
1
1
1
1
b: 220 mb
b: 220 mb
c:240 mb
c:240 mb
a: 200 mb
b: 220 mb
b: 220 mb
1
1

Page 20 / 63
Issue 4
BUOYANCY CHAMBER - PRESSURE
RISK OF OVERPRESSURE
Example:
Your boat is inflated to its recommended pressure (240 mb/3.4 PSI) at the beginning or end of the day
(low outside temperature = 10°C). Later in the day, your boat is left in the sun on the beach or on the
deck of a boat (temperature = 50°C). Temperature inside the inflatable compartments will increase (up
to 70°C) especially with a dark colour buoyancy chamber, causing the pressure to double (480 mb).
YOU MUST THEN DEFLATE the boat to return to the recommended pressure.
WARNING!!!
IF YOUR BOAT IS OVERINFLATED, THE PRESSURE WILL ABNORMALLY
WEAR THE INFLATABLE STRUCTURE WHICH MAY LEAD TO A BREACH
OF THE ASSEMBLY.
IN THE EVENT OF OVERPRESSURE
Release air by pressing the valve plunger
