Zodiac Edenpac 1 User manual

Ed. 09/2009
Réf. : 1011463-11
Heat pump ...............................................................Instructions for installation and use
F
GB
P
I
1-2-3-4-5-6-7-8

IMPORTANT
These installation instructions are an integral part of the product and must be given to the
installer and kept by the user.
The warnings and indications contained in the present handbook must be carefully read and
understood as they provide important information relative to handling and operating safety.
This handbook must therefore always be kept available for later consultation.
Installation must be carried out in compliance with valid regulations and the manufacturer’s
instructions by a qualified professional.
The term «qualified professional» refers to a person possessing the technical knowledge
associated with Z.P.C.E. components and heating installations.
An installation error could result in physical injury to persons or animals as well as mechanical
damage for which the manufacturer may under no circumstances be held responsible.
After having unpacked the heat pump, the content should be checked for possible damage.
Before connecting the heat pump, ensure that the data provided by Z.P.C.E. is compatible with
the true installation conditions and does not exceed the maximum authorised limits for the
product in question.
Before beginning any installation, handling or repair work on the heat pump, always isolate
the electrical power supply to the unit.
In the case of a fault and/or operating error on the heat pump, the electrical power supply
must be isolated and no attempt should be made to repair the fault.
Repair work may only be carried out by an authorised technical assistance service using
original spare parts only. Non-respect of the aforementioned clauses may have a negative
influence on the operating safety of the heat pump.
To guarantee the efficiency and correct operation of the heat pump, it is important to ensure
it is regularly maintained in compliance with the instructions provided by Z.P.C.E.
In the case where a heat pump is sold or transferred to another user, always ensure that all
technical documentation is sent with the equipment to be used by the new user or installer.
This heat pump may only be used for the purpose for which it was designed: to heat a
swimming pool; all other uses must be considered inappropriate, incorrect or even
dangerous.
All contractual or extra-contractual responsibilities of Z.P.C.E. will be considered nil and void for
any damage caused by installation or operating errors, or due to non-respect of the
instructions provided by Z.P.C.E. or valid installation standards for the equipment object of the
present document.

1
CONTENTS
1 General..................................................2
1.1 General terms of delivery ..............................2
1.2 Voltage ..........................................................2
1.3 Water treatment .............................................2
2 Description............................................2
2.1 Presentation ...................................................2
2.1.1 Edenpac 1, 2, 3, 4 and 5
2.1.2 Edenpac 6
2.1.3 Edenpac 7 and 8
2.2 Dimensional characteristics...........................6
2.2.1 Edenpac 1, 2, 3, 4 and 5
2.2.2 Edenpac 6, 7 and 8
3 Installation ............................................8
4 Connections...........................................9
4.1 Access to the electrical card..............................9
4.1.1 Edenpac with single fan
4.1.2 Edenpac with double fan
4.2 Hydraulic connections ......................................10
4.3 Electric connections..........................................11
5 Regulator operation .............................12
5.1 Presentation.......................................................12
5.2 Setting the target temperature...........................13
6 Starting up ............................................13
6.1 Check................................................................14
6.2 Start up the heat pump ......................................14
6.3 Checking...........................................................15
6.4 Troubleshooting................................................15
6.5 Winter storage...................................................16
7 Maintenance instructions ....................16
8 Recycling the product ..........................16
9 Electrical diagrams ..............................17
9.1 Electrical diagram EdenPAC single-phase .......17
9.2 Electrical diagrams EdenPAC three-phase .......19

2
1. GENERAL
1.1 General terms of delivery
Any equipment, even CARRIAGE and PACKING FREE, travel at the consignee’s risk. The consignee shall make
reserves in writing on the CARRIER’S delivery bill if he notes damage caused during transport (confirmation to be
sent to the CARRIER within 48 hours by registered mail with acknowledgement of receipt).
Reminder: The unit must be shipped and stored in the upright position on a pallet and in the original packaging. In the
contrary case, place the unit in the vertical position on the pallet and check its global state (in case of doubt regarding the unit’s
good state of operation establish reserves in writing with the carrier).
Under no circumstances may the heat pump be operated immediately if it was placed horizontally.
Wait at least 12 hours before operating the pump
1.2 Voltage
Prior to any operation, check that the voltage on the name plate of the appliance corresponds to the mains voltage
provided on site.
1.3 Water treatment
In order to use our appliances under the best conditions, the following parameters must be respected: free chlorine:
max. 2.5 mg/L, total bromine: max. 5.5 mg/L, pH between 6.9 and 8.0. If chemical or electrophysical disinfection
systems are used, the installer and user must contact the supplier to ensure they are compatible with our materials.
These systems must be installed after the heating system.
2. DESCRIPTION
2.1 Presentation
Contents after unpacking:
The unit with its instructions, warranty card
Note:inside the appliance you will find a sachet of accessories. To extract it, see paragraph 4.1 of these instructions.
Content of sachet:
two sealing rings + two half-union connectors Ø50 with strap - four silent blocks
a plastic cap - a grooved elbow union - four anchor bolts and dowels (only supplied with double fan unit).




Must be installed
with a double fan
machine
+
+

3
2.1.1 Edenpac 1, 2, 3, 4 and 5
1Front panel with polypropylene grid
2Motor fan unit
3Access door to digital display (EVK)
4Electric board
5Flow switch
6TITANIUM condenser
7Control sensor
8Cased SCROLL compressor
9Arched “plate fin” evaporator
Anti-frost sensor
11 Fastening plates (with silent blocks)
12 Pool inlet water connection (40/49 male
screw fastening)
13 Packing gland (and/or cable inlet)
14 Pool outlet water connection (40/49
male screw fastening)
15 Removable polypropylene panel to
access the technical compartment
16 Closing snap clips
17 Phase order relay on three-phase PAC
cj Dehydrator
ck Grooved elbow
db Plastic plug
dc EVK digital display front panel
dd EVK control plate
de Connecting cable between the plate and
the EVK digital display
df 4/20 mA pressure sensor
dg Progressive starter on single-phase PAC
1
6
7
8
9

11
12
13
14
15
16
1j
2f
2e
22
c9
2b
2c
2345ci
25
Attention! Never use
the panel
reinforcement as a
load-bearing support.

4
2.1.2 Edenpac 6
1
2
6
5
7
8
9

16
14
15
12
11
13
1j
2f
c92b
2c
2e
22
ci
Attention! Never use the
panel reinforcement as a
load-bearing support.
1Front panel with polypropylene grid
2Motor fan unit
3Access door to digital display (EVK)
4Electric board
5Flow switch
6TITANIUM condenser
7Control sensor
8Cased SCROLL compressor
9Arched “plate fin” evaporator
Anti-frost sensor
11 Fastening plates (with silent blocks)
12 Pool inlet water connection (40/49
male screw fastening)
13 Packin
g
g
land
(
and/or cable inlet
)
14 Pool outlet water connection (40/49 male
screw fastening)
15 Removable polypropylene panel to access the
technical compartment
16 Closing snap clips
17 Phase order relay on three-phase PAC
cj Dehydrator
ck Grooved elbow
db Plastic plug
dc EVK digital display front panel
dd EVK control plate
de Connecting cable between the plate and the
EVK digital display
df 4/20 mA pressure sensor
34

5
2.1.3 Edenpac 7 and 8
3Access door to digital display (EVK)
9Arched “plate fin” evaporator
Anti-frost sensor
11 Fastening plates
12 Pool inlet water connection (40/49 male screw
fastening)
13 Packing gland (and/or cable inlet)
14 Pool outlet water connection (40/49 male screw
fastening)
15 Removable polypropylene panel to access the
technical compartment
16 Closing snap clips
d1EVK digital display front panel
11
12
14
16
15
dc
9

13
3
Attention! Never use the panel
reinforcement as a load-bearing support.

6
2.2 Dimensional characteristics
2.2.1 Edenpac 1, 2, 3, 4 and 5
Dimensions of the appliance with packaging (in mm):
1275
480
870
To be transported upright in its original
packaging close to the installation site.
Weight of Edenpac 1 with packaging: ≅96 kg
Weight of Edenpac 2 with packaging: ≅98 kg
Weight of Edenpac 3 with packaging: ≅101 kg
Weight of Edenpac 4 - 5 with packaging: ≅110 kg

7
2.2.2 Edenpac 6, 7 and 8
Dimensions of the appliance with packaging (in mm) :
1370
To be transported upright in its original
packaging close to the installation site.
1275
480
Side view EdenPAC 7 and 8
Rear view EdenPAC 6 Rear view EdenPAC 7 and 8
Weight of Edenpac 6 with packaging: ≅145 kg
Weight of Edenpac 7 with packaging: ≅175 kg
Weight of Edenpac 8 with packaging: ≅170 kg
Side view EdenPAC 6

8
3. INSTALLATION
Tools required for installation:
-1 set of flat head screwdrivers
-1 set of crosshead screwdrivers
-1 cutter
-1 wire stripper
-1 pipe or round head spanner 13
-1 ratchet spanner
-1 pliers
-2 straps (for handling)
Choose the appliance installation site according to the following criteria:
• the appliance must be installed outdoors
• the clearance around the appliance must be respected (see minimum dimensions on the drawings below) to
avoid recycling of cold air produced.
vers égout
Dense obstacle (hedge, wall, fencing).
• the installation must be simple and allow for easy maintenance interventions.
• the appliance must be installed on a solid base (fastening centre distance 810 x 370) and protected against
flooding (using a « concrete » base with drain facility for condensation or installation of an additional
condensation evacuation kit placed at your disposal in the accessories sachet). The silent blocks supplied must
be used, paying attention not to compress them too much when tightening the fastening screws.
• the appliance must be level to allow for the gravitational evacuation of possible condensation produced during
operation.
To use the additional condensation evacuation
kit:
- Use the grooved elbow union and cap.
- The tank is equipped with two evacuation holes,
one for the cap and the other for the grooved
elbow union (their position is interchangeable).
Note: To facilitate installation raise the unit 100 mm
above the ground with the additional blocks made of
a hard, water-resistant material (not supplied).




4 m

9
• the blower must not be directed towards surrounding windows.
• vibrations and noise must not be transmitted to a building close by.
• the heat pump must be installed at a minimum distance from the end of the pool, as defined by the applicable
national electrical standards. In France, the NF C 15 100 standard (section 702) specifies that this device must
be installed more than 2 meters from any basin or water reserve. In case it may be subjected to water jets,
provide for a minimum distance of 3.5 meters.
Attention!
• Do not lift the appliance by picking it up at the front and/or the water inlet/outlet points. Use 2 lifting
slings (not supplied) placed on either side of the appliance (see drawing below). The handle on the right side
may be used only to help with the final positioning of the appliance.
• Do not install the heat pump close to an inflammable gas source.
• Do not install the heat pump close to a road or path to protect the appliance against mud splashing.
• Avoid places that are subject to strong winds, in particular if the wind blows against the appliance’s air outlet.
• The installation as well as electric and hydraulic connections must be carried out in compliance with
applicable standards, in particular standard NF C 15 100 for France (equivalent to CE I 364) .
• Keep the appliance out of reach of children.
4. CONNECTIONS
4.1 Access to the electric card
4.1.1 Edenpac with single fan
•Turn the clips ¼ turn clockwise on the front panel 1using a flat head screwdriver.
•Unscrew the 2 screws 2and 3on the right side using a cross head screwdriver.
•Slide the entire front panel forward and then down.
Slings

1
2
3

10
4.1.2 Edenpac with double fan
•Turn the 2 clips 1a and 1b in the front ¼ turn clockwise using a flat head screwdriver.
•Unscrew the 2 screws 2and 3on the right side using a cross head screwdriver.
•Slide the entire front panel forward and then down.
4.2 Hydraulic connections
Connect the appliance’s PVC Ø 50 hose water inlet and outlet (according to symbols) to the removable fittings
provided with the heat pump. See symbols : for inlet and for outlet.
Connection is established with a by-pass on the pool filtration circuit after the filter and before the water treatment
device (see diagrams below).
- Hydraulic circuit test pressure: 3 bars - Hydraulic circuit operating pressure: 1.5 bar
Edenpac 1,2,3,4 and 5: average water flow 3.8 to 6.5 m³/h- pressure drop 1.3 to 1.7 mCE (0.13 to 0.17
bar)
V1-V2-V3: By-pass valve
V5-V4: Regulator valve*
* Recommended to facilitate
ad
j
ustment close to the machine.
V1
V2 V3
V4
V5
1b
1a
2
3

11
Edenpac 6, 7 and 8: average water flow 7.5 to 10 m³/h- pressure drop 1.1 to 1.3 mCE (0.11 to 0.13 bar)
4.3 Electric connections
• The power supply of the heat pump must pass via a protection facility and circuit-breaker (not supplied) in
compliance with applicable standards and regulations.
• The appliance is foreseen for connection to the mains circuit with TT and TN.S neutral connection (according
to NF C 15-100 or national standards in force).
• Supply cable section: protection:
- Edenpac 1: 3 x 2.5 mm²* (single-phase 230V/1/50Hz) Ù16 A
- Edenpac 2: 3 x 2.5 mm²* (single-phase 230V/1/50Hz) Ù16 A
- Edenpac 3: 3 x 4 mm²* (single-phase 230V/1/50Hz) Ù20 A
- Edenpac 3: 5 x 2.5 mm²* (three-phase 400V/3N/50Hz) Ù10 A
- Edenpac 4: 3 x 6 mm²* (single-phase 230V/1/50Hz) Ù25 A
- Edenpac 5: 5 x 2.5 mm²* (three-phase 400V/3N/50Hz) Ù12 A
- Edenpac 6: 5 x 2.5 mm²* (three-phase 400V/3N/50Hz) Ù16 A
- Edenpac 7: 3 x 10 mm²* (single-phase 230V/1/50Hz) Ù50 A
- Edenpac 8: 5 x 4 mm²* (three-phase 400V/3N/50Hz) Ù25 A
* This section is indicative and must be checked and adapted, if necessary, according to installation conditions .
• Electrical protection: circuit breaker (curve D) or fuse (Am) delayed designed for motors adapted to the type of
unit (refer to the protection values above) with a protection system by 30 mA differential on the incoming supply
side (circuit breaker or switch).
Note:
• The acceptable voltage variation during operation is ± 10%
• The cable ways and ducts must be fastened.
• Only use cable suitable for outdoor use.
• Use the packing glands and cable inlets to feed the cables into the unit.
V1-V2-V3: By-pass valve
V5-V4: Regulator valve*
* Recommended to facilitate
ad
j
ustment close to the unit.
Configuration of supply terminal
In three-
p
hase 400V 50Hz with neutral +
p
hase + earth
Configuration of supply terminal
In single phase 230V 50Hz with neutral + phase + earth
V1
V2 V3
V4
V5
With EdenPAC 7 and 8
V4
V5

12
Optional remote control functions:
•Remote On/Off start up: The terminals 26 and 27 of the Edenpac heat pump enable a remote start up by means of a
switch or any other device. The heat pump is supplied with a jumper between these terminals. If this function is used, the
jumper shall be removed. Otherwise it shall be kept.
•Priority to heating: A heating device, whatever it is, is designed to heat the water of the pool only when the water
circulates. Most of the time, a pool is filtered between 6 and 8 hours a day. But such a time can’t be sufficient sometimes to
maintain the water at the desired temperature, depending on the seasons. This is the reason why the Edenpac, like all
models of ZPCE’s range, is equipped with the “priority to heating” function that will manage the temperature of the pool,
taking itself the time to do it without caring of the scheduled time of operation of the filtration.
Terminals 4 and 5 shall be connected to the terminals of the filtration timer (see attached diagram). Every hour, the contact
between 4 and 5 is going to be closed, starting up the filtration for 5 minutes. If after 5 minutes, the temperature of the
water is over the required temperature, the filtration shuts off for one more hour. Otherwise, the filtration and the heat
pump are going to keep on operating until the desired temperature is reached. By this mean, the user is sure the water is
always ready for bath, at day or at night.
If this option is not used, the heat pump will operate only while the filtration runs.
• It is possible to connect a remote control module (1) (with display) . To do this use terminals: 39-40 (signals A-B) and 42-
43 for 12 Vac or Vdc supply of the interface A1 card.
Important:
To connect the remote On/Off(2) functions, and/or ″heating priority″(3) , use cables with a section of at least 1mm².
Packing glands and cable inlets are available for passage of these cables into the unit.
To connect the remote module(1) (max. distance = 50 m) use a shielded cable of 4x0.75 mm² minimum (connected
the braid shielded on terminal 41 on the heat pump and the remote control module).
(1) module available as an optional extra
(2) it is essential to use an independent cable for connection of this function (terminals 26 and 27)
(3) it is essential to use an independent cable for connection of this function (terminals 4 and 5)
5. REGULATOR OPERATION
5.1 Presentation
The EVK setting thermostat with digital display is supplied fitted in the appliance, electrically connected and pre-
set in the factory for swimming pool heating.
Setting principle: a control sensor placed at the water inlet side of the heat pump measures the temperature in the
pool and compares it to the target temperature. If the water temperature becomes or is lower than the target
temperature, the regulator unit authorises heating after a set time of 180 seconds, the Led blinks and then
remains on.
or
Attention!
Incorrect connection of terminals 26-27 and 4-5 could
result in damage to the regulator and cancellation of
the guarantee.
Filter timer
Terminal rail
in heat pump Contactor
Filter pump
Phase
Neutral
Remote On/Off switch
Independent cable
F
1
Never power the filter pump motor directly through terminals 4-5 located on platec.
Terminals 4-5 may remain live even if the heat pump is disconnected from the power source.
Before performing any work on the machine, cut off the power to the filter timer at its circuit breaker (F on
the dia
g
ram above.
)

13
(1) Stop operation in Heating mode
Remarks:
- when a defrost cycle is in progress, it ends with maintaining ventilation except if the ambient temperature drops below
+5°C or if filtration is stopped (J1 open).
- in the case where the unit requests heating (Leds and on or on and blinking) led remains on (contact
4-5 closed) for 120 s then switches off (contact 4-5 open).
5.2 Setting the target temperature
Press and hold the key to display the target temperature, and then press key to increase it or key
to decrease it. Then release both keys to return to the display of the water temperature.
Locking of the keyboard: press and 2 seconds => “Loc” is displayed.
“Loc” is displayed if one presses on a key in locking mode.
Unlocking of the keyboard: press and 2 seconds => “UnL” is displayed.
Note: the maximum target temperature is limited to 32°C in order to protect the swimming pool liner. This high target may,
however, be modified by the installer, but at his own responsibility.
6. STARTING UP
Technical characteristics:
Appliance Power
consumption* Power restored*
Rated
current
consumption*
Max.
current
consumed
Acoustic
power
Acoustic
power at
10 m
Net
weight
EDENPAC 1 Single phase 1,8 kW 8,5 kW 7,8 A 13,5 A 65,5 dBA 37,5 dBA 86 kg
EDENPAC 2 Single phase 2,04 kW 10 kW 9,8 A 15 A 66,5 dBA 38,5 dBA 87 kg
EDENPAC 3 Single phase 2,42 kW 12 kW 13 A 16 A 66,5 dBA 38,5 dBA 90 kg
EDENPAC 3 Three phase 2,46 kW 12 kW 5,8 A 7 A 66,5 dBA 38,5 dBA 90 kg
EDENPAC 4 Single phase 3,15 kW 15 kW 15,2 A 19 A 67,4 dBA 39,4 dBA 94 kg
EDENPAC 5 Three phase 3,22 kW 16 kW 6 A 9 A 70 dBA 42 dBA 99 kg
EDENPAC 6 Three phase 4,02 kW 21 kW 7 A 11 A 71,5 dBA 43,5 dBA 130 kg
EDENPAC 7 Single phase 4,8 kW 24 kW 26 A 45 A 70 dBA 42 dBA 165 kg
EDENPAC 8 Three phase 5,5 kW 28,5 kW 10 A 18 A 71,6 dBA 43,6 dBA 160 kg
* With ambient air at + 15°C and pool water at 24°C
• Appliance protection index: IP 24.
• Refrigerant gas type: R410A (see product name plate for refrigerant charge)
Do not vent R410A into atmosphere: R410A is a fluorinated greenhouse gas, covered by
Kyoto Protocol, with a Global Warming Potential (GWP) = 1975 - (Directive of the EC
842/2006)
Heating mode
Defrost cycle
(blinking = timer)
Program temperature or set
regulator parameters On/Off (1), Stand-by (1)
(red dot), Fault reset
Increase value (UP)
Decrease value (DOWN)
Compressor operation
(blinking = timer)
Filter pump control/heat pump on
(if connected)
thenÔthen Ò
Temperature display in °C or °F
Measurement indication in bar

14
Heat pump operating conditions:
• The outside temperature must be higher than +5°C (automatic shut-off by anti-frost sensor SD2) and below
+38°C.
• A sufficient water flow must pass into the heat pump.
Note:The heat pump stops heating the pool when it starts a defrost cycle that can occur when surrounding air temperature is
between 5 and 12°C. The operation of the compressor is interrupted but the fan keeps running, according to the information
provided by the defrost sensor SD3 which is factory-set to -10 °C in the refrigeration circuit. As soon as this temperature
increases to 3 °C, the fan switches off and a 120 to 300 second time period starts (depending on the compressor stoppage time)
before the fan and compressor restart simultaneously.
¾Possible traces of humidity at the base of the unit are due to normal condensation of the water vapour in the
air or due to the defrost cycle in progress (phenomenon visible if the additional condensation evacuation kit is not
used).
6.1 Check
• that the hydraulic connections are correctly tightened.
• that there is no water leak.
• that the appliance is stable (with a level gauge and spirit level).
• that the cables are correctly connected to their terminals.
¾Incorrectly tightened cables may cause overheating of terminals.
• that the cables cannot be damaged by sharp metal sheets or elements.
• the earth connection.
• that no tools or other objects have been left inside the appliance.
6.2 Start up the heat pump
• Switch on the heat pump power supply protection device located inside the filter control cabinet.
• Start filtration.
• Set the by-pass and setting valves* as follows:
- Valve V1 slightly closed to increase the filter pressure from 150 to 200g (0.15 to 0.20 bar).
- Valve V2 fully open.
- Valve V3 fully open.
- Valve V4 fully open.
- Valve V5 half closed.
* see paragraph 4.2.
If the valves (V4 & V5) are not present, open Valve V2 and close Valve V3 half-way.
• Check that the swimming pool water hydraulic circuit has been vented.
• start the heat pump if it is standby mode (red dot) by pressing for 3 seconds, ON appears on the display
for a period of 5 s before displaying the water temperature.
• Set the target temperature ( then or then ) => if the pool should be heated: Led blinks
and then remains on after approx. 2 to 3 minutes max. and the heat pump starts.
Note: with an EdenPAC 7 single-phase unit, the compressors start up one after the other (the N°1 then N°2) in 36 seconds
intervals.
Flow rate adjustment, read the refrigerating pressure and the temperature probes:
1) Press for 3 seconds ÎÎread the value with key :
- if the value expressed in bars is red with a high digit : the flow rate adjustment is too high;
-if the value expressed in bars is green : the flow rate adjustment is correct;
-if the value expressed in bars is red with a low digit : the flow rate adjustment is too low;
-if the value is flashing red, wait for the timeout of 5 minutes to elapse (return to the pull-down menu by
pressing )
2) Press ; Î Î are displayed;
3) Press to display the desired probe value in °C (return to the pull-down menu by pressing )
4) Press or press for 3 seconds to return to the temperature display.
Reminder:If, when setting the by-pass and setting valves, the flow rate is less than 1.5 m3/h the heat pump will not function
(the flow switch remains open and the regulator displays the message AId alternating with the water temperature). Adjust the
setting valves : -V5- (if present) or -V3- and -V1-.
When the heat pump is running:
-If the flow rate switch switches on or off for a period longer than or equal to 3 s, a timer of 130 seconds* min.
is activated before the unit starts again.

15
* For information: this time period may increase during a defrost cycle or if the compressor stop time is less than 180 s.
-In case of a power failure, a timer of 125 seconds starts when the power supply is restored before the unit starts
again.
Observation:when the water attains the target temperature (Leds and off) the heat pump switches off
automatically.
Reminder: the 3-phase heat pump is equipped with a phase order control system (KA1) used to check that the
phase order is correct at start up (and during operation) and to signal a phase order fault (regulator indicates dCP
fault and the orange led KA1 inside the unit is off. The green led remains on as long as phases L2 and L3 are
present). In that event, switch off and isolate the unit and it is sufficient to invert two phase wires directly on the
main supply terminal.
ATTENTION! this operation must be carried out by a qualified and authorised professional
6.3 Checking
Check that the heat pump stops heating when:
• the target temperature on the digital display thermostat is decreased.
• filtration is switched off or valve V2 or V4 closed.
6.4 Troubleshooting
The states:
N° Message Designation Cause Remedy Reset
n
Flow switch open for
more than 3 s.
1- Filter pump is off (filter timer is outside
the operating time limit)
2- Insufficient water flowing through the
unit
3- Flow controller damaged or
disconnected
1- Wait for the programmed filter time period
* Test possible in mode : filtration « manual »
2- Adjust the BY-PASS
* Filtration on
3- Change or reconnect the flow controller
Automatic
after timer
o
Anti-frost safety
triggered Outside temperature too low (< à +5°C) Wait for natural rise of outside temperature Automatic
p
Anti-frost protection
heater is on Outside temperature too low (< +3°C) with compressor OFF Wait for natural rise of outside temperature Automatic
q
Remote control
ON/OFF.
Remote control on OFF
(Contact open)
1- Switch the remote control to ON (Contact
closed)
2- Contact a ZPCE approved technician to check
the cable linking the remote control box to the
unit
Automatic
Faults:
N° Message Designation Cause Remedy Reset
r
Control sensor fault Sensor defective or
disconnected Replace or reconnect the sensor Cut power supply or press
button if dSr starts blinking
s
Anti-frost sensor
fault Sensor defective or disconnected Replace or reconnect the sensor Cut power supply or press button
if dSA starts blinking
t
Defrost sensor fault Sensor defective or
disconnected Replace or reconnect the sensor Cut power supply or press button
if dSd starts blinking
u
Low pressure fault
in refrigerating
circuit Insufficient refrigerant Consult a ZPCE-approved technician
to look for leaks and refill refrigerant
Automatic
(if less than 4 faults within an hour) or
by pressing the button if dbP
starts blinking
Info: led remains on for 120s after a fault is indicated (except in the case of a dC indication when the heat pump remains operational).
Info: led remains on for 120s after the status signal (except in the case of a
defrost cycle with the remote On/Off function (CAd) and SD3 < 3°C).
: Example of the pool water
tem
p
erature dis
p
la
y
.
: Alternating

16
v
High pressure fault
in refrigerating
circuit
1- Water and air mixture
passing in the appliance
2- Refrigerant overload
1- Purge hydraulic circuit
2- Consult a ZPCE-approved
technician to check the refrigerant
level
Automatic
(if less than 4 faults within an hour) or
by pressing the button if dHP
starts blinking
nm
Pressure sensor
defect Sensor out of order or disconnected Change or connect the sensor Automatic
nn
Phase order fault
(only on three-
phase heat pumps)
1- Incorrect wiring at unit
supply terminals
2- Modification of phase order
by electrical supplier
3- Temporary failure of one or
several phases
1- Check wiring at unit supply
terminals
2- Contact your local electricity
supplier to ensure no modifications
have been made to your supply
Cut power supply or press the
button if dCP starts blinking
no
Defrost cycle Time
Out
Incorrect signal from the
defrost sensor or defrost cycle
too long (> one hour)
Consult a ZPCE-approved technician
to check the sensor and operation of
the defrost cycle.
Cut power supply or press the button
if dtd starts blinking (after stand
by ‘Ofr5 => .’ and switch the regulator
on again by pressing )
nq
Voltage error Network power insufficient 1- Check the main power line, 2- See with the electrical
network supplier Automatic
nr
EEPROM fault Incorrect parameter data in the
regulator EEPROM Consult a ZPCE-approved technician to replace the regulator Cut off power
ns
Connection fault
Remote control module
(optional) incorrectly
connected or declared present
for the regulator but in reality
absent
Consult a ZPCE-approved technician
and refer to the installation
instructions of the remote control
module
Automatic
Only on
Edenpac
7
High or low
pressure fault in
refrigerating circuit
1- Water and air mixture
passing in the appliance
2- Refrigerant overload
3- Insufficient refrigerant
1- Purge hydraulic circuit
2- Consult a ZPCE-approved
technician to check the refrigerant
level
3- Consult a ZPCE-approved
technician to look for leaks and refill
refrigerant
Automatic
(if less than 4 faults within an hour) or
by pressing the button if dHP or
dBP starts blinking
6.5 Winter storage
• Set control in “standby” by pressing for 3 seconds , is displayed for 5 s before a small red dot
appears.
•Close the valves V2 and V3 of the BY-PASS.
•Open valves V4 and V5 next to the unit (if present).
• Drain the water condenser (RISK OF FROST)by unscrewing the two pool water inlet and outlet unions on
the side of the heat pump.
• Lightly retighten the two unions to avoid any risk of foreign bodies entering the condenser.
• Do not hermetically seal the unit (risk of condensation). A special-purpose ventilated cover is available
(optional accessory provided by ZPCE).
Incorrect winter storage automatically cancels the GUARANTEE.
7. MAINTENANCE INSTRUCTIONS
Tasks to be carried out by a qualified and authorised person:
The following operations must be carried out at least once a year:
• Clean the evaporator at the back of the heat pump (with a soft brush and gentle water spray).
- Never use a high-pressure cleaner for this operation -
• Check the settings.
• Check safety devices.
• Check sealing of the cooling circuit on the EdenPAC 6 & 8.
• Check electrical connections and terminals (retighten the supply cable terminals).
• Check earth connections.
• Do not use solvents to clean the outside of your unit, PAC NET offers an optional specific cleaning kit.
8. RECYCLING THE PRODUCT
Please refer to the paragraph with the symbol at the end of the instructions.
All interventions must be carried out by persons who are qualified and authorised to work on this
type of equipment. Before working on the appliance, ensure that the power supply is disconnected
and secured.
Warning! If the “Heating priority” function is connected, voltage may remain in the adjustment plate

17
9. ELECTRICAL DIAGRAMS
9.1 Electrical diagram EdenPAC single-phase
IMPORTANT
Elimination or shunting of one of the safety or remote control devices automatically cancels the GUARANTEE.

18
IMPORTANT
Elimination or shunting of one of the safety or remote control devices automatically cancels the GUARANTEE.
