Zodiac PW-5m User manual

H0357900.D - 2014/03
Instrucons for installaon and use
English
More documents on:
www.zodiac-poolcare.com
EN
PW 5M-7M-9M-11M

H0357900.D - EN - 2014-031
•Read this noce carefully before installing, maintaining or repairing this appliance!
•The symbol indicates important informaon that you must take into account to avoid the risk
of damage to persons or the appliance.
•The symbol indicates useful informaon as an indicaon.
Warning
•As part of a connuous improvement process our products may be modied without prior noce.
•Exclusive use: the heang of pool water (must not be used for any other purpose),
•The appliance must be installed by a qualied technician, in compliance with the manufacturer’s
instrucons and in compliance with current local standards. The installer is responsible for the
installaon of the appliance and compliance with local regulaons in maers of installaon. Under
no circumstances can the manufacturer be held liable in the event that local installaon standards
are not respected.
•Incorrect installaon may cause damage to property or serious injuries (possibly causing death),
•It is important that this appliance be handled by skilled and apt persons (physically and mentally)
having received the instrucons for use beforehand (by reading these instrucons). All persons not
meeng these criteria must not approach the appliance in order to avoid exposure to dangerous
elements.
•If the appliance suers a malfuncon: do not try to repair the appliance yourself, contact your
reseller,
•Before any intervenon on the appliance, make sure it has been powered o and locked out.
•Before any operaons check that:
-the voltage indicated on the appliance plate corresponds to the mains voltage,
-the socket and the power supply is suitable for use with a heat pump, and that it has a ground
connecon.
-the electrical plug is adapted to the socket available.
•Eliminang or shunng any safety devices automacally voids the warranty, as does the replacement
of parts using parts not originang from our warehouses,
•Keep the appliance out of the reach of children,
•Do not release R410A coolant liquid into the atmosphere. This is a uoride greenhouse eect gas
covered by the Kyoto agreement with a global warming potenal (GWP) = 1975 - (see the European
Community regulaons on uoride greenhouse eect gases Direcve EC 842/2006).
•This heat pump is compable with all types of water treatment.

H0357900.D - EN - 2014-03 2
EN
Contents
1. Informaon before installing................................................................................................................... 3
1.1 General delivery terms and condions...................................................................................................... 3
1.2 Content............................................................................................................................................................ 3
1.3 Technical specicaons ................................................................................................................................ 3
2. Installaon....................................................................................................................................................... 3
2.1 Selecon of the locaon .............................................................................................................................. 3
2.2 Installing the appliance ................................................................................................................................ 3
2.3 Hydraulic connecons .................................................................................................................................. 4
2.4 Electric connecons ...................................................................................................................................... 4
3. Use....................................................................................................................................................................... 5
3.1 Presentaon of the regulaon .................................................................................................................... 5
3.2 Checks before commissioning ..................................................................................................................... 5
3.3 Starng up the appliance............................................................................................................................. 5
3.4 Checks to carry out once the appliance is running .................................................................................. 6
3.5 Wintering ........................................................................................................................................................ 6
4. Maintenance................................................................................................................................................... 6
4.1 Maintenance instrucons ............................................................................................................................ 6
4.2 Addional recommendaons...................................................................................................................... 6
4.3 Recycling ......................................................................................................................................................... 7
5. Troubleshoong ............................................................................................................................................ 7
5.1 Displays ........................................................................................................................................................... 7
5.2 Appliance malfuncons................................................................................................................................ 7
5.3 FAQ................................................................................................................................................................... 8
6. Registering the product.............................................................................................................................. 8
Are available in the appendices at the end of these instrucons:
• Electric Diagram
• Size
• Descripon
• EC Declaraon of compliance

H0357900.D - EN - 2014-033
1. Informaon before installing
1.1 General delivery terms and condions
All equipment, even postage and packing paid, travels at the risks and perils of the recipient. The laer must make
wrien reserves on the transporter’s delivery documents if damage during transport is discovered (conrmed by
registered leer to the transporter within 48 hours).
If the appliance has been pped over, make wrien reserves to the transporter.
1.2 Content
PW Wintering Cap Screw-on
ng Gasket Ø40 Adapter Ø50 Adapter
x1 x2 x2 x2 x2 x2
1.3 Technical specicaons
PW 5M 7M 9M 11M
Single phased voltage 230V-50Hz
Input power* kW 0.98 1.56 2 2.6
Rated input intensity* A 4.45 7.09 9.09 11.82
* with surrounding air temperature at 15°C and pool water at 24°C, humidity level 70%
• Operang temperatures: from 7 to 32°C air and up to 32°C water (30°C with Zodiac® Easy Connect)
2. Installaon
Do not li the appliance using the casing, handle it from the base.
2.1 Selecon of the locaon
The appliance must be installed outside and be surrounded by free space (see §2.3).
• the heat pump must be installed at a minimum distance from the edge of the pool in order to avoid any projecons
of spray onto the appliance. This distance is determined by the electric standards applicable locally (for France: 3.5
meters).
• the heat pump must not be installed:
-close to a heat source or to a source of inammable gas,
-close to a road with a risk of water or mud being sprayed,
-facing strong winds,
-with the blower facing a permanent or temporary obstrucon (window, wall, hedge, etc.) less than 3 metres away.
2.2 Installing the appliance
Fixing holes
• install on a stable, solid surface (concrete slab for example) which is level,
• protect from risks of ooding due to condensates from the appliance when it is
running.
The an-vibraon pads are built into the heat pump base.
The appliance can be xed to the ground using the holes in the appliance
base, or using rails (not supplied). It is also possible to x the appliance to
brackets (not supplied).
A drilling diagram is available on the back of the packaging box.

H0357900.D - EN - 2014-03 4
EN
2.3 Hydraulic connecons
VE: water intake valve
VB: by-pass valve
VS: water output valve
* minimum distance
PW 5M 7M 9M 11M
Test pressure bar 6
Service pressure bar 1.5
Load loss mCE 1 1 1.5 1.5
Water ow
opmum
minimum
m³/h 4 6 8 8
Water ow
maximum* m³/h 10
* rate not to be exceeded
Follow the hydraulic connecon direcon (see § «Sizes» in the appendix).
• The connecon will use Ø40 piping, or Ø50 using the supplied adapter (see §1.2), use the half-union ngs to connect
to the pool ltering circuit, aer the lter and before water treatment.
• Installing a by-pass is mandatory and facilitates operaons on the appliance.
• Adjust the water ow using valve VB, and leave valves VE and VS open.
• Make sure the hydraulic ngs are correctly ghtened and that there are no leaks.
Condensate drainage: warning, your appliance can release several litres of water per day; it is highly recommended
to connect the drainage to the drains.
Connect an interior Ø15 pipe (not supplied) to the corrugated angle to be ed under the appliance base
(supplied, see §1.2).
2.4 Electric connecons
2.4.1 Voltage and protecon
• The appliance is designed for connecon to mains electricity using a neutral TT and TNS wiring,
• Electric protecon: using a circuit breaker (D curve) or a fuse (Am) (calibre 16A), with a 30 mA ground fault circuit
breaker at the head of the line (circuit breaker or switch).
PW 5M-7M-9M
• connect the power cord supplied with the appliance to a 16A socket complying with the standards and regulaons in
force in the country where it is installed,
• extension cords and adapters must not be used,
• If the power supply cable is not long enough, contact a qualied technician.
PW 11
• the electrical supply of the appliance must come from a protecon and switching device (not supplied) complying with
the standards and regulaons in force in the country,
• the electrical supply cable must not be exposed to elements that are sharp, hot or represent a crush hazard,
• check that all cables are secure and all terminal connecons are correct.
Acceptable voltage variaon: -10%, +7% (while running).
2.4.2 Connecons
• Check the strength of the power supply cable on the connecon terminal block
phase (L) + neutral (N) + Ground (PE)

H0357900.D - EN - 2014-035
• Loose terminals can cause the terminal block to heat and lead to the warranty being voided.
• It is imperave to connect the appliance to an earth rod.
• Risk of electric shocks inside the appliance.
• Only a qualied and experienced technician is authorised to wire inside the appliance.
• If the power supply cable is damaged it should be replaced by a qualied technician.
2.4.3 Cable size
• Power supply cable size: for a maximum length of 20 metres (calculaon on the basis of: NFC 15-100), must be checked
and suitable for the installaon condions.
PW Voltage I Maximum absorbed Cable cross secon Electric protecon
Amm² A
5M 230V-50Hz 5.2 3x1.5 3G1.5 16
7M 230V-50Hz 8.7 3x1.5 3G1.5 16
9M 230V-50Hz 12.4 3x2.5 3G2.5 16
11M 230V-50Hz 15.5 3x2.5 3G2.5 20
3. Use
3.1 Presentaon of the regulaon
Symbol Meaning Fixed Flashing O
Water ow Water ow
correct Water ow too low or absent /
Heang Acve Starng up Inacve
Ambient air
temperature Sucient Insucient /
Oponal external
heat pump or
heang priority
connected
Opon connected
and running to
achieve heang
set point
Opon connected
but with no heang
set point
Opon not
connected
Fault Fault detected,
see §5
External pump or
heang priority
connected, running
to reach set point
but water ow too
low or missing
No fault
«On/O» buon
Pool water temperature reading and parameter seng buon
Value adjustment buons
3.2 Checks before commissioning
• Correct ghtening of hydraulic ngs,
• Good stability (appliance level and vercal),
• The electric power supply cable must be isolated from all sharp or hot elements that could damage or crush it.
3.3 Starng up the appliance
• Start up water circulaon and adjust the valves (see §2.3),
• Connect the heat pump electricity supply: (programme version n° dierent depending on the model)
then ,
• Powering on: press for 2 seconds: then by default the screen displays the set point
temperature,
• The appliance starts aer a mer that can last up to 5 minutes,
• Set the required temperature (so-called «set point»): when the heat pump is running, press or to set the
temperature.

H0357900.D - EN - 2014-03 6
EN
• Possibility of reading the water temperature: when water is owing through the heat pump, press :
ashes 10 seconds then the xed temperature set point is displayed,
• Possibility of locking the keyboard:
- Keyboard lock: press and at the same me for 3 seconds: appears for 3 seconds, then:
,
- Unlocking the keyboard: press and at the same me for 3 seconds: ashes for 4 seconds,
then: .
3.4 Checks to carry out once the appliance is running
Aer the heat pump commissioning steps, temporarily shut o the water ow to check that your appliance shuts down
aer a few seconds (by triggering the ow meter): the water ow indicator should ash.
3.5 Wintering
Wintering is imperave, failure to do so exposes the condenser to a risk of freezing, this situaon is not
covered by the warranty. To avoid condensaon damaging the appliance, do not cover it hermecally.
• Power o the heat pump by pressing for 2 seconds and then disconnect it from the power supply,
• Make sure there is no water ow in the heat pump,
• Drain the water condenser (risk of freezing) by unscrewing the two pool water intake and discharge ngs behind the
heat pump,
• In the event of full pool wintering: screw the two ngs back on a full turn to avoid foreign bodies from entering the
condenser,
• If wintering the heat pump only: do not screw the ngs back on, instead t 2 caps (supplied) to the condenser water
intake and discharge.
• Install a micro venlated wintering cover on the heat pump (accessory available as an opon).
4. Maintenance
4.1 Maintenance instrucons
It is recommended to carry out general servicing of the appliance on wintering and recommissioning, in order
to check it is in good working order and maintain its performances, as well as to prevent certain possible
defects.
These acons are the user’s responsibility and must be carried out by a technician.
Do not use high pressure cleaners.
• Make sure that no foreign bodies block the venlaon grate.
• Clean the evaporator (for the locaon see § «Size» in the appendices) using a exible brush and a clean water hose
(disconnect the power supply), do not bend the metal heat sinks, the clean the condensate drainage pipe to remove
any dirt that may be obstrucng it.
• Clean the outside of the appliance, do not use solvent based products,
• Check that the regulaon is in working order.
• Check that the condensates are draining correctly when the appliance is running.
• Check that the regulaon is in working order.
• Check the safety devices.
• Check that metal casing is connected to the earth.
• Check the ghtness of the electric wire connecons and the cleanliness of the control box.
4.2 Addional recommendaons
Relave to pressurised appliances (PED-97/23/EC)
4.2.1 Installaon and maintenance
• It is prohibited to install the appliance close to combusble materials or close to the air intake on an adjacent building.
• For some appliances it is imperave to use the protecon grate accessory if the installaon is located in an unregulated
access area.
• During installaon, repair, or maintenance operaons it is prohibited to use piping as a step ladder: under stress the
piping could rupture and the coolant could cause serious burns.
• During maintenance of the appliance the composion and condion of the heat transporng uid will be checked as
will the absence of traces of coolant.
• During the annual appliance seal inspecon in compliance with applicable regulaons, check that the high and low
pressure switches are correctly connected to the refrigeraon circuit and that they cut the electric circuit when triggered.

H0357900.D - EN - 2014-037
• During the maintenance phase make sure there are no traces of corrosion or oil stains around the refrigerang
components.
• Before any operaons on the refrigerang circuit it is imperave to shut down the appliance and to wait a few minutes
before ng temperature or pressure sensors. Some equipment such as the compressor and piping can reach
temperatures in excess of 100°C and high pressures which can cause serious burns.
4.2.2 Repairs
• All welding operaons are to be carried out by qualied welders
• Piping can only be replaced using copper tube in compliance with NF EN 12735-1 standard.
• Leak detecon, pressure test:
- never use oxygen or dry air, there is a risk of re and explosion,
- use dehydrated nitrogen or a mixture of nitrogen and the coolant indicated on the idencaon plate,
- the test pressure on the low and high pressure sides must not exceed 42 bar.
• For the high pressure circuit piping using copper pipes of a diameter = or > than 1’’5/8, a §2.1 cercate under standard
NF EN 10204 is to be requested from the supplier and kept with the installaon technical documents.
• The technical informaon relave to the safety requirements for the dierent applicable direcves is indicated on
the idencaon plate. All this informaon must be recorded on the appliance installaon manual which must be
part of the installaon technical le: model, code, serial number, maximum and minimum service voltage and service
pressure, year of manufacture, CE marking, manufacturer’s address, coolant type and weight, electric parameters,
thermodynamic and acousc performances.
4.3 Recycling
This symbol means that your appliance must not be disposed of as household waste. It will be subject to selecve
waste sorng with a view to its reuse, recycling or sale. If it contains substances that are potenally harmful to the
environment, they will be eliminated or neutralised.
Ask your reseller for informaon about recycling.
5. Troubleshoong
5.1 Displays
Symbol Meaning Cause Soluon
Air
temperature
sensor fault
Sensor out of order or
incorrectly connected Replace the sensor, contact your reseller or a qualied technician
Defrosng
sensor fault Sensor out of order or incorrectly connected Replace the sensor, contact your reseller or a qualied technician
Low pressure
fault Gas leak on the refrigerang circuit Contact your reseller or a qualied technician
High pressure
fault • No water ow or defecve ow controller
• Water temperature too high
(32°C maximum, 30°C with
Easy Connect)
• Other
• Check the water ow or contact your reseller or
a qualied technician
• Wait for the temperature to drop
• Contact your reseller or a qualied technician
Water
temperature
sensor fault
Sensor out of order or
incorrectly connected Replace the sensor, contact your reseller or a qualied technician
Defrosng
cycle fault (>20
minutes)
• Air temperature too low
• The venlator is out of order
• The evaporator is dirty
• Air or defrosng
temperature incorrect
• Wait for the temperature to come within the
operang range
• Contact your reseller or a qualied technician
• Clean the evaporator (see §4.1)
• Contact your reseller or a qualied technician
5.2 Appliance malfuncons
Malfuncon Possible causes Soluons
The appliance is out
of order • No display • The pool temperature is above the
set point temperature
• There is a message on the screen
• Water ow absent or incorrect
• Check the power supply voltage and fuse F1
• Increase the set point temperature
• Check the meaning of the message in §5.1
• Check the water ow (by-pass, ltering)
The venlator is
running but the
compressor stops
from me to me
without any error
messages
• The heat pump occasionally performs
defrosng cycles
• The evaporator is dirty
• Normal if the outside temperature is less than 12°C
• Clean the evaporator

H0357900.D - EN - 2014-03 8
EN
Malfuncon Possible causes Soluons
The appliance is
working but the
water temperature
does not rise
• Insucient ltering me
• Usage period not compliant
• The heat pump is undersized
• The automac pool lling is blocked
in the open posion
• The heat insulated cover is not used
• The evaporator is dirty
• The appliance is incorrectly located
• There is a message on the screen
• Switch the ltering to manual 24h/24 for the
temperature rise
• Check that the outside temperature is compliant
with the operang range (see §1.3)
• Check the heat pump specicaons for the pool
• Check that automac lling is in working order
• Posion the heat insulated cover
• Clean the evaporator (see §4.1)
• The appliance must be installed outside.
• Check that there are no obstacles at less than 4
metres from the blower, and 0.50 metres behind
the heat pump (see §2)
• Check the meaning of the message §5.1
The heat pump is
tripping the circuit
breaker
• The circuit breaker is incorrectly or
wrongly sized
• The cable size is undersized
• The supply voltage is too low
• Check the circuit breaker (see § 2.4.3)
• Check the cable size (see §2.4.3)
• Contact your electricity supplier
5.3 FAQ
Is it possible
to improve the
temperature rise?
To improve
the eciency
of your heat
pump it is
recommended
to:
• Cover the pool using a cover (bubble cover, shuer, etc.) to avoid heat
losses.
• Take advantage of a period when outside temperatures are warm (on
average > 10°C), to guarantee easier temperature rises (this can take several
days, its duraon can vary depending on weather condions and the heat
pump sizing).
• The hoer the surrounding air, the more the heat pump will be eecve.
• Keep the evaporator clean.
Check that the
ltering me is
sucient
• During the temperature rise phase, water circulaon must be connuous
(24*7).
• To maintain the temperature throughout the season, switch to «automac»
circulaon at least 12h/day (the longer this period, the more the heat pump
will have a sucient operang range to warm).
Seng the set point to the maximum will not heat the water quicker.
Why doesn’t my
heat pump heat? • On start-up the appliance stays in «pause» for 30 seconds before starng: check that this me has elapsed.
• When the set point temperature is reached, the heat pump stops heang: check that the
water temperature is less than the set point (see §3.3)
• When the water ow is nil or insucient, the heat pump stops: check that the water is
owing correctly through the heat pump and that the hydraulic ngs have been installed
correctly.
• When the outside temperature drops below 7°C, the heat pump stops: check the outside
temperature.
• The heat pump may have detected an operang fault: check for a code displayed on the
screen, if there is one refer to §5.1.
• If these points have been checked and the problem persists: contact your reseller.
My appliance is
draining water: Is
this normal?
• Your appliance drains water in the form of condensates. This water is the humidity from the
air that condenses when in contact with some of the cold components of the heat pump.
• Warning: your appliance can drain several litres of water per day.
Where should my
water treatment
system be located
relave to the
heang system?
• The water treatment system (chlorinator, salt water chlorinator, etc.) must be installed
preferably downstream from the heat pump (see locaon §2.3) and be compable with it
(contact the manufacturer)
6. Registering the product
Register your product on our website:
-be the rst to be informed of new Zodiac® products and special oers,
-help us to constantly improve our product quality.
Europe & Rest of the World www.zodiac-poolcare.com
America www.zodiacpoolsystems.com
Australia – Pacic www.zodiac.com.au

H0357900.D - EN - 2014-031
Electric diagram
PW 5M-7M-9M P1 PW 11M L-N-PE
Power supply 230V-1N-50Hz

H0357900.D - EN - 2014-03 2
AF Digital display KM2 Fan relay
Earth KM3 Auxiliary pump relay
C1 Compressor capacitor KM4 Complementary relay
C2 Fan capacitor M1 Compressor
C3 Auxiliary pump capacitor M2 Fan
CD Flow rate controller M3 Auxiliary pump
E1 High pressure switch P2 Auxiliary pump connector
E2 Low pressure switch SD1 Water temperature sensor
ED1 Auxiliary pump SD2 Air temperature sensor
F1 Fuse SD3 Defrost sensor
KM1 Compressor relay T1 Transformer
Dimensions
PW Weight (Kg)
5M 45
7M 47
9M 48
11M 51
Descripon
1Pool water inlet
2Pool water outlet
3Evaporator
4Auxiliary pump connector
2
1
3
4

Pour plus de renseignements, merci de contacter votre revendeur.
For further informaon, please contact your retailer.
ZODIAC® is a registered trademark of Zodiac Internaonal, S.A.S.U., used under license.
Votre revendeur / your retailer
www.zodiac-poolcare.com
Zodiac Pool Care Europe - BP 90023 - 49180 St Barthélémy d’Anjou cedex - S.A.S.U. au capital de 517 200 € / SIREN 395 068 679 / RCS PARIS
