Zotac Inspire Studio User manual

ZOTAC Inspire Studio
1
ZOTAC Inspire Studio
User’s Manual
No part of this manual, including the products and software described in it, may
be reproduced, transmitted, transcribed, stored in a retrieval system, or translated
into any language in any form or by any means, except documentation kept by the
purchaser for backup purposes, without the express written permission of ZOTAC.
Products and corporate names mentioned in this manual may be registered trademarks
or copyrights of their respective companies, and are used for identication purposes
only. All trademarks are the property of their respective owners.
Every effort has been made to ensure that the contents of this manual are correct and
up to date. However, the manufacturer makes no guarantee regarding the accuracy of
its contents, and reserves the right to make changes without prior notice.
CAUTION:
Risk of explosion if the battery is replaced with an incorrect type. Batteries should be
recycled where possible. Disposal of used batteries must be in accordance with local
environmental regulations.

ZOTAC Inspire Studio
2
Table of Contents
Product Specications ----------------------------------------------------------------------------------------3
Safety information ----------------------------------------------------------------------------------------------4
Setting up your system-------------------------------------------------------------------------------------4
Care during use ----------------------------------------------------------------------------------------------4
Welcome -----------------------------------------------------------------------------------------------------------5
Package contents -------------------------------------------------------------------------------------------5
Getting to know your ZOTAC Inspire Studio-----------------------------------------------------------6
Front view -----------------------------------------------------------------------------------------------------6
Rear view ------------------------------------------------------------------------------------------------------7
Installing Hardware inside ZOTAC Inspire Studio----------------------------------------------------8
Installing Optane memory module (optional) ---------------------------------------------------------9
Setting up your ZOTAC Inspire Studio-------------------------------------------------------------------10
Using your ZOTAC Inspire Studio -------------------------------------------------------------------------12
Conguring a wireless connection ----------------------------------------------------------------------12
Conguring audio output-----------------------------------------------------------------------------------12
Intel® OptaneTM technology (optional) --------------------------------------------------------------------13
Enabling Intel®OptaneTM memory -----------------------------------------------------------------------13
Disabling Intel®OptaneTM memory ----------------------------------------------------------------------20

ZOTAC Inspire Studio
3
Product Specications
qMicroprocessor support
vIntel Core i7-9700 (8-core 3.0 GHz, up to 4.7 GHz)
qOnboard Graphics support
vZOTAC GeForce®RTX 2060 Super Mini w/ 8 GB GDDR6
vThree DisplayPort 1.4, one HDMI 2.0b (Max 4 output)
qSystem Memory support
v32 GB DDR4-2666 SODIMM memory preinstalled
qOnboard Serial ATA
v2 TB SATA 6.0 Gb/s HDD preinstalled
qExpansion slot
v512 GB NVMe M.2 SSD preinstalled
vOne Optane memory slot (22/42, 22/80)
qUSB Ports
vFive USB 3.1 ports
vOne USB 3.1 Type-C port
q Onboard Dual LAN
vSupports one 10/100/1000 Mbps Killer Ethernet
vSupports one 10/100/1000 Mbps Ethernet
vSupports IEEE 802.3
q WiFi 6/Bluetooth support
vKiller Wireless-AX 1650
vCompliant with IEEE802.11ax standard
vBluetooth 5
qOnboard Audio
vStereo analog audio output and Microphone input
qPower Supply
v19.5V/330W
qOperating systems
vWindows 10 Pro 64-bit preinstalled
qProduct Size
v225mm x 203mm x 128mm

ZOTAC Inspire Studio
4
Safety information
Your ZOTAC Inspire Studio is designed and tested to meet the latest standards of safety for informa-
tion technology equipment. However, to ensure your safety, it is important that you read the following
safety instructions.
Setting up your system
vRead and follow all instructions in the documentation before operating your system.
vDo not use this product near water or a heat source such as a radiator.
vSet up the system on a stable surface with the provided stand. Never use the system alone
without the stand.
vOpenings on the chassis are for ventilation. Do not block or cover these openings. Make sure
you leave plenty of space around the system for ventilation. Never insert objects of any kind into
the ventilation openings.
vUse this product in environments with ambient temperatures between 0℃and 35℃.
 If you use an extension cord, please use the UL listed cord and make sure that the total
ampere rating of the devices plugged into the extension cord does not exceed its ampere
rating.
Care during use
vDo not walk on the power cord or allow anything to rest on it.
vDo not spill water or any other liquids on your system.
vWhen the system is turned off, a small amount of electrical current still ows. Always unplug all
power, modem, and network cables from the power outlets before cleaning the system.
vIf you encounter the following technical problems with the product, unplug the power cord and
contact a qualied service technician or your retailer.
¾The power cord or plug is damaged.
¾Liquid has been spilled onto the system.
¾The system does not function properly even if you follow the operating instructions.
¾The system was dropped or the cabinet is damaged.

ZOTAC Inspire Studio
5
Welcome
Congratulations on your purchase of the ZOTAC Inspire Studio. The following illustration displays the
package contents of your new ZOTAC Inspire Studio. If any of the below items is damaged or missed,
contact your retailer.
Package contents
• 1 x ZOTAC Inspire Studio
• 1 x AC Adapter
• 1 x Power Cord
• 2 x Antenna
• 1 x Support DVD (optional)
• 1 x USB ash drive with OS drivers (optional)
• 1 x User Manual & Warranty Card
• 1 x Quick Start Guide

ZOTAC Inspire Studio
6
Getting to know your ZOTAC Inspire Studio
Front view
Refer to the diagram below to identify the components on this side of the system
1. Power switch
The power switch allows powering ON and OFF the system. The ring LED can be disabled
in BIOS setting.
2. Memory card reader
The built-in memory card reader reads SD/SDHC/SDXC cards used in devices such as digital
cameras, MP3 players, mobile phones and PDAs.
3. USB 3.1 port
The USB 3.1 port supports the SuperSpeed USB 3.1 device. Use this port for USB 3.1 devices
for maximum performance with USB 3.1 compatible devices.
4. Microphone jack
The microphone jack is designed to connect the microphone used for video conferencing,
voice narrations or simple audio recordings.
5. Headphone/Audio Out jack
The stereo headphone jack (3.5mm) is used to connect the system’s audio out signal to
amplied speakers or headphones.
6. USB 3.1 Type-C port
The type-C USB 3.1 port supports the SuperSpeed USB 3.1 devices. Use this port for USB
3.1 devices for maximum performance with USB 3.1 compatible devices.
12
3
4 5
6

ZOTAC Inspire Studio
7
Rear view
Refer to the diagram below to identify the components on this side of the system.
1. WiFi antenna connectors
The WiFi antenna connector supports WiFi antenna module.
2. USB 3.1 ports
The USB 3.1 port supports the SuperSpeed USB 3.1 device. Use this port for USB 3.1 devices
for maximum performance with USB 3.1 compatible devices.
3. DisplayPorts
DisplayPorts supports both external (box-to-box) and internal (laptop LCD panel) display
connections.
4. HDMI port
The HDMI (High Denition Multimedia Interface) port supports a UHD device such as an LCD
TV or monitor to allow viewing on a larger external display.
5. LAN ports
The eight-pin RJ-45 LAN ports support standard Ethernet cables for connection to a local
network. The LAN port marked with K is for Killer Ethernet.
6. Power input (DC19.5V)
The supplied power adapter converts AC power to DC power for use with this power port. To
prevent damage to the mini-PC, always use the supplied power adapter.
The power adapter may become warm to hot when in use. Do not cover the adapter and keep it away from your body.
1
2
34
56
3
1

ZOTAC Inspire Studio
8
Installing Hardware inside ZOTAC Inspire Studio
Before installing hardware, please follow the instructions below to remove the cover of your
ZOTAC Inspire Studio.
1. Rotate and remove the thumb screws.
2. Gently remove the cover as shown below.
 
 

ZOTAC Inspire Studio
9
Installing Optane memory module (optional)
1. Locate the Optane memory slot and remove the two screws.
2. Insert an Optane memory module into the slot at a 45 degree angle.
3. Gently press down on the Optane memory module, and install the screw.

ZOTAC Inspire Studio
10
Setting up your ZOTAC Inspire Studio
You need to connect peripherals before using your ZOTAC Inspire Studio.
1
234
561
12
33 4
561

ZOTAC Inspire Studio
11
1. Connecting WiFi antenna modules
Connect WiFi antenna modules to the WiFi antenna connectors.
2. Connecting to USB 3.1 devices
Connect USB 3.1 devices such as external hard drives, SSDs and ash drives to the USB 3.1
port on the system rear panel.
3. Connecting to DisplayPort displays
Connect the DisplayPort connectors to the DP ports of the monitor or display.
4. Connecting to an HDMI display
Connect one end of an HDMI cable to the HDMI port on the system rear panel and the other
end to a HDMI-compatible display such as an HDTV or monitor.
5. Connecting to network devices
Connect one end of a network cable to the LAN port on the system rear panel and the other
End to a hub or switch. The LAN port marked with K is for Killer Ethernet.
6. Turning on the system
Connect the supplied AC adapter to the DC IN jack on the system rear panel and then press
the power switch on the front panel to turn on the system. Follow the on-screen instructions to
complete the initial setup of Windows. This process may take several minutes.
When your ZOTAC Inspire Studio is not in use, unplug the power adapter or switch off the AC
outlet to save on power consumption.

ZOTAC Inspire Studio
12
Conguring audio output
Follow the steps below to enable audio output when
connecting the ZOTAC Inspire Studio to a TV or
receiver via DP/HDMI adapter.
1. Access the Sound settings via the system
Control Panel.
2. Under Playback devices, click the display device
that corresponds with your audio compatible
display.
3. Click the “Set Default” button in the lower right
hand corner.
4. Click “OK” to exit the setup.
Using your ZOTAC Inspire Studio
Conguring a wireless connection
Please follow the instructions below to connect to a wireless network:
1. Double-click the wireless network icon (pic) in the notication
area.
2. Select the wireless network you want to connect to from the list
and click Connect.
3. After connection is established, you will see “Connected.”
Note 1: For security concerns, Do NOT connect to an unsecured network,
otherwise, the transmitted information without encryption might be visible to
others.
Note 2: Enter the network security key if necessary.

ZOTAC Inspire Studio
13
Intel® OptaneTM technology (optional)
Intel®OptaneTM is a new ultra-high-speed memory technology with 3D XPointTM memory media,
compatible with NVMe storage protocol.
The program SetupOptaneMemory.exe is included in the driver DVD and USB ash drive (X:\
OptaneMemory\SetupOptaneMemory.exe).
Enabling Intel® OptaneTM memory
Please follow the recommended procedure to enable Optane memory, as listed below. (X: your
driver DVD / USB ash drive letter)
1. Locate and open the le OptaneMemory in the driver DVD / USB ash drive, double-click
SetupOptaneMemory.exe to run.
2. Follow the pictures below to complete the installation.

ZOTAC Inspire Studio
14

ZOTAC Inspire Studio
15

ZOTAC Inspire Studio
16

ZOTAC Inspire Studio
17
3. Restart the system, the following dialog box will display. Click “Yes”.
4. When the Intel®OptaneTM Memory interface displays, click “Enable”.

ZOTAC Inspire Studio
18

ZOTAC Inspire Studio
19
6. When the Optane Memory is successfully enabled, the created Intel®OptaneTM
information will show in Device Manager > Disk drivers.
5. Click “Restart” to complete enabling the Optane Memory.
