Zte Blade A7S User manual

1
ZTE Blade A7s
Quick Start Guide

2
LEGAL INFORMATION
Copyright © 2019 ZTE CORPORATION.
All rights reserved.
No part of this publication may be quoted, reproduced,
translated or used in any form or by any means, electronic or
mechanical, including photocopying and microfilm, without
the prior written permission of ZTE Corporation.
Notice
ZTE Corporation reserves the right to make modifications on
print errors or update specifications in this guide without
prior notice.
We offer self-service for our smart terminal device users.
Please visit the ZTE official website (at www.ztedevices.com)
for more information on self-service and supported product
models. Information on the website takes precedence.
Visit http://www.ztedevices.com to download the user
manual. Just click Support from the home page and then
select the location, product type, and name to search for
related support information.
Disclaimer
ZTE Corporation expressly disclaims any liability for faults
and damages caused by unauthorized modifications of the
software.
Images and screenshots used in this guide may differ from
the actual product. Content in this guide may differ from the
actual product or software.
Trademarks
ZTE and the ZTE logos are trademarks of ZTE Corporation.
Android™ is a trademark of Google LLC.
The Bluetooth® word mark and logos are registered
trademarks owned by the Bluetooth SIG, Inc. and any use of
such marks by ZTE Corporation is under license.
microSDXC Logo is a trademark of SD-3C, LLC.
Other trademarks and trade names are those of their
respective owners.
Version No.: R1.0
Edition Time : September 4, 2019
Manual No.:

3
Getting to Know Your Phone
Front camera
Touch screen
Earpiece Proximity sensor
Volume keys
Power key
Charging/
micro-USB jack
Headset jack
Back
cameras
Speaker
Indicator light
nano-
SIM/
microSDXC
card tray
Flash
Light sensor

4
Setting Up Your Phone
The nano-SIM card(s) can be installed or removed while the
phone is turned on.
WARNING!
To avoid damage to the phone, do not use any other kind of
SIM cards, or any non-standard nano-SIM card cut from a SIM
card. You can get a standard nano-SIM card from your service
provider.
1. Insert the tip of the tray eject tool into the hole on the
card tray.
2. Pull out the card tray and place a nano-SIM card in slot 1
and a microSDXC card (optional) or a nano-SIM card in
slot 2, as shown. Carefully slide the tray back into place.
Slot 2
Slot 1

5
NOTE:
When two nano-SIM cards are installed, both cards can
connect to the 4G, 3G, or 2G network, and either card can be
used for mobile data.
Charging the Phone
Your phone’s battery should have enough power for the
phone to turn on, find a signal, and make a few calls. You
should fully charge the battery as soon as possible.
WARNING!
Use only ZTE-approved chargers and USB cables. The use of
unapproved accessories could damage your phone or cause
the battery to explode.
WARNING!
Do not remove the back cover. The battery is not
removable. Removal may cause fire or explosion.
1. Connect the adapter to the charging jack. Ensure that
the adapter is inserted in the correct direction.
2. Connect the charger to a standard AC power outlet.
3. Disconnect the charger when the battery is fully
charged.
NOTE:
If the battery is extremely low, you may be unable to power
on the phone even when it is being charged. In this case, try

6
again after charging the phone for at least 20 minutes.
Contact the customer service if you still cannot power on the
phone after prolonged charging.
Powering On/Off Your Phone
Make sure the battery is charged before powering on.

Press and hold the Power key to turn on your phone.

To power off, press and hold the Power key to open the
options menu, and touch > .
NOTE:
If the screen freezes or takes too long to respond, try pressing
and holding the Power key for about 10 seconds to restart
the phone.
Waking Up Your Phone
Your phone automatically goes into sleep mode when it is
not in use for some time. The display is turned off to save
power and the keys are locked to prevent accidental
operations.
You can wake up your phone by turning on the display and
unlocking the keys.
1. Press the Power key to turn the screen on.
2. Swipe up on the screen.
NOTE:
If you have set a face verification, an unlock pattern, a PIN or
a password for your phone, you’ll need to use your face, draw
the pattern, or enter the PIN/password to unlock your screen.

7
Product Safety Information
Don’t make or receive phone calls while driving.
Never text while driving.
Keep your phone at least 5 mm away from your
body while making calls.
Small parts may cause choking.
Your phone can produce a loud sound.
To prevent possible hearing damage, do not listen
at high volume levels for long periods. Exercise
caution when holding your phone near your ear
while the loudspeaker is in use.
Avoid contact with anything magnetic.
Keep away from pacemakers and other electronic
medical devices.
Turn off when asked to in hospitals and medical
facilities.
Turn off when told to on aircraft and at airports.
Turn off when near explosive materials or liquids.
Don’t use at gas stations.
Your phone may produce a bright or flashing light.
Don’t dispose of your phone in fire.
Avoid extreme temperatures.
Avoid contact with liquids. Keep your phone dry.
Do not attempt to disassemble your phone.

8
Only use approved accessories.
For pluggable equipment, the socket-outlet shall
be installed near the equipment and shall be easily
accessible.
Don’t rely on your phone as a primary device for
emergency communications.
Specific Absorption Rate (SAR)
Your mobile device is a radio transmitter and receiver. It is
designed not to exceed the limits for exposure to radio waves
recommended by international guidelines. These guidelines
were developed by the independent scientific organization
ICNIRP and include safety margins designed to assure the
protection of all persons, regardless of age and health.
The guidelines use a unit of measurement known as Specific
Absorption Rate, or SAR. The SAR limit for mobile devices is 2
W/kg and the highest SAR value for this device when tested
at the head was xxx W/kg*, and when tested at the body was
xxx W/kg* with 5 mm distance. As mobile devices offer a
range of functions, they can be used in other positions, such
as on the body as described in the user manual**.
As SAR is measured utilizing the device’s highest transmitting
power, the actual SAR of this device while operating is
typically below that indicated above. This is due to automatic
changes to the power level of the device to ensure it only
uses the minimum power required to communicate with the
network.
* The tests are carried out in accordance with EN 50360, EN
50566, EN 62479, EN 62311, EN 62209-1 and EN 62209-2.
** Please see body worn operation in the user manual.

9
FCC RF Exposure Information (SAR)
This phone is designed and manufactured not to exceed the
emission limits for exposure to radio frequency (RF) energy
set by the Federal Communications Commission of the
United States.
During SAR testing, this device was set to transmit at its
highest certified power level in all tested frequency bands,
and placed in positions that simulate RF exposure in usage
against the head with no separation, and near the body with
the separation of 15 mm. Although the SAR is determined at
the highest certified power level, the actual SAR level of the
device while operating can be well below the maximum value.
This is because the phone is designed to operate at multiple
power levels so as to use only the power required to reach the
network. In general, the closer you are to a wireless base
station antenna, the lower the power output.
The exposure standard for wireless devices employing a unit
of measurement is known as the Specific Absorption Rate, or
SAR. The SAR limit set by the FCC is 1.6 W/kg.
This device is complied with SAR for general
population/uncontrolled exposure limits in ANSI/IEEE
C95.1-1992 and had been tested in accordance with the
measurement methods and procedures specified in
IEEE1528.
The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as in
compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC and
can be found under the Display Grant section of
www.fcc.gov/oet/ea/fccid after searching on
FCC ID: SRQ-ZTEA7S. The FCC ID also can be found on the
device when you open For this device, the highest reported
SAR value for usage against the head is 0.64 W/kg, and for
usage near the body is 1.18 W/kg.
While there may be differences between the SAR levels of

10
various phones and at various positions, they all meet the
government requirements.
SAR compliance for body-worn operation is based on a
separation distance of 15 mm between the unit and the
human body. Carry this device at least 15 mm away from your
body to ensure RF exposure level compliant or lower to the
reported level. To support body-worn operation, choose the
belt clips or holsters, which do not contain metallic
components, to maintain a separation of 15 mm between this
device and your body.
RF exposure compliance with any body-worn accessory,
which contains metal, was not tested and certified, and using
such body-worn accessory should be avoided.
FCC Regulations
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
 Reorient or relocate the receiving antenna.

11
 Increase the separation between the equipment and
receiver.
 Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
 Consult the dealer or an experienced radio/TV technician
for help.
CAUTION:
Changes or modifications not expressly approved by the
manufacturer could void the user’s authority to operate the
equipment.
The antenna(s) used for this transmitter must not be
co-located or operating in conjunction with any other
antenna or transmitter.
Specification
EUT supports
radios
application
GSM Band 2, 3, 8
WCDMA Band 1, 8
LTE Band 1, 3, 7, 8, 20
802.11b/g/n
Bluetooth V4.2+LE
GPS
WCDMA Version Rel.9
LTE Version Rel.11
Maximum RF
output power
GSM Band 2/3: 30.5 dBm
GSM Band 8: 33.5 dBm
WCDMA Band 1/8: 24.5 dBm
LTE Band 1/3/7/8: 24.5 dBm
LTE Band 20: 24 .5dBm
802.11 b/g/n:20 dBm
Bluetooth EDR: 12 dBm
Bluetooth LE: 5 dBm
GPS (RX Only)
CE Caution
Battery Caution

12
Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
USB Port
This product shall only be connected to a USB interface of
version USB 2.0.
Proper Use
As described in this guide, your device can be used only in
right location. If possible, please do not touch the antenna
area on your device.
Do not expose your device to extreme temperatures lower
than - 10 °C and higher than + 55 °C.
Disposal of Your Old Appliance
1. When this crossed-out wheeled bin
symbol is attached to a product, it means
the product is covered by the European
Directive 2012/19/EU.
2. All electrical and electronic products
should be disposed of separately from
the municipal waste stream via
designated collection facilities appointed
by the government or the local
authorities.
3. The correct disposal of your old appliance
will help prevent potential negative
consequences for the environment and
human health.
For this product’s recycling information based on WEEE
directive, please send an e-mail to [email protected]n

13
EU DECLARATION OF CONFORMITY
Hereby, ZTE Corporation declares that the radio equipment
type ZTE Blade A7s is in compliance with Directive
2014/53/EU.
The full text of the EU declaration of conformity is available
at the following Internet address:
http://certification.ztedevices.com
Battery Safety

Using ZTE-unapproved or incompatible battery, charger
or power adapter may damage your device, shorten its
lifespan or cause a fire, explosion or other hazards.

The recommended operating temperatures are 0 °C to
35 °C and the storage temperatures are -20 °C to +45 °C.
Extreme temperatures can damage the device and
reduce the charging capacity and lifespan of your device
and battery.
WARNING!
Do not remove the back cover. The battery is not
removable. Removal may cause fire or explosion.

Do not change or replace the built-in rechargeable
battery in your device by yourself. The battery can only
be changed or replaced by ZTE or ZTE authorized service
provider.

Do not place the device or the battery in or near heating
equipment, such as microwave ovens, stoves or radiators.
Keep the device and the battery away from excessive
heat and direct sunlight. If not, the device or the battery
may overheat and cause explosion or fire.

Do not disassemble, squeeze or puncture the device, as
this can cause explosion or fire.

14

Do not throw the device into a fire to avoid explosion.

Please disconnect the charger when the battery is fully
charged. Overcharging may shorten the battery life.

When not using the device for a long period, please
charge the battery about half and then store the device
in a cool dry place.

If the battery damages or shows signs of swelling or
leakage, please stop use immediately and contact ZTE or
ZTE authorized service provider for replacement.
