Zte E1320 User manual

E1320
Wi-Fi6 Wireless Router
User Manual

Step 1-Install the Device
1

Step 2-Add the Router
Download and install ZLife Lite. For iOS, download
ZLife Lite on App Store. For Android, download it on
Google Play.
Tap Add device.
2

Tap Wi-Fi Router.
Connect the WAN port of the router to the broadband
port. Tap Next.
3

NOTE:
If the operating system of your mobile phone is
Android, you must connect to Wi-Fi manually after
scanning the QR code. If you do not want to enter the
password manually, tap copy the password. This opera-
tion arises from Android rather than ZLife Lite because
of Android security requirements.
Scan the QR code found at the bottom of the router.
If no QR code is present, enter your wireless account
and password.
4

To perform more advanced congurations, go to the
web page for router management. For the login
address and the default username and password, see
the label at the bottom of the router.
NOTE:
After the router is added successfully, the Congure
network screen is displayed. Tap Bind immediately.
After the router is added successfully, the indicator is
green and steady.
LED indicator/WPS
5

Step 3- Set Up a Mesh Network
NOTE:
Step 3 is required only if you want to deploy multiple
E1320 routers.
Method 1: Use ZLife Lite app for connection
1. Make sure the router you have just congured is connected
to the Internet.
2. After the new router is powered on, follow the instructions
given by the app.
3. After the new router is connected to the existing router, the
LED of the new router will turn solid blue.
Method 2: Use WPS key for connection
1. Make sure the router you have just congured is connected
to the Internet.
2. Place a new router close to the existing router, and then
power it on.
3. Press the WPS buttons on the routers until the LEDs blink
green. The time between pressing the two WPS buttons
should be less than 1 minute.
4. The pairing process may take up to 2 minutes. When pairing
is complete, the LED of the new router will turn solid blue.
5. Now you can move your new router to your intended
location.
6

Troubleshooting
The Power indicator on the front panel is o after the
power button is pressed.
Power switch does not turn on.
The power adapter is not correctly connected to the device.
Be sure to use the power adapter supplied with the device.
Unable to connect to the network.
Check that the Ethernet cable is correctly connected to the
WAN interface and the Ethernet cable is correctly connected
to the LAN interface.
Check that the WAN indicator on the front panel is on and
the Internet indicator on the front panel is solid green or
ashing green.
Restore the factory default settings.
After the power is on, use a needle to press the button for over
5 seconds to restore the default factory settings.
7

FAQ
How to use the Repeater mode?
Only the Repeater mode(used to extend the Wi-Fi signals of
the existing router or optical modem) needs to be set on the
Web interface. Other modes can be self-adaptive without this
operation.
1. After the device is powered on, use a network cable to
connect the network interface of the computer to the LAN
interface of the device.
2. In the address bar of the browser, enter 192.168.50.1, and
press Enter to open the Web page.
3. Enter the username and password (initial username: admin,
initial password: ZTE_Polar), and click Login.
4. On the main page of the E1320, select Management &
Diagnosis >Work Mode to open the Work Mode page.
5. Select Repeater from the Mode drop-down menu and click
Apply.
6. Extended Wi-Fi.
Use wired mode to extend Wi-Fi: Connect the LAN
interface of the existing router or optical modem to the
WAN interface of E1320 with a network cable.
8

Use wireless mode to extend Wi-Fi: The WPS key can be used
for pairing. lf the existing router or optical modem does not
support the WPS key mode, perform the following opera-
tions:
On the main page of the E1320, select Local Network>
WLAN >WLAN Discovery > WLAN Discovery to open
the WLAN Discovery page.
Click Scan wireless network to scan the Wi-Fi signal, select
the wireless network you want to connect to, and enter
the password to connect to the wireless network.
7. After the device is networked. the device can be managed
on the APP by following the operation of Step 2 and Step 3.
9
