Zte VS2801SG User manual

1GE DUAL MODE ONU
USER MANUAL
Version V1.0
Release Date 2020-08-24

1GE Dual Mode ONU User Manual
Contents
Chapter 1 Product Introduction 1
1.1 Product Description 1
1.2 Special features 1
1.3 Technical Parameter 1
1.4 Application chart 2
1.5 Panel description 2
Chapter 2 Quick Installation 4
2.1 Standard Packing Contents 4
2.2 Quick Installation 4
Chapter 3 Configuration 6
3.1 Login 6
3.2 Status 7
3.2.1 Device Information 7
3.2.2 Network Interface 7
3.2.3 User Interface 8
3.3 Network 9
3.3.1 Internet 9
3.3.2 LAN 11
3.3.3 PON Settings 14
3.3.4 Routing(Ipv4) 16
3.4 Security 18
3.4.1 Firewall 18
3.4.2 Service Control 20
3.4.3 MAC Filter 21
3.5 Application 22
3.5.1 Multicast 22
3.5.2 BPDU 24
3.5.3 DNS Service 25
3.5.3 Port Forwarding 26
3.6 Administration 27
3.6.1 User Management 27
3.6.2 Login Timeout 27
Page 1

1GE Dual Mode ONU User Manual
3.6.3 System Management 28
3.6.4 Diagnosis 29
3.6.5 Loopback Detection 31
3.6.6 LED Control 33
3.8 Help 33
Page 2

1GE Dual Mode ONU User Manual
Chapter 1 Product Introduction
1.1 Product Description
1GE Dual mode ONU meets telecom operators FTTO (office), FTTD (Desk), FTTH(Home)
broadband speed, SOHO broadband access, video surveillance and other requirements and
design EPON/GPON Gigabit Ethernet products. It is based on mature and stable,
cost-effective EPON/GPON technology, high reliability, easy management, configuration
flexibility and good quality of service (QoS) guarantees. They are fully compliant with GPON
and EPON technical regulations such as ITU-T G.984.x, IEEE802.3ah and so on. Dual mode
ONU can detect and exchange PON mode automatically.
Figure 1-1: 1GE Dual Mode ONU
1.2 Special features
●Integrated auto detecting, auto configuration, and auto firmware upgrade technology.
●Support OAM/OMCI remote configuration and maintenance.
●Support rich VLAN, DHCP Server and IGMP snooping multicast feature.
●Fully compatibility with OLT based on Broadcom/PMC/Cortina chipset.
●Support NAT, Firewall function.
●Support bridge and router mode.
1.3 Technical Parameter
Technical items
Descriptions
PO
N
i
n
t
e
r
f
a
c
e
1 G/EPON port(EPON PX20+ and GPON Class B+)
Receiving sensitivity: ≤-28dBm
Transmitting optical power: 0~+4dBm
Transmission distance: 20KM
Wavelength
Tx1310nm,Rx 1490nm
Page 1

1GE Dual Mode ONU User Manual
Optical interface
SC/PC connector
Interface
1* 10/100/1000Mbps auto adaptive Ethernet interfaces. Full /Half
Duplex, RJ45 connectors.
Indicator
3 indicators, SYS, LINK/ACT, REG.
Operating condition
-5℃～55℃，10%～90%（non-condenseing）
Storing condition
-30℃～60℃，10%～90%（non-condenseing）
Power supply
DC 12V, 0.5A
Power consumption
≤4W
Dimension
82mm×82mm×25mm（L×W×H）
Net weight
0.08Kg
1.4 Application chart
Figure 1-2: Application chart
1.5 Panel description
Interface/Button panel
Page 2

1GE Dual Mode ONU User Manual
Figure 1-3: Interface/Button panel
Name
Function
PON
Connect to OLT by SC type fiber connector, single mode optical fiber
cable.
LAN
Connect PC or other devices with Ethernet port by Cat5 cable, RJ-45
connector.
DC 12V
Connect with power adapter. DC 12V, 0.5A.
RST
Press RST button over 10 seconds, onu restores factory default and
reboot.
Indication Panel
Figure 1-4: Indication panel
LED
Mark
Status
Description
Interface
LINK/ACT
ON
Port is connected properly (LINK).
Off
Port connection exception or not connected.
Blink
Port is sending or/and receiving data (ACT).
Registration
REG
ON
Green：the device is registered to PON system.
OFF
Device has received optical signal and not registered to the
PON system.
Blink
Red：the Device does not receive optical signals.
Green：the device registration is incorrect.
System
SYS
On / Off
System is not running or fatal error
Blink
Normal running
Page 3

1GE Dual Mode ONU User Manual
Chapter 2 Quick Installation
2.1 Standard Packing Contents
When you received our product, please check carefully to make sure that our products
whether have some defects or not. If something wrong with shipping, please contact carrier;
other damage or lack of some parts, please contact with dealer.
Contents
Quantity
Dual Mode ONU
1 pcs
Power Adapter
1 pcs
Installation Guide
1 pcs
2.2 Quick Installation
1. Connecting the optical fiber cable to the unit.
a) Remove the protective cap of the optical fiber.
b) Clean the end of the optical fiber with an optical fiber end cleaner.
c) Remove the protective cap of the ONU optical interface (PON interface). Connect the
fiber to the PON port on the unit.
Note: When measuring the optical power before connecting to the ONU, it is
recommended to use a PON Inline Power Meter.
While connecting, please note:
●Keep the optical connector and the optical fiber clean.
●Make sure there are no tight bends in the fiber and that the bending diameter is greater
than 6cm. Otherwise, the optical signal loss may be increased, to the extent that signal
may be unavailable.
●Cover all optic ports and connectors with protective cap to guard against dust and
moisture when the fiber is not used.
2. Apply power to the unit. Push the power button.
3. After the ONU is power ON, Indicators should light up as for normal operation. Check
whether the PON interface status LED (PON) is on continuously. If it is, the connection is
normal; otherwise there is either problem of the physical connection or the optical level at
either end. This may be caused by either too much or too little attenuation over the optical
fiber. Please refer to the Layout Description section of this installation manual for normal
LED activity.
4. Check all signal levels and services on all the ONU communication ports.
Unit Installation Adjustment
Installing the ONU on a horizontal surface (Bench top)
Put the ONU on a clean, flat, sturdy bench top. You must keep the clearance for all sides of
the unit to more than 10cm for heat dissipation.
Installing the ONU on a vertical surface (Hanging on a wall)
You can install the ONU on a vertical surface by using the mounting holes on the bottom
of the ONU chassis and two flat-head wood screws.
a) Insert the screws into the wall. The screw positions must be in the same horizontal line
Page 4

1GE Dual Mode ONU User Manual
and the distance between them must be 145mm. Reserved at least 6mm between the
screw caps and the wall.
b) Hang the ONU on the screws through the mounting holes.
Page 5

1GE Dual Mode ONU User Manual
Chapter 3 Configuration
After finishing the basic connection configuration, you can use its basic function. In order
to satisfy individuation service requirements, this charter provides the user parameter
modification and individuation configuration description.
This model of ONU is designed as SFU(single family unit, bridge mode), there is no bridge
mode WAN in ONU. When it works on bridge mode, VLAN of LAN port should be
configured by OLT. When it works on router mode, you may configure through its web
management.
3.1 Login
The device is configured by the web interface. The following steps will enable you to login:
1. Conform “2.2 Quick Installation” to install;
2. The device default IP is 192.168.1.1;
3. Open your web browser, type the device IP in address bar;
4. Entry of the user name and password will be prompted. Enter the default login user name
and password.
By default, there are two user levels for management. Administration level user name is
"admin", password is "stdONUi0i". Normal level user name is "user", password is
"user".
Figure 3-1: Login
For security, you will be asked to modify password after you logged in by default
password. The new password must meet the requirements that display on the webpage. After
submitted, it requires you to login by new password.
Page 6

1GE Dual Mode ONU User Manual
Figure 3-2: Change Password
3.2 Status
This part shows the main information of product.
3.2.1 Device Information
This page shows the device basic information, such as Device Model, Hardware Version,
Software Version, PON SN, PON mode and so on.
Figure 3-3: Device Information
3.2.2 Network Interface
3.2.2.1 WAN Connection
This page shows WAN connection information you have configured.
Page 7

1GE Dual Mode ONU User Manual
Figure 3-4: WAN Connection
3.2.2.2 PON Inform
This page shows the PON information, such as PON state, input power, output power, and
optical module voltage, current, temperature.
Figure 3-5: PON Information
3.2.3 User Interface
This page shows the Ethernet port information, including port status, MAC address and
statistics.
Page 8

1GE Dual Mode ONU User Manual
Figure 3-6: Ethernet Information
3.3 Network
3.3.1 Internet
This page allows user to configure router mode WAN connection. You can only configure
route mode WAN connections here. The device default settings is bridge mode(without any
WAN).
Page 9

1GE Dual Mode ONU User Manual
Figure 3-7: WAN Connection
Parameter
Illustration
Connection Name
The list of WAN connection name that has been created.
If you want to create a new WAN connection, please select “Create
WAN Connection” and input other Parameter at the same time and
then click “Create” button. If you want to edit WAN connection,
please select the wan connect name you want to edit and change
some Parameter and then click “Modify” button. If you want to
delete one connection, please select the wan connection you want to
delete and then click “Delete” button.
New Connection Name
Name of new connection that you want to create.
VLAN
Enable
VLAN
Checked indicates the packets are transmitted by the PON port take
VLAN tag. Unchecked indicates the packets are transmitted by the
PON port don’t take VLAN tag.
VLAN ID
Input the VLAN ID you want to set. Range is 0~4094. Input 0
means don’t use any VLAN.
802.1P
Select VLAN priority you want to set. Range is 0~7.
Type
Bridge/Route. There is only Route mode can be selected. The
device works on route mode with this WAN connection. If you want
it to work on bridge mode, don’t configure any WAN connection.
Service List
Service mode indicates what the wan connection is used for.
There is only INTERET can be selected.
MTU
Max transfer unit. Default Value (in Byte):
1500(static/DHCP) or 1492(PPPoE).
Link Type
PPP/IP. PPP is used for PPPoE, and IP is used for static IP or
DHCP.
Page 10

1GE Dual Mode ONU User Manual
PPP
Username
PPPoE account.
Password
PPPoE password.
DMS name
Server name.
Authentication
Type
PPPoE authentication type, including Auto, PAP and CHAP.
Connection
Trigger
The trigger of PPPoE connection after disconnected.
Always On: once PPPoE disconnected, ONU will connect again
automatically.
On Demand: ONU will connect again if there is data traffic.
Manual: ONU will connect again after submitted the configurations.
IP Version
IPv4/IPv6
Enable NAT
Checked indicates NAT function is enabled. Unchecked indicates
NAT function is disabled.
Only IPv4 has this option.
IP Type/PPP TransType
Method of WAN connection Obtains IP address. If link type is PPP,
PPP TransType will be PPPOE; if link type is IP, IP Type will be
static or DHCP.
IPv6
IPv6 Info Get
Mode
Method of WAN connection obtains IPv6 address, including
Manual Mode and Auto Mode.
GUA From
Method of WAN connection obtains Global Unique IPv6 Address.
DNSv6 From
Method of WAN connection obtains DNSv6.
Prefix
Delegation From
Method of prefix delegation.
3.3.2 LAN
This page supports the management of the ONU's IP address, dynamic address
management, including dynamic address distribution and relevant parameters distribution,
such as lease time, address range, DHCP Proxy, etc.
3.3.2.1 DHCP Server
This page contains LAN IPv4 address and LAN DHCP server configurations.
Page 11

1GE Dual Mode ONU User Manual
Figure 3-8: LAN IPv4 Address Settings
Parameter
Illustration
LAN IP Address
LAN IPv4 address.
Subnet Mask
LAN IPv4 mask.
Enable DHCP Server
Switch of ONU DHCP server.
Start IP Address
The start IP address of DHCP IP pool.
End IP Address
The end IP address of DHCP IP pool.
DNS
Assign ISP
DNS
Checked indicates LAN DHCP will use ISP DNS. Unchecked indicates
LAN DHCP use DNS that set in the textbox.
DNS Server IP
Address
DNS server addresses for LAN DHCP.
Default Gateway
Default gateway of LAN DHCP. It should be the same as LAN IPv4 IP
address.
Lease Time
Lease time of the IP address.
3.3.2.2 RA Service
This page show RA configuration.
Page 12

1GE Dual Mode ONU User Manual
Figure 3-9: RA Configuration
3.3.2.3 DHCP Server(IPv6)
This page contains LAN IPv6 address and LAN DHCP server configurations.
Figure 3-10: LAN IPv6 Address Settings
3.3.2.4 Prefix Management
This page is used to configure IPv6 prefix parameters.
Page 13

1GE Dual Mode ONU User Manual
Figure 3-11: Prefix Management
3.3.2.5 Port Service(Ipv6)
This page is used to configure DHCPv6 and RA function of LAN port.
Figure 3-12: Port Service(IPv6)
3.3.3 PON Settings
3.3.3.1 LOID
This page allows user to configure LOID and password which are used for registering to
OLT.
Page 14

1GE Dual Mode ONU User Manual
Figure 3-13: LOID settings
3.3.3.2 SN
This page allows user to configure GPON SN and password which are used for registering
to OLT.
Figure 3-14: GPON SN Settings
3.3.3.3 PON Mode
This page allows user to configure PON mode when connected to corresponding system.
AUTO: ONU will detect PON mode and shift to proper PON mode.
GPON: ONU will work on GPON mode.
EPON: ONU will work on EPON mode.
Page 15

1GE Dual Mode ONU User Manual
Figure 3-15: PON Mode
3.3.4 Routing(Ipv4)
3.3.4.1 Default Gateway
This page allows user to configure default gateway of ONU. Just need to specify the WAN
connection that connected to the gateway.
Figure 3-16: Default Gateway
3.3.4.2 Static Routing
This page allows user to specify a WAN connection as the Route Interface, and then configure
destination IP, mask and gateway.
Page 16

1GE Dual Mode ONU User Manual
Figure 3-17: Static Routing
Parameter
Illustration
WAN Connection
Select WAN connection as static routing interface.
Network Address
Destination network address.
Subnet Mask
The Mask of destination network address.
Gateway
Gateway IP address of static routing.
3.3.4.3 Routing Table
This page displays IP routing rules.
Figure 3-18: Routing Table
3.4 Security
Page 17
