Zultys ZIP 36G User manual

Quick Installation Guide
96-35361-02
Configuring your Phone
Configuration of the phone is centrally managed from the Zultys MX IP phone system. For
most deployments the phone will receive an IP address from the DHCP server on the local
network. For the phone to automatically download its configuration information the DHCP
server must have Option 66 enabled and configured with the address of the Zultys MX IP
phone system.
Wall Mount Drilling Template
Drill two holes vertically spaced 70mm/2.75” apart.
After the IP phone is connected to the network
and supplied with power, it automatically
begins a process of initializing on the network
and downloading it's configuration information.
Contact your system administrator if the phone
fails to register with the IP phone system.
Startup
FCC Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
70mm/2.75”
ZIP 36G Business Phone
www.zultys.com
ZIP 36G

1. Attach the stand, as shown below:
2. Connect the handset and optional headset, as shown below:
3. Connect the network and power, as shown below:
a. AC Power Option
b. PoE (Power over Ethernet) Option
The following items are included in your package. If you find anything missing, contact your
system administrator.
Packing List
Assembling the Phone
Desk Mount Method
Handset Cord
HandsetIP Phone
Ethernet Cable
Quick Installation
Guide & Quick
Reference Guide
Note: Headset purchased separately.
ZIP 36G Quick Installation Guide
You have two options for network and power connections. Your system administrator will advise
you on which one to use.
Note: If PoE (Power over Ethernet) option is used, the power adapter is not required.
ZIP 36G Quick Installation Guide
Wall Mount Method
Stand &
Wall Mount
Power Adapter
(optional)
ZIP 36G
A
AC Power Option
PC Connection
(Optional)
Power Adapter
(DC 5V)
B
PoE ( Power over
Ethernet ) Option
PC Connection
(Optional) IEEE 802.3af compliant
PoE Switch
A
B
Network
